Daikin MXS-E Instruction manual

Air Conditioning
Technical Data
Multi model application
EEDEN15-100
MXS-E

• Split - Sky Air • MXS-E 1
• Outdoor Unit • MXS-E
TABLE OF CONTENTS
MXS-E
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Combination table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Capacity Table Legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8 Centre of gravity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
10 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
11 Sound data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Sound Power Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Sound Pressure Spectrum - Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Sound Pressure Spectrum - Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
12 Operation range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

• Outdoor Unit • MXS-E
1
• Split - Sky Air • MXS-E
2
1 Features
OutdoorUni Split-Sk MXS-EMultimodel • Outdoor units for multi model application.
• Up to 5 indoor units can be connected to 1 multi outdoor unit; all
indoor units are individually controllable and do not need to be
installed in the same room or at the same time; they operate
simultaneously within the same cooling or heating mode
• Different types of indoor units can be connected: e.g. wall mounted,
ceiling mounted cassette corner, concealed ceiling unit
• Night quiet mode automatically reduces the operation sound of the
outdoor unit by 3dBA during nighttime (multi outdoor units in cooling
mode only)
• The use of inverter type outdoor units results in an air conditioning
system with a high energy efficiency and very low sound level
• Daikin outdoor units are neat, sturdy and can easily be mounted on a
roof or terrace or simply placed against an outside wall
• Outdoorunitsarefitted withaswing compressor,renownedforits low
noise and high energy efficiency
Inverter Night quiet
mode

3
2
• Split - Sky Air • MXS-E 3
• Outdoor Unit • MXS-E
2 Specifications
2-1 Technical Specifications 3MXS52E 4MXS80E 5MXS90E
Capacity control Method Inverter controlled
Casing Colour Ivorywhite
Dimensions Unit Height mm 735 770
Width mm 936 900
Depth mm 300 320
Packed unit Height mm 797 900
Width mm 992 925
Depth mm 390
Weight Unit kg 49 72 73
Packed unit kg 56 80
Heat exchanger Length mm 845 879
Rows Quantity 2
Fin pitch mm 1.8 1.40
Stages Quantity 32 34
Tube type ø7.94 grooved tubes 24 ø8 Hi-XA
Fin Type Colgate fin WF fin
Treatment Anti-corrosion treatment -
Compressor Model 2YC36BXD 2YC63BXD#C
Type Hermetically sealed swing compressor
Output W 1,100 1,920
Fan Type Propeller fan
Air flow rate Cooling High m³/min 45 54.5 57.1
cfm 1,589 1,924 2,016
Nom. m³/min 45 - 54.5
cfm 1,589 - 1,924
Low m³/min 45 46.0
cfm 1,589 1,624
Super
low m³/min -
cfm -
Heating High m³/min 45 46.0 52.5
cfm 1,589 1,624 1,854
Low m³/min 41 14.7
cfm 1,448 519
Super
low m³/min -
cfm -
Running current Cooling Low A 0.29 0.69
Standar
dA - 0.97
High A 0.33 0.97 1.02
Heating Low A 0.29 0.05
High A 0.33 0.69 0.90
Power consumption Cooling Low W 34 55
Standar
dW- 86
High W 43 86 95
Heating Low W 34 9
High W 43 55 78
Fan motor Model KFD-380-50-8C KFD-280-66-8A
Output W 53 66.00
Speed Cooling High rpm 720 860 900
Nom. rpm - 860
Low rpm 660 730
Super
low rpm -
Heating High rpm 720 730 830
Low rpm 660 250
Super
low rpm -

• Outdoor Unit • MXS-E
2
• Split - Sky Air • MXS-E
4
2 Specifications
Standard Accessories : Installation manual; Quantity : 1;
Standard Accessories : Drain plug; Quantity : 1;
Standard Accessories : Reducer assembly; Quantity : 1;
Standard Accessories : Air direction adjustment plate; Quantity : 1;
Notes
Cooling: indoor temp. 27°CDB, 19.0°CWB; outdoor temp. 35°CDB; equivalent piping length: 7.5m
Heating: indoor temp. 20°CDB; outdoor temp. 7°CDB, 6°CWB; equivalent refrigerant piping: 7.5m
Contains fluorinated greenhouse gases
Sound power level Cooling dBA 59 62 66
Heating dBA 60 -
Sound pressure level Cooling Nom. dBA 46 48 52
Heating Nom. dBA 47 49 52
Operation range Cooling Ambien
tMin. °CDB -10
Max. °CDB 46
Heating Ambien
tMin. °CWB -15
Max. °CWB 18
Refrigerant Type R-410A
Charge kg 2.0 2.99
TCO2eq 4.2 6.2
GWP 2,087.5
Refrigerant oil Type FVC50K
Charged volume l 0.65 0.75
Piping connections Liquid Quantity 3 4 5
OD mm 6.35
Gas Quantity 2 1 2
OD mm 9.52
Drain ID mm -
OD mm 16 (innerdiameterofconnecting
hose) 25
Gas 2 Quantity 1
OD mm 12.7
Gas 3 Quantity - 2
OD mm - 15.9
Piping length OU - IU Max. m 25
Additional refrigerant charge kg/m 0.02 (for piping length exceeding 30m)
Level difference IU - OU Max. m 15
IU - IU Max. m 7.5
Heat insulation Both liquid and gas pipes
Total piping length System Actual m 50 70 75
2-2 Electrical Specifications 3MXS52E 4MXS80E 5MXS90E
Power supply Name V1 V3
Phase 1~
Frequency Hz 50
Voltage V 230
Current Starting current Cooling A 6.2 9.7 11.8
Heating A 6.2 9.7 11.8
Current - 50Hz Maximum fuse amps (MFA) A 20
Current - 60Hz Maximum fuse amps (MFA) A -
Wiring connections For power supply Remark 3 for power supply, 4 for interunit wiring (including earth wiring)
2-1 Technical Specifications 3MXS52E 4MXS80E 5MXS90E

3
3
• Split - Sky Air • MXS-E 5
• Outdoor Unit • MXS-E
3 Electrical data
3 - 1 Electrical Data

• Outdoor Unit • MXS-E
4
• Split - Sky Air • MXS-E
6
4 Options
4 - 1 Options

3
5
• Split - Sky Air • MXS-E 7
• Outdoor Unit • MXS-E
5 Combination table
5 - 1 Combination Table

• Outdoor Unit • MXS-E
5
• Split - Sky Air • MXS-E
8
5 Combination table
5 - 1 Combination Table

3
5
• Split - Sky Air • MXS-E 9
• Outdoor Unit • MXS-E
5 Combination table
5 - 1 Combination Table

• Outdoor Unit • MXS-E
5
• Split - Sky Air • MXS-E
10
5 Combination table
5 - 1 Combination Table

3
5
• Split - Sky Air • MXS-E 11
• Outdoor Unit • MXS-E
5 Combination table
5 - 1 Combination Table

• Outdoor Unit • MXS-E
5
• Split - Sky Air • MXS-E
12
5 Combination table
5 - 1 Combination Table

3
5
• Split - Sky Air • MXS-E 13
• Outdoor Unit • MXS-E
5 Combination table
5 - 1 Combination Table

• Outdoor Unit • MXS-E
5
• Split - Sky Air • MXS-E
14
5 Combination table
5 - 1 Combination Table

3
5
• Split - Sky Air • MXS-E 15
• Outdoor Unit • MXS-E
5 Combination table
5 - 1 Combination Table

• Outdoor Unit • MXS-E
5
• Split - Sky Air • MXS-E
16
5 Combination table
5 - 1 Combination Table

3
5
• Split - Sky Air • MXS-E 17
• Outdoor Unit • MXS-E
5 Combination table
5 - 1 Combination Table

• Outdoor Unit • MXS-E
5
• Split - Sky Air • MXS-E
18
5 Combination table
5 - 1 Combination Table
