Daikin FXLQ-M Series Dimension Guide

EDUS391502-F7
FXLQ-M / FXNQ-M
Floor Standing Type /
Concealed Floor Standing Type

EDUS391502-F7
FXLQ-M / FXNQ-M 1
FXLQ-M / FXNQ-M
Floor Standing Type /
Concealed Floor Standing Type
1. Features and Benefits .................................................................................2
1.1 FXLQ ............................................................................................................ 2
1.2 FXNQ ........................................................................................................... 3
2. Specifications ..............................................................................................4
2.1 FXLQ ............................................................................................................ 4
2.2 FXNQ ........................................................................................................... 6
3. Dimensions .................................................................................................8
3.1 FXLQ ............................................................................................................ 8
3.2 FXNQ ......................................................................................................... 11
4. Piping Diagrams........................................................................................14
5. Wiring Diagrams........................................................................................15
6. Electric Characteristics..............................................................................16
7. Safety Devices Setting ..............................................................................17
8. Capacity Tables ........................................................................................18
8.1 Cooling Capacity at Te: 43°F (6°C) ............................................................ 18
8.2 Heating Capacity ........................................................................................ 18
8.3 Correction Factor for Cooling Capacity at Te: 48°F (9°C) .......................... 18
9. Sound Levels (Reference Data)................................................................19
9.1 FXLQ .......................................................................................................... 19
9.2 FXNQ ......................................................................................................... 23
10.Center of Gravity .......................................................................................27
10.1 FXLQ .......................................................................................................... 27
10.2 FXNQ ......................................................................................................... 27
11.Accessories...............................................................................................28
11.1 Optional Accessories (For Unit) ................................................................. 28
11.2 Optional Accessories (For Controls) .......................................................... 28
Appendix ........................................................................................................... i
1. Installation Manual ......................................................................................1

Features and Benefits EDUS391502-F7
2FXLQ-M / FXNQ-M
1. Features and Benefits
1.1 FXLQ
The floor standing unit can be installed quickly and easily in new or existing facilities in a variety of applications. Its compact
design makes it suitable for perimeter zone air conditioning.
FXLQ_MVJU9 - Floor Standing
Models range from 0.6 to 2 Ton
Stylish modern casing finished in ivory white
Ideal for installation beneath a window thanks to its low
height
One of our slimmest indoor units (less than 9'') fits any
interior design
Requires minimal installation space
Space-saving unit can be freestanding or wall-mounted
Fitted with washable long-life filter
Wide air discharge outlet distributes a comfortable airflow
throughout the entire space
Wall mounted installation facilitates cleaning beneath the unit
where dust tends to accumulate

EDUS391502-F7 Features and Benefits
FXLQ-M / FXNQ-M 3
1.2 FXNQ
The concealed floor units cover a wide range of capacities and can be built into counter in order to maintain the aesthetics of the
room.
Models range from 0.6 to 2 Ton
Ideal for installation beneath a window thanks to its low height
One of our slimmest indoor units (less than 9'') fits any interior design - only the suction and discharge grilles are visible
Requires minimal installation space
Fitted with washable long-life filter
The connecting port faces downward, eliminating the need to attach auxiliary piping
FXNQ_MVJU9 - Concealed Floor Standing

Specifications EDUS391502-F7
4FXLQ-M / FXNQ-M
2. Specifications
2.1 FXLQ
Floor Standing Type
Notes:
+1. Nominal cooling capacities are based on the following conditions:
Return air temperature: 80.0°FDB (26.7°CDB), 67.0°FWB (19.4°CWB)
Outdoor temperature: 95.0°FDB (35.0°CDB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+2. Nominal heating capacities are based on the following conditions:
Return air temperature: 70.0°FDB (21.1°CDB).
Outdoor temperature: 47.0°FDB (8.3°CDB), 43.0°FWB (6.1°CWB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+4. Anechoic chamber conversion value, measured under JIS conditions. During actual operation,
these values may be higher as a result of installation conditions.
5. Refer to Electric Characteristics for the power input.
+1 +3 Cooling capacity Btu/h
(kW) 7,500 (2.2) 9,500 (2.8) 12,000 (3.5)
+2 +3 Heating capacity Btu/h
(kW) 8,500 (2.5) 10,500 (3.1) 13,500 (4.0)
Casing color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) in.
(mm) 23-5/8×39-3/8×8-3/4 (600×1,000×222) 23-5/8×39-3/8×8-3/4 (600×1,000×222) 23-5/8×44-7/8×8-3/4 (600×1,140×222)
Coil (Cross
fin coil)
Rows×Stages×FPI 3×14×17 3×14×17 3×14×17
Face area ft² (m²) 1.71 (0.159) 1.71 (0.159) 2.15 (0.200)
Fan
Model D14B20 D14B20 2D14B13
Type Sirocco fan Sirocco fan Sirocco fan
Motor output W 15 15 25
Airflow rate (H/L)
cfm
(m³/min)
245/210 (7/6) 245/210 (7/6) 280/210 (8/6)
Drive Direct drive Direct drive Direct drive
Temperature control Microprocessor thermostat for cooling
and heating Microprocessor thermostat for cooling and heating Microprocessor thermostat for cooling and heating
Sound absorbing thermal insulation material Glass fiber/urethane foam Glass fiber/urethane foam Glass fiber/urethane foam
Air filter Resin net (with mold resistant) Resin net (with mold resistant) Resin net (with mold resistant)
Piping
connections
Liquid pipes in.
(mm) φ1/4 (φ6.4) (Flare connection) φ1/4 (φ6.4) (Flare connection) φ1/4 (φ6.4) (Flare connection)
Gas pipes in.
(mm) φ1/2 (φ12.7) (Flare connection) φ1/2 (φ12.7) (Flare connection) φ1/2 (φ12.7) (Flare connection)
Drain pipe in.
(mm) φ27/32 (φ21) O.D (Vinyl chloride) φ27/32 (φ21) O.D (Vinyl chloride) φ27/32 (φ21) O.D (Vinyl chloride)
Weight lbs (kg) 58 (26) 58 (26) 66 (30)
+4 Sound pressure level (H/L) dB (A) 35/32 35/32 36/33
Safety devices Fuse,
Thermal protector for fan motor Fuse, Thermal protector for fan motor Fuse, Thermal protector for fan motor
Refrigerant control Electronic expansion valve Electronic expansion valve Electronic expansion valve
Connectable outdoor unit R410A VRV series R410A VRV series R410A VRV series
Standard accessories
Operation manual, Installation manual,
Insulation for fitting, Drain hose, Clamps,
Screws, Washers, Level adjustment
screw
Operation manual, Installation manual,
Insulation for fitting, Drain hose, Clamps,
Screws, Washers, Level adjustment
screw
Operation manual, Installation manual,
Insulation for fitting, Drain hose, Clamps,
Screws, Washers, Level adjustment
screw
Drawing No. C: 3D045640A
Model FXLQ07MVJU9FXLQ09MVJU9FXLQ12MVJU9
Power supply 1 phase, 60Hz, 208/230V 1 phase, 60Hz, 208/230V 1 phase, 60Hz, 208/230V

EDUS391502-F7 Specifications
FXLQ-M / FXNQ-M 5
Floor Standing Type
Notes:
+1. Nominal cooling capacities are based on the following conditions:
Return air temperature: 80.0°FDB (26.7°CDB), 67.0°FWB (19.4°CWB)
Outdoor temperature: 95.0°FDB (35.0°CDB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+2. Nominal heating capacities are based on the following conditions:
Return air temperature: 70.0°FDB (21.1°CDB).
Outdoor temperature: 47.0°FDB (8.3°CDB), 43.0°FWB (6.1°CWB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+4. Anechoic chamber conversion value, measured under JIS conditions. During actual operation,
these values may be higher as a result of installation conditions.
5. Refer to Electric Characteristics for the power input.
+1 +3 Cooling capacity Btu/h
(kW) 18,000 (5.3) 24,000 (7.0)
+2 +3 Heating capacity Btu/h
(kW) 20,000 (5.9) 27,000 (7.9)
Casing color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) in.
(mm) 23-5/8×55-7/8×8-3/4 (600×1,420×222) 23-5/8×55-7/8×8-3/4 (600×1,420×222)
Coil (Cross
fin coil)
Rows×Stages×FPI 3×14×17 3×14×17
Face area ft² (m²) 3.04 (0.282) 3.04 (0.282)
Fan
Model 2D14B20 2D14B20
Type Sirocco fan Sirocco fan
Motor output W 35 35
Airflow rate (H/L)
cfm
(m³/min)
490/380 (14/11) 560/420 (16/12)
Drive Direct drive Direct drive
Temperature control Microprocessor thermostat for cooling and heating Microprocessor thermostat for cooling and heating
Sound absorbing thermal insulation material Glass fiber/urethane foam Glass fiber/urethane foam
Air filter Resin net (with mold resistant) Resin net (with mold resistant)
Piping
connections
Liquid pipes in.
(mm) φ1/4 (φ6.4) (Flare connection) φ3/8 (φ9.5) (Flare connection)
Gas pipes in.
(mm) φ1/2 (φ12.7) (Flare connection) φ5/8 (φ15.9) (Flare connection)
Drain pipe in.
(mm) φ27/32 (φ21) O.D (Vinyl chloride) φ27/32 (φ21) O.D (Vinyl chloride)
Weight lbs (kg) 80 (36) 80 (36)
+4 Sound pressure level (H/L) dB (A) 40/35 41/36
Safety devices Fuse,
Thermal protector for fan motor Fuse, Thermal protector for fan motor
Refrigerant control Electronic expansion valve Electronic expansion valve
Connectable outdoor unit R410A VRV series R410A VRV series
Standard accessories Operation manual, Installation manual, Insulation for fitting, Drain hose, Clamps, Screws, Washers, Level adjustment
screw
Operation manual, Installation manual, Insulation for fitting,
Drain hose, Clamps, Screws, Washers, Level adjustment
screw
Drawing No. C: 3D045640A
Model FXLQ18MVJU9FXLQ24MVJU9
Power supply 1 phase, 60Hz, 208/230V 1 phase, 60Hz, 208/230V

Specifications EDUS391502-F7
6FXLQ-M / FXNQ-M
2.2 FXNQ
Concealed Floor Standing Type
Notes:
+1. Nominal cooling capacities are based on the following conditions:
Return air temperature: 80.0°FDB (26.7°CDB), 67.0°FWB (19.4°CWB)
Outdoor temperature: 95.0°FDB (35.0°CDB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+2. Nominal heating capacities are based on the following conditions:
Return air temperature: 70.0°FDB (21.1°CDB).
Outdoor temperature: 47.0°FDB (8.3°CDB), 43.0°FWB (6.1°CWB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+4. Anechoic chamber conversion value, measured under JIS conditions. During actual operation,
these values may be higher as a result of installation conditions.
5. Refer to Electric Characteristics for the power input.
+1 +3 Cooling capacity Btu/h
(kW) 7,500 (2.2) 9,500 (2.8) 12,000 (3.5)
+2 +3 Heating capacity Btu/h
(kW) 8,500 (2.5) 10,500 (3.1) 13,500 (4.0)
Casing color Galvanized steel plate Galvanized steel plate Galvanized steel plate
Dimensions: (H×W×D) in.
(mm) 24×36-5/8×8-5/8 (610×930×220) 24×36-5/8×8-5/8 (610×930×220) 24×42-1/8×8-5/8 (610×1,070×220)
Coil (Cross
fin coil)
Rows×Stages×FPI 3×14×17 3×14×17 3×14×17
Face area ft² (m²) 1.71 (0.159) 1.71 (0.159) 2.15 (0.200)
Fan
Model D14B20 D14B20 2D14B13
Type Sirocco fan Sirocco fan Sirocco fan
Motor output W 15 15 25
Airflow rate (H/L)
cfm
(m³/min)
245/210 (7/6) 245/210 (7/6) 280/210 (8/6)
Drive Direct drive Direct drive Direct drive
Temperature control Microprocessor thermostat for cooling
and heating Microprocessor thermostat for cooling and heating Microprocessor thermostat for cooling and heating
Sound absorbing thermal insulation material Glass fiber/urethane foam Glass fiber/urethane foam Glass fiber/urethane foam
Air filter Resin net (with mold resistant) Resin net (with mold resistant) Resin net (with mold resistant)
Piping
connections
Liquid pipes in.
(mm) φ1/4 (φ6.4) (Flare connection) φ1/4 (φ6.4) (Flare connection) φ1/4 (φ6.4) (Flare connection)
Gas pipes in.
(mm) φ1/2 (φ12.7) (Flare connection) φ1/2 (φ12.7) (Flare connection) φ1/2 (φ12.7) (Flare connection)
Drain pipe in.
(mm) φ27/32 (φ21) O.D (Vinyl chloride) φ27/32 (φ21) O.D (Vinyl chloride) φ27/32 (φ21) O.D (Vinyl chloride)
Weight lbs (kg) 47 (21) 47 (21) 56 (25)
+4 Sound pressure level (H/L) dB (A) 35/32 35/32 36/33
Safety devices Fuse,
Thermal protector for fan motor Fuse, Thermal protector for fan motor Fuse, Thermal protector for fan motor
Refrigerant control Electronic expansion valve Electronic expansion valve Electronic expansion valve
Connectable outdoor unit R410A VRV series R410A VRV series R410A VRV series
Standard accessories
Operation manual, Installation manual,
Insulation for fitting, Drain hose, Clamps,
Screws, Washers, Level adjustment
screw
Operation manual, Installation manual,
Insulation for fitting, Drain hose, Clamps,
Screws, Washers, Level adjustment
screw
Operation manual, Installation manual,
Insulation for fitting, Drain hose, Clamps,
Screws, Washers, Level adjustment
screw
Drawing No. C: 3D045648A
Model FXNQ07MVJU9FXNQ09MVJU9FXNQ12MVJU9
Power supply 1 phase, 60Hz, 208/230V 1 phase, 60Hz, 208/230V 1 phase, 60Hz, 208/230V

EDUS391502-F7 Specifications
FXLQ-M / FXNQ-M 7
Concealed Floor Standing Type
Notes:
+1. Nominal cooling capacities are based on the following conditions:
Return air temperature: 80.0°FDB (26.7°CDB), 67.0°FWB (19.4°CWB)
Outdoor temperature: 95.0°FDB (35.0°CDB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+2. Nominal heating capacities are based on the following conditions:
Return air temperature: 70.0°FDB (21.1°CDB).
Outdoor temperature: 47.0°FDB (8.3°CDB), 43.0°FWB (6.1°CWB)
Equivalent ref. piping length: 25ft (7.6m) (Horizontal)
+3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+4. Anechoic chamber conversion value, measured under JIS conditions. During actual operation,
these values may be higher as a result of installation conditions.
5. Refer to Electric Characteristics for the power input.
+1 +3 Cooling capacity Btu/h
(kW) 18,000 (5.3) 24,000 (7.0)
+2 +3 Heating capacity Btu/h
(kW) 20,000 (5.9) 27,000 (7.9)
Casing color Galvanized steel plate Galvanized steel plate
Dimensions: (H×W×D) in.
(mm) 24×53-1/8×8-5/8 (610×1,350×220) 24×53-1/8×8-5/8 (610×1,350×220)
Coil (Cross
fin coil)
Rows×Stages×FPI 3×14×17 3×14×17
Face area ft² (m²) 3.04 (0.282) 3.04 (0.282)
Fan
Model 2D14B20 2D14B20
Type Sirocco fan Sirocco fan
Motor output W 35 35
Airflow rate (H/L)
cfm
(m³/min)
490/380 (14/11) 560/420 (16/12)
Drive Direct drive Direct drive
Temperature control Microprocessor thermostat for cooling and heating Microprocessor thermostat for cooling and heating
Sound absorbing thermal insulation material Glass fiber/urethane foam Glass fiber/urethane foam
Air filter Resin net (with mold resistant) Resin net (with mold resistant)
Piping
connections
Liquid pipes in.
(mm) φ1/4 (φ6.4) (Flare connection) φ3/8 (φ9.5) (Flare connection)
Gas pipes in.
(mm) φ1/2 (φ12.7) (Flare connection) φ5/8 (φ15.9) (Flare connection)
Drain pipe in.
(mm) φ27/32 (φ21) O.D (Vinyl chloride) φ27/32 (φ21) O.D (Vinyl chloride)
Weight lbs (kg) 69 (31) 69 (31)
+4 Sound pressure level (H/L) dB (A) 40/35 41/36
Safety devices Fuse,
Thermal protector for fan motor Fuse, Thermal protector for fan motor
Refrigerant control Electronic expansion valve Electronic expansion valve
Connectable outdoor unit R410A VRV series R410A VRV series
Standard accessories Operation manual, Installation manual, Insulation for fitting, Drain hose, Clamps, Screws, Washers, Level adjustment
screw
Operation manual, Installation manual, Insulation for fitting,
Drain hose, Clamps, Screws, Washers, Level adjustment
screw
Drawing No. C: 3D045648A
Model FXNQ18MVJU9FXNQ24MVJU9
Power supply 1 phase, 60Hz, 208/230V 1 phase, 60Hz, 208/230V

Dimensions EDUS391502-F7
8FXLQ-M / FXNQ-M
3. Dimensions
3.1 FXLQ
3D090732A
Unit: in. (mm)
FXLQ07MVJU9/ FXLQ09MVJU9

EDUS391502-F7 Dimensions
FXLQ-M / FXNQ-M 9
3D045642A
Unit: in. (mm)
FXLQ12MVJU9

Dimensions EDUS391502-F7
10 FXLQ-M / FXNQ-M
3D045643A
Unit: in. (mm)
FXLQ18MVJU9/ FXLQ24MVJU9

EDUS391502-F7 Dimensions
FXLQ-M / FXNQ-M 11
3.2 FXNQ
3D090733
Unit: in. (mm)
FXNQ07MVJU9/ FXNQ09MVJU9

Dimensions EDUS391502-F7
12 FXLQ-M / FXNQ-M
3D045650A
Unit: in. (mm)
FXNQ12MVJU9

EDUS391502-F7 Dimensions
FXLQ-M / FXNQ-M 13
3D045651A
Unit: in. (mm)
FXNQ18MVJU9/ FXNQ24MVJU9

Piping Diagrams EDUS391502-F7
14 FXLQ-M / FXNQ-M
4. Piping Diagrams
Unit: in. (mm)
Model Gas Liquid
φ1/2
(φ12.7)
φ1/4
(φ6.4)
FXLQ24MVJU
FXNQ24MVJU
φ5/8
(φ15.9)
φ3/8
(φ9.5)
C: 4D034245L
FXLQ07MVJU9/ FXLQ09MVJU9/ FXLQ12MVJU9/ FXLQ18MVJU9/ FXLQ24MVJU9
FXNQ07MVJU9/ FXNQ09MVJU9/ FXNQ12MVJU9/ FXNQ18MVJU9/ FXNQ24MVJU9
FXLQ07MVJU / FXLQ09MVJU / FXLQ12MVJU / FXLQ18MVJU
FXNQ07MVJU / FXNQ09MVJU / FXNQ12MVJU / FXNQ18MVJU

EDUS391502-F7 Wiring Diagrams
FXLQ-M / FXNQ-M 15
5. Wiring Diagrams
FXLQ07MVJU / FXLQ09MVJU / FXLQ12MVJU / FXLQ18MVJU / FXLQ24MVJU
FXNQ07MVJU / FXNQ09MVJU / FXNQ12MVJU / FXNQ18MVJU / FXNQ24MVJU
3D045644C

Electric Characteristics EDUS391502-F7
16 FXLQ-M / FXNQ-M
6. Electric Characteristics
FXLQ07MVJU / FXLQ09MVJU / FXLQ12MVJU / FXLQ18MVJU / FXLQ24MVJU
FXNQ07MVJU / FXNQ09MVJU / FXNQ12MVJU / FXNQ18MVJU / FXNQ24MVJU
4D047090B

EDUS391502-F7 Safety Devices Setting
FXLQ-M / FXNQ-M 17
7. Safety Devices Setting
C: 3D045646B
Model FXLQ07MVJU
FXNQ07MVJU
FXLQ09MVJU
FXNQ09MVJU
FXLQ12MVJU
FXNQ12MVJU
FXLQ18MVJU
FXNQ18MVJU
FXLQ24MVJU
FXNQ24MVJU
Printed circuit board fuse 250V 5A 250V 5A 250V 5A 250V 5A 250V 5A
Fan motor thermal protector °F
(°C)
OFF: 275
±18
(135
±10
)
ON: 248 (120) or less
OFF: 275
±18
(135
±10
)
ON: 248 (120) or less
OFF: 275
±18
(135
±10
)
ON: 248 (120) or less
OFF: 275
±18
(135
±10
)
ON: 248 (120) or less
OFF: 275
±18
(135
±10
)
ON: 248 (120) or less

Capacity Tables EDUS391502-F7
18 FXLQ-M / FXNQ-M
8. Capacity Tables
8.1 Cooling Capacity at Te: 43°F (6°C)
TC: Total capacity: MBH
SHC: Sensible heat capacity: MBH
Notes: 1. These capacity tables can be used when selecting a VRV indoor unit. The actual capacity of the VRV system depends on factors such
as the selected model of outdoor units, outdoor air temperature and piping length. Please confirm that the corrected capacity of the VRV
system satisfies the required heat load.
2. shows rated condition.
8.2 Heating Capacity
TC: Total capacity: MBH
Notes: 1. These capacity tables can be used when selecting a VRV indoor unit. The actual capacity of the VRV system depends on factors such
as the selected model of outdoor units, outdoor air temperature and piping length. Please confirm that the corrected capacity of the VRV
system satisfies the required heat load.
2. shows rated condition.
8.3 Correction Factor for Cooling Capacity at Te: 48°F (9°C)
TC: Total capacity
SHF: Sensible heat factor
Model
Indoor air temp. °FWB (Te: 43°F (6°C))
61 64 67 70 72 75
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
MBH MBH MBH MBH MBH MBH MBH MBH MBH MBH MBH MBH
FXLQ07MVJU
FXNQ07MVJU 5.9 4.9 6.7 5.4 7.5 5.8 7.6 5.6 7.7 5.1 7.9 4.8
FXLQ09MVJU
FXNQ09MVJU 7.5 5.9 8.5 6.5 9.5 7.1 9.7 6.9 9.8 6.4 10.0 6.0
FXLQ12MVJU
FXNQ12MVJU 9.5 7.5 10.7 7.9 12.0 8.3 12.7 8.4 12.9 8.0 13.1 7.6
FXLQ18MVJU
FXNQ18MVJU 14.2 10.7 16.1 11.5 18.0 12.2 19.1 12.6 19.3 12.1 19.7 11.4
FXLQ24MVJU
FXNQ24MVJU 18.9 14.1 21.5 15.1 24.0 15.9 25.5 16.5 25.8 15.8 26.3 14.7
Model
Indoor air temp. °FDB (Tc: 115°F (46°C))
62 65 68 70 72 75
TC TC TC TC TC TC
MBH MBH MBH MBH MBH MBH
FXLQ07MVJU
FXNQ07MVJU 9.9 9.3 8.8 8.5 8.2 7.7
FXLQ09MVJU
FXNQ09MVJU 12.3 11.5 10.9 10.5 10.1 9.5
FXLQ12MVJU
FXNQ12MVJU 14.9 14.7 14.0 13.5 13.0 12.3
FXLQ18MVJU
FXNQ18MVJU 22.3 22.1 21.0 20.0 19.5 18.4
FXLQ24MVJU
FXNQ24MVJU 29.7 29.5 28.0 27.0 26.0 24.5
Model
Indoor air temp. °FWB (Te: 48°F (9°C))
61 64 67 70 72 75
TC SHF TC SHF TC SHF TC SHF TC SHF TC SHF
FXLQ07MVJU
FXNQ07MVJU 0.71 1.16 0.77 1.11 0.79 1.09 0.81 1.07 0.84 1.05 0.87 1.03
FXLQ09MVJU
FXNQ09MVJU 0.71 1.16 0.77 1.11 0.79 1.09 0.81 1.07 0.84 1.05 0.87 1.03
FXLQ12MVJU
FXNQ12MVJU 0.71 1.16 0.77 1.11 0.79 1.09 0.81 1.07 0.84 1.05 0.87 1.03
FXLQ18MVJU
FXNQ18MVJU 0.71 1.16 0.77 1.11 0.79 1.09 0.81 1.07 0.84 1.05 0.87 1.03
FXLQ24MVJU
FXNQ24MVJU 0.71 1.16 0.77 1.10 0.80 1.08 0.81 1.07 0.84 1.05 0.87 1.04
Refer to the correction factor table below when a mini-
split indoor unit is connected to your VRV system.
