Danfoss SASA Operating and maintenance instructions

Installation Guide
Steering Wheel Sensor
Type SASA
powersolutions.danfoss.com

AMP
Deutch
min. 20.8 [0.819] max. 22.3 [0.878]
min. 27 [1.06] max. 30 [1.81]
min 45[1.77]
30 ± 5 N•m
[266 ± 45 lbf•in]
P006 091
Customer
consol plate
Customer
consol plate
OTP
OTP
OSP
OSP
SASA
SASA
There is a risk of bending the spline profile of SASA sensor in case of using force.
Make sure that the spline profile of the SASA sensor is aligned to the profile of the steering column shaft.
A safe method of assembly is to place SASA sensor on the steering column spline shaft first - and not
opposite!
Cable Connections
AMP connector version, type 2-967059-1
AMP connector pin-out
43
21
1. CAN-Low
2. + Supply voltage
3. Ground
4. CAN-High
Mating connector assembly AMP type 2-965261-1
JPT contact 2-962915-1
Wire sealing 828904-1
Installation Guide
Steering Wheel Sensor, Type SASA
SASA Assembly
4 | ©Danfoss | June 2017 AN00000360en-US0101

Deutsch connector version, type DT04-4P-CE02
Deutsch connector pin-out
23
4
1
1. CAN-High
2. CAN-Low
3. + Supply voltage
4. Ground
Housing DT04-4S-CE02
Crimp 0462-201-16141
Wedge W4S
AMP or Deutsch operating conditions
Description Type Value
Supply voltage Nominal 12 - 24 VDC
Minimum 9 V
Maximum 32 V
Temperature Range 30° to 60°C [86 - 140°F]
Minimum -30°C [-22°F]
Maximum 85°C [185°F]
Power consumption - <1 W
Current consumption Operational mode <85 mA
Grade of enclosure AMP or Deutsch IP 65
Safety function: If a failure occurs, the CAN-bus will “fail silent”.
The CAN-bus driver will be disabled.
Warning
All types of sensors are used under a wide range of operating conditions, in many types of machines and
therefore may fail and cause serious injury or damage.
The machine manufacturer has the sole responsibility for determining which product is most suitable and
ensuring that requirements on performance, safety and warnings are met for all machines.
It is important that the machine will be analysed in all details.
When choosing a control system and level of safety, ISO 13849 (Safety-related parts of control systems)
may provide suitable help.
