dallmeier DDF5 50HDV-DN-IM Series Guide

IM
DDF5(X)50HDV-DN
Commissioning
English
007530 | Rev. 2.0.0 | 2019-05-22

Copyright © 2019 Dallmeier electronic GmbH & Co.KG
The reproducon, distribuon and ulizaon of this document as well as the communicaon of its contents to
others without express authorizaon is prohibited. Oenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of a patent, ulity model or design.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due to minor
defects of the product or documentaon, e.g. print or spelling errors, and for those not caused by intenon or
gross negligence of the manufacturer.
Figures in this document may dier from the actual product.
We reserve the right to make technical modicaons.
All trademarks idened by ® are registered trademarks of Dallmeier.
All trademarks idened by *) are trademarks or registered trademarks of the following owners:
Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;
HDMI of HDMI Licensing, LLC headquartered in Sunnyvale, California, USA;
JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;
microSDXC of SD-3C, LLC headquartered in North Hollywood, California, USA;
Microso, Internet Explorer, Microso Edge and Windows of Microso Corporaon headquartered in
Redmond, Washington, USA;
Mozilla and Firefox of Mozilla Foundaon headquartered in Mountain View, California, USA;
Torx of Acument Intellectual Properes, LLC headquartered in Rockford, Illinois, USA;
Phillips of Phillips Screw Company headquartered in Burlington, Massachuses, USA.
Third-party trademarks are named for informaon purposes only.
Dallmeier respects the intellectual property of third pares and always aempts to ensure the complete
idencaon of third-party trademarks and indicaon of the respecve holder of rights.
In case that protected rights are not indicated separately, this circumstance is no reason to assume that the
respecve trademark is unprotected.
This product includes soware developed by the OpenSSL Project for use in the OpenSSL Toolkit
(hp://www.openssl.org) and cryptographic soware wrien by Eric Young (eay@cryptso.com).

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 3
Contents
1 Validity 4
2 Documents 4
This Document 5
Other Applicable Documents 5
3 TypographicalConvenons 6
4 SafetyInstrucons 8
5 General Notes 12
Scope of Delivery 12
Transportaon and Packaging 12
Warranty 13
Appropriate Use 13
Operaon 14
Approvals/Cercaons 15
6 Requirements 16
Ambient Condions 16
Power Supply 17
7 Maintenance,InspeconandCleaning 20
8 InstallaonandCommissioning 22
9 Interfaces 40
10 PinAssignment 42
11 InserngaMemoryCard 44
12 Connecon,First-TimeAccessandLogin 46
Connecon 47
First-Time Access 48
Login 49
13 TechnicalProductSpecicaon(BasicData) 50
14 Dimensions 54

DDF5(X)50HDV-DN-IM Commissioning
4 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
1 Validity
This document applies to the following devices:
• DDF5250HDV-DN-IM
• DDF5450HDV-DN-IM
For reasons of simplicaon, the term “device” or “camera” is used in the following.
Figures in this document may dier from the actual product.
2 Documents
The product documentaon for the device consists of various documents which
are provided in printed and/or digital form, as for example via the website
www.dallmeier.com.
Read the complete product documentaon for the device carefully and thoroughly
before using the device. Always observe and follow the contained instrucons,
notes and warnings as well as the technical data in the currently valid product
specicaon.
Keep all documents in legible condion and in a suitable locaon for future refer-
ence.
Regularly check the website www.dallmeier.com for the latest product documen-
taon updates.

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 5
This Document
Commissioning
The document entled “Commissioning” (this document) contains detailed infor-
maon concerning the installaon, connecon and commissioning of the device as
well as safety instrucons and general notes.
The target audience of this document is trained system integrators (installaon
contractors of video security/surveillance systems).
OtherApplicableDocuments
ProductSpecicaon
The product specicaon contains detailed technical data, features and character-
iscs of the device.
The target audience of the document is trained system integrators (installaon
contractors of video security/surveillance systems).
Conguraon
The document entled “Conguraon” contains detailed informaon concerning
the conguraon of the device.
The target audience of the document is trained system integrators (installaon
contractors of video security/surveillance systems).

DDF5(X)50HDV-DN-IM Commissioning
6 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
3 TypographicalConvenons
This document may contain various warning words and symbols that indicate
potenal sources of danger:
DANGER
DANGER indicates a hazardous situaon which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situaon which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situaon which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTICE addresses pracces not related to physical injury and
indicates measures to prevent device and/or property damage due
to improper installaon, assembly, wiring, operaon, conguraon
or maintenance of the device.

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 7
For reasons of clarity and readability, various text formang elements and types
of emphasis are used in this documentaon:
Instrucons are indicated by arrows (➡).
➡Always carry out instrucons one aer the other in the sequence described.
“Expressions” in quotaon marks usually refer to individual components of the
device (housing parts, mounng elements, connecons/interfaces, etc.) or to
control elements of the device’s web-based graphical user interface (menu items,
buons, etc.).
Paragraphs in italics provide informaon on basic principles, special features
and ecient procedure as well as general recommendaons.

DDF5(X)50HDV-DN-IM Commissioning
8 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
4 SafetyInstrucons
Only use the device if it is in technically perfect condion, according to the in-
tended purpose, in a safety and hazard conscious manner and in compliance with
the following safety instrucons:
• QualiedPersonnel
The assembly, installaon, connecon, commissioning and conguraon of the
device may only be carried out by qualied personnel.
This also applies to the maintenance, inspecon and repair of the device in
compliance with the regulaons of the DIN VDE 0701-0702 series of standards
(VDE 0701-0702: “Inspecon aer repair, modicaon of electrical appliances –
Periodic inspecon on electrical appliances – General requirements for electrical
safety”).
• Regulaons
The use of video and audio security/surveillance systems is, in general, strictly
regulated. Before using the device, inform yourself about the currently valid
laws and regulaons regarding data, worker and environmental protecon and
ensure compliance with them.
• System Components
Only use internal components that have been tested and approved by Dallmeier.
Inappropriate internal components may cause malfuncons, damage and data
loss and may result in the loss of warranty.

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 9
• ModicaonstotheDevice
Do not make any modicaons to the hardware or soware of the device that
have not been tested and approved by Dallmeier.
Inappropriate modicaons may cause malfuncons, damage and data loss and
may result in the loss of warranty.
• ProductDocumentaon
The product documentaon for the device consists of various documents which
are provided in printed and/or digital form, as for example via the website
www.dallmeier.com.
Read the complete product documentaon for the device carefully and
thoroughly before using the device. Always observe and follow the contained
instrucons, notes and warnings as well as the technical data in the currently
valid product specicaon.
Keep all documents in legible condion and in a suitable locaon for future
reference.
Regularly check the website www.dallmeier.com for the latest product docu-
mentaon updates.
• Condensaon
If the device is brought from a cold to a warm environment, resulng condensa-
on may cause malfuncons and damage. In this case, wait unl the device has
reached room temperature (up to 8 hours) before commissioning.

DDF5(X)50HDV-DN-IM Commissioning
10 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
• Earthing/Grounding&EquipotenalBonding
For the safety of persons (protecon against dangerous contact voltages)
and devices (protecon against over-voltages) as well as for the immunity of
informaon and communicaon technology equipment to electromagnec in-
terferences (EMI), all protecve measures, which are specied by the currently
applicable DIN, VDE and ISO standards and which provide for a standard-com-
pliant earthing/grounding and a correct equipotenal bonding of electrical and
electronic devices, are mandatory and must be fullled by all means.
• LightningStorms
To avoid damage to the device by electrical surge during lightning storms, all
protecve measures, which are specied by the currently applicable DIN, VDE
and ISO standards and which provide for a standard-compliant lightning protec-
on equipotenal bonding, are mandatory and must be fullled by all means.
• OperangCondions
Unfavorable operang condions may shorten the lifeme of the device,
may cause malfuncons, damage and data loss and may result in the loss of
warranty. Observe the specicaons given in the technical data, the operang
condion requirements and the maintenance instrucons.
• ForeignBodiesintheDevice
If objects or liquids get into the device, immediately disconnect it from the
power supply (pull out the power plug or disconnect the device from the PoE
enabled PSE port).
Contact the sales partner responsible for your area.

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 11
• BurntSmellfromtheDevice
If you noce burnt smell or a formaon of smoke coming from the device,
immediately disconnect it from the power supply (pull out the power plug or
disconnect the device from the PoE enabled PSE port).
Contact the sales partner responsible for your area.
• Opening the Device
The device may only be opened by qualied personnel for commissioning,
inspecon, maintenance and repair.
• Disposal of the Device
Do not dispose waste electrical and electronic equipment into the household
trash.
Disconnect the device from the power supply.
Remove all connected peripherals.
Return the device to the sales partner responsible for your area.

DDF5(X)50HDV-DN-IM Commissioning
12 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
5 General Notes
Scope of Delivery
The standard scope of delivery includes:
• Security Torx*) L-wrench with hollow point (T20 H) for
tamper-resistant housing screws (Torx-TR 20)
• Pre-assembled Cat.5e RJ45 adapter cable with rubber grommet (length 150 mm)
• Ceiling hook, safety cable (steel wire rope with two loops) and carabiner
• PG16 cable gland with sealing insert and sealing ring on connecon thread
• Product documentaon
The scope of delivery may dier depending on the ordered equipment, device
variant or country of desnaon.
TransportaonandPackaging
Store the original packaging for later transportaon.
Dallmeier is not responsible for any damage resulng from unprofessional or
improper transportaon.
The device should only be shipped in the original packaging.
If the original packaging is no longer available, ensure that the used packaging suf-
ciently protects the device against damage, moisture, heat and cold.

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 13
Warranty
The terms and condions valid at the me the contract was signed shall apply.
AppropriateUse
The DDF5(X)50HDV-DN-IM (in-ceiling mount variant) is a HD network camera that
is built into a vandal-resistant (IK10) dome enclosure.
The device is exclusively designed for indoor installaons in suspended ceilings
or drywall (plasterboard) systems and can be operated with Power over Ethernet
(PoE, Class 0, IEEE 802.3af) or powered by an external 24 V DC power supply unit.
NOTICE
Damagetothedeviceduetoanunsuitablemounnglocaon
The device is exclusively designed for indoor use.
An outdoor installaon is prohibited and may result in malfuncon,
damage, data loss and loss of warranty.
➡Do not install/operate the device in outdoor environments.

DDF5(X)50HDV-DN-IM Commissioning
14 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
Operaon
• If the device is powered by an external DC power supply unit (i.e. is not operated
with Power over Ethernet), interference caused by a ground loop may occur
in the analog video preview signal. In this case, use a video signal transformer
(balun) for galvanic (ground) isolaon between the signal source (this camera)
and the RG-59 cable.
• In order to prevent damage to the device, a galvanic isolator (balun) must be
installed if the BNC interface is permanently in use.
• If the device or the cables connected to the device are located near sources
with strong radiaon, the video image may be distorted.
• The device is equipped with Automac Gain Control (AGC). In low-light condi-
ons the image may be altered (e.g. noise). This is not a malfuncon.
• The quality of the video image depends on the lighng condions and the used
monitor.
• The accuracy of the Automac White Balance (AWB) algorithm depends on the
used lighng. Mixed light (consisng of arcial light and daylight) may cause
color distorons (inaccurate color reproducon).
• Poor lighng can lead to an incorrect white balance.

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 15
Approvals/Cercaons
The following approvals/cercaons were valid for the device at the me of this
document’s compilaon:
• CE, FCC, RCM, UL, DIN 50130-4 compliant
Visit www.dallmeier.com for possible updates.
Note(USA)
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protecon against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instrucon manual, may cause harmful interfer-
ence to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference
at his own expense.

DDF5(X)50HDV-DN-IM Commissioning
16 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
6 Requirements
AmbientCondions
The device is exclusively designed for indoor use.
NOTICE
Damagetothedeviceduetounfavorableambientcondions
Unfavorable local condions may shorten the lifeme of the device
and may cause malfuncons or damages.
➡Do not install/operate the device in places
• with a large amount of dust and dirt,
• with steam or oil vapors (e.g. kitchen),
• with direct sunlight,
• with strong heat emissions (e.g. radiator),
• with improper ambient temperatures,
• near sources with strong radiaon (e.g. radio transmiers,
magnec elds),
• with corrosive surroundings (e.g. gases, salt water),
• with insucient air venlaon (e.g. closed cabinet).

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 17
PowerSupply
The device is by default operated with Power over Ethernet (PoE, Class 0) and is
compable with all Power Sourcing Equipment (PSE) that is compliant with the
IEEE 802.3af PoE standard.
Oponally, the device can also be powered by an external 24 V DC power supply
unit.
WARNING
Electricalshockcausedbyexposedelectricalpartsandduetothe
lackoforimproperearthing/grounding
Risk of death or serious injury
➡The installaon of the device and the connecon of peripheral
equipment may only be carried out by qualied personnel and
in a voltage-free state.
➡Before connecng or disconnecng an external DC power sup-
ply unit, make sure that the power supply unit is disconnected
from the mains socket (pull the power plug out of the socket).
➡Carry out all protecve measures for a standard-compliant
earthing/grounding of the device in accordance with the cur-
rently applicable DIN, VDE and ISO standards in order to ensure
the safety of persons (protecon against dangerous contact
voltages).

DDF5(X)50HDV-DN-IM Commissioning
18 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
NOTICE
Damagetothedeviceduetoimproperpowersupply
Damage to electronic components or serious malfuncons
➡Always ensure the correct polarity when connecng an external
DC power supply unit.
➡Do not operate the device with Power over Ethernet (PoE) if the
device is powered by an external DC power supply unit.
Damagetothedeviceormalfunconsduetothelackoforim-
properearthing/grounding
Damage to electronic components caused by lightning strikes and
over-voltages (electrical surges) or malfuncons due to electro-
magnec interferences
➡Carry out all protecve measures for a standard-compliant
earthing/grounding and a correct equipotenal bonding of the
device in accordance with the currently applicable DIN, VDE and
ISO standards in order to ensure the safety of the device (pro-
tecon against over-voltages) and its immunity to electromag-
nec interferences (EMI).

Commissioning DDF5(X)50HDV-DN-IM
Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com 19
NOTICE
DamagetothecontactsoftheRJ45connectorswhenun-mang
thejack-plugconneconunderPoEload
Un-mang the jack-plug connecon while transming PoE power
causes erosion and ping by electrical arcs on both the jack and
plug contacts (especially when repeatedly un-mang the jack-plug
connecon under PoE load). Electrical arcs are generated, since the
electric potenal dierence (voltage) and therefore the intensity
of the electric eld between the contacts rises sharply when un-
mang the jack-plug connecon.
The more un-mang cycles are carried out under PoE load, the
higher the loss of contact material due to metal evaporaon by
electrical arcs, which in turn accelerates the material erosion pro-
cess on the contact surfaces.
Damaged contacts with an increased contact resistance may lead
to a reduced data transfer rate, unreliable network connecvity or
even total device failure.
➡Always disable PoE on the relevant port of your PoE switch (or
PoE midspan device) or disconnect the used single-port PoE
injector from the power supply before un-mang the jack-plug
connecon in order to prevent damage to the contacts of the
RJ45 connectors by contact erosion.

DDF5(X)50HDV-DN-IM Commissioning
20 Rev. 2.0.0 | © 2019 Dallmeier | www.dallmeier.com
7 Maintenance,InspeconandCleaning
Maintenance and inspecon of the device may only be carried out by qualied
personnel in compliance with the regulaons of the DIN VDE 0701-0702 series
of standards (VDE 0701-0702: “Inspecon aer repair, modicaon of electrical
appliances – Periodic inspecon on electrical appliances – General requirements
for electrical safety”).
If it is necessary to clean the device, observe the following notes:
NOTICE
Damage to the surfaces of the device due to improper cleaning
pracces
➡Clean the outside of the housing with a clean, so, dry and
anstac cloth.
• Do not use detergents.
➡Clean the plasc dome/bubble with water and some hand
dishwashing liquid using a clean, so and non-linng cloth or
sponge.
• Do not rub the plasc bubble with a dry cloth.
• Do not use common glass cleaners.
• Do not use microber cleaning cloths.
• Avoid excessive rubbing.
• To dry the plasc bubble, dab it carefully and gently with a
clean, so, dry and anstac cloth to avoid scratching the
surface.
This manual suits for next models
2
Table of contents
Other dallmeier IP Camera manuals

dallmeier
dallmeier DF5250HD-DN/IR Guide

dallmeier
dallmeier DDF4900HDV Series Operating and maintenance instructions

dallmeier
dallmeier DDF4820HDV-DN-IM Guide

dallmeier
dallmeier DF4820HD-DN Guide

dallmeier
dallmeier DF3000IP Operating and maintenance instructions

dallmeier
dallmeier DF5 00HD-DN/IR Series User manual

dallmeier
dallmeier DF4 20HD-DN/IR Series Guide

dallmeier
dallmeier DF5400HD-DN/IR Guide

dallmeier
dallmeier DDZ5000HD-DN/IR Series Guide

dallmeier
dallmeier DDF51 HDV-DN-SM Series Guide
