BIM-01-2-FTCH
Bridge Module for FiTech EFI Systems
This Bus Interface Module is designed to read engine information from the FiTech bus. The module is connected to the
FiTech Bus through the 394287 CAN bus-adapter.
There are two interface (I/O) ports on the BIM-01-2-FTCH module. Either one can be connected to the instrument system
or to another module, allowing several units to be daisy chained together.
The information that is available from the unit depends on the ECU programming and add-ons.
*FiTech will be releasing compatibility for AF/R and Boost in an upcoming firmware release. This BIM
unit is pre-programmed to be compatible with these readings once the firmware is released by FiTech*
A GPS-50-2 CANNOT be linked (daisy chained) to a BIM-01-2-FTCH with a BIM cable.
The two units cannot talk to the display control box at the same time.

[2] MAN #650819A
Table of Contents
VFD3 / VFD3X Setup
Page 2
VHX Setup
Page 4
HDX / RTX Setup
Page 5
GRAFIX Setup
Page 6
BIM Setup Menu
Page 7
Troubleshooting
Page 10
Notes
Page 11
Warranty
Page 12
Display Setup
VFD and VHX systems will add extra readings to the message displays under the tach.
HDX and RTX need a group screen configured to show additional information, such as Boost or Intake temp
GRAFIX systems will show extra readings if they are selected in the LAYOUTS>>GAUGES menu
Setting up the display system will configure the instrument control box to read each input from either the terminals or
through the BIM cable from the Bus Interface Module.
The BIM menu of the display will not find the BIM-01-2-FTCH, but will find specific channels for Boost and Air/Fuel Ratio.
The following settings are for the basic information to be displayed with data from the BIM module.
Extra data that might be sent such as Intake Air Temp, Air/Fuel Ratio or Boost, can be brought up in the message centers
of the VFD3 and VHX system by toggling SW2 in normal operation of the vehicle. Similar data that might be present will
not automatically be shown in the HDX and RTX systems. That extra information must be placed in a group screen of
your choice, in the HDX and RTX setup. GRAFIX systems may need gauge regions in the current layout adjusted
Display data usage
The following readings can each be used in place of dedicated sending units to the instrument system control box. These
are individually selectable in the display system instrument setup menus.
VFD3 / VFD3X Setup:
Entering the VFD3 setup is done by holding SW1 (I) and turning the ignition to “on”, or “acc”.
Once in setup, one can move between speed, tach, volt, water, etc…. by tapping SW1 (I)
If you are setting multiple items, once done with one section you will automatically move onto the next item.
Obtaining speed from the BIM-01-2-FTCH (N/A on TBI system)
•Hold the SW1 switch from the instrument system control box while turning the key on.
oThe speed display will show  and the message display will show SETUP.
•Release SW1. The displays should show and SPEED, respectively.
•Press and hold SW1 for at least 3 seconds, until  changes to “-”. The message display will show SENDER.
•Press and hold SW1 for at least 3 seconds, until  changes to “-”. The speed display will show the current
setting.
•Tap SW1 until  and BUS are displayed.
•Press and hold SW1 until  and DONE are displayed.
oNOTE: The AUTO, auto calibration, is removed.
oSpeed can only be fine-tuned with the ADJUST mode at a standstill.
oADJUST now only alters the percentage of speed by +/- 25%.
▪Drive a known speed and calculate how far off the speed is in percentage.
•GPS speed / displayed speed x 100
•Sample - [60/50=1.2] [1.2x100 = 120] 120%
▪Enter setup and go to ADJUST, tap SW1 to increment from 100% up to 125%.
▪After 125% the values will fall back to 75% and increment up again.
▪When the desired percentage is reached, hold SW1 until  changes to “-”.
•Tap SW1 until  and DONE are displayed.
•Press and hold SW1 until “-”and DONE are displayed.

[3] MAN #650819A
VFD3 Setup Continued:
Obtaining RPM from the BIM-01-2-FTCH
•Hold the SW1 switch from the instrument system control box while turning the key on.
oThe speed display should show  and the message display should show SETUP.
•Release SW1. Tap SW1 until  and TACH are displayed.
•Press and hold SW1 for at least 3 seconds, until  changes to “-”. The displays should show  and T CAL.
•Press and hold SW1 for at least 3 seconds, until  changes to “-”. The speed display will show the current
setting.
•Tap SW1 until and BUS are displayed.
•Press and hold SW1 until “-”and DONE are displayed.
•Tap SW1 until  and DONE are displayed.
•Press and hold SW1 until “-”and DONE are displayed.
Obtaining engine temperature from the BIM-01-2-FTCH
•Hold the SW1 switch from the instrument system control box while turning the key on.
oThe speed display should show  and the message display should show SETUP.
•Release SW1. Tap SW1 until  and WATER are displayed.
•Press and hold SW1 for at least 3 seconds, until  changes to “-”. The displays should show  and SENDER.
•Press and hold SW1 for at least 3 seconds, until  changes to “-”. The speed display will show the current
setting.
•Tap SW1 until  and BUS F (Fahrenheit) is displayed.
oTap SW1 once more for  and BUS C (Celsius) if desired.
•Press and hold SW1 until “-”and DONE are displayed.
•Tap SW1 until  and DONE are displayed.
•Press and hold SW1 until “-”and DONE are displayed.
***Intake/manifold air temp, air fuel ratio, trans fluid temp, and boost will be displayed in the message center if activated through the display menu setup.

[4] MAN #650819A
VHX Setup:
Entering the VHX setup is done by holding SW1 (I) and turning the ignition to “on”, or “acc”.
Once in setup, one can move between speed,tach,volt,water, etc…. by tapping SW1 (I)
If you are setting multiple items, once done with one section you will automatically move onto the next item.
Obtaining speed from the BIM-01-2-FTCH (N/A on TBI system)
•Hold the SW1 (I) switch from the instrument system control box while turning the key on.
oThe message display should show SETUP.
•Release SW1 (I) - LCD1 should show SETUP SPEED.
•Press and hold SW1 (I) for at least 3 seconds until SPEED SENDER is displayed.
•Press and hold SW1 (I) for at least 3 seconds until SENDER is displayed.
•Release the switch and SENDER NORMAL will be displayed.
•Tap SW1 (I) until SENDER BUS is displayed.
•Press and hold SW1 (I) until DONE is displayed.
oNOTE: The AUTO, auto calibration, is removed.
oSpeed can only be fine-tuned with the ADJUST mode at a standstill.
oADJUST now only alters the percentage of speed by +/- 25%.
▪Drive a known speed and calculate how far off the speed is in percentage.
•GPS speed / displayed speed x 100
•Sample - [60/50=1.2] [1.2x100 = 120] 120%
▪Enter setup and go to ADJUST, tap SW1 (I) to increment from 100% up to 125%.
▪After 125% the values will fall back to 75% and increment up again.
▪When the desired percentage is reached, hold SW1 (I) until DONE is displayed
•Tap SW1 (I) until SPEED DONE is displayed.
•Press and hold SW1 (I) until a big DONE is displayed.
Obtaining RPM from the BIM-01-2-FTCH
•Hold the SW1 (I) switch from the instrument system control box while turning the key on.
oThe message display should show SETUP.
•Release SW1 (I) - LCD1 should show SETUP SPEED.
•Tap SW1 (I) until SETUP TACH is displayed.
•Press and hold SW1 (I) for at least 3 seconds until TACH ENGINE is displayed.
•Press and hold SW1 (I) for at least 3 seconds until ENGINE is displayed.
•Release the switch and ENGINE 8 will be displayed.
•Tap SW1 (I) until ENGINE BUS is displayed.
•Press and hold SW1 (I) until DONE is displayed.
•Tap SW1 (I) until TACH DONE is displayed.
•Press and hold SW1 (I) until a big DONE is displayed.
Obtaining engine temperature from the BIM-01-2-FTCH
•Hold the SW1 (I) switch from the instrument system control box while turning the key on.
oThe message display should show SETUP.
•Release SW1 (I) - LCD1 should show SETUP SPEED.
•Tap SW1 (I) until SETUP WATER is displayed.
•Press and hold SW1 (I) for at least 3 seconds until WATER SENDER is displayed.
•Press and hold SW1 (I) for at least 3 seconds until SENDER DD F is displayed.
•Release the switch and SENDER DD F will be displayed.
•Tap SW1 (I) until SENDER BUS F (Fahrenheit) is displayed.
oTap SW1 (I) once more for SENDER BUS C (Celsius) if desired.
•Press and hold SW1 until DONE is displayed.
•Tap SW1 (I) until WATER DONE is displayed.
•Press and hold SW1 (I) until a big DONE is displayed.
***Intake/manifold air temp, air fuel ratio, trans fluid temp, and boost will be displayed in the message center if activated through the display menu setup.

[5] MAN #650819A
HDX and RTX setup:
**HDX/RTX systems can be configured with the Dakota Digital app for Apple and Android devices**
HDX and RTX Operations
•HDX: With the ignition key already on, press and hold both switches to enter SETUP, release when instructed.
oIf using the external rocker switch, hold SW2 (II) while turning the ignition on.
oRelease the switch when SETUP is shown.
oLeft switch on display is SW1, and right switch on display is SW2
•RTX: With the ignition off, press hold SW2 (II) while turning the ignition key on to enter SETUP
oRelease the switch when SETUP is shown.
•BOTH: When holding for an option, release the button when the screen says “RELEASE”
•BOTH: You may skip to whichever reading you’d like to configure below; they do not need to be done in order.
•BOTH: After making a selection, tap a switch and select BACK to save and return to the main menu, then select
EXIT SETUP to return to normal operation.
•BOTH: SWI (left) moves up ↑the menu list, SWII (right) moves down ↓the menu list
Obtaining speed from the BIM-01-2-FTCH (N/A on TBI system)
•Tap SWII (right) switch until SPEED is selected. Press and hold SWII (right) switch to enter SPEED menu.
•Tap SWII (right) switch until INPUT is displayed. Press and hold SWII (right) switch to enter INPUT menu.
•SIGNAL will be displayed. Press and hold SWII (right) switch to enter SIGNAL menu.
•Tap right switch until BIM is displayed. Press and hold SWII (right) switch to select BIM.
•When SIGNAL is displayed again, tap switch until BACK is displayed, then hold to return to INPUT.
•When INPUT is displayed again, tap switch until BACK is displayed, then hold the switch to exit.
oNOTE: The AUTO CAL, auto calibration, is not accessible.
oADJUST now only alters the percentage of speed by +/- 25%.
▪After the engine is running, enter setup and go to ADJUST.
▪While driving a known speed, SWI and SWII (left/right) can adjust speed.
•Percentage can also be adjusted without driving.
▪Tap SWII (right) to increment up to 125%.
▪Tap SW1 (left) to decrement down to 75%.
▪The speed will be displayed in the LCD along with the percent chosen.
▪Once the speed is correct, hold either switch until RELEASE is displayed.
▪You may now continue to exit the setup menu.
oThe Dakota Digital Automotive app can also be used either while driving or not driving.
Obtaining RPM from the BIM-01-2-FTCH
•Tap SWII (right) switch until TACH is selected. Press and hold SWII (right) switch to enter TACH menu.
•Tap SWII (right) switch until INPUT is displayed. Press and hold SWII (right) switch to enter INPUT menu.
•Tap SWII (right) switch until CYLINDER is displayed. Press and hold SWII (right) switch to select CYLINDER.
•Tap SWI (left) switch until BIM is displayed. Press and hold SWII (right) switch to select BIM.
•When INPUT is displayed again, tap until BACK is displayed, then hold the switch to exit.
Obtaining engine temperature from the BIM-01-2-FTCH
•Tap SWII (right) switch until WATER is selected. Press and hold SWII (right) switch to enter WATER menu.
•Tap SWII (right) switch until INPUT is displayed. Press and hold SWII (right) switch to enter INPUT menu.
•Tap SWII (right) switch until BIM is displayed. Press and hold SWII (right) switch to select BIM.
•When INPUT is displayed again, tap until BACK is displayed, then hold the switch to exit.
HDX/RTX TIP: Intake/manifold air temp, air fuel ratio, trans fluid temp, and boost will be displayed in the group screens if
activated through the displays>>group set menu setup.

[6] MAN #650819A
GRAFIX setup:
**GRAFIX systems can be configured with the Dakota Digital app for Apple and Android devices**
GRAFIX Operations
•With the vehicle stopped, tap the Control Knob to enter the Main Menu
oThe Main menu can be entered with the vehicle moving, but only the speedometer ADJUST menu will be
available in the SETUP menu
•Twist the Control Knob clockwise until SETUP is highlighted. Tap the knob to enter the SETUP menu.
•You may skip to whichever reading you’d like to configure below; they do not need to be done in order.
•After making a selection, select BACK to save and return to the main menu, then select EXIT to return to normal
operation.
•Twisting the Control Knob clockwise moves up ↑the menu list, twisting counterclockwise moves down ↓the menu
list.
Obtaining speed from the BIM-01-2-FTCH (N/A on TBI system)
•Twist the Control Knob clockwise until SPEED is highlighted. Tap the knob to enter SPEED menu.
•Twist the Control Knob clockwise until INPUT is highlighted. Tap the knob to enter INPUT menu.
•SIGNAL will be displayed. Tap the Control Knob to enter SIGNAL menu.
•Twist the Control Knob clockwise until BIM is highlighted. Tap the knob to select BIM.
•When SIGNAL is displayed again, twist the Control Knob until BACK is displayed, then tap to return to INPUT.
•When INPUT is displayed again, twist the Control Knob until BACK is displayed, then tap to return to SPEED.
•When SPEED is displayed again, twist the Control Knob until BACK is displayed, then tap to return to SETUP.
•When SETUP is displayed again, twist the Control Knob until BACK is displayed, then tap to exit.
oNOTE: The AUTO CAL, auto calibration, is not accessible.
oTo adjust speed, enter SETUP, enter SPEED, then enter the ADJUST menu.
▪While driving a known speed, twisting the Control knob clockwise/counterclockwise can adjust
speed.
•Percentage can also be adjusted without driving.
▪Twist the Control Knob clockwise to increment up to 125%.
▪Twist the Control Knob counterclockwise to decrement down to 75%.
▪Once the speed is correct, twist the Control Knob until BACK is displayed, then tap the knob.
▪You may now continue to exit the setup menu.
oThe Dakota Digital Automotive app can also be used either while driving or not driving.
Obtaining RPM from the BIM-01-2-FTCH
•Twist the Control Knob clockwise until TACH is highlighted. Tap the knob to enter TACH menu.
•INPUT will be displayed. Tap the Control Knob to enter INPUT menu.
•CYLINDER will be displayed. Tap the Control Knob to enter CYLINDER menu.
•Twist the Control Knob counterclockwise until BIM is highlighted. Tap the knob to select BIM.
•When INPUT is displayed again, twist the Control Knob until BACK is displayed, then tap to return to TACH.
•When TACH is displayed again, twist the Control Knob until BACK is displayed, then tap to return to SETUP.
•When SETUP is displayed again, twist the Control Knob until BACK is displayed, then tap to exit.
Obtaining engine temperature from the BIM-01-2-FTCH
•Twist the Control Knob clockwise until WATER is highlighted. Tap the knob to enter WATER menu.
•INPUT will be displayed. Tap the Control Knob to enter INPUT menu.
•Twist the Control Knob counterclockwise until BIM is highlighted. Tap the knob to select BIM.
•When INPUT is displayed again, twist the Control Knob until BACK is displayed, then tap to return to WATER.
•When WATER is displayed again, twist the Control Knob until BACK is displayed, then tap to return to SETUP.
•When SETUP is displayed again, twist the Control Knob until BACK is displayed, then tap to exit.
TIP: Intake/manifold air temp, air fuel ratio, trans fluid temp, and boost will be displayed if selected in the
LAYOUTS>>GAUGES menu

[7] MAN #650819A
BIM setup:
BIM menu table:
Menu
Options
Default
Notes




Enable air fuel ratio reading












Enable boost reading












Check engine light sent by ECU








View the current BIM ID numbers




Automatically set bus ID numbers








Enable gear position reading








Exit Setup
Enable CAN Outputs using the FiTech handheld
(Required for operation, and if the vehicle battery is disconnected or the FiTech ECU firmware is updated)
•Connect the FiTech handheld to the ECU using the provided CAN-bus adapter harness.
•Enter the “FiTech Initial Setup”menu:
o
•Enter the “CAN OUTPUT”menu:
o
•For each CAN output, change the “val”field to On, then press the “Send to ECU”button to turn the output on.
o
oNOTE: The “Send to ECU”button will only enable the currently highlighted CAN output. This step must
be repeated for every CAN output that you wish to enable.
oIf the CAN output for a respective reading is not enabled, the BIM-01-2-FTCH will not receive these
readings from the FiTech bus.

[8] MAN #650819A
Enabling Air Fuel Ratio: (FiTech will be releasing compatibility for this reading in an upcoming Firmware release)
The BIM-01-2-FTCH has an option to monitor Air Fuel Ratio.
•Hold the switch on the BIM-01-2-FTCH case while turning the key on. The BIM display will show the current
revision code while this is held.
•Release the switch.
•Tap the switch until the display shows  (Air Fuel). Press and hold to enter this menu.
•When you see  on the display release the switch.
•The display will show the current Air Fuel state,  (disable) or  (enable).
•Tap the switch to change the state.
•To save the setting press and hold the switch until you see  on the display, then release the switch.
•The display will display the next available menu. Press and hold the switch to enter that menu or tap the switch to
select another menu.
•To exit, tap the switch until the display shows  then press and hold the switch until you see  on the display.
Enabling Boost: (FiTech will be releasing compatibility for this reading in an upcoming Firmware release)
The BIM-01-2-FTCH has an option to enable boost readings if the car has a turbocharger.
•Hold the switch on the BIM-01-2-FTCH case while turning the key on. The BIM display will show the current
revision code while this is held.
•Release the switch.
•Tap the switch until the display shows  (boost). Press and hold to enter this menu.
•When you see  on the display release the switch.
•The display will show the current boost state,  (disable) or  (enable).
•Tap the switch to change the state.
•To save the setting press and hold the switch until you see  on the display, then release the switch.
•The display will display the next available menu. Press and hold the switch to enter that menu or tap the switch to
select another menu.
•To exit, tap the switch until the display shows  then press and hold the switch until you see  on the display.
Enable or disable engine indicator status from the BIM-01-2-FTCH (Future FiTech Firmware release)
•Hold the switch on the BIM-01-2-FTCH case while turning the key on. The BIM display will show the current
revision code while this is held.
•Release the switch.
•Tap the switch until the display shows (engine). Press and hold to enter this menu.
•When you see  on the display release the switch.
•The display will show the current state or the engine indicator enable  (enable) or  (disable).
•Tap the switch to change the state.
•To save the setting press and hold the switch until you see  on the display then release the switch.
•The display will display the next available menu. Press and hold the switch to enter that menu or tap the switch to
select another menu.
•To exit, tap the switch until the display shows  then press and hold the switch until you see  on the display.
To view the current BIM ID numbers:
•Hold the switch on the BIM-01-2-FTCH case while turning the key on. The BIM display will show the current
revision code while this is held.
•Tap the switch until the display shows  (LIN channels).
•Press and hold to enter this menu. When you see  on the display, release the switch.
•The display will show followed by the current ID of the boost option (for example: ). Tapping the switch will
cycle through the options, displaying the currently assigned IDs to the boost option. If the option is disabled, the
display will show .
•To exit this menu, tap the switch until  is displayed. Then press and hold the switch until  is displayed.
•The display will show the next available menu. Press and hold the switch to enter that menu or tap the switch to
select another menu.
•To exit, tap the switch until the display shows  then press and hold the switch until you see  on the display.

[9] MAN #650819A
To automatically set bus ID numbers:
•Hold the switch on the BIM-01-2-FTCH case while turning the key on. The BIM display will show the current
revision code while this is held.
•Press and release the switch until the display shows  (auto channel).
•Press and hold to enter this menu. When you see  on the display, release the switch.
•The display will display , , then as the BIM automatically determines the best ID to assign for the boost
option (if enabled).
•The display will show . Press and hold the switch to exit setup or press and release to choose another menu
option.
Enabling Gear Position:
•Hold the switch on the BIM-01-2-FTCH case while turning the key on. The BIM display will show the current
revision code while this is held.
•Press and release the switch until the display shows  (gear position).
•Press and hold to enter this menu. When you see  on the display, release the switch.
•The display will show the current gear position state,  (disable) or  (enable).
•Tap the switch to change the state.
•To save the setting press and hold the switch until you see  on the display, then release the switch.
•The display will display the next available menu. Press and hold the switch to enter that menu or tap the switch to
select another menu.
•To exit, tap the switch until the display shows  then press and hold the switch until you see  on the display.
Quick tips:
While the BIM is operating, the dot in the upper left corner of the display will indicate the status:
•On steady indicates it is powered up but not receiving any BIM bus activity.
•Flashing indicates it is communicating on the BIM bus.
•A dot in the upper center indicates that there is an engine code set (MIL active).
•If the display shows “BUS”, then it is scanning to try and communicate with the vehicle bus but cannot get an
answer.
oThis could indicate that the FiTech CAN outputs have not been enabled (pg. 7), or that the BIM-01-2-
FTCH is not compatible with this ECU.
To see the sensor and channel status on the BIM display, press and hold the switch to cycle through the screens.
The first screen will show the bus type ( - FiTech), and the following screens will display the data that is available:
“” –Engine Coolant Temp
“” - Intake Air Temp
“”- Gear Position
“”- Boost/Vacuum data
“”- RPM/Tachometer data
If you do not see any number of these listed, the data may not be transmitted for the BIM-01-2-FTCH to read.
Emissions note:
If your vehicle requires emissions testing in your area, the check engine feature of this unit cannot be used to operate the
Check Engine or Service Engine indicator.

[10] MAN #650819A
Troubleshooting guide:
Problem
Possible cause
Solution
No BIM data on instrument readout;
BIM does not light up.
PWR wire does not have power.
GND wire is not properly grounded.
Power/data harness is damaged.
Module is damaged.
Connect to a location that has +12V key-on power.
Connect to a different ground location.
Inspect harness. Repair or replace any damaged
areas.
Return for service. (see instructions)
No BIM data on instrument readout;
BIM display is scanning “BUS”
CAN Interface cable is not connected
FiTech CAN outputs are not enabled
Connect the supplied CAN interface cable between
the BIM unit and the ECU’s CAN output.
Enable CAN outputs using the FiTech handheld
(see pg. 7)
No BIM data on instrument readout;
BIM has a steady dot lit.
Interface cable is not connected.
Interface cable is loose.
On VHX systems, the BIM display for
this channel is disabled.
Connect the supplied harness between the BIM
unit and the instrument system control box.
Ensure both ends of the cable are seated securely.
Follow instructions in VHX manual to enable the
BIM display screen.
BIM display shows “:”
Data cable is damaged or connected
improperly.
Another module on the bus is damaged.
Inspect and replace harness or power/data
harness.
Inspect other modules on the data bus.

[11] MAN #650819A
Notes:

[12] MAN #650819A
SERVICE AND REPAIR
DAKOTA DIGITAL offers complete service and repair of its product line. In addition, technical support is
available to help you work through any questions or problems you may be having installing one of our
products. Please read through the Troubleshooting Guide. There, you will find the solution to most problems.
For additional support, please visit www.dakotadigital.com. A “Product Support” link will be found at the
bottom of the home page.
Should you ever need to send the unit back for repairs, please call our technical support line,
[phone], to request a Return Merchandise Authorization number.
•Package the product in a good quality box along with plenty of packing material.
•Ship the product by a common carrier with tracking abilities.
•Be sure to include the RMA number on the package.
•Include a complete description of the problem, with RMA number, your full name and address (street
address preferred), and a telephone number where you can be reached during the day.
•Any returns for warranty work must include a copy of the dated sales receipt from your place of
purchase.
•Send no money. We will contact you for payment.
Dakota Digital Limited Lifetime Warranty
DAKOTA DIGITAL warrants to the ORIGINAL PURCHASER of this product that should it, under normal use and
condition, be proven defective in material or workmanship for the lifetime of the original vehicle it was installed in, such
defect(s) will be repaired or replaced at Dakota Digital’s option.
This warranty does not cover nor extend to damage to the vehicle’s systems, and does not cover diagnosis, removal or
reinstallation of the product.
This Warranty does not apply to any product or part thereof which in the opinion of the Company has been damaged
through alteration, improper installation, mishandling, misuse, neglect, or accident.
Dakota Digital assumes no responsibility for loss of time, vehicle use, owner inconvenience nor related expenses.
Dakota Digital will cover the return standard freight once the product has been evaluated for warranty consideration,
however the incoming transportation is to be covered by the owner.
This Warranty is in lieu of all other expressed warranties or liabilities. Any implied warranties, including any implied
warranty of merchantability, shall be limited to the duration of this written warranty. No person or representative is
authorized to assume, for Dakota Digital, any liability other than expressed herein in connection with the sale of this
product.
WARNING: This product can expose you to chemicals including lead, which is known to the
State of California to cause cancer and birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
