Danfoss EKE User manual

080R0407 080R0407
© Danfoss | Climate solutions | 2023.07
Superheat controller EKE 100 is for use where superheat must be accurately controlled or as driver for
stepper motor valves typically in air conditioning, heat pumps, commercial refrigeration, food retailing
and industrial application.
Compatible valves: ETS 6, ETS 8M(Bipolar)/ETS C/KVS C/ ETS L/ETS 500-800P/ CCMT L/CCMT/CCM/CTR
Basic application
Introduction
EKE 100 1V SH control
EKE 100 2V SH control
Danfoss
R64-3033.10
Danfoss
R
64-3033.1
0
S2 Pe
ETS Colibri®
RS485
Communication
Valve A
EKE 2U
AA
S2 Pe
ETS Colibri®
RS485
Communication
Valve A
Valve B
EKE 2U
AA
S2 Pe
ETS Colibri®
AA
089
Info for UK customers only: Danfoss Ltd., 22 Wycombe End, HP9 1NB, GB :  “ ”04080,  80, / 168, 
Installation guide
EKE
Type EKE 100
AN433741508202en-000203 | 1

© Danfoss | Climate solutions | 2023.07
Dimension
BAT -BAT + B2 B1 A2 A1 B2 B1 A2 A1 B- A+ GND
Valve AValve BMODBUS
-/AC+/ACPE
+SV +SV DO PeAPeB
S2AS2B D11D12
Power
EXT-GND GND GND GND GND GND GND GND
70 mm
110 mm
