dallmeier DMS 80 Quick guide

English
Rev. 5.0.1 / 2010-06-22
Configuration and Data
Hybrid audio and video recorder
DMS 80
DMS 160
DMS 240
DMS 240 HSR

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 2
Information about copyright, trademarks, design patents
© 2010 Dallmeier electronic
The reproduction, distribution and utilization of this document as well as the communication of
its contents to others without express authorization is prohibited. Offenders will be held liable for
the payment of damages. All rights reserved in the event of the grant of a patent, utility model or
design.
We reserve the right to make technical modications.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due
to minor defects of the product or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
93051 Regensburg, Germany
www.dallmeier.com
[e-mail]
All trademarks identied by ® are registered trademarks of Dallmeier electronic.
All trademarks identied by *) are trademarks or registered trademarks of the following owners:
Adobe and Flash of Adobe Systems Incorporated headquartered in San José, California, USA
Sony, EXview HAD and Super HAD of Sony Corporation headquartered in Tokyo, Japan
Third-party trademarks are named for information purposes only.
Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identication of third-party
trademarks and indication of the respective holder of rights. In case that protected rights are not indicated separately, this circumstance is
no reason to assume that the respective trademark is unprotected.

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 3
Table of contens
1 This document ..............................................................................................8
1.1 Validity .............................................................................................................8
1.2 Documents ......................................................................................................8
1.2 Conventions ....................................................................................................8
2 Safety instructions......................................................................................10
3 General instructions ...................................................................................12
3.1 Scope of delivery ..........................................................................................12
3.2 Transportation and packaging ......................................................................12
3.3 Warranty ......................................................................................................12
4 Start and Login............................................................................................13
5 Basic settings..............................................................................................15
5.1 Language ......................................................................................................15
5.2 System time ..................................................................................................15
5.2.1 Setting ...........................................................................................................16
5.2.2 Time server ...................................................................................................16
5.2.3 Radio clock ...................................................................................................16
5.3 System security.............................................................................................17
5.4 Options..........................................................................................................17
5.4.1 Alarm duration...............................................................................................18
5.4.2 Test modes....................................................................................................18
5.4.2.1 Compare .......................................................................................................19
5.4.2.2 Performance .................................................................................................20
5.4.2.3 Tracking ........................................................................................................20
5.4.3 Keyboard mode.............................................................................................21
5.4.4 Single split replay ..........................................................................................21
5.4.5 Playback monitor ..........................................................................................22
5.4.6 System messages.........................................................................................23
5.4.7 Assistant mode .............................................................................................24
5.4.8 Recording timeout .........................................................................................24
5.4.8.1 Max. recording pause ...................................................................................25
5.4.8.2 Min. Storage period.......................................................................................25
5.4.9 OSD texts......................................................................................................26
5.4.10 Logging .........................................................................................................28
5.4.11 Recording monitor.........................................................................................29
5.4.12 Simple Export................................................................................................29
5.4.13 Audio deactivation.........................................................................................30
6 Recording setting .......................................................................................31
6.1 Track mode ...................................................................................................31
6.1.1 Standard .......................................................................................................32
6.1.1.1 Recording......................................................................................................32
6.1.1.2 Modications .................................................................................................32
6.1.1.3 Track types ...................................................................................................32
6.1.1.4 Recording modes ..........................................................................................33
6.1.2 Manual ..........................................................................................................33
6.1.2.1 Recording......................................................................................................33

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 4
6.1.2.2 Modications .................................................................................................34
6.1.2.3 Track types ...................................................................................................34
6.1.2.4 Recording modes ..........................................................................................34
6.1.3 Automatic ......................................................................................................34
6.1.3.1 Recording......................................................................................................35
6.1.3.2 Modications .................................................................................................35
6.1.3.3 Track types ...................................................................................................35
6.1.3.4 Recording modes ..........................................................................................35
6.1.4 Change .........................................................................................................36
6.2 Connection ....................................................................................................37
6.2.1 Analogue cameras ........................................................................................37
6.2.2 IP cameras ....................................................................................................37
6.2.2.1 Dallmeier IP and HD cameras ......................................................................37
6.2.2.2 Other IP cameras ..........................................................................................38
6.3 Basic conguration........................................................................................39
6.3.1 Camera and track name ...............................................................................39
6.3.2 Camera timer ................................................................................................40
6.3.3 Tracks timer ..................................................................................................42
6.3.4 Areas.............................................................................................................42
6.3.4.1 Active areas ..................................................................................................42
6.3.4.2 Private Zones ................................................................................................43
6.4 Recording mode............................................................................................45
6.4.1 Manual and automatic mode.........................................................................45
6.4.1.1 Permanent ....................................................................................................46
6.4.1.2 Motion ...........................................................................................................47
6.4.1.3 Contact..........................................................................................................48
6.4.1.4 Switching by motion ......................................................................................49
6.4.1.5 Switching by contact .....................................................................................50
6.4.1.6 Switching by timer .........................................................................................50
6.4.2 Standard mode .............................................................................................52
6.4.2.1 Permanent ....................................................................................................52
6.4.2.2 Motion ...........................................................................................................53
6.4.2.3 Contact..........................................................................................................54
6.4.2.4 Sensor...........................................................................................................56
6.5 Video quality .................................................................................................56
6.5.1 Manual and automatic mode.........................................................................56
6.5.1.1 Analogue cameras ........................................................................................56
6.5.1.2 Dallmeier IP and HD cameras ......................................................................57
6.5.1.3 Other IP cameras ..........................................................................................59
6.5.2 Standard mode .............................................................................................60
6.5.2.1 Analogue cameras ........................................................................................60
6.5.2.2 Dallmeier IP and HD cameras ......................................................................60
6.5.2.3 Other IP cameras ..........................................................................................61
6.5.3 Optional conguration ...................................................................................62
6.5.3.1 Direct conguration .......................................................................................62
6.5.3.2 Auto conguration .........................................................................................62
6.5.3.3 B-Frames ......................................................................................................63
6.6 Activation ......................................................................................................63
6.7 Video memory ...............................................................................................64
6.7.1 Standard .......................................................................................................64

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 5
6.7.1.1 Longplay tracks .............................................................................................64
6.7.1.2 Secure tracks ................................................................................................65
6.7.1.3 Fixed recording duration ...............................................................................66
6.7.2 Manual ..........................................................................................................66
6.7.3 Automatic ......................................................................................................67
6.8 Other functions..............................................................................................67
6.8.1 Audio .............................................................................................................67
6.8.2 Dual Streaming .............................................................................................67
6.8.3 SEDOR .........................................................................................................68
6.8.4 SmartFinder ..................................................................................................71
6.8.5 Camera control .............................................................................................72
7 Display settings ..........................................................................................74
7.1 Splitter ...........................................................................................................75
7.1.1 Automatic assignment...................................................................................76
7.1.2 Manual assignment .......................................................................................76
7.2 Sequencer.....................................................................................................77
7.2.1 VGA display sequence ..................................................................................77
7.2.2 CVBS display sequence ...............................................................................79
7.2.3 Display frame rate .........................................................................................79
7.2.4 OSD display ..................................................................................................80
8 Network and PAS ........................................................................................81
8.1 Ethernet ........................................................................................................81
8.1.1 Manual conguration.....................................................................................82
8.1.2 DHCP ............................................................................................................82
8.2 PSTN/Terminal-Adapter ................................................................................83
8.3 Alarm hosts ...................................................................................................83
8.3.1 Selection and name ......................................................................................83
8.3.2 Connection ....................................................................................................84
8.3.3 Alternative alarm host ...................................................................................85
8.3.4 Connection check .........................................................................................86
8.3.5 Messages......................................................................................................87
8.3.6 Timer .............................................................................................................90
8.3.7 Activation ......................................................................................................91
8.3.8 EBueS ...........................................................................................................91
8.4 Parameter backup.........................................................................................92
8.4.1 Export............................................................................................................92
8.4.2 Import ............................................................................................................93
9 Serial Interface ............................................................................................94
9.1 Setting ...........................................................................................................94
9.2 Functions ......................................................................................................94
10 Contact IN ....................................................................................................96
10.1 Global and camera-related contacts .............................................................96
10.2 Make and break contact functions ................................................................96
10.3 Setting ...........................................................................................................97
10.4 Functions ......................................................................................................98
10.5 Conguration of camera-related contacts ...................................................100

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 6
11 Relay OUT ..................................................................................................101
11.1 Setting .........................................................................................................101
11.2 Functions ....................................................................................................101
12 Optional periphery ....................................................................................105
12.1 Printers........................................................................................................105
12.1.1 Create printer ..............................................................................................105
12.1.2 Set printer ...................................................................................................107
12.2 DIS control ..................................................................................................107
12.3 Storage .......................................................................................................108
12.4 Weather server ...........................................................................................108
12.5 DNI ..............................................................................................................109
12.5.1 DNI - external system .................................................................................109
12.5.2 DNI - camera control ...................................................................................110
12.6 UPS.............................................................................................................112
12.7 Card reader .................................................................................................113
12.8 VSC.............................................................................................................113
12.9 Serial PTZ cameras ....................................................................................114
12.10 UTC camera................................................................................................116
12.10.1 Required settings ........................................................................................116
12.10.2 Conrol panel................................................................................................118
12.10.3 Zoom function .............................................................................................118
12.10.3.1 Save zoom factor and position....................................................................119
12.10.3.2 Enter name for position ...............................................................................119
12.10.4 Congure camera .......................................................................................119
12.10.4.1 Functions ....................................................................................................121
12.10.4.2 Close menu and save conguration............................................................122
12.10.4.3 Save camera conguration for direct selection ...........................................122
12.10.5 Reset camera settings ................................................................................123
12.10.6 End UTC camera conguration...................................................................123
13 Optional functions ....................................................................................124
13.1 Signal loop through .....................................................................................124
13.2 PRemote .....................................................................................................124
14 HDD management .....................................................................................126
15 User management .....................................................................................128
15.1 Edit groups ..................................................................................................128
15.1.1 Issuing permissions ....................................................................................129
15.1.2 Change group name or login ......................................................................129
15.1.3 Dene or change passwords ......................................................................130
15.1.4 Dual-control login ........................................................................................130
15.1.5 Access restriction ........................................................................................131
15.2 Login as User ..............................................................................................131
15.2.1 Create users ...............................................................................................132
15.2.2 User rights...................................................................................................132
15.2.3 Change user password ...............................................................................133
15.2.4 Delete users ................................................................................................133
15.2.5 User options ................................................................................................134

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 7
16 Service .......................................................................................................136
16.1 Activation ....................................................................................................136
16.2 Update ........................................................................................................136
17 System parameter .....................................................................................138
17.1 Default system parameters .........................................................................138
17.2 Parameter export ........................................................................................138
17.3 Parameter import ........................................................................................139
18 HDD replacement ......................................................................................140
18.1 Conditions ...................................................................................................140
18.2 Localization of the HDD ..............................................................................141
18.3 Replace the HDD ........................................................................................141
19 Technical data ...........................................................................................144

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 8
1 This document
1.1 Validity
This document applies to the hybrid audio and video recorder DMS 80 / 160 / 240 / 240 HSR.
It has been produced on the basis of version 7.0.0 (software).
The descriptions in this document apply to all above-mentioned models. For simplication
reasons, the term “DMS” is thus used. If text passages require distinctions to be made be-
tween the devices, the complete device name will be mentioned.
1.2 Documents
Commissioning
The document entitled Commissioning contains the most important steps for the connec-
tion and commissioning of the device.
Main Functions
The document entitled Main Functions contains descriptions on how to operate the es-
sential functions of the device. The target audience of this document is the operator. No
special technical knowledge is required.
Operation
The document entitled Operation contains detailed descriptions on how to operate the
unit. General information on the appropriate use and maintenance is also provided.
The target audience of this document is the operator of the unit. No special technical knowl-
edge is required.
Conguration and data (this document)
The document entitled Conguration contains detailed descriptions conguration of the
unit. Safety notes, general information and technical data are additionally provided.
The target audience of this document is exclusively specially trained and authorized pro-
fessionals (“installers”).
1.2 Conventions
This document contains various warning words and symbols that indicate potential sources
of danger.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 9
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE indicates practices for preventing property damage, incorrect con-
gurations or faulty operations.
Expressions in bold/italics generally indicate a control element on the device (switches or
labels) or on its user interface (buttons, menu entries).
Paragraphs in italics provide information on basic principles, special features and efcient
procedure as well as general recommendations.

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 10
2 Safety instructions
Only use this unit if it is technically in proper working order, to the intended purpose and
while keeping safety and potential dangers in mind.
Qualied personnel
Installation, mounting, connection, commissioning and conguration of the unit may only
be carried out by qualied personnel. This also applies to the maintenance, testing and re-
pair, whereat the regulations of the DIN VDE 0701 series of standards (repair, modication
and inspection of electrical appliances) must be followed.
Regulations
The use of video and audio surveillance systems in general is strictly regulated. Inform
yourself about the applicable laws and regulations regarding data, working and environ-
mental protection before using the unit and ensure compliance with them.
System components
Only use internal components that have been tested and approved by Dallmeier. Inappro-
priate internal components can cause malfunctions, damages and data loss and can result
in loss of warranty.
Modications
Do not make any modications to the hardware or software that has not been tested and
approved by Dallmeier. Inappropriate modications can cause malfunctions, damages and
data loss and can result in loss of warranty.
Documentation
Carefully and completely read the documents included in delivery. Always observe the
contained instructions, notes and warnings.
Condensation water
If the unit is brought from a cold to a warm environment, resulting condensation water
can cause malfunctions and damages. In this case wait (up to 8 hours) until the unit has
reached room temperature before commissioning.
Operating conditions
Unfavourable operating conditions can shorten the life of the unit and can cause malfunc-
tions, damages and data los s and can result in loss of warranty. Observe the specications
given in the technical data, the operating condition requirements and the maintenance
instructions.
Shocks
Shocks can cause malfunctions and damages. The unit may not be moved while in opera-
tion.
Foreign bodies
If objects or liquids get into the unit, immediately disconnect it from the power supply (pull
out the power plug). Contact the sales partner responsible for your area.

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 11
Burnt smell
If you notice burnt smell or formation of smoke from the unit, immediately disconnect it from
the power supply (pull out the power plug). Contact the sales partner responsible for your
area.
Opening
The housing of the unit may only be opened by qualied personnel for inspection, mainte-
nance and repair.
Disposal
Disconnect the unit from the power supply. Remove all connected devices. Return the unit
to your respective sales partner.

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 12
3 General instructions
3.1 Scope of delivery
Included in the standard scope of delivery is:
1x Recorder including HDDs (as ordered)
1x Dallmeier mouse (optical, small version)
1x Power cable
1x Audio IN cable set (as ordered)
2x 9-pin D-SUB interfaces with housing
5x 8-pin Weidmüller plug connector
1x 10-pin Weidmüller plug connector
1x Spare set of lters (5 lters)
1x DVD +R1x
1x Dokumentation Conguration and Data (CD)
1x Documentation Operation (CD)
1x Documentation Commissioning (printed)
1x Documentation Main Functions (printed)
The scope of delivery may differ depending on the ordered equipment or device variant.
The device’s range of functions depends on the ordered equipment or device variant and
may therefore not correspond with this document’s content. Certain functions and features
may require an activation that is subject to costs.
3.2 Transportation and packaging
Store the original packaging for transportation at a later date. Dallmeier electronic is not
responsible for damage resulting from unprofessional/improper transportation. The goods
should only be shipped in their original packaging.
If the original packaging is no longer available, ensure that the packaging used sufciently
protects the unit against damage, moisture, heat and cold.
3.3 Warranty
The terms and conditions valid at the signing of the contract shall apply.

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 13
4 Start and Login
Observe the documentation Commissioning. It contains detailed instructions on moun-
ting, connection assignment and commissioning of the device.
¾Connect the recorder and relevant peripherals to the voltage supply.
¾Ensure that the VGA monitor and a mouse are connected to the recorder.
¾Switch on the VGA monitor, the peripherals and the recorder.
The connected analogue cameras 1 - 4 are displayed after the start.
Fig. 4-1
In the initial state it is possible to login without password. The rights of the Administ-
rator group are valid.
Note that the denition of the passwords and of the network parameters is necessary
for remote access (Dallmeier PView or DMS WebCong).
¾Left-click the background.
The Recorder login dialogue is displayed.
Fig. 4-2
¾Click Later to login without changing a password.

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 14
The graphical operation and conguration interface will be displayed.
Fig. 4-3

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 15
5 Basic settings
5.1 Language
The graphical user interface can be displayed in various languages.
¾Open the Language dialog using Setup > System > Language.
Fig. 5-1 : Language dialog
¾Select a Language.
¾Conrm with OK.
5.2 System time
The system time be set or retrieved from an external time emitter (time server or radio
clock). The Date format and the Time zone must be adopted in any case.
¾Open the Time dialog via Setup > System > System Time.
Fig. 5-2 : Set the time manually

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 16
¾Set the Datum format.
¾Set the Time zone.
¾Congure the system time as described on the following pages.
5.2.1 Setting
The system time is provided by the internal RTC (Real Time Clock), if no external time
emitter is activated.
¾Set the Time.
¾Set the Date.
¾Finally conrm with OK.
5.2.2 Time server
The recorder supports the Network Time Protocol (NTP). It can retrieve the system time
from an external time server via network.
Other NTP capable devices (e.g. IP cameras, recorders) always can use the recorder as a
time server in the network. This function is independent from the local settings.
¾Activate the Use external time server check-box.
¾Enter the IP address of the time server.
¾Check the connection to the time server with Ping.
¾Finally conrm with OK.
The time of the external time server is taken over as system time after the restart of the
recorder.
5.2.3 Radio clock
The recorder can retrieve the system time from an external radio clock.
The USB radio clock DFM-1-USB is available for all Dallmeier recorders.
¾Note the separate documentation for the radio clock.
¾Ensure that the radio clock is connected.
¾Activate the relevant interface in the Radio Clock section.
¾Finally conrm with OK.
The time of the external radio clock is taken over as system time after the restart of the
recorder.
Status LED of the DFM-1-USB
Glowing red no reception
Blinking red/green in a circle of one second good reception
Blinking red/green in a unsteady circle bad reception

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 17
5.3 System security
Some functions require the external access via the network interface and therefore the
opening of the corresponding ports of the system.
For system security reasons, the number of open ports should be kept to a minimum. Ports
denitely not required for Dallmeier systems are closed ex factory and can not be opened.
Relevant ports are open to ensure full compatibility. Relevant ports that are not required
can be closed in the System Security dialog.
¾Open the System Security dialog via Setup > System > System Security.
Fig. 5-3 System Security dialog
¾Activate the required protocols/ports.
¾Deactivate the not required protocols/ports.
¾Conrm with OK.
5.4 Options
The basic functions of the recorder can be set in the Options dialog.
¾Open the Options dialog using Setup > System > Options.
Fig. 5-4 : Options dialog

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 18
5.4.1 Alarm duration
The recorder can be congured in such a way that it is set to alarm status by a Contact IN
function. In this case various actions are carried out automatically.
• The Secure or Hold-up tracks are saved
• The Longplay tracks declared (system parameters) as alarm track are blocked
• Recording with different settings for the duration of the alarm status
The alarm status is ended either by triggering the opposite Contact IN function or after the
elapse of the Alarm duration.
¾Set the Alarm duration, if necessary.
¾Conrm with OK.
5.4.2 Test modes
The test modes are designed to check the recording performance of the recorder and the
selected function for analog cameras. Please note that the evaluation is only possible on
the actual recorder (not, for example, via DMS NetCong).
Fig. 5-5 : Options/Test modes dialog
The test results will be displayed in a separate window. This will be shown both in sequen-
cer/live mode and in playback/live mode over the current splits.
Fig. 5-6 : Example output of test results (compare)

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 19
5.4.2.1 Compare
The Compare test mode shows the results of the picture comparison (motion detection)
function in four different views.
The output alternates between all the analog cameras that are congured for Picture com-
parison recording mode.
Fig. 5-7 : Example of test mode Compare (without detection)
Please note that the numbering (A) of the cameras starts at 0 (camera 1 = 0, camera 2 =
1, etc.).
Fig. 5-8 : Example of test mode Compare (with detection)
If a motion is detected, the area of the motion is shown in four additional views and marked
(B). In addition the number of detection motions will also be displayed (C).
A
CB

DMS 80 / DMS 160 / DMS 240 / DMS 240 HSR
www.dallmeier.com 20
5.4.2.2 Performance
The Performance test mode displays the recording performance of the recorder in table
form. All the tracks earmarked for recording from analog cameras will be shown on the rst
line (track 1 = a, track 2 = b, etc.).
Fig. 5-9 : Example Performance test mode
If recording is taking place in a track, the frame rate (Fp/1s) and bit rate (BRate) will be
shown in the following two lines. The last line contains the total frame rate (FTot) and bit
rate (BRTot) for the recording.
5.4.2.3 Tracking
The Tracking setting ensures that the coordinates of a motion that is relevant for SmartFin-
der will be shown in the live picture in addition to being saved to the database.
Fig. 5-10 : Example Tracking test mode
Please note that only one camera may be activated for SmartFinder. The camera numbers
and displayed views correspond to the properties of Compare test mode.
D
