Scroll compressors
VCH115
Single, R410A

Contents
Safety and warnings 4
Introduction 5
Product description 5
Cut Away VCH115 5
Vapor injection 5
Wet injection 6
Product identication 7
Name Plate 7
Nomenclature 7
Compressors serial number 7
Internal free volume 8
Refrigerants 9
General Information 9
R410A 9
Technical specication 10
Compressor size 10
Compressor specication 10
Sound and vibration data 11
Sound level and acoustic hood 11
Operating envelope data 12
Operating envelope 12
Dimensions 14
VCH115 14
VCH115 with IP54 E-Box 15
Mechanical connections 16
Connection Details 16
Design compressor mounting 16
System design generalities 17
Electrical connections 18
Wiring connections 18
Electrical specications 19
Scroll compressors, VCH115 | Contents
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 2

Frequency converter 21
Product identication 21
Technical specication 21
Dimensions 21
Electrical connections 22
Drive installation 23
Troubleshooting 24
Compressor and drive control 27
Application 32
Manage Operating enevlope 32
Manage sound and vibration 36
Oil return management 37
Manage Superheat 39
Manage o cycle migration 42
Assembly line procedure 44
Commissioning 47
Dismantle and disposal 48
Packaging 49
Single pack 49
Industrial pack 49
Frequency converter single pack 49
Ordering 50
Single pack 50
Industrial pack 50
Voltage code G-380 Volt 50
Accessories and Spare parts 51
Acoustic hoods - Lubricant, acoustic hoods and spare parts 51
E-box Plug 51
Mounting kits 51
Terminal boxes, covers & T-block connectors 51
Lubricant / oils 51
Spare parts for frequency converter 51
Discharge thermostats and sensors 51
Online support 52
Scroll compressors, VCH115 | Contents
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 3

Safety and warnings
Danfoss scroll compressors are designed and manufactured with state of the art technology. There is an added
emphasis placed on safety and reliability. Critical instructions are highlighted with the following icons:
This icon indicates instructions to avoid safety risk.
This icon indicates instructions to avoid reliability risk.
The purpose of this guideline is informational, with the intent to educate customers as to how the compressors
should properly function. If you need any additional assistance, please contact Danfoss Technichal Support. In any
case, Danfoss manufacturing accepts no liability as a result of misuse or improper integration of the compressor
unit.
Scroll compressors, VCH115 | Safety and warnings
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 4

1
2
3
4
6
5
Danfoss CA-000001
1
2
3
4
5
6
Optimize scroll sets PR, combine vapor injection,
and optimize eciency in heat pump application
Increase injection pipe diameter, and reduce pipe
vibration
Optimize structure design, reduce compressor
acoustic at high speed
New designed high eciency motor, improve
eciency at Part- load condition
Oil strainer reduce the oil stirring when
compressor running
Compact compressor outline design, benecial for
system unit layout
Introduction
Product description
Danfoss scroll compressor VCH115 for R410A is optimized for China low ambient heat pump and modular chiller
application.
Cut Away VCH115
Figure 1: Cut Away VCH115
Vapor injection
The VCH115 compressor is tted with an injection port that enables to carry out vapor injection by connecting an
intermediate exchanger.
This vapor injection will have three benets:
• Operating envelope enlargement by reduction of resulting discharge temperature.
• Cooling capacity and cooling eciency improvement by reduction of the liquid temperature before expansion
(Intermediate exchanger acting as economizer).
• Heat capacity and heating eciency improvement by increase of the massow at the condenser side (condenser
massow will be the sum of the evaporator massow and the injected massow).
The diagrams below explain the vapor injection principle, considering:
m inj: Injected massow
ΔT IntX: Dierence of temperature between the outlet of intermediate exchanger and the intermediate pressure
bubble point.
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 5
Scroll compressors, VCH115 | Introduction

P
Pc (m + mInj)
Inj SH
SHΔT IntX
SC
mInj
m
Pi
Pe
E
CC-000546
P
E
Pressure
Enthalpy
EXV
E
CC-000547
C
Sol v
EXV
Control
(Injec SH)
IE
C
E
IE
Condenser
Evaporator
Intermediate Exchanger
Suct SH: Superheat at compressor suction.
Inj SH: Superheat of injected gas (at intermediate pressure).
SC: Subcooling at intermediate exchanger inlet.
For system with vapor injection we should also consider, in addition of the suction superheat and the condenser
subcooling, the injection superheat and Intermediate exchanger DeltaT as key inuent parameters on the
compressor performance.
The injection massow must be regulated through an EXV piloted by the injection superheat which must be above
5 K.
It is recommended to install an additional solenoid valve on the injection line to prevent the refrigerant to come
back directly into the compressor scroll set in case of power shortage.
The vapor injection must not be activated during defrost course.
Wet injection
Whenever the vapor is no longer enough to cool the scroll and the application requires more envelope then the
controller must reduce the injection SH down to zero and control the injection by reading the compressor DGT. This
part is called wet (to dierentiate from liquid). There is no gain in eciency and capacity, only envelope.
Considering the distance between sensor and scroll set, the wet injection is activated for when discharge
temperature exceeds 121°C (250°F) at the measurement point (the surface of discharge pipe with 40mm away from
the compressor discharge port). A minimum 4K (7.2°F) subcooling is necessary to ensure correct wet
injection.Injection temperature set point is 130°C (266°F), maximum safety value is 135°C (275°F).
Scroll compressors, VCH115 | Introduction
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 6

中国制造
型号 : VCH115DGENA
序列号 : MK2500000123 380 V3 ~ 50 Hz
连接 CDC100 变频器
热电保护系统
设计压力
压力
最高温度
最低温度
容量
润滑剂 :P.O.E. 160SZ
低压 高压
33.3 bar
55 °C
-35 °C
10.6 L
频率 :90-420 Hz
速度 :30-140 rps
最大运行电流 : 65A
48.7 bar
150 °C
-35 °C
0.85 L
I
2021
制冷剂: R410A
876543210
受国内外专利保护
注意：变频压缩机只能丹佛斯认证过的变频器供电
Danfoss A/S, 6430 Nordborg, Denmark
1
4
5
6
7
2
3
1
2
3
4
5
6
7
Model number
Serial number
Refrigerant
Supply voltage to CDC frequency converter
Housing service pressure
Factory charged lubricant
Compressor frequency & Max operating current
Product identication
Name Plate
Figure 2: Name Plate
Nomenclature
The example below presents the compressor nomenclature which equals the technical reference as shown on the
compressor nameplate. Code numbers for ordering are listed in section Ordering.
ANEGD115C HV
Variable speed
Family
VCH scroll,
for China market
Lubricant
POE lubricant,
R410A refrigerant
Swept volume
in cm³/rev
Design pressure ratio
D: Vapor injection,
heating optimized
Evolution index
Motor protection type
N: no internal motor protection
(protection by drive)
Equipement version
E: brazed connection, no oil sight glass,
IP22 E-box
F: brazed connection, no oil sight glass,
IP54 E-Box
Motor voltage code to CDC100*
G: 380 V/ 3~ / 50 Hz
* main supply voltage to frequency converter
Compressors serial number
Year code 8 Digit serial number
12345678A 25B
Plant assembly line code
Month code
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 7
Scroll compressors, VCH115 | Product identication

Table 1: Serial number code legend table
Year code
Month code
Plant assembly line code
Year
Code
Month
Code
Plant
Code
1990, 2010
A
January
A
Trévoux, France
11
1991, 2011
B
February
B
1992, 2012
C
March
C
1993, 2013
D
April
D
Wuqing ,China
25
1994, 2014
E
May
E
1995, 2015
F
June
F
1996, 2016
G
July
G
1997, 2017
H
August
H
1998, 2018
J
September
J
1999, 2019
K
October
K
2000, 2020
L
November
L
2001, 2021
M
December
M
2002, 2022
N
2003, 2023
P
2004, 2024
Q
2005, 2025
R
2006, 2026
S
2007, 2027
T
2008, 2028
U
2009, 2029
V
Internal free volume
Table 2: Internal free volume
Products
Internal free volume at LP side without oil
litre
cu.inch
VCH115
10.6
647
Scroll compressors, VCH115 | Product identication
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 8

Refrigerants
General Information
When choosing a refrigerant, dierent aspects must be taken into consideration:
• Legislation (now and in the future)
• Safety
• Application envelope in relation to expected running conditions
• Compressor capacity and eciency
• Compressor manufacturer recommendations & Guidelines
Additional points could inuence the nal choice:
• Environmental considerations
• Standardisation of refrigerants and lubricants
• Refrigerant cost
• Refrigerant availability
R410A
R410A is a HFC blend (R32: 50%; R125: 50%) with a zero Ozone Depletion Potential (ODP=0) and a Global Warming
Potential of 1924/AR5 (2088/AR4). It is a near-azeotropic mixture with a temperature glide less than 0.2 K.
With its high net refrigeration eect coupled to a high density, the R410A has appeared in last decade to be the
preferred refrigerant for use in commercial air conditioners and heat pumps.
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 9
Scroll compressors, VCH115 | Refrigerants

Technical specication
Compressor size
Compressor can be sized on peak load, for best applied cost, or optimal eciency. For optimal eciency, see our
performance details in Coolselector software.
For regular updates and detailed capacities, please refer to Coolselector®2.
Compressor specication
Table 3: Compressor specication
Com‐
pressor
model
Swept volume
Displacement
Oil charge
Net weight
30 rps
60 rps
90 rps
120 rps
140 rps
cm3/rev
cu.in/rev
m³/h
cu.ft/h
m³/h
cu.ft/h
m³/h
cu.ft/h
m³/h
cu.ft/h
m³/h
cu.ft/h
dm³
oz
kg
lbs
VCH115
115
7.01
12.42
438
24.84
877
37.26
1315
49.68
1754
57.96
2046
3.3
128
62
136
Scroll compressors, VCH115 | Technical specication
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 10

Sound and vibration data
Typical sounds and vibrations in systems can be broken down into the following three categories:
• Sound radiation (through air)
• Mechanical vibrations (through parts and structure)
• Gas pulsation (through refrigerant)
The following sections focus on the causes and methods of mitigation for each of the above sources.
Sound level and acoustic hood
Model
Frequency RPS
Without accoustic hood (dBA)
Acoustic hood code
VCH115
120
89
120Z0850
VCH115 with IP54 E-Box
120
89
120Z0897
NOTE:
Nominal sound power for reference at ARI A/C (7.2°C/54.4°C/11.1°C/8.3°C) (45°F/130°F/20°F/15°F) conditions
measured in free space.
• Max. tolerance +3dBA for individual compressor.
• With acoustic hood in the table, acoustic can decrease 5~7dBA.
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 11
Scroll compressors, VCH115 | Sound and vibration data

Operating envelope data
Operating envelope
Figure 3: VCH115 envelop map (NO VI)- SSH5K
Condensing temperature (°C)
Evaporating temperature (°C)
5
10
15
20
25
30
35
40
45
50
55
60
65
70
-40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30
30-140rps
30-120rps
Condensing temperature (°F)
41
50
59
68
77
86
95
104
113
122
131
140
149
158
Danfoss
OE-000001
Evaporating temperature (°F)
-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86
Figure 4: VCH115 envelop map (with VI)-SSH5K
Condensing temperature (°C)
Evaporating temperature (°C)
5
10
15
20
25
30
35
40
45
50
55
60
65
70
-40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30
30-140rps
40-140rps
40-120rps 40-120rps
Wet injection area
Condensing temperature (°F)
41
50
59
68
77
86
95
104
113
122
131
140
149
158
Danfoss
OE-000002
Evaporating temperature (°F)
-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86
NOTE:
The solid line envelope is valid for a suction superheat with 5K at nominal voltage.
Higher suction superheat may lead to discharge temperature above 135° and map shrinkage for No VI and VI area.
Scroll compressors, VCH115 | Operating envelope data
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 12

Pressure settings
Table 4: Pressure settings
Pressure settings
R410A
bar (g)
psi (g)
Working pressure range low side
1.2~13.4
17~194
Working pressure range high side
9.8~41.6
142.3~603.6
Maximum high pressure safety switch setting
44
638
Minimum low pressure safety switch setting
1
14.5
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 13
Scroll compressors, VCH115 | Operating envelope data

Dimensions
VCH115
Figure 5: Outline drawing
H3
H2
H1
H4
L4
L3
L1
L2
Danfoss
Di-000002
Table 5: Dimensions for VCH115
Compressor
model
D
H1
H2
H3
H4
L1
L2
L3
L4
Outline
drawing
number
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
VCH115
224.3
8.83
291.4
11.47
485.4
19.11
520.9
20.51
353.4
13.9
231
9.09
231
9.09
190.5
7.5
171.1
6.74
8560210
Also refer Grommets and Wiring connections
Scroll compressors, VCH115 | Dimensions
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 14

VCH115 with IP54 E-Box
Figure 6: Outline drawing
H4
L2 L4
L1
L3
H1
H2
H3
Danfoss
Di-8560250
Table 6: Dimensions for VCH115 with IP54 E-Box
Compressor
model
D
H1
H2
H3
H4
L1
L2
L3
L4
Outline
drawing
number
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
VCH115 with
IP54 E-Box
224.3
8.83
291.4
11.47
485.4
19.11
520.9
20.51
353.4
13.9
231
9.09
231
9.09
190.5
7.5
191.7
7.54
8560250
Also refer Grommets and Wiring connections
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 15
Scroll compressors, VCH115 | Dimensions

Mechanical connections
Connection Details
Table 7: Connection Details
Connection Details
VCH115
Suction connection
1"5/8
Discharge connection
1"1/8
EVI connection
Ø13
Outline
1
Figure 7: Outline drawing 1
CC000195
Table 8: Brazed connection
Compressor models
Brazed
connection
size
VCH115
Suction
1"5/8
VCH115
Discharge
1"1/8
VCH compressor is all delivered with suction and discharge brazed connections only. They are copper-plated steel
connections.
Design compressor mounting
Grommets
Compressors must be mounted with exible grommets and metal sleeve delivered with compressor. The grommets
attenuate the transmission of compressor vibrations to the base frame. The grommets must be compressed until
contact between the at washer and the steel mounting sleeve is established.
The required bolt size for the VCH115 compressor is HM8-40. This bolt must be tightened to a torque of 15 Nm (11
ft/lbs.).
Scroll compressors, VCH115 | Mechanical connections
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 16

15 mm
(0.59 Inch)
1
2
3
4
5
6
7
cc-0048
1
2
3
4
5
6
7
Tightening torque 15 Nm
HM 8 bolt
Lock washer
Flat washer
Steel mounting sleeve
Rubber grommet
Nut
Figure 8: Grommets for VCH115
Max inclination
During operation, the maximum inclination from the vertical plane must not exceed 3 degrees.
System design generalities
Compressor capacity and modulation
Usually, compressors are selected to cover peak load cooling/heating capacities between 70-140 rps.
Modulation (dierence between minimum speed and maximum speed) is a very important point for unit design.
The larger the modulation number, the challenging the unit design will be. This would consequently increase unit
cost.
The minimum compressor speed must be dened according to unit need. It often makes sense to set unit minimum
speed higher than minimum compressor speed qualied by Danfoss.
Dierences between variable speed and x in speed unit design
Variable speed compressors were created with state of the art technology with the intent to be ecient and
precise. Speed variations have led to challenges that must be addressed by unit design.
Variable speed compressor is a great technology to design ecient and precise unit, however, speed variation leads
to challenges that must be addressed by unit design. The rst challenge is linked to part of the load operation. Unit
design must ensure that oil is returning back to the compressor, even while it is at the lowest speed. The expansion
device must also ensure safe superheat across speed range. The second challenge is due to variation of speed itself.
On the opposite hand, on a variable speed system, compressor speed is permanently changing according to load.
Consequently, expansion valve must adapt quickly enough to guaranty proper superheat control during transient.
Variation of compressor speed can also lead it’s own challenges for vibrations. While in x speed, only one frequency
is excited by the compressor. In variable speed, the whole compressor frequency range may excite the system. The
chance of going through resonant frequency is then more greatly increased. The following chapters give details
advices to integrate variable speed compressor in a unit. Designing a variable speed unit requires to go through all
of them to dene necessary safeties and qualications.
Compressor and
drive control
Superheat Man-
agement
Oil return man-
agement
Operating enve-
lope
compressor Me-
chanical installa-
tion
Sound and vibra-
tions manage-
ment
Drive installation
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 17
Scroll compressors, VCH115 | Mechanical connections

2
1
cc-000194
C
T
1T
2
RT
3
S
1
2
Ø 36 mm (1.4 inch) hole
Power supply
Electrical connections
Wiring connections
Electrical power is connected to the compressor terminals by #10-32 UNF 2A screws. The maximum tightening
torque is 3 Nm. Use a 1/4" ring terminal on the power leads.
For VCH115 model, a special Plug should be used on the E-Box before connecting the electric wire to protect
against accidental contact with electrical parts inside and protect against the wire and E-Box hard contacting.
The special Plug is in the accessory list, customer can book it independently. It is also OK that customer make the
plug by themself.
VCH115 with IP54 E-Box is IP class optimization. For VCH115 with IP54 E-Box model, a cable gland, conduit
connector or approved electrical ttings must be used on electrical box's knockouts to protect against accidental
contact with electrical parts inside.
Motor protection
VCH scroll compressors are not equipped with an internal motor protector. Motor protection is provided by the
variable speed drive. All parameters are factory preset in order to guaranty locked rotor or overload current
protection.
When a warning situation is reached in the current control, the CDC100 frequency converter will automatically
reduce the compressor speed in order to keep the motor current of the compressor below the maximum allowed.
VCH115
The terminal box is provided with a Ø36mm (Ø1.4 inch) U hole for power supply.
Figure 9: Terminal box for VCH115
VCH115 with IP54 E-Box
The terminal box is provided with a Φ40.5mm (Φ1.59inch) hole (ISO40) for power supply and a Φ16.5mm
(Φ0.65inch) knockout (ISO16).
Scroll compressors, VCH115 | Electrical connections
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 18

3
2
1
CC-0400
1
2
3
Ø 16.5mm (φ0.65inch) knockout
Ø 40.5mm (φ1.59inch) hole
Power supply
Figure 10: terminal box for VCH115 with IP54 E-Box
Electrical specications
IP rating
VCH115 compressor terminal box IP rating according to IEC60529 is IP22 after installing the U Plug 120Z0852 on the
E-Box.
VCH115 with IP54 E-Box compressor terminal box IP rating according to IEC60529 is IP54 when correctly sized IP54
rated cable glands are used.
Element
Numerals or letters
Meaning for the protection of equipment
First characteristic numeral
Against ingress of solid foreign objects
0
(non protected)
1
≥ 50 mm diameter
2
≥ 12.6 mm diameter
3
≥ 2.5 mm diameter
4
≥ 1.0 mm diameter
5
dust protected
6
dust tight
Second characteristic numeral
Against ingress of water with harmful
eects
0
(non protected)
1
vertically dripping
2
dripping (15° tilted)
3
spaying
4
splashing
5
jetting
6
powerful jetting
7
temporary immersion
8
continuous immersion
MCCB / FUSE / Contactor
Danfoss recommends using the fuses/circuit breakers to protect service personnel and property in case of
component break-down in the frequency converter.
Table 9: MCCB / FUSE / Contactor
Model
Power
model
MCCB
Contactor
gG fuse
Recommended circuit
breaker
Maximum fuse
IP20
[kW]
[A]
[A]
[A]
Moeller type
3 × 380 V
25TR/VCH115
30
CDC100
100
100
80
NZMB1-A100
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 19
Scroll compressors, VCH115 | Electrical connections

Compressors 3 phase electrical characteristics
Table 10: Compressors 3 phase electrical characteristics
Volt
Compressor
RW(1)
MOC
(Ohm)
(A)
380V
VCH115
0.037
65A
(1) Winding resistance per winding (in CDC100 parameter list) (1) Winding resistance per winding (in CDC100 parameter list)
NOTE:
Parameter 1-30 in the frequency converter settings reects the winding resistance per winding. This is not the same
value as measured at the motor terminals.
MOC (Max Operating Current)
Max. operating current is the max. continuous current output from drive to compressor within operating map.
MOC is tested at max. load condition with nominal voltage.
MOC is printed on the nameplate, it can be used to select cable and contactor for customer by adding some safety
coecient.
Phase sequence and reverse rotation protection
The compressor will only operate properly in a single direction. If electrical connections are done correctly
between the drive and the compressor terminals (compressor T1/T2/T3 and drive terminals U, V & W matching), the
drive will provide correct phase supply to the compressor, and reverse rotation will be not possible:
• CDC100 terminal U to VCH terminal T1
• CDC100 terminal V to VCH terminal T2
• CDC100 terminal W to VCH terminal T3
If compressor T1/T2/T3 and drive U, V & W terminals are not matching, the compressor can operate in a reverse
rotation. This results in excessive noise and no pressure dierential between suction and discharge, and suction line
warming rather than immediate cooling. The compressor can be rapidly damaged in these conditions. Reverse
rotation of the compressor for only a few seconds can quickly cause irreversible damage to the scroll sets. Before
starting always review the wiring and be prepared to shuto immediately in case of noise. If reverse rotation
symptoms occur, shut the compressor down and connect the phases to their proper terminals. Allow the
compressor to run and then check amps at operating condition versus Danfoss published performance data to see if
there was damage.
Scroll compressors, VCH115 | Electrical connections
© Danfoss | Climate Solutions | 2023.08 AB392939083370en-000202 | 20
