Daikin RZQSG-LY1 Instruction manual

Air Conditioning
Technical Data
EEDEN14-100
RZQSG-L(8)Y1

• Split - Sky Air • RZQSG-L(8)Y1 1
• Outdoor Unit • RZQSG-L(8)Y1
TABLE OF CONTENTS
RZQSG-L(8)Y1
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Nominal Capacity And Nominal Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5 Combination table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cooling Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Heating Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Capacity Correction Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
8 Centre of gravity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Piping Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Piping Diagram Twin Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Piping Diagram Triple Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Piping Diagram Double Twin Application . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Wiring Diagrams - Three Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
11 Sound data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Sound Power Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Sound Pressure Spectrum - Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Sound Pressure Spectrum - Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Sound Pressure Spectrum Quiet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
12 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Installation Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
13 Operation range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

• Outdoor Unit • RZQSG-L(8)Y1
1
• Split - Sky Air • RZQSG-L(8)Y1
2
1 Features
OutdoorUni Split-Sk RZQSG-L(8)Y1 • Seasonal classic series already comply with EU's 2014 Eco-Design
requirements
• Top efficiency: - new compressor that offers substantial efficiency
improvements - new control logic thatoptimises efficiency at the most
frequently encountered operating conditions and that optimises the
auxiliary modes (when the unit is not active) - newly designed heat
exchangers that optimise the refrigerant flow at the most frequent
operating conditions (temperature and load) - via improved nominal
performances
• Re-use of existing R-22 or R-407C technology
• Guarantees operation in heating mode down to -15°C
• Maximum piping length up to 50m, minimum piping length is 5m.
• Daikin outdoor units are neat, sturdy and can easily be mounted on a
roof or terrace or simply placed against an outside wall
• Seasonal efficiency, optimized for all seasons.
• Seasonal efficiency gives an indication on how efficient an air
conditioner operates over an entire heating or cooling season.
• Compatibility with D-BACS
Inverter

3
2
• Split - Sky Air • RZQSG-L(8)Y1 3
• Outdoor Unit • RZQSG-L(8)Y1
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
2-1 Nominal Capacity And Nominal Input FCQHG100F/RZQSG100L8Y1 FCQHG125F/RZQSG125L8Y1 FCQHG140F/RZQSG140LY1
Coolingcapacity Nom. kW 9.5 12.0 13.4
Heating capacity Nom. kW 10.8 13.5 15.5
Power input Cooling Nom. kW 2.57 3.71 4.17
Heating Nom. kW 2.51 3.60 4.29
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A++ A -
Pdesign kW 9.50 12.00 -
SEER 6.70 5.40 -
Annual energy
consumption kWh 496 778 -
Heating (Average
climate) Energy label A+ -
Pdesign kW 8.03 -
SCOP 4.30 4.10 -
Annual energy
consumption kWh 2,614 2,741 -
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.70 3.23 3.21
COP 4.30 3.75 3.61
Annual energy consumption kWh 1,285 1,855 2,085
Energy label Cooling A -
Heating A -
2-2 Nominal Capacity And Nominal Input FCQG100F/RZQSG100L8Y1 FCQG125F/RZQSG125L8Y1 FCQG140F/RZQSG140LY1
Coolingcapacity Nom. kW 9.5 12.0 13.4
Heating capacity Nom. kW 10.8 13.5 15.5
Power input Cooling Nom. kW 2.88 3.74 4.45
Heating Nom. kW 3.05 3.96 4.54
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A++ A -
Pdesign kW 9.50 12.00 -
SEER 6.50 5.30 -
Annual energy
consumption kWh 512 792 -
Heating (Average
climate) Energy label A+ -
Pdesign kW 7.60 8.03 -
SCOP 4.10 4.01 -
Annual energy
consumption kWh 2,595 2,803 -
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.30 3.21 3.01
COP 3.54 3.41
Annual energy consumption kWh 1,440 1,870 2,225
Energy label Cooling A -
Heating B -
2-3 Nominal Capacity And Nominal Input FAQ100C/RZQSG100L8Y1
Cooling capacity Nom. kW 9.5
Heating capacity Nom. kW 10.8
Power input Cooling Nom. kW 3.16
Heating Nom. kW 3.17

• Outdoor Unit • RZQSG-L(8)Y1
2
• Split - Sky Air • RZQSG-L(8)Y1
4
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A+
Pdesign kW 9.50
SEER 5.61
Annual energy
consumption kWh 593
Heating (Average
climate) Energy label A+
Pdesign kW 6.81
SCOP 4.01
Annual energy
consumption kWh 2,378
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.01
COP 3.41
Annual energy consumption kWh 1,580
Energy label Cooling B
Heating B
2-4 Nominal Capacity And Nominal Input FVQ100C/RZQSG100L8Y1 FVQ125C/RZQSG125L8Y1 FVQ140C/RZQSG140LY1
Cooling capacity Nom. kW 9.5 12.0 13.4
Heating capacity Nom. kW 10.8 13.5 15.5
Power input Cooling Nom. kW 2.96 4.27 4.45
Heating Nom. kW 2.99 3.96 4.54
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A -
Pdesign kW 9.50 12.00 -
SEER 5.50 -
Annual energy
consumption kWh 605 764 -
Heating (Average
climate) Energy label A+ A -
Pdesign kW 7.60 -
SCOP 4.01 3.85 -
Annual energy
consumption kWh 2,653 2,764 -
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.21 2.81 3.01
COP 3.61 3.41
Annual energy consumption kWh 1,480 2,135 2,225
Energy label Cooling A C -
Heating A B -
2-5 Nominal Capacity And Nominal Input FBQ100C8/RZQSG100L8Y1 FBQ125C8/RZQSG125L8Y1 FBQ140C8/RZQSG140LY1
Cooling capacity Nom. kW 9.5 12.0 13.4
Heating capacity Nom. kW 10.8 13.5 15.5
Power input Cooling Nom. kW 2.87 3.74 4.44
Heating Nom. kW 2.96 3.85 4.54
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A -
Pdesign kW 9.50 12.00 -
SEER 5.50 5.20 -
Annual energy
consumption kWh 605 808 -
Heating (Average
climate) Energy label A+ A -
Pdesign kW 7.60 -
SCOP 4.01 3.90 -
Annual energy
consumption kWh 2,653 2,728 -
2-3 Nominal Capacity And Nominal Input FAQ100C/RZQSG100L8Y1

3
2
• Split - Sky Air • RZQSG-L(8)Y1 5
• Outdoor Unit • RZQSG-L(8)Y1
2 Specifications
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
Notes
(1) EER/COP according to Eurovent 2012, for use outside EU only
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.31 3.21 3.02
COP 3.65 3.51 3.41
Annual energy consumption kWh 1,435 1,870 2,220
Energy label Cooling A -
Heating A B -
2-6 Nominal Capacity And Nominal Input FDQ125C/RZQSG125L8Y1
Cooling capacity Nom. kW 12.0
Heating capacity Nom. kW 13.5
Power input Cooling Nom. kW 3.74
Heating Nom. kW 3.85
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A
Pdesign kW 12.00
SEER 5.20
Annual energy
consumption kWh 808
Heating (Average
climate) Energy label A
Pdesign kW 7.60
SCOP 3.90
Annual energy
consumption kWh 2,728
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.21
COP 3.51
Annual energy consumption kWh 1,870
Energy label Cooling A
Heating B
2-7 Nominal Capacity And Nominal Input FHQ100C/RZQSG100L8Y1 FHQ125C/RZQSG125L8Y1 FHQ140C/RZQSG140LY1
Coolingcapacity Nom. kW 9.5 12.0 13.4
Heating capacity Nom. kW 10.8 13.5 15.5
Power input Cooling Nom. kW 2.96 4.15 4.45
Heating Nom. kW 2.99 3.73 4.54
Seasonal efficiency
(according to
EN14825)
Cooling Energy label A+ -
Pdesign kW 9.50 12.00 -
SEER 5.61 -
Annual energy
consumption kWh 593 749 -
Heating (Average
climate) Energy label A A+ -
Pdesign kW 7.60 -
SCOP 3.91 4.01 -
Annual energy
consumption kWh 2,721 2,653 -
Nominal efficiency
(cooling at 35°/27°
nominal load, heating
at 7°/20° nominal
load)
EER 3.21 2.89 3.01
COP 3.61 3.62 3.41
Annual energy consumption kWh 1,480 2,075 2,225
Energy label Cooling A C -
Heating A -
2-5 Nominal Capacity And Nominal Input FBQ100C8/RZQSG100L8Y1 FBQ125C8/RZQSG125L8Y1 FBQ140C8/RZQSG140LY1

• Outdoor Unit • RZQSG-L(8)Y1
2
• Split - Sky Air • RZQSG-L(8)Y1
6
2 Specifications
2-8 Technical Specifications RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1
Capacity control Method Inverter controlled
Casing Colour Ivory white
Material Painted galvanized steel plate
Dimensions Unit Height mm 990 1,430
Width mm 940
Depth mm 320
Packed unit Height mm 1,170 1,610
Width mm 1,015
Depth mm 422
Weight Unit kg 82 101
Packed unit kg 94 114
Heat exchanger Fin Type WF fin
Treatment Anti-corrosion treatment (PE)
Compressor Quantity 1
Type Hermetically sealed swing compressor
Starting method Inverter driven
Fan Type Propeller fan
Discharge direction Horizontal
Quantity 1 2
Air flow rate Cooling Nom. m³/min 76 77 83
Super
low m³/min -
cfm -
Heating Nom. m³/min 83 62
Super
low m³/min -
cfm -
Fan motor Quantity 1 2
Model Brushless DC motor
Output W 200 94
Drive Direct drive
Speed Cooling Super
low rpm -
Heating Super
low rpm -
Sound power level Cooling dBA 69 70 69
Heating dBA -
Sound pressure level Cooling Nom. dBA 53 54 53
Heating Nom. dBA 57 58 54
Night quiet mode Level 1 dBA 49
Operation range Cooling Ambien
tMin. °CDB -15
Max. °CDB 46
Heating Ambien
tMin. °CWB -15
Max. °CWB 15.5
Refrigerant Type R-410A
Charge kg 2.9 4.0
Control Expansion valve (electronic type)
GWP 1,975
Circuits Quantity 1
Refrigerant oil Type FVC50K
Charged volume l 0.9 1.35

3
2
• Split - Sky Air • RZQSG-L(8)Y1 7
• Outdoor Unit • RZQSG-L(8)Y1
2 Specifications
Notes
(1) PED: assembly = category l : excluded from scope of PED due to article 1, item 3.6 of 97/23/EC
(2) See separate drawing for electrical data
Piping connections Liquid Quantity 1
Type Flare connection
OD mm 9.52
Gas Quantity 1
Type Flare connection
OD mm 15.9
Drain Quantity 5
Type Hole
ID mm -
OD mm 26
Piping length OU - IU Min. m 5
Max. m 50
System Equival
ent m70
Chargel
ess m30
Additional refrigerant charge kg/m See installation manual
Level difference IU - OU Max. m 30
IU - IU Max. m 0.5
Heat insulation Both liquid and gas pipes
Defrost method Reversed cycle
Defrost control Sensor for outdoor heat exchanger temperature
Safety devices Item 01 High pressure switch
02 Fan driver overload protector
03 Fuse
2-9 Electrical Specifications RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1
Power supply Name Y1
Phase 3N~
Frequency Hz 50
Voltage V 380-415
Voltage range Min. % 10
Max. % 10
Current Zmax List Complies to EN61000-3-11
Recommended fuses A 20 25
Current - 50Hz Maximum fuse amps (MFA) A 20
Current - 60Hz Maximum fuse amps (MFA) A -
Wiring connections For power supply Remark See installation manual outdoor unit
For connectionwith
indoor Remark See installation manual outdoor unit
Power supply intake Outdoor unit only
2-8 Technical Specifications RZQSG100L8Y1 RZQSG125L8Y1 RZQSG140LY1

• Outdoor Unit • RZQSG-L(8)Y1
3
• Split - Sky Air • RZQSG-L(8)Y1
8
3 Electrical data
3 - 1 Electrical Data

3
3
• Split - Sky Air • RZQSG-L(8)Y1 9
• Outdoor Unit • RZQSG-L(8)Y1
3 Electrical data
3 - 1 Electrical Data

• Outdoor Unit • RZQSG-L(8)Y1
3
• Split - Sky Air • RZQSG-L(8)Y1
10
3 Electrical data
3 - 1 Electrical Data

3
4
• Split - Sky Air • RZQSG-L(8)Y1 11
• Outdoor Unit • RZQSG-L(8)Y1
4Options
4 - 1 Options

• Outdoor Unit • RZQSG-L(8)Y1
5
• Split - Sky Air • RZQSG-L(8)Y1
12
5 Combination table
5 - 1 Combination Table

3
6
• Split - Sky Air • RZQSG-L(8)Y1 13
• Outdoor Unit • RZQSG-L(8)Y1
6 Capacity tables
6 - 1 Cooling Capacity Tables

• Outdoor Unit • RZQSG-L(8)Y1
6
• Split - Sky Air • RZQSG-L(8)Y1
14
6 Capacity tables
6 - 1 Cooling Capacity Tables

3
6
• Split - Sky Air • RZQSG-L(8)Y1 15
• Outdoor Unit • RZQSG-L(8)Y1
6 Capacity tables
6 - 1 Cooling Capacity Tables

• Outdoor Unit • RZQSG-L(8)Y1
6
• Split - Sky Air • RZQSG-L(8)Y1
16
6 Capacity tables
6 - 2 Heating Capacity Tables

3
6
• Split - Sky Air • RZQSG-L(8)Y1 17
• Outdoor Unit • RZQSG-L(8)Y1
6 Capacity tables
6 - 2 Heating Capacity Tables

• Outdoor Unit • RZQSG-L(8)Y1
6
• Split - Sky Air • RZQSG-L(8)Y1
18
6 Capacity tables
6 - 2 Heating Capacity Tables
