dallmeier DF5400HD-DN/IR Guide

006476 | Rev. 1.0.2 | 2018-12-14
DF5400HD-DN/IR
Commissioning
English

Copyright © 2018 Dallmeier electronic GmbH & Co.KG
The reproducon, distribuon and ulizaon of this document as well as the communicaon
of its contents to others without express authorizaon is prohibited. Oenders will be held
liable for the payment of damages.
All rights reserved in the event of the grant of a patent, ulity model or design.
The manufacturer accepts no liability for damage to property or pecuniary damages arising
due to minor defects of the product or documentaon, e.g. print or spelling errors, and for
those not caused by intenon or gross negligence of the manufacturer.
Figures in this document may dier from the actual product.
We reserve the right to make technical modicaons.
All trademarks idened by ® are registered trademarks of Dallmeier electronic.
All trademarks idened by *) are trademarks or registered trademarks of the following owners:
Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;
JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;
Microso, Internet Explorer, Microso Edge and Windows of Microso Corporaon headquartered in Redmond,
Washington, USA;
Mozilla and Firefox of Mozilla Foundaon headquartered in Mountain View, California, USA;
Torx of Acument Intellectual Properes, LLC headquartered in Rockford, Illinois, USA.
Third-party trademarks are named for informaon purposes only.
Dallmeier electronic respects the intellectual property of third pares and always aempts to ensure the complete
idencaon of third-party trademarks and indicaon of the respecve holder of rights.
In case that protected rights are not indicated separately, this circumstance is no reason to assume that the respecve
trademark is unprotected.
This product includes soware developed by the OpenSSL Project for use in the OpenSSL Toolkit (hp://www.openssl.org)
and cryptographic soware wrien by Eric Young (eay@cryptso.com).

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 3
1× 1×
1×
1× 1×
1× 4× 4× 4× 1×1×

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 5
Contents
1 Validity 6
2 Documents 6
This Document 7
Other Applicable Documents 7
3 TypographicalConvenons 8
4 SafetyInstrucons 10
5 General Notes 13
Scope of Delivery 13
Transportaon and Packaging 14
Warranty 14
Appropriate Use 14
Operaon 15
Formaon of Condensaon – Fogging of the Front Glass 16
Approvals/Cercaons 18
6 Requirements 19
Ambient Condions 19
Power Supply 20
7 Maintenance and Cleaning 22
8 InstallaonandCommissioning 23
9 FrontViewofCamera 40
10 WireColorCodeforPre-assembledPatchCable 41
11 ConneconandLogin 42
System Requirements 42
Connecon 43
Login 44
12 TechnicalProductSpecicaon 46
13 Dimensions 48

DF5400HD-DN/IR
6Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
1 Validity
This document applies to the following device:
• DF5400HD-DN/IR
For reasons of simplicaon, the term “device” or “camera” is used in the
following.
Figures in this document may dier from the actual product.
2 Documents
The product documentaon for the device contains several documents
which are included in the scope of delivery in a printed form and/or on
a digital medium. Addional informaon, if available, is provided exclu-
sively on the website www.dallmeier.com.
Read the complete product documentaon for the device carefully and
thoroughly before using the device.
Always observe and follow the contained instrucons, notes and warnings
as well as the technical data in the currently valid product specicaon.
Keep all documents in legible condion and in a suitable locaon for
future reference.
Regularly check the website www.dallmeier.com for the latest product
documentaon updates.

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 7
This Document
Commissioning
The document entled “Commissioning” (this document) contains
detailed informaon concerning the installaon, connecon and commis-
sioning of the device as well as safety instrucons and general notes.
The target audience of this document is trained system integrators (video
security/surveillance systems installaon contractors).
OtherApplicableDocuments
ProductSpecicaon
The product specicaon contains detailed technical data, features and
characteriscs of the device.
The target audience of the document is trained system integrators (video
security/surveillance systems installaon contractors).
Conguraon
The document entled “Conguraon” contains detailed informaon
concerning the conguraon of the device.
The target audience of the document is trained system integrators (video
security/surveillance systems installaon contractors).

DF5400HD-DN/IR
8Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
3 TypographicalConvenons
This document may contain various warning words and symbols that
indicate potenal sources of danger:
DANGER
DANGER indicates a hazardous situaon which, if not avoided, will
result in death or serious injury.
WARNING
WARNING indicates a hazardous situaon which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situaon which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE addresses pracces not related to physical injury and indi-
cates measures to prevent device and/or property damage due to
improper installaon, assembly, wiring, operaon, conguraon or
maintenance of the device.

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 9
For reasons of clarity and readability, various text formang elements
and types of emphasis are used in this documentaon:
Instrucons are indicated by arrows (➡).
➡Always carry out instrucons one aer the other in the sequence
described.
“Expressions” in quotaon marks usually refer to individual components
of the device (housing parts, mounng elements, connecons/interfaces,
etc.) or to control elements of the device’s web-based graphical user
interface (menu items, buons, etc.).
Paragraphs in italics provide informaon on basic principles, special
features and ecient procedures as well as general recommenda-
ons.

DF5400HD-DN/IR
10 Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
4 SafetyInstrucons
Only use the device if it is in technically perfect condion, according to
the intended purpose, in a safety and hazard conscious manner and in
compliance with the follow ing safety instrucons:
• QualiedPersonnel
The assembly, installaon, connecon, commissioning and conguraon
of the device may only be carried out by qualied personnel.
This also applies to the maintenance, inspecon and repair of the device
in complying with the regulaons of the DIN VDE 0701-0702 series of
standards (VDE 0701-0702: “Inspecon aer repair, modicaon of
electrical appliances – Periodic inspecon on electrical appliances –
General requirements for electrical safety”).
• Regulaons
The use of video and audio security/surveillance systems is, in general,
strictly regulated.
Before using the device, inform yourself about the currently valid laws
and regulaons regarding data, worker and environmental protecon
and ensure compliance with them.
• System Components
Only use internal components that have been tested and approved by
Dallmeier.
Inappropriate internal components may cause malfuncons, damage
and data loss and may result in the loss of warranty.
• ModicaonstotheDevice
Do not make any modicaons to the hardware or soware of the device
that have not been tested and approved by Dallmeier.
Inappropriate modicaons may cause malfuncons, damage and data
loss and may result in the loss of warranty.

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 11
• ProductDocumentaon
The product documentaon for the device contains several documents
which are included in the scope of delivery in a printed form and/or on
a digital medium.
Addional informaon, if available, is provided exclusively on the web-
site www.dallmeier.com.
Read the complete product documentaon for the device carefully
and thoroughly before using the device. Always observe and follow the
contained instrucons, notes and warnings as well as the technical data
in the currently valid product specicaon.
Keep all documents in legible condion and in a suitable locaon for
future reference.
Regularly check the website www.dallmeier.com for the latest product
documentaon updates.
• Condensaon
If the device is brought from a cold to a warm environment, resulng
condensaon may cause malfuncons and damage. In this case, wait
unl the device has reached room temperature (up to 8 hours) before
commissioning.
• EyeProteconWhenUsingIRRadiaon
When looking directly into the switched on infrared (IR) LEDs in a dark
environment, ensure a minimum safety distance of 1 meter and short
exposure mes in order to avoid eye damage.
• Earthing&EquipotenalBonding
For the safety of persons (protecon against dangerous contact volt-
ages) and devices (protecon against over-voltages) as well as for the
immunity of informaon and communicaon technology equipment to
electromagnec interferences (EMI), all protecve measures, which are
specied by the currently valid DIN, VDE and ISO standards and which
provide for a standard-compliant earthing and a correct equipotenal
bonding of electrical and electronic devices, are mandatory and must
be fullled by all means.

DF5400HD-DN/IR
12 Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
• LightningStorms
To avoid damage to the device by electrical surge during lightning
storms, all protecve measures, which are specied by the currently
valid DIN, VDE and ISO standards and which provide for a standard-
compliant lightning protecon equipotenal bonding, are mandatory
and must be fullled by all means.
• OperangCondions
Unfavorable operang condions may shorten the lifeme of the device,
may cause malfuncons, damage and data loss and may result in the loss
of warranty.
Observe the specicaons given in the technical data, the operang
condion requirements and the maintenance instrucons.
• ForeignBodiesintheDevice
If objects or liquids get into the device, immediately disconnect it from
the power supply (pull out the power plug or disconnect the device
from the PoE enabled PSE port).
Contact the sales partner responsible for your area.
• BurntSmellfromtheDevice
If you noce burnt smell or a formaon of smoke coming from the
device, immediately disconnect it from the power supply (pull out the
power plug or disconnect the device from the PoE enabled PSE port).
Contact the sales partner responsible for your area.
• Opening the Device
The device may only be opened by qualied personnel for commission-
ing, inspecon, maintenance and repair.
• Disposal of the Device
Do not dispose waste electrical and electronic equipment into the
household trash.
Disconnect the device from the power supply.
Remove all connected devices.
Return the device to the sales partner responsible for your area.

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 13
5 General Notes
Scope of Delivery
Included in the standard scope of delivery is:
• 1× Outdoor wall mount bracket with internal cable roung
• 1× Flat gasket (adhesive-backed) for outdoor wall mount bracket
• 1× Drilling template for outdoor wall mount bracket
• 4× Chipboard screw Ø 5 × 40 mm
(partly threaded, pan head, 6-lobe drive/Torx*) T25)
• 4× Plain washer (VA, DIN 9021 / ISO 7093, inner diameter: 5.3 mm)
• 4× Expansion nylon plug S6 (drill hole diameter: 6 mm,
min. drill hole depth: 40 mm, anchor length: 30 mm)
• 1× Hexagon socket head cap screw
(fully threaded, DIN 912 / ISO 4762, M8 × 12, for hex key size: 6 mm)
• 1× Hex key L-wrench for hexagon socket screws (key size: 6 mm)
• 1× Hexalobular L-wrench (Torx T8)
• 1× E-DAT modul Cat.6A 8(8) jack, T568A
• 1× Cat.5e RJ45 inline coupler STP
• 1× IR lens hood
• Product documentaon (published in print and/or on DVD-ROM)
The scope of delivery may dier depending on the ordered equip-
ment, device variant or country of desnaon.
The funconal range of the device depends on the ordered equip-
ment or device variant and may dier from this document’s content.
Certain funcons and features may require the purchase of an ad-
dional license.

DF5400HD-DN/IR
14 Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
TransportaonandPackaging
Store the original packaging for later transportaon.
Dallmeier is not responsible for any damage resulng from unprofes-
sional/improper transportaon.
The device should only be shipped in the original packaging.
If the original packaging is no longer available, ensure that the used pack-
aging suciently protects the device against damage, moisture, heat and
cold.
Warranty
The terms and condions valid at me the contract was signed shall apply.
AppropriateUse
The DF5400HD-DN/IR is a weather-proof 4K UHD (Ultra High Denion)
color network camera for an IP-based 24-hour video surveillance with
automac day/night operaon that is supported by ambient light sensing,
a mechanically removable infrared(IR)-cut lter (ICR) as well as an inte-
grated IR illuminaon.
The camera is equipped with an ambient light sensor that measures the
intensity of visible light. Depending on the lighng condions, the camera
automacally switches between day and night mode (switching threshold
level adjustable; manual switching addionally possible).
In day mode, the incorporated mechanically removable IR-cut lter
blocks out unwanted IR light and only allows visible light to pass through
so that colors in the image are reproduced without distoron (as the
human eye sees them). In night mode (when the amount of visible light
drops), the camera switches from color mode to the more light-sensive
black-and-white mode, while automacally removing the IR-cut lter so
that near-infrared light (with a wavelength of 850 nanometers) can reach
the image sensor.
The night mode is supported by the integrated homogeneous IR illumina-
on that is provided by semi-covert 850 nm high power LEDs. This allows
for a round-the-clock video monitoring even in totally dark environments.

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 15
The camera features a fast (large maximum aperture) and IR-corrected
motor-driven megapixel varifocal lens with P-Iris technology which en-
ables the control of opcal zoom (focal length), focus and iris (opmum
aperture) remotely over the network by using a web browser.
The focus posion can be automacally set by using the one-push autofo-
cus funcon and manually adjusted if needed.
Built into an IP66-rated weather-proof enclosure and delivered with an
outdoor wall mount bracket that features internal cable roung, the
camera is designed for residenal, public, commercial and industrial use
(24/7/365 connuous operaon) in both indoor and outdoor areas.
The camera is operated via Power over Ethernet (PoE, Class 0) and is com-
pable with all IEEE 802.3af compliant Power Sourcing Equipment (PSE).
Operaon
➡Observe the following notes for operang the device:
• If the device or the cables connected to the device are located near
sources with strong radiaon, the video image may be distorted.
• The device is equipped with Automac Gain Control (AGC). In low-light
condions the image may be altered (e.g. noise). This is not a malfunc-
on.
• The quality of the video image depends on the lighng condions and
the used monitor.
• The accuracy of the Automac White Balance (AWB) algorithm depends
on the used lighng. Mixed light (consisng of arcial light and day-
light) may cause color distorons (inaccurate color reproducon).
• Poor lighng can lead to an incorrect white balance.

DF5400HD-DN/IR
16 Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
FormaonofCondensaon–
Fogging of the Front Glass
Condensaon forms mainly due to temperature or pressure uctuaons.
If the device is transported between locaons with high temperature
dierences, condensaon may form on the outside of the housing as well
as inside the device. In this case, wait unl the temperature of the device
will have slowly adapted to the ambient temperature prior to commis-
sioning.
PressureEqualizaonElement
The device is equipped with a pressure equalizaon element.
Pressure equalizaon elements are used to prevent the formaon of con-
densaon in sealed enclosures, where humidity normally cannot escape
to the outside.
Fig. 1
Pressure equalizaon element

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 17
The built-in pressure equalizaon element of the device connuously
equalizes the internal pressure of the device to the ambient pressure.
Thus, the temperature and humidity dierence between the housing
interior and the ambient air is balanced, and hence the formaon of con-
densaon is largely prevented.
CondensaonInsidetheHousing
Despite the built-in pressure equalizaon element, a sudden drop in tem-
perature (e.g. based on heavy showers or thunderstorms) may temporar-
ily cause water vapor (moisture) inside the housing, resulng in conden-
saon on the inner surface of the front glass.
In this case, acvate the integrated IR lighng via the device’s WebCong
user interface. Set the IR power to the highest level unl the glass is free
of condensaon due to the self-heang generated by the IR LEDs.
This phenomenon also occurs during winter commissioning when the
unit is brought from a warm storage room to the outside area.
As a result of the residual moisture inside the housing due to storage,
the glass may take longer (than during operaon) to become fog-free
again.
CondensaonontheOutsideoftheHousing
Condensaon on the outside of the housing may form temporarily – usu-
ally in the early morning when the humidity level is high, as the ambient
air is warming faster than the outer surface of the housing.
This results in condensaon on the outer surface of the front glass (like
dew on the grass).
This phenomenon is due to physical reasons and, therefore, does not
constute a defect.

DF5400HD-DN/IR
18 Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
Approvals/Cercaons
The following approvals/cercaons were valid for the device at the
me of this document’s compilaon:
• CE
• FCC
• RCM
• UL
• DIN 50130-4 compliant
• IEC/EN 62471 compliant
Visit www.dallmeier.com for possible updates.
Note(USA)
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protecon against harmful interfer-
ence when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual,
may cause harmful interference to radio communicaons.
Operaon of this equipment in a residenal area is likely to cause harmful
interference in which case the user will be required to correct the inter-
ference at his own expense.

DF5400HD-DN/IR
Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com 19
6 Requirements
AmbientCondions
The device is designed for both indoor and outdoor use. However, note
that unfavorable local condions may shorten the lifeme of the product
and may cause malfuncons or damages.
➡Do not install/operate the device in places
• with a large amount of dust and dirt,
• with steam or oil vapors (e.g. kitchen),
• with direct sunlight,
• with strong heat emissions (e.g. radiator),
• with improper ambient temperatures,
• near sources with strong radiaon (e.g. radio transmiers, magnec
elds),
• with corrosive surroundings (e.g. gases, salt water),
• with insucient air venlaon (e.g. closed cabinet).

DF5400HD-DN/IR
20 Rev. 1.0.2 | © 2018 Dallmeier | www.dallmeier.com
PowerSupply
The device is operated via Power over Ethernet (PoE, Class 0) and is com-
pable with all IEEE 802.3af compliant Power Sourcing Equipment (PSE).
WARNING
Personalinjuryfromelectricalshockaswellaspropertydamage
causedbylightningstrikes,over-voltages(electricalsurges)and
electromagnecinterferences
Risk of death or serious injury as well as damage to the device or
malfuncons
➡For the safety of persons (protecon against dangerous contact
voltages) and devices (protecon against lightning strikes and
over-voltages/electrical surges) as well as for the immunity of
informaon and communicaon technology equipment to elec-
tromagnec interferences (EMI), all protecve measures, which
are specied by the currently valid DIN, VDE and ISO standards
and which provide for a standard-compliant earthing and a correct
(lightning protecon) equipotenal bonding of electrical and elec-
tronic devices, are mandatory and must be fullled by all means.
