INSTALLATION INSTRUCTIONS
LAT-NR350
LED Tail Lights for 1964-1966 Mustang
MAN#650204
Kit Includes:
Installation:
1. Remove both right and left tail light lenses as described below at the same time, taking care to
keep the left and right lenses and trim with the correct side of the vehicle.
2. Remove the four screws that hold the chrome tail light trim piece.
3. Remove the tail light trim piece and the lens.
4. Remove the light bulb from socket.
5. Loosen the lens seal from the housing by gently pulling the seal away from the housing.
6. Now is a good time to clean the lenses and the tail light housings. If the lenses are in poor
condition a replacement set is recommended.
7. Make sure the housings and lenses are clean and dry. DO NOT remove backing from tape yet!
Place the light diffuser onto the back of the lens. Check for proper fitment of diffuser to inside
of lens and note the places where the tape touches the lens.

MAN#650204
8. DO NOT remove the backing from the tape yet! Place the LED assembly in the housing. The
wide black bar on the wire side of the LED assembly is marked to show which end of the
assembly should be up. Note the places where the tape touches the housing.
9. Squeeze the primer tube to break the glass bulb and wet the brush end with primer. Rub the
primer on the lenses and the housings at the places where the tape will touch. Treat both left
and right housings and lenses at the same time before the primer tube dries out.
10.Wait for 5 minutes for the primer to dry and cure.
11.Remove the backing from the tape on the diffuser and place diffuser onto lens.
12.Insert the bulb base from the LED assembly into the bulb socket. Test the tail and brake lamps
to make sure they work as expected before going on.
13.Remove the backing from the tape on the LED assembly and insert assembly into the tail light
housing keeping the assembly centered in housing. Make sure the arrow is still pointing up.
Press firmly on the bracket to ensure good tape bonding.
14.Place lens gasket onto housing and reinstall the tail light lens and trim piece. Secure with the
trim piece screws.

MAN#650204
15.Test the tail lights, brake lights, and turn signals. If the turn signals do not flash you will need
to upgrade your flasher. If you are replacing only the rear turn signals you should be able to
use a heavy duty electronic flasher from your local parts store. If you are replacing both front
and rear or do not have front bulbs you will need a no-load flasher, Dakota Digital part number
LAT-NLF.
SERVICE AND REPAIR
DAKOTA DIGITAL offers complete service and repair of its product line. In addition, technical consultation is available to help you work through any questions or
problems you may be having installing one of our products. Please read through the Troubleshooting Guide. There, you will find the solution to most problems.
Should you ever need to send the unit back for repairs, please call our technical support line, [phone], to request a Return Merchandise Authorization
number. Package the product in a good quality box along with plenty of packing material. Ship the product by UPS or insured Parcel Post. Be sure to include the RMA
number on the package, and include a complete description of the problem with RMA number, your full name and address (street address preferred), and a telephone number
where you can be reached during the day. Any returns for warranty work must include a copy of the dated sales receipt from your place of purchase. Send no money. We will
bill you after repair.
