Service Manual
Digital Satellite Receiver
MODEL : DSD-9502
March. 2006
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Cent
S/N : DSD9502001

PRODUCT SPECIFICATION ...............................................................................................2
BOM LIST.............................................................................................................................3
SC EMATIC DIAGRAM ......................................................................................................8
EXPLODED VIEW................................................................................................................17
1
CONTENTS

2
Product Specification
Tuner & Service Decoder
MPEG Transport Stream A/V Decoding
Main System
A/V In/Out
Power Supply
Physical Specification
Antenna 75 ohms(UHF)
Channel coverage UHF :Ch21-Ch69
RF frequency range 474-858 MHz
Channel bandwidth 8Mhz
RF Input/Output Connector IEC connector Female,Male
Modulator COFDM
Transport stream MPEG2 ISO/IEC 13818 Transport Stream Spec
Profile level MPEG-2 MP@ML
Input rate 68Mbits/s Max
Aspect ratio 4:3,16:9
Video resolution 720 x 576
Audio format MPEG1-I,II,III &MPEG-2 layer II
Audio sampling 32,44.1,48kHz
Main processor STi5518
Flash memory 4MByte
Sync DRAM 8MByte X 2
Antenna jack type
-Antenna jack layout In :Up,Out :Down
Scart jack
-TV RGB,SVHS,CVBS,Audio L/R Output
-VCR/DVD RGB,SVHS,CVBS Input
RCA jack Analog Audio L/R Output
Optical jack Digital Audio Output
Input voltage 100V-240V~,50/60Hz
Type SMPS
Power consumption
-Maximum 18W
-Operate 15W
-Stand-by 8W
Dimensions(W x H x D) 340 x 60 x 260mm
Mass 2.6kg
Storage temp -5°C~40°C
Storage humidity 5% to 90%
HDD
Drive Interface ATA (IDE bus)Interface
Capacity 40 GB / 80 GB / 160 GB
RPM 5400

3
BOM LIST
✐ CAUTION :In this Service Manual, some parts can be changed for improving their
performance without notice in the parts list. So, if you need the latest parts
information, please refer to PPL(Parts Price List)in Service information
Center(http://svc.dwe.co.kr)
LOC PART CODE PART NAME PART DESC REMARK
1 PSACPSE623 ACCESSORYASSY DSD-9520
M001 97P4809400 POLYBAGFORSET 900*900*T0.5PE-FOAM
M2001 B2MHDAE001P0 MANUALOWNERS DAEWOO PVRSTB
M2002 97P7701000 CABLECANALPLUS PERI-PERI1200M/M9PIN
M2003 97P1RA2HA0 REMOCONHANDSET PVR (AAA)
2 PSPKCPE623 PACKINGASSY DSD-9520
M001 97P4933800 EPSPADLEFT+RIGHT EPSPADDVRSTB
M1002 97P5081000P01 BOXCARTONNBUDVR 2COLBROWNDAEWOO425X322X106
3 PVMCASE623 CHASSISMAINAS DSD-9520
A001 97P0485100 COVERBOTTOM SECCT0.8
A0012 97P4220200 CUSHIONLEG EVAT4.0
A040 4952101600 COVERTOP SECCT0.8
A041 7173300812 SCREWTAPPTITE TT2BIN3X8BK
A051 7173300812 SCREWTAPPTITE TT2BIN3X8BK
A060 97P0485200 COVERBACK DSD-9520
HD01 97P2448300 BRKTHDD SECCT1.0
HD01A 7043350611 SCREWMACHINE BINM3.5*6 0.8THREADPITCH
HD01D 97P885X268 CONNAS 40H40H240MMFLAT
HD01E 97P885X266 CONNAS 4H-4H200MM(2.5-5.08)
HD901 97Q5100108 DISK HARD DRIVE ST380012ACE 80GB 5400RPM
M01 97PP345000 FRONTPANELAS DSD-9256M
M01A 7174300811 SCREWTAPPTITE TT2RND3X8MFZN
PW01 97PA48460B CORDPOWERAS (H/S) G/MARKUKSHIELDEDPCBPLUG
Z001 PVMPMSE623 PCB MAIN MANUAL AS DSD-9520
AM01 2193010300 SOLDERWIRE SN63% PB37%DIA.3.00MM
AM06 97P93B2101 LABELCD(PCB) PAPER(13X48)
JK101 97P6318630 JACKSCART DSAM-0320RASHIELD
JK102 97P6314900 JACKPIN A.CINCH DPAM-9825
JK103 97P0S03000 JACKSENSOROPTIC VST5B-12M
P103 97P62Y17A7 CONNWAFER YW025-07STPLUG2.5MM
P104 97P62A0539 CONNWAFER 2-440091-52.54MM39PIN
RF01 97P761344V TUNER2IN1 TD1344L/IVP-2DTTTUNERNOMOD
Z0011 PVMPJ2E623 MAINCHIPMOUNTB DSD-96520
AMB1 2193011650 SOLDERPASTE SMQ92JTYPE3(INDIUM)
C102 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C103 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C104 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C106 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C107 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C108 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C109 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C110 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
C111 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
C114 HCQK430JBA CCHIPCERA COG50V43PF5%1608
C115 HCQK430JBA CCHIPCERA COG50V43PF5%1608
C116 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C119 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
LOC PART CODE PART NAME PART DESC REMARK
C120 HCQK101JBA CCHIPCERA COG50V100PF5%1608
C121 HCQK101JBA CCHIPCERA COG50V100PF5%1608
C122 HCFK154ZCA CCHIPCERA 50VY5V0.15MFZ
C123 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C124 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C125 HCQK220JBA CCHIPCERA COG50V22PF5%1608
C126 HCQK220JBA CCHIPCERA COG50V22PF5%1608
C127 HCQK430JBA CCHIPCERA COG50V43PF5%1608
C128 HCQK430JBA CCHIPCERA COG50V43PF5%1608
C129 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C130 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C131 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C132 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C133 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C134 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C135 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C136 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C137 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C138 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C139 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C140 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C141 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C142 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C143 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C144 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C145 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C146 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C147 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C148 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C149 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C150 HCQK470JBA CCHIPCERA COG50V47PF5%1608
C151 HCQK101JBA CCHIPCERA COG50V100PF5%1608
C152 HCQK101JBA CCHIPCERA COG50V100PF5%1608
C153 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C154 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C155 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C156 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C157 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C158 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C159 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C160 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C161 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C162 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C163 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C164 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C165 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C166 HCBK103KBA CCHIPCERA X7R50V10NF10%1608

BOM LIST
4
LOC PART CODE PART NAME PART DESC REMARK
C167 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C168 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C169 HCQK101JBA CCHIPCERA COG50V100PF5%1608
C170 HCQK101JBA CCHIPCERA COG50V100PF5%1608
C171 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C172 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C173 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C174 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C175 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C176 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C177 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C178 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C179 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C180 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C181 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C182 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C183 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C184 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C185 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C186 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C188 HCBK392KBA CCHIPCERA X7R50V3900PF10%1608
C189 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C190 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C191 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C192 HCBK392KBA CCHIPCERA X7R50V3900PF10%1608
C193 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C194 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C195 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C196 HCBK392KBA CCHIPCERA X7R50V3900PF10%1608
C197 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C198 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C199 HCBK103KBA CCHIPCERA X7R50V10NF10%1608
C200 HCBK392KBA CCHIPCERA X7R50V3900PF10%1608
C201 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C202 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C203 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C204 HCBK392KBA CCHIPCERA X7R50V3900PF10%1608
C205 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C206 HCQK391JBA CCHIPCERA COG50V390PF5%1608
C207 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C212 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C213 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C214 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C215 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C216 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C217 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C218 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C219 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C220 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C221 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C222 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C223 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C224 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C225 HCFF105ZBA CCHIPCERA Y5V16V1000NF+80~-20%1608
C226 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
LOC PART CODE PART NAME PART DESC REMARK
C227 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
C228 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
C229 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
C230 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
C231 HCBK102KBA CCHIPCERA X7R50V1NF10%1608
C234 HCQK181JBA CCHIPCERA COG50V180PF5%1608
C235 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C238 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C239 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C240 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C241 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C242 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C245 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C246 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C247 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
C251 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C252 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C253 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C254 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C255 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C256 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C257 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C258 HCQK331JBA CCHIPCERA COG50V330PF5%1608
C261 HCFH104ZBA CCHIPCERA Y5V25V100NF(-20%+80%)1608
IC01 1ST15518BQ ICCHIPDECODER STI5518BVC208PINPQFP
IC02 1IS421640B ICSDRAM 1MX16X47NSTSOP2_54
IC03 1IS421640B ICSDRAM 1MX16X47NSTSOP2_54
IC04 1MT28F32FS ICFLASH MT28F320J3FS-11GME32MBITFBGA
IC05 1MT352GC ICCOFDMDEMODULATOR MT352/GC/GP1NLQFP-64
IC06 1AP1186K5E IC REGULATOR AP1186K525LA1.5A2.5VT0263
IC07 1A1117E18D IC REGULATOR AP1117E18A1.8V2%SOT-223
IC08 1FM809TS3B ICCHIPRESET FM809TS3
IC09 1CS4334KS- ICAUDIODAC CS4334KS24BITSOIC8
IC10 1C374APWRD ICCHIPLATCHES SN74HCT374APWRTSSOP20PIN
IC12 1K1A358F-C ICCHIPOPAMP KIA358FDUALOPAMPFLP-8
IC13 1SN74HCU0D ICHEXINVERTER 2BCONFIRMED
IC15 1HCT245PWD ICCHIPTRANSCEIVERS SN74HCT245PWRTSSOP20PINREEL
IC16 1HCT245PWD ICCHIPTRANSCEIVERS SN74HCT245PWRTSSOP20PINREEL
IC17 1HCT245PWD ICCHIPTRANSCEIVERS SN74HCT245PWRTSSOP20PINREEL
L101 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L102 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L103 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L104 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L105 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L106 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L107 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L108 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L111 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L112 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L113 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L114 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L115 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L117 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L118 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L119 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM

5
BOM LIST
LOC PART CODE PART NAME PART DESC REMARK
L120 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L121 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L122 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L123 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L124 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L125 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L127 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L128 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L129 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L130 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L131 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L132 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L133 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L134 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L135 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L140 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L141 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L142 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L143 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L144 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L145 HLB301MT1B LCHIPBEAD 2.0X1.2X0.9MM2A300OHM
L146 HLB301MT1B LCHIPBEAD 2.0X1.2X0.9MM2A300OHM
L151 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
L152 HLX601-01B LCHIPBEAD BLM18AG601SN1200MA 600OHM
P102 97P62K06EP CONN FFC SMD SCB-2223-M-2SMDST1.0
Q103 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q104 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q105 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q106 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q107 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q109 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q110 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q111 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q112 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q113 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q114 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q115 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q116 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q117 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q118 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q119 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q120 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q121 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q122 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q123 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q124 TKSR1104-B TRCHIP KSR1104
Q125 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q126 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q127 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q128 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q129 TKSR1104-B TRCHIP KSR1104
Q130 TKSR1104-B TRCHIP KSR1104
Q131 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q132 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q133 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
LOC PART CODE PART NAME PART DESC REMARK
Q134 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q135 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q136 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q137 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q138 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q139 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q140 TPMBT2222A TRCHIP PMBT2222ATRNPNSOT23
Q142 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q143 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q145 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q146 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q147 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q148 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q149 TBC857 TRCHIP BC857 LOW NOISE TR PNP
Q150 TBC857 TRCHIP BC857 LOW NOISE TR PNP
R108 HRFS330JBA RCHIP 1/16 33OHM5%1608
R119 HRFS101JBA RCHIP 1/16100ROHM5%1608
R120 HRFS330JBA RCHIP 1/16 33OHM5%1608
R121 HRFS330JBA RCHIP 1/16 33OHM5%1608
R122 HRFS330JBA RCHIP 1/16 33OHM5%1608
R123 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R124 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R127 HRFS103JBA RCHIP 1/1610KOHM5%1608
R128 HRFS103JBA RCHIP 1/1610KOHM5%1608
R129 HRFS470JBA RCHIP 1/1647ROHM5%1608
R130 HRFS470JBA RCHIP 1/1647ROHM5%1608
R133 HRFS103JBA RCHIP 1/1610KOHM5%1608
R134 HRFS103JBA RCHIP 1/1610KOHM5%1608
R135 HRFS750JBA RCHIP 1/16 75OHM5%1608
R137 HRFS105JBA RCHIP 1/161MOHM5%1608
R138 HRFS101JBA RCHIP 1/16100ROHM5%1608
R139 HRFS101JBA RCHIP 1/16100ROHM5%1608
R141 HRFS102JBA RCHIP 1/161KOHM5%1608
R142 HRFS102JBA RCHIP 1/161KOHM5%1608
R143 HRFS101JBA RCHIP 1/16100ROHM5%1608
R144 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R145 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R146 HRFS470JBA RCHIP 1/1647ROHM5%1608
R147 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R148 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R149 HRFS101JBA RCHIP 1/16100ROHM5%1608
R150 HRFS101JBA RCHIP 1/16100ROHM5%1608
R151 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R152 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R153 HRFS000-BA RCHIP 1/160OHM1608
R154 HRFS000-BA RCHIP 1/160OHM1608
R155 HRFS000-BA RCHIP 1/160OHM1608
R156 HRFS101JBA RCHIP 1/16100ROHM5%1608
R157 HRFS101JBA RCHIP 1/16100ROHM5%1608
R158 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R164 HRFS330JBA RCHIP 1/16 33OHM5%1608
R165 HRFS203JBA RCHIP 1/1620KOHM5%1608
R166 HRFS203JBA RCHIP 1/1620KOHM5%1608
R167 HRFS104JBA RCHIP 1/16100KOHM5%1608
R168 HRFS680JBA RCHIP 1/1668ROHM5%1608

6
BOM LIST
LOC PART CODE PART NAME PART DESC REMARK
R169 HRFS680JBA RCHIP 1/1668ROHM5%1608
R170 HRFS680JBA RCHIP 1/1668ROHM5%1608
R171 HRFS680JBA RCHIP 1/1668ROHM5%1608
R172 HRFS680JBA RCHIP 1/1668ROHM5%1608
R173 HRFS680JBA RCHIP 1/1668ROHM5%1608
R174 HRFS104JBA RCHIP 1/16100KOHM5%1608
R175 HRFS104JBA RCHIP 1/16100KOHM5%1608
R176 HRFS103JBA RCHIP 1/1610KOHM5%1608
R177 HRFS103JBA RCHIP 1/1610KOHM5%1608
R178 HRFS103JBA RCHIP 1/1610KOHM5%1608
R179 HRFS330JBA RCHIP 1/16 33OHM5%1608
R180 HRFS470JBA RCHIP 1/1647ROHM5%1608
R181 HRFS103JBA RCHIP 1/1610KOHM5%1608
R182 HRFS103JBA RCHIP 1/1610KOHM5%1608
R183 HRFS103JBA RCHIP 1/1610KOHM5%1608
R184 HRFS560JBA RCHIP 1/1656ROHM5%1608
R185 HRFS330JBA RCHIP 1/16 33OHM5%1608
R186 HRFS330JBA RCHIP 1/16 33OHM5%1608
R187 HRFS330JBA RCHIP 1/16 33OHM5%1608
R188 HRFS330JBA RCHIP 1/16 33OHM5%1608
R189 HRFS330JBA RCHIP 1/16 33OHM5%1608
R190 HRFS330JBA RCHIP 1/16 33OHM5%1608
R191 HRFS330JBA RCHIP 1/16 33OHM5%1608
R192 HRFS103JBA RCHIP 1/1610KOHM5%1608
R193 HRFS560JBA RCHIP 1/1656ROHM5%1608
R194 HRFS104JBA RCHIP 1/16100KOHM5%1608
R195 HRFS103JBA RCHIP 1/1610KOHM5%1608
R196 HRFS103JBA RCHIP 1/1610KOHM5%1608
R197 HRFS104JBA RCHIP 1/16100KOHM5%1608
R198 HRFS103JBA RCHIP 1/1610KOHM5%1608
R199 HRFS103JBA RCHIP 1/1610KOHM5%1608
R200 HRFS103JBA RCHIP 1/1610KOHM5%1608
R201 HRFS103JBA RCHIP 1/1610KOHM5%1608
R205 HRFS821JBA RCHIP 1/16820ROHM5%1608
R206 HRFS221JBA RCHIP 1/16220R OHM5%1608
R207 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R208 HRFS120JBA RCHIP 1/1612OHM5%1608
R209 HRFS759JBA RCHIP 1/167.5OHMJ1608
R210 HRFS750JBA RCHIP 1/16 75OHM5%1608
R211 HRFS821JBA RCHIP 1/16820ROHM5%1608
R212 HRFS221JBA RCHIP 1/16220R OHM5%1608
R213 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R214 HRFS120JBA RCHIP 1/1612OHM5%1608
R215 HRFS759JBA RCHIP 1/167.5OHMJ1608
R216 HRFS750JBA RCHIP 1/16 75OHM5%1608
R217 HRFS821JBA RCHIP 1/16820ROHM5%1608
R218 HRFS221JBA RCHIP 1/16220R OHM5%1608
R219 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R220 HRFS120JBA RCHIP 1/1612OHM5%1608
R221 HRFS759JBA RCHIP 1/167.5OHMJ1608
R222 HRFS750JBA RCHIP 1/16 75OHM5%1608
R223 HRFS821JBA RCHIP 1/16820ROHM5%1608
R224 HRFS221JBA RCHIP 1/16220R OHM5%1608
R225 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R226 HRFS120JBA RCHIP 1/1612OHM5%1608
R227 HRFS759JBA RCHIP 1/167.5OHMJ1608
R228 HRFS750JBA RCHIP 1/16 75OHM5%1608
R229 HRFS120JBA RCHIP 1/1612OHM5%1608
R230 HRFS759JBA RCHIP 1/167.5OHMJ1608
R231 HRFS750JBA RCHIP 1/16 75OHM5%1608
R235 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R236 HRFS103JBA RCHIP 1/1610KOHM5%1608
R237 HRFS103JBA RCHIP 1/1610KOHM5%1608
R238 HRFS103JBA RCHIP 1/1610KOHM5%1608
R239 HRFS103JBA RCHIP 1/1610KOHM5%1608
R240 HRFS103JBA RCHIP 1/1610KOHM5%1608
R241 HRFS103JBA RCHIP 1/1610KOHM5%1608
R242 HRFS103JBA RCHIP 1/1610KOHM5%1608
R243 HRFS103JBA RCHIP 1/1610KOHM5%1608
R244 HRFS104JBA RCHIP 1/16100KOHM5%1608
R245 HRFS104JBA RCHIP 1/16100KOHM5%1608
R246 HRFS104JBA RCHIP 1/16100KOHM5%1608
R247 HRFS104JBA RCHIP 1/16100KOHM5%1608
R248 HRFS104JBA RCHIP 1/16100KOHM5%1608
R249 HRFS104JBA RCHIP 1/16100KOHM5%1608
R250 HRFS104JBA RCHIP 1/16100KOHM5%1608
R251 HRFS104JBA RCHIP 1/16100KOHM5%1608
R252 HRFS102JBA RCHIP 1/161KOHM5%1608
R253 HRFS102JBA RCHIP 1/161KOHM5%1608
R254 HRFS102JBA RCHIP 1/161KOHM5%1608
R255 HRFS102JBA RCHIP 1/161KOHM5%1608
R256 HRFS102JBA RCHIP 1/161KOHM5%1608
R257 HRFS102JBA RCHIP 1/161KOHM5%1608
R258 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R260 HRFS103JBA RCHIP 1/1610KOHM5%1608
R261 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R262 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R263 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R264 HRFS103JBA RCHIP 1/1610KOHM5%1608
R265 HRFS104JBA RCHIP 1/16100KOHM5%1608
R266 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R267 HRFS103JBA RCHIP 1/1610KOHM5%1608
R268 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R269 HRFS102JBA RCHIP 1/161KOHM5%1608
R270 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R271 HRFT222JCA RCHIP 1/102.2KOHM5%2012
R272 HRFS103JBA RCHIP 1/1610KOHM5%1608
R273 HRFS103JBA RCHIP 1/1610KOHM5%1608
R274 HRFS103JBA RCHIP 1/1610KOHM5%1608
R275 HRFS103JBA RCHIP 1/1610KOHM5%1608
R276 HRFS330JBA RCHIP 1/16 33OHM5%1608
R277 HRFS103JBA RCHIP 1/1610KOHM5%1608
R278 HRFS103JBA RCHIP 1/1610KOHM5%1608
R279 HRFS103JBA RCHIP 1/1610KOHM5%1608
R280 HRFS103JBA RCHIP 1/1610KOHM5%1608
R281 HRFS103JBA RCHIP 1/1610KOHM5%1608
R282 HRFS472JBA RCHIP 1/164.7KOHM5%1608
R283 HRFS103JBA RCHIP 1/1610KOHM5%1608
R291 HRFS103JBA RCHIP 1/1610KOHM5%1608
R292 HRFS103JBA RCHIP 1/1610KOHM5%1608
R293 HRFS222JBA RCHIP 1/162.2KOHM5%1608

7
BOM LIST
LOC PART CODE PART NAME PART DESC REMARK
R294 HRFS103JBA RCHIP 1/1610KOHM5%1608
R296 HRFS103JBA RCHIP 1/1610KOHM5%1608
R301 HRFS103JBA RCHIP 1/1610KOHM5%1608
R302 HRFS103JBA RCHIP 1/1610KOHM5%1608
R303 HRFS330JBA RCHIP 1/16 33OHM5%1608
R304 HRFS330JBA RCHIP 1/16 33OHM5%1608
R305 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R306 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R307 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R308 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R309 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R310 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R311 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R312 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R313 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R314 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R315 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R316 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R317 HRFS222JBA RCHIP 1/162.2KOHM5%1608
R318 HRFS330JBA RCHIP 1/16 33OHM5%1608
R319 HRFS330JBA RCHIP 1/16 33OHM5%1608
R320 HRFS330JBA RCHIP 1/16 33OHM5%1608
R321 HRFS330JBA RCHIP 1/16 33OHM5%1608
R322 HRFS330JBA RCHIP 1/16 33OHM5%1608
R323 HRFS330JBA RCHIP 1/16 33OHM5%1608
R324 HRFS330JBA RCHIP 1/16 33OHM5%1608
R325 HRFS330JBA RCHIP 1/16 33OHM5%1608
RA01 HRTS8E470J RCHIPARRAY 1/168P47OHM5%3216
RA02 HRTS8E470J RCHIPARRAY 1/168P47OHM5%3216
RA03 HRTS8E470J RCHIPARRAY 1/168P47OHM5%3216
RA04 HRTS8E470J RCHIPARRAY 1/168P47OHM5%3216
RA05 HRTS8E470J RCHIPARRAY 1/168P47OHM5%3216
RA06 HRTS8E470J RCHIPARRAY 1/168P47OHM5%3216
U101 97P65488MA PCBMAIN 213X144X1.6TDSD-9520
X001 HXJ27R000F SMD XTAL QUARTZ 27MHZ 30PPM HC49/4H SMX 30PF
X002 HXJ20R480C SMDXTALQUARTZ 20M4820PPMHC49/4HSMX30PF
LOC PART CODE PART NAME PART DESC REMARK
Z0012 PVMPJRE623 MAINRADIALASSY DSD-9520
C315 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C318 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C319 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C320 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C321 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C322 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C344 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C345 CEXF1C100A CELECTRO 16VRSM10MF(4X7)TP
C401 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C402 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C403 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C405 CEXF1H100V CELECTRO 50VRSS10MF(5X11)TP
C406 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C407 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C409 CEXF1H100V CELECTRO 50VRSS10MF(5X11)TP
C416 CEXA1C471H CELECTRO 16VRMU470MF(8X11.5)TP
C417 CEXF1H100V CELECTRO 50VRSS10MF(5X11)TP
C423 CEXA1C471H CELECTRO 16VRMU470MF(8X11.5)TP
C424 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C425 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C426 CEXA1C471H CELECTRO 16VRMU470MF(8X11.5)TP
C427 CEXA1C471H CELECTRO 16VRMU470MF(8X11.5)TP
C428 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C435 CEXA1C471H CELECTRO 16VRMU470MF(8X11.5)TP
C454 CEXA1C471H CELECTRO 16VRMU470MF(8X11.5)TP
C455 CEXF1C101V CELECTRO 16VRSS100MF(6.3X11)TP
C456 CEXA1C471H CELECTRO 16VRMU470MF(8X11.5)TP
L126 5CPX100K COILPEAKING W0810TB10UH K RADIAL
L153 5CPX681J COILPEAKING EL0606RA680UH J RADIAL
Z001A 7174300811 SCREWTAPPTITE TT2RND3X8MFZN
Z003 PVLAMSM089P PCBLOGICAS DSD-9520PKD
Z003A 7174301011 SCREWTAPPTITE TT2RND3X10MFZN
Z008 PVPWMSP576 PCBPOWER MANUAL AS DSD-9520 PKD
Z008A 7278300611 SCREWTAPPTITE TT3WAS3X6MFZN
Z008B 7174300811 SCREWTAPPTITE TT2RND3X8MFZN

8
SCHEMATIC DIAGRAM

9
SC EMATIC DIAGRAM

10
SC EMATIC DIAGRAM

11
SC EMATIC DIAGRAM

12
SC EMATIC DIAGRAM

13
SC EMATIC DIAGRAM

14
SC EMATIC DIAGRAM

15
SC EMATIC DIAGRAM

16
SC EMATIC DIAGRAM

17
EXPLODED VIEW
1
2
3
4
5
6
89
10
11
12
13
14
15
16
17
18
12
7
19
20
19
19
COVER BOTTOM
197P0485100 1 SECC T=0.8
2
PCB MAIN MANUAL AS 1
3
4
PCB POWER MANUAL AS 1
5
PCB LOGIC MANUAL AS 1
6
COVER BAC 97P0485200 1 SECC T0.6
7
PANEL FRONT AS 97PP345000
1
DSD-9256M1
8
COVER TOP 4952101600 1 SECC T0.6+PCM
9
CUSHION LEG 97P4220200 2 EVA T4.0
10
CORD POWER 97P69PB90B 1 U. P-660 YFH800 2.1M
11
SCREW TAPPTITE 7174301011 TT2 RND 3X10 MFZN
12
7174300811 2
13
17
18
SCREW TAPPTITE TT2 RND 3X8 MFZN
PCB LOGIC FIX
PANEL FRONT FIX
SCREW TAPPTITE 7174300811 4 TT2 RND 3X8 MFZN PCB MAIN FIX
14
SCREW MACHINE 7043350611 4 BIN M3.5*6 HDD+BR T FIX
15
SCREW TAPPTITE 7278300611 2 TT3 WAS 3X6 MFZN PCB POWER LEFT FIX
16
TT2 RND 3X8 MFZNSCREW TAPPTITE 7274300811 2 PCB POWER RIGHT FIX
SCREW TAPPTITE 7173300812 4 TT2 BIN 3X8 MFZN B JAC FIX
TT2 BIN 3X8 MFZN BSCREW TAPPTITE 7173300812 3 COVER TOP FIX
HDD 97P5100100 1 SGT 80G 5400RPM(ST380012ACE)
BR T HDD 97P2448300 1 SECC T1.0
SCREW TAPPTITE 7174300811 4 TT2 RND 3X8 MFZN BR T+BOTTOM FIX
5
20
19
PART NAMENO. MATERIALQ'TYPART NO. REMARK

DAEWOO ELE TRONI S ORP.
686, AHYEON-DONG, MAPO-GU,
SEOUL, KOREA.
C.P.O. BOX 8003 SEOUL KOREA
PRINTED DATE: March. 2006
