Dakota OverView DMOV-7MQ-C2 User manual

TROUBLESHOOTING
Problem
Possible Causes
No picture, no sound
Improper connection with 12v power adapter. Use of
unauthorized power supply. Power Switch is on OFF
position
No picture
Check whether AV cable is securely plugged in
No sound
Check whether audio connector is secure, or the sound
volume is turned off or down
Dark picture
Ensure that bright and contrast settings are properly
adjusted. Ensure monitor is warm enough
No color
Ensure color settings are properly adjusted in menu
Upside down or lateral
inverted picture
Check horizontal/vertical adjustment on remote.
No car-backing function
(i.e. Picture)
Event trigger is not securely connected
Remote Controller Fault
Battery may be dead or improperly installed:
replacement battery Model:CR2025,3V
Remote controller is not pointed in the direction of the
receiving sensor: Make sure remote is pointed at the
monitor
Long distance or improper angle: The effective distance
between the remote controller and the receiving sensor
is 7 meters and the angle is ±30°.
Obstacle: Move any obstacles out of the path
www.dakotamicro.com
Dakota Micro, Inc.
8659 148th Ave. SE
Cayuga, ND 58013
www.dakotamicro.com
Quad View Monitoring System
User Guide
Part Numbers: DMOV-7MQ-C2

110
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
NOTES
FEATURES
There are no reparable parts in the system, so please do not attempt to
take apart the camera or the monitor should a malfunction occur, doing so will
void your warranty. Call the factory at 1 866 462-4226 for repair issues.
WARNING
7” LED Backlit, high resolution TFT LCD screen capable of displaying 4 cameras
Wide voltage input: 11-32V
4 Channel Inputs, displays 4 images simultaneously
Manual or automatic image switching modes
Forward/Mirror image selection
Event Triggers provided for all 4 cameras. Cameras can be triggered for events such
as backing up or door opening
Power provided to only active camera, prolonging the life of the cameras.
AV input and output jacks provided
Auto ON/OFF LED sensor automatically triggers night vision when required
Includes credit card style remote control
Backlit control buttons enable easy menu navigation in all lighting conditions
Please read entire manual before using our products
Before you power your rear view monitoring system, ensure that all cables are
properly connected to avoid damage to the system
Monitor IS NOT WATERPROOF, please do not place the monitor outdoors
Ensure that all cables are routed a sufficient distance from high temperature areas
and rotary objects
To ensure proper heat dispersal, ensure that vent holes in monitor remain clear
Do not open the monitor or camera casing, doing so will void the warranty
DO NOT watch DVD’s etc. while driving
Please do not use caustic chemicals to wipe the camera and/or monitor
Consumer Limited Warranty (North America ONLY)
Dakota Micro, Inc. (Hereinafter referred to as DM) warrants to the
first consumer purchaser that this DM brand product will be free from
defective workmanship and materials, and agrees that it will, at its
option, either repair the defect or replace the defective product or
part thereof with a new or remanufactured equivalent at no charge to
the purchaser for parts or labor for the period of 18 (eighteen)
months.
Warranty extends throughout North America (US & Canada). 1 year
warranty applies to all other geographic locations unless otherwise
states in writing by DM.
This warranty does not apply to any appearance items of the product
nor any part of the exterior of the product which has been damaged
or defaced, which has been subjected to improper voltage or other
misuse, abnormal service or handling, or which has been altered or
modified in design or construction.
Neither the sales personnel of the seller, nor any other person is
authorized to make any warranties other than those described
herein, or to extend the duration of any warranties beyond the time
period described herein on behalf of DM.
The warranties described herein shall be the sole and exclusive
warranties granted by DM and shall be the sole and exclusive
remedy available to the purchaser. Correction of defects, in the
manner and for the period of time described herein, shall constitute
complete fulfillment of all liabilities and responsibilities of DM to the
purchaser with respect to the product. DM shall not be liable or in
any way responsible for any incidental or consequential economic or
property damage. Some states do not allow the exclusion of
incidental or consequential damages, so that above exclusion may
not apply to you.
Any action at law, suit in equity, or other judicial proceeding for the
enforcement of any warranty provided for herein or otherwise, will be
instituted only in the Courts of the State of North Dakota, the laws of
which shall govern.
This warranty gives you specific legal rights and you may also have
other rights, which may vary from state to state.

2
I. Monitor Introduction
Monitor
II. Specifications
Included Components
CDS
Sensor for controlling the button
backlights. DO NOT BLOCK
Sun Visor
A/V output
Earphone
Bracket
MENU
Remote Receiver
Vol-
Vol+
Menu
Down
Up/CAM Selection
Quad View Mode Switch ON/OFF
LED Backlit
LCD Screen
Monitor
LED backlit, Digital Screen TFT LCD Color
Size
7 Inch
Connector
Digital TTL
Resolution
800(RGB)
×
480
No. Camera Inputs
4
Visible
Angle (LR/UD)
140 / 110
Contrast
500:1
Volume (nits)
300
Response Time (ms)
25
Color System
PAL/NTSC (AUTO)
Support Four Camera Inputs
1.0Vp-p75Ω
Audio
Output
（
W
）≤
1W
Loudspeaker
φ
4
.
0cm,16Ω/1W
Connector
DVI24+1
Power Source
DC11-32V Free Power Input
Consumption
MIN 8W, MAX 20W (four cameras
ON)
External dimensions(mm)
185 X W 124 X T48 (without mounting)
Weight
400g
9
Monitor remote control Power/Video harness
Monitor w/ bracket
Connection Chart
MENU
(Yellow)Video Output
(Red) Audio Output
(Yellow*)Trigger Cable for DVR
(Green*)Trigger Cable for CAMF
(Blue*)Trigger Cable for CAMR
(White*)Trigger Cable for CAML
(Brown*)Trigger Cable for CAMB
DVI24+1Plug
connector with
screws
CAM F (Black)
CAM B (Yellow)
CAM L (White)
CAM R (Red)
12v power
FUSE
12v lighter adaptor
x2 20M power/video cables
x2 Camera(s) w/ bracket
1) Cameras 1-4 have an available event trigger wire. Cameras are identified as F (front), B (Back),
L (Left) and R (Right)
2) Regardless if monitor is ON or in Standby mode, if power is applied to the trigger, activated camera
will become powered
3) Camera F has highest priority, camera R the lowest. Example: if both camera F and B are triggered
simultaneously, camera F will take precedence.
4) Peripheral DVR trigger cable
1. When the monitor is in quad view or front and back view, the cable has a DC12V output.
2. When the back trigger cable makes the monitor activated, the peripheral DVR trigger
cable has a DC12V output
* Event Trigger wire colors are subject to change without notice and may vary slightly from
colors indicated above.

Camera Specifications
Mounting Bracket
Top
Bracket Screws
Bracket Screws
Mounting Bracket
Base
OverView
Camera
3
V. Installation of Monitor Bracket
Install DVI24+1Plug
Plug in securely and tighten screws
Screw
Screw
III. Installation of DVI24+1 Plug
MENU
MENU
Bottom Clip-buckle
Top Clip-buckle
MENU
MENU
Bottom Clip-buckle
Top Clip-buckle
Push
Pull
Installation
Remove
Sunshade
Monitor
Monitor with
sunshade
press
press
Pull
monitor
sunshade
Push
Push
monitor with
sunshade
Complete
IV. Install/Remove Sun Visor
8
Monitor
MENU
Camera
Image pick-up Device
TV System
Lens Mount
Horizontal Resolution
Sync System
Number of Pixels
Usable Illumination
Operation Temp
Power Supply
Weight
Environmental
1/3" Sharp Color CCD
NTSC/PAL (depending upon model)
420 TV lines
Internal Synchronization
NTSC 510(H) x 492(V) PAL 500(H) x 562(V)
0 Lux at Night (IR LED ON)
CDS Auto Control Under 10 Lux by CDS
-20 C - +50C
DC 12v +/-10%
Weight 450g
Watertight

Remote Control
III. Button Function
MUTE
Press Mute to turn sound off，to resume volume, press Mute again or press VOL+
POWER
For ON/OFF
Up/CAM
a.Toselect menu option
b.To switch images in the mode of one camera view in order: B→L→R→F
VOL-/+
a. Adjust volume of monitor.
b .Adjustbrightness,contrast,etc.
c. Activate other functions, such as: mirror/normal image switch, delay time
adjustment, etc.
MENU
Menu Display.
MODE:
User can use this key to select four modes: standard color,soft color, richcolor
and bright.
CALL
Press this button is to display currently displayed AV channel
SLEEP
Time setup of sleep off, it is used to set the time off within 120 minutes.
Language
Language selection of Chinese or English,
Quad View Switch
Turnmonitor on，pressQuad View Mode Switch key, the quad view will be
changed in the order displayed below:
4
Monitor
VI. Monitor Operation:
BRIGHTNESS
CONTRAST
SATURATION
HUE
SELECT ADJUST
50
50
50
50
50
MENU
Vol+
Vol-Menu
Down
Up/CAM
Selection
Quad View Mode Switch
ON/Standby
1. Press ON\Standby to turn monitor ON/OFF.
2. Quad View Mode Switch: Turn monitor on and press "Quad View Mode Switch key", the quad
view will be changed as below one by one:
3.Up/CAM Selection:
a. After pressing the Menu key, press the Up/CAM Selection to select menu and set up;
b. To switch the images in single camera mode in the following order B→L→R→F
4. Down: Toselect menu and set up.
5. Menu：Menu display.
6. VOL-/+:
a. Adjust volume of monitor.
b. Adjust brightness, contrast, etc.
c. Activateother functions such as: mirror/normal image switch, delay time adjustment, etc.
7. Monitor Menu Instruction
Press Menu key do display as following: PICTURE, MIRROR, TRIGDELAY, SYSTEM
a. PICTURE
Press Up/Down to select brightness, press Vol+/-to set up the value between 0 and 100.
Press Up/Down toselect CONTRAST/SATURATION/HUE. pressVol+/- tosetthe value.
Press this button to flip the picture horizontally.
Press this button to flip the picture vertically.
7
FB
FB
R
L
F
B
LR
LR
FB
FB
R
L
F
B
LR
LRF
B
L

5
Monitor
Press Up/Down to select Language, press Vol+/- to select Chinese/English.
SYSTEM
LANGUAGE ENGLISH
SELECT ADJUST
7
Remote Control
I. Introduction
II. Replace Battery
Pull Press
Model of Battery:
(CR2025)
Mute
Up\CAM Selection
Volume-
Mode
Language
Horizontal Flip
Vertical Flip
Calendar
Quad View Mode Switch
Volume+
6
b. Normal/Mirror Image
Monitor displays Camera function as listed below:
SELECT ADJUST
CAM B
CAM L
CAM R
CAM F
NORMAL
MIRROR
MIRROR
MIRROR
MIRROR
CAM B
CAM L
CAM R
CAM F
c. TRIGDELAY
Monitor displays camera function as listed below:
SELECT ADJUST
TRIG DELAY
Press Up/Down to select CAMB / CAML / CAMR / CAMF
press Vol+/-to set up Normal/Mirror image of CAMB / CAML / CAMR / CAMF
Press Up/Down to select CAMB / CAML / CAMR / CAMF
press Vol+/-to set up TRIGDELAY (0-10 seconds) of CAMB / CAML / CAMR / CAMF.
d. Language
ON/Standby
Menu
Down
Call
Sleep
0S
0S
0S
0S
