Danfoss OF7S1 User manual

Installation Guide
Sine-wave Filter OF7S1
2.4–170 A
drives.danfoss.com

•
•
•
•
-
-
1 Instructions
1.1 Safety and Installation Awareness
Before starting installation, review all safety guidelines and precautions in this guide. Additional resources – including the drive in-
stallation guide and the application guide – can be downloaded at www.danfoss.com/service-and-support.
1.2 Qualified Personnel
The products must only be assembled, installed, programmed, commissioned, maintained, and decommissioned by persons with
proven skills. Persons with proven skills:
Are qualified electrical engineers, or persons who have received training from qualified electrical engineers and are suitably
experienced to operate devices, systems, plant, and machinery in accordance with the general standards and guidelines for
safety technology.
Are familiar with the basic regulations concerning health and safety/accident prevention.
Have read and understood the safety guidelines given in this manual and also the instructions given in the operating guide of
the drive.
Have good knowledge of the generic and specialist standards applicable to the specific application.
1.3 Safety Symbols
The following symbols are used in this guide:
DANGER
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE
Indicates information considered important, but not hazard-related (for example, messages relating to property damage).
1.4 Safety Precautions
NOTICE
The Sine-wave Filter OF7S1 is designed and qualified for use only with iC7 frequency converters.
A specific sine-wave filter must be matched to a specific iC7 frequency converter. For more details, refer to the iC7-Automa-
tion Frequency Converters, 1.3–1260 A Design Guide.
Danfoss takes no responsibility for the use of third-party output filters installed with Danfoss frequency converters.
AN405139032638en-000201 / 136R0277 | 3Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

-
-
-
-
-
-
-
-
-
-
-
-
-
WARNING
LIFTING HEAVY LOAD
The filter is heavy. Failure to follow local safety regulations for lifting heavy weights may cause death, personal injury, or property
damage.
Follow local regulations for lifting.
Check the weight of the filter. The weight is provided on the outside of the shipping box and the exterior of the filter.
If needed, ensure that the lifting equipment is in proper working condition and can safely lift the weight of the filter.
Use the integrated lifting eyes to lift the filter.
Test lift the unit to verify the proper center of gravity lift point. Reposition if not level.
WARNING
HAZARDOUS VOLTAGE
Sine-wave filters contain hazardous voltage when connected to an iC7 drive. Failure to perform installation, start-up, and mainte-
nance by qualified personnel can result in death or serious injury.
Only qualified personnel must perform installation, start-up, and maintenance.
Never work on a filter in operation.
WARNING
DISCHARGE TIME
The drive and filter contain capacitors that can remain charged even when the drive is powered off. High voltage can be present
in filter terminals even when the drive's warning indicator lights are off. Failure to wait the specified time after power has been
removed before performing service or repair work can result in death or serious injury.
Stop the motor.
Disconnect all power sources, including permanent magnet type motors.
Wait for the drive capacitors to discharge fully. The discharge time is shown on the exterior of the drive.
Verify full discharge by measuring the voltage level between the motor phases on the filter's output terminals (U2, V2, W2).
WARNING
INDUCED VOLTAGE
Induced voltage from output motor cables that run together can charge equipment capacitors, even with the equipment turned
off and locked out. Failure to run output motor cables separately or to use shielded cables could result in death or serious injury.
Run output motor cables separately or use shielded cables.
Simultaneously lock out all the drives.
AN405139032638en-000201 / 136R02774 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

•
•
•
•
•
-
-
-
-
-
-
-
WARNING
ELECTRICAL SHOCK HAZARD
Due to the stray capacitance of the shielded motor cable, the leakage currents exceed 3.5 mA. Failure to connect the drive or filter
properly to protective earth may result in death or serious injury.
Ensure minimum size of the ground conductor complies with the local safety regulations for high touch current equipment.
Ensure reinforced protective earthing (PE) conductor according to IEC 60364-5-54 cl. 543.7 or local safety regulations for
equipment with leakage current >3.5 mA.
The reinforced protective earthing can be done with:
PE conductor with a cross-section of at least 10 mm2(8 AWG) Cu or 16 mm2(6 AWG) Al, or an additional PE conductor of the
same cross-sectional area as the original PE conductor as specified by IEC 60364-5-54, with a minimum cross-sectional area
of 2.5 mm2(14 AWG) mechanically protected or 4 mm2(12 AWG) not mechanically protected.
PE conductor completely enclosed within an enclosure or otherwise protected throughout its length against mechanical
damage.
PE conductor that is part of a multi-conductor power cable with a minimum PE conductor cross-section of 2.5 mm2(14 AWG)
that is permanently connected or plugged in by an industrial connector. The multi-conductor power cable must be installed
with an appropriate strain relief.
CAUTION
INTERNAL FAILURE HAZARD
An internal failure in the filter can result in serious injury when the filter cover is not properly secured.
Ensure that all safety covers are in place and securely fastened before applying power.
CAUTION
BURN HAZARD
The IP00/Open Type filter model (S1C02–S1C08) does not have protective covers over all components that may still be hot even
after the unit has been powered off. Failure to avoid touching these components can result in serious burns.
Install the IP00/Open Type filter in an enclosed cabinet.
Do not touch exterior areas that are marked by the high temperature symbol (yellow triangle). These areas are hot while the
drive and filter are in use and immediately after being powered off.
WARNING
ELECTRIC SHOCK
The IP00/Open Type filter model (S1C02–S1C08) does not have protective covers over all high-voltage components. Failure to
avoid touching these components can result in death or serious injury.
Install the IP00/Open Type filter inside a supplementary enclosure or in a restricted-access area that provides protection
against electric shock.
1.5 Required Tools
Lifting aid
Tape measurer
Wrench with extension and various sockets (see the wiring illustrations for the specific size)
Torx, slotted, and Pozidrive screwdrivers (T20, T30, T50, SL1.2, SL2, PZ3)
Wire crimper
1.6 Verifying the Shipment and the Contents
Make sure that the items supplied and the information on the product label correspond to the order confirmation. The product
label is found on the front of the filter.
AN405139032638en-000201 / 136R0277 | 5Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

•
•
•
•
5
6
7
8
9
10
4
3
2
1
e30bj554.10
Illustration 1: Example of a Product Label
1
Product type
2
Type code
3
Part number
4
Voltage range, motor frequency, and current
5
Serial number
6
Inductance value
7
Capacitance value
8
Minimum switching frequency
9
Terminal torque for motor cables
10
Frame
1.7 EMC-compliant Installation
Follow the same guidelines for filter installation as for drive installation. For EMC-compliant installation guidelines, refer to the drive
design or installation guide, and follow the electrical installation instructions.
Shielded cables or unshielded cables within metal conduit are required between the filter and the drive, and between the filter
and the motor.
Connect the shield to the filter at both ends.
Provide a minimum 200 mm (7.9 in) separation, if possible, between mains input, motor cables, and control cables.
Convey the currents back to the unit using the included EMC plate. Ensure good electrical contact from the EMC plate through
the mounting screws to the filter chassis. The EMC plate must be mounted during filter installation.
AN405139032638en-000201 / 136R02776 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

•
•
•
•
•
1.
2.
-a.
-b.
3.
4.
-
-
-
5.
6.
-
-
-
1.8 Installing the Filter
Installation location is important. Full nominal current is available when the following installation conditions are met:
Maximum surrounding air temperature is 45 °C (113 °F)
Minimum surrounding air temperature is -30 °C (-22 °F).
Altitude is less than 1000 m (3280 ft) above sea level.
There is enough free space above and below the filter.
Vibration levels according to IEC 60721-3-3:2019 have been considered.
For temperatures and altitudes outside this range, as well as derating values, see 1.11 Specifications.
Identify the sine-wave filter frame. See Illustration 1.
If the reference in an illustration, text, or table applies to all variants, the second character is replaced with an x, for exam-
ple S1x02, indicating both S1A02 and S1C02.
Make sure that the operating environment and electrical installation meet the environmental conditions according to IEC
61800-2:2021. Unless stated otherwise, the same standards apply for the filters as for the drives.
Indoor unconditioned/pollution degree 2.
Overvoltage category 3.
Provide required clearance above and below the filter. See step 2 in the Illustrations section.
Mount the filter on or against a solid, non-combustible mounting surface such as concrete or metal.
For S1x02–S1x04, use 4 screws for vibration levels specified in IEC 60721-3-3:2019 3M11 and IEC 60721-3.3:2019 3M12.
For S1x05–S1x08, use 4 screws for vibration levels specified in IEC 60721-3-3:2019 3M11.
For S1x05–S1x08, use 8 screws for vibration levels specified in IEC 60721-3-3:2019 3M12.
Install the filter following steps 1–3 in the Illustrations section. Certain illustrations or steps apply to specific filter frames
and are marked as such.
Configure the specific drive parameters (P3.5.1, P3.5.2, and P3.5.3) for sine-wave filter operation. Setting too low a switching
frequency can damage the filter. For information on configuring parameters, see the iC7 application guide.
1.9 Fuses and Cable Sizes
NOTICE
WIRING GUIDELINES
All wiring must comply with local and national regulations regarding cross-section and ambient temperature requirements.
Loose connections can cause equipment faults or reduced performance. Tighten the terminals according to the proper torque
value shown in the illustrations.
Minimize interference by keeping control wires as short as possible and separate from high-power cables.
Tighten the terminals according to the proper torque value shown in the illustrations.
Follow the same guidelines for filter cables as for drive cables. For more information, refer to the iC7-Automation Frequency
Converters, 1.3–1260 A Design Guide.
AN405139032638en-000201 / 136R0277 | 7Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

1.10 Illustrations
e30bb047.10
1
S1x02–S1x03
1.1
1.2
– [1.8 Nm (16 in-lb)]
T1
T1
Illustration 2:
AN405139032638en-000201 / 136R02778 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

S1x04–S1x05
e30bb048.10
1.1
1.2
– [3.5 Nm (31 in-lb)]
T1
T1
S1x05
Illustration 3:
AN405139032638en-000201 / 136R0277 | 9Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

e30bb052.10
S1x06–S1x08
T1
1.2
1.3
T1
1.1
– [6 Nm (53 in-lb)]
Illustration 4:
AN405139032638en-000201 / 136R027710 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

X
X
X
B
A
2
2.1 2.2
mm (in)
A
B
C1 107 (4.2)
4 x M5
e30bb045.10
0 mm
(0.0 in)
X
C2
C1
257 (10.1)
94 (3.7)
S1x02–S1x04 S1x02 S1x03
107 (4.2)
4 x M5
257 (10.1)
70 (2.8)
107 (4.2)
4 x M6
380 (15.0)
105 (4.1)
S1x04
2x
C2 107 (4.2)
107 (4.2) 161 (6.3)
Illustration 5:
AN405139032638en-000201 / 136R0277 | 11Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

XXX
A
C2
C1
e30bb046.10
X
2.1 2.2
S1x05–S1x08
XXXX
B/2 B/2
4x
0 mm
(0.0 in)
B
S1x05
S1x06
S1x07
S1x08
mm (in) A BB/2 C1
380 (15.0) 140 (5.5) 40 (1.6) 107 (3.9) 4–8 x M6
535 (21.1) 170 (6.7) 40 (1.6) 112 (4.4) 4–8 x M8
580 (22.8) 200 (7.9) 45 (1.8) 112 (4.4) 4–8 x M8
721 (28.4) 200(7.9) 45 (1.8) 112 (4.4) 4–8 x M8
C2
160 (6.2)
160 (6.2)
208 (8.2)
260 (10.2)
Illustration 6:
AN405139032638en-000201 / 136R027712 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

e30bb050.10
3S1x02–S1x03
U2, V2, W2
U1, V1, W1
L1
L2
L3
U
V
W
U1
V1
W1
U2
V2
W2
U
V
W
1.2–2.0 Nm (11–18 in-lb)
U1, V1, W1
U2, V2, W2 1.2–2.0 Nm (11–18 in-lb)
S1x02
U1, V1, W1
U2, V2, W2
1.2–2.0 Nm (11–18 in-lb)
1.2–2.0 Nm (11–18 in-lb)
S1x03
SL1
T20
10
mm
1.8 Nm (16 in-lb)
1.8 Nm (16 in-lb)
Fx02–Fx03 S1x02–S1x03
15 m (49 ft)
6.0 Nm (53 in-lb)
1.8 Nm (16 in-lb)
6.0 Nm (53 in-lb)
Illustration 7:
AN405139032638en-000201 / 136R0277 | 13Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

L1
L2
L3
U
V
W
U1
V1
W1
U2
V2
W2
U
V
W
e30bb051.10
S1x04–S1x05
U1, V1, W1
U2, V2, W2
2.0–4.0 Nm (18–35 in-lb)
U1, V1, W1
U2, V2, W2
2.0–4.0 Nm (18–35 in-lb)
S1x04
U1, V1, W1
U2, V2, W2
2.5–5.0 Nm (22–44 in-lb)
2.5–5.0 Nm (22–44 in-lb)
S1x05
SL1
SL2
T20
PZ3
10
mm
2.0 Nm (18 in-lb)
6.0 Nm (53 in-lb)
6.0 Nm (53 in-lb)
S1x04–S1x05
Fx04–Fx05
15 m (49 ft)
Illustration 8:
AN405139032638en-000201 / 136R027714 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

e30bb053.10
S1x06–S1x08
4.4 4.5 4.6 4.7
50 mm (1 AWG)
2
2
95 mm (3/0 AWG)
2
150 mm (300 mcm)
S1x06
S1x07
S1x08
2
50 mm (1 AWG)
2
35 mm (2 AWG)
2
16 mm (6 AWG)
4.1
4.2
4.3
Illustration 9:
AN405139032638en-000201 / 136R0277 | 15Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

e30bb054.10
6 Nm (53 in-lb)
14 Nm (124 in-lb)
U1, V1, W1
U2, V2, W2 14 Nm (124 in-lb)
S1x06
SL1, SL2, PZ3, T30
S1x06–S1x07
SL2, PZ3, T30, T50
S1x08
10
mm
4.8
L1
L2
L3
U
V
W
U1
V1
W1
U2
V2
W2
U
V
W
S1x06–S1x08
Fx06–Fx08
13
mm
6 Nm (53 in-lb)
14 Nm (124 in-lb)
U1, V1, W1
U2, V2, W2 14 Nm (124 in-lb)
S1x07
14.5 Nm (128 in-lb)
20 Nm (177 in-lb)
U1, V1, W1
U2, V2, W2
20 Nm (177 in-lb)
S1x08
15 m (49 ft)
4.10
4.9
6 Nm (53 in-lb)
U1, V1, W1
U2, V2, W2
2 Nm (18 in-lb)
4 Nm (35 in-lb)
S1x06
S1x07–S1x08
Illustration 10:
AN405139032638en-000201 / 136R027716 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

1.11 Specifications
1.11.1 Product Approvals and Certifications
Sine-wave Filter OF7S1 complies with the required standards and directives. For a list of product approvals and certifications, see
the product label. Certificates and Declarations of Conformity are available on request or at www.danfoss.com.
Table 1: Approvals and Certifications Applicable to the Sine-wave Filter
Approval
Description
The sine-wave filter complies with relevant directives and their related standards for the extended Single Market in
the European Economic Area. The filter complies with EN/IEC 61558-2-20:2011.
The Underwriters Laboratory (UL) mark indicates the safety of products and their environmental claims based on
standardized testing. The sine-wave filters are UL-certified up to 500 V. The filter complies with UL 508. For the UL
file number, see the product label.
1.11.2 Operating Environment
Table 2: Operating Environment Specifications for the Sine-wave Filter
Function
Data
Ambient temperature during transport
-30 °C...+70 °C (-22 °F...+158 °F)
Ambient temperature during storage
-30 °C...+70 °C (-22 °F...+158 °F)
Ambient temperature during operation
Minimum (without derating): -30 °C (-22 °F)
Maximum (without derating): 45 °C (113 °F)
Maximum (with derating)(1): 60 °C (140 °F)
Altitude
Maximum (without derating): 1000 m (3250 ft)
Maximum (with derating)(2): 5000 m (16400 ft)
Humidity (non-condensing)
95 (%)
Chemically active substances
C3
Pollution degree
3
Vibration
IEC 60721-3-3:2019 3M11: Standard classification requires 4 screws to install frames
S1x02–S1x08.
IEC 60721-3-3:2019 3M12: Medium classification requires 4 screws to install frames
S1x02–S1x04.
IEC 60721-3-3:2019 3M12: Medium classification requires 8 screws to install frames
S1x05–S1x08.
1Derating: 1%/K from 45 °C (113 °F)
2Derating: 5% of nominal filter current per every 1000 m (3250 ft)
AN405139032638en-000201 / 136R0277 | 17Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

1.11.3 Mechanical Specifications
Table 3: Weight and Terminal Cable Size for the Sine-wave Filter
P/N
Weight [kg (lb)]
Terminal cable size [mm2(AWG)]
Minimum
Maximum
132H4239
3.9 (9)
0.2 (22)
10 (10)
132H5061
4.5 (10)
0.2 (22)
10 (10)
132H5062
7.1 (16)
0.2 (22)
10 (10)
132H5063
8.9 (20)
0.2 (22)
10 (10)
132H5064
12.4 (27)
0.2 (22)
10 (10)
132H5065
22.7 (50)
1.0 (18)
16 (4)
132H5066
30.9 (68)
2.5 (12)
35 (2)
132H5067
55.6 (123)
2.5 (6)
50 (1/0)
132H5068
81.8 (180)
16 (4)
95 (4/0)
132H5069
104.8 (231)
35 (2)
150 (300)
132H5070
5.4 (12)
0.2 (22)
10 (10)
132H5071
6.0 (13)
0.2 (22)
10 (10)
132H5072
8.6 (19)
0.2 (22)
10 (10)
132H5073
10.4 (23)
0.2 (22)
10 (10)
132H5074
14.0 (31)
0.2 (22)
10 (10)
132H5075
25.2 (56)
1.0 (18)
16 (6)
132H5077
33.6 (74)
2.5 (12)
35 (2)
132H5078
60.3 (133)
2.5 (6)
50 (1/0)
132H5080
87.0 (192)
16 (4)
95 (4/0)
132H5081
112.5 (248)
35 (2)
150 (300)
AN405139032638en-000201 / 136R027718 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

A
B
C
D
E
F1
G
HI
J
K
I
A
B
AB
F2
F2
e30bb055.10
[]
[]
[]
Illustration 11: Example of a Sine-wave Filter Cabinet
Table 4: Exterior Dimensions for the Sine-wave Filter, [mm (in)]
P/N
A
B
C
D
E
F1(1)
F2(1)
G
H
I
J
K
132H4239
270
(10.6)
87 (3.4)
202 (7.9)
218 (8.5)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5061
270
(10.6)
87 (3.4)
202 (7.9)
218 (8.5)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5062
270
(10.6)
87 (3.4)
202 (7.9)
218 (8.5)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5063
270
(10.6)
87 (3.4)
202 (7.9)
218 (8.5)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5064
270
(10.6)
111
(4.3)
211 (8.3)
340
(13.3)
257
(10.1)
94
(3.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5065
399
(15.7)
127
(5.0)
237 (9.3)
503
(19.8)
380
(14.9)
105
(4.1)
–
15
(0.5)
8 (0.3)
7 (0.2)
12.5
(0.4)
11
(0.4)
132H5066
399
(15.7)
162
(6.3)
256 (10.0)
522
(20.5)
380
(14.9)
140
(5.5)
40
(1.5)
15
(0.5)
8 (0.3)
7 (0.2)
12.5
(0.4)
11
(0.4)
132H5067
555
(21.8)
197
(7.7)
276 (10.8)
668
(26.2)
535
(21.0)
170
(6.6)
40
(1.5)
23
(0.9)
12
(0.4)
10
(0.3)
16
(0.6)
8 (0.3)
132H5068
600
(23.6)
227
(8.9)
292 (11.4)
760
(29.9)
580
(22.8)
200
(7.8)
45
(1.7)
23
(0.9)
12
(0.4)
10
(0.3)
16
(0.6)
8 (0.3)
AN405139032638en-000201 / 136R0277 | 19Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide

P/N
A
B
C
D
E
F1(1)
F2(1)
G
H
I
J
K
132H5069
743
(29.2)
255
(10.0)
367 (14.4)
943
(37.1)
721
(28.3)
200
(7.8)
45
(1.7)
23
(0.9)
12
(0.4)
10
(0.3)
16
(0.6)
10
(0.3)
132H5070
270
(10.6)
90 (3.5)
221 (8.7)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5071
270
(10.6)
90 (3.5)
221 (8.7)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5072
270
(10.6)
90 (3.5)
221 (8.7)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5073
270
(10.6)
90 (3.5)
221 (8.7)
340
(13.3)
257
(10.1)
70
(2.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5074
270
(10.6)
114
(4.4)
221 (8.7)
340
(13.3)
257
(10.1)
94
(3.7)
–
14.5
(0.5)
6.5
(0.2)
5.5
(0.2)
11
(0.4)
6.5
(0.2)
132H5075
399
(15.7)
130
(5.1)
262 (10.3)
503
(19.8)
380
(14.9)
105
(4.1)
–
15
(0.5)
8 (0.3)
7 (0.2)
12.5
(0.4)
11
(0.4)
132H5077
399
(15.7)
165
(6.4)
269 (10.5)
522
(20.5)
380
(14.9)
140
(5.5)
40
(1.5)
15
(0.5)
8 (0.3)
7 (0.2)
12.5
(0.4)
11
(0.4)
132H5078
555
(21.8)
200
(7.8)
294 (11.5)
668
(26.2)
535
(21.0)
170
(6.6)
40
(1.5)
23
(0.9)
12
(0.4)
10
(0.3)
16
(0.6)
8 (0.3)
132H5080
600
(23.6)
230
(9.0)
308 (12.1)
760
(29.9)
580
(22.8)
200
(7.8)
45
(1.7)
23
(0.9)
12
(0.4)
10
(0.3)
16
(0.6)
8 (0.3)
132H5081
743
(29.2)
255
(10.0)
354 (13.9)
943
(37.1)
721
(28.3)
200
(7.8)
45
(1.7)
23
(0.9)
12
(0.4)
10
(0.3)
16
(0.6)
10
(0.3)
1For S1x02–S1x04, use 4 screws (F1) for vibration levels according to IEC 60721-3-3:2019 3M11 + IEC 60721-3-3:2019 3M12. For S1x05–S1x08, use 4
screws (F1) for vibration levels according to IEC 60721-3-3:2019 3M11. For S1x05–S1x08, use 8 screws (F1+F2) for vibration levels according to IEC
60721-3-3:2019 3M12.
1.11.4 Electrical Specifications
Table 5: Electrical Specifications for the Sine-wave Filter
Function
Data
Cooling
AN, natural convection
Overload rating
160% for 1 min every 10 min / 200% for 3 s every 1 min
Maximum motor cable length
150 m (492 ft) shielded cable without derating
300 m (984 ft) shielded cable with derating 3.3% per every 50 m (164 ft) from 150 m (492 ft)
300 m (984 ft) unshielded cable without derating
Switching frequency(1)
S1x02–S1x05: 3–16 KHz
S1x06–S1x08: 2–12 KHz
Discharge time
<5 s from motor standstill to voltage is below 60 V DC phase-phase
Filter impedance
Average 7% at 400 V, nominal current and 50 Hz motor frequency
AN405139032638en-000201 / 136R027720 | Danfoss A/S © 2022.05
Instructions
Sine-wave Filter OF7S1
Installation Guide
