Danfoss TS3 User manual

TS3 Floor Sensor
Installation Instructions
Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also
applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specications already agreed.
Part No: 3498v01 08/07
Wiring
Specications
10KΩ±2% @ 25ºC
Encapsulated in Ø8mm x 50mm long Copper
Tube 2 meter PVC cable.
With end-stripped outer sheath 10mm, inner
core insulation 5mm.
Mounting
The oor sensor is recommended to be placed
in an installation pipe.
The oor sensor should be placed between two
pipes and near to the oor surface.
Floor sensor wiring
to thermostat
