Dancing Wings Hobby T30 User manual

T30 Trainer Airplane Instruction Manual
工具 Tools Needed
F1
F2
F3
爪牙螺母
Claw nut
F7-3
F7-2
F7-1
F21
F4
F5 F6
F13
F8
F9
F14
F14-1
F15
F15-1
F21
F11
F12
F10 F16
F12-1
F22
F17
F27
F28
F29
F18 F19 F20
F38
P4
F40
F23
F30
F25
F26 F24
F23-1
P5
F32
F33 F34
F35
F36
P3
F32-1
F37 F37-1
F31
F14
F14-1
F14-2
背面装爪牙螺母
打磨成机身一体弧度
螺丝固定
碳杆
carbon rod
磁铁magnet
磁铁magnet
R4
E8
E3
E4
E1
E7
E6
E5
E2
E9
E10
R11
R10
R9
R5
R7
R6
R1x2
R2
R3
R8
R12
P2
P1
W1
W14 W14-1
W2
W3 W4 W6
W16
W16-1
W5
W7 W8
W18
W18-1
W9 W10
W11
W21 W22
W4-1
W23
W16
W17 W17-1
W19
W20
W13x2
W38x3
W20-1x3
W16-1
W24 W25
W26 W28
W27 W29
2,尾翼组装 Assemble the Tail Wing
机翼和尾翼请在平整的工作台上进行拼装，拼装时保持机翼平直。
3,机翼组装 Assemble the Wing
W5
1,机身组装 Assemble the Fuselage
Claw nut
爪牙螺母
Claw nut
爪牙螺母
Claw nut
爪牙螺母
F30 F40粘贴时用
水湿润后再进行
蒙板粘贴
Soak the F30 and
F40,and paste the
cover board.
Firm with screws
螺丝固定
Firm with screws
install the claw nut at the back.
Polish it with same radian as fuselage
Assemble the wing and tail on the smooth desk,make sure the wing is straight.
轻木条P6 P6-1交错拼接
Install the balsawood strips
P6 and P6-1 in cross.
参数
翼展：1400mm
机长：1070mm
起飞重量：≈2000-2500g
推荐配置
马达：2814-3520 600-1000KV
电调：40A
电池：4S 3600-5000mAh
舵机：17g*4
引擎：2C36 / 4C56
桨叶：10-12inch
通道：≥4CH
Speci�ication
Wingspan: 1400mm
Length: 1070mm
Flying Weight≈2000-2500g
Suggested Equipment
Electric powered: 2814-3520 600-1000kv
ESC: 40A
Battery: 4S 3600-5000mAh
Servos: 17g*4
Gas engine class: 2C36 / 4C56
Propeller: 10-12inch
Radio≥4CH

W32
W30
W30-1
W36
W15x2
W32-1
W12
W35-1 W35
W37
W21x3
（按机翼弧度打磨成弧形）
W33
W33-1
W34
W31-1
W31
D3x2
D2 D2 D4
D1
D6
D5
螺丝
screw
插入
Insert
4,马达座组装 Install the Motor Mount
5,起落架安装图示 Assemble the Landing Gear
7,舵机，舵角安装图示 Install the servo and servo horn
8,重心调试位置图示 Adjust the C.G.
6,机翼及尾翼安装到机身图示 Assemble the wing onto the fuselage
升降舵舵机 副翼舵机
X1*2X2X3
垫入X1-3并打磨
C.G
≈80mm
(Polish as per the radian of the wing)
(Paste the W12 only with W35)
（W12只与W35粘贴）
机翼组装完成后切
下副翼，按图示粘
贴W37并打磨，
再用纸合页把副翼
连接到机翼。
Cut off the aileron
once the wing is
built up,paste the
W37 as picture
shown,then polish
;and connect the
aileron with the
wing by the paper
hinges.
Assemble the other wing same as the above
steps,connect the two wings together with the carbon
tube,and firm with glue.
另一边机翼参考以上步骤拼装，两边机翼组装完成后通过碳
管对插在一起，连接处用胶水粘合。
D4可根据选用的马达长度
进行增加或减少。
The length of D4 could be
increased or lessened as per
the motor length.
Firm the motor mount onto
the head with screws.
马达座用螺丝固定到机头
Elevator servo 转向舵舵机
Connect the
rudder servo
with the front
steering wheel.
When it's powered by gasoline,this
servo controls the throttle.
连接前转向轮
使用油动马达时，
此舵机控制油门
Aileron servo
