DAPAudio EDGE EHS-1 User manual

EDGE EHS-1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Product code: D1475B
USER MANUAL
ENGLISH
V3

1
EDGE EHS-1
Product code: D1475B
Preface
Thank you for purchasing this DAP product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Installation and operation of the device
●Intended and non-intended use of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2023 DAP. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at [e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
EDGE EHS-1
Product code: D1475B
Table of contents
1. Introduction..........................................................................................................................................................4
Before Using the Product ..................................................................................................................................4
Intended Use .......................................................................................................................................................4
Product Lifespan.................................................................................................................................................4
Text Conventions ................................................................................................................................................4
Symbols and Signal Words................................................................................................................................5
Symbols on the Information Label ..................................................................................................................5
2. Safety ....................................................................................................................................................................6
Warnings and Safety Instructions ....................................................................................................................6
Requirements for the User.................................................................................................................................7
3. Description of the Device ...................................................................................................................................8
Receiver –Front View ........................................................................................................................................8
Receiver –Back View ........................................................................................................................................8
Microphone (Handheld Transmitter) ..............................................................................................................9
Product Specifications ....................................................................................................................................10
Optional Accessories.......................................................................................................................................11
Dimensions.........................................................................................................................................................12
4. Installation and Setup .......................................................................................................................................13
Ambient Conditions .........................................................................................................................................13
Installation..........................................................................................................................................................13
Single Receiver .......................................................................................................................................13
Two Receivers .........................................................................................................................................14
Setup...................................................................................................................................................................15
Installation of the Antennas..................................................................................................................15
Connecting to Power Supply ...............................................................................................................16
Power Linking of Multiple Devices...................................................................................................16
Setup Examples.......................................................................................................................................17
4 x EDGE EHS-1 ....................................................................................................................................17
8 x EDGE EHS-1 ....................................................................................................................................18
Connecting the Receiver to Mixer/Amplifier ....................................................................................18
Switching ON/OFF –Receiver ..............................................................................................................19
Installation of the Batteries ...................................................................................................................19
Switching ON/OFF –Transmitter...........................................................................................................20
Pairing .......................................................................................................................................................20
5. Operation ...........................................................................................................................................................20
Safety Instructions for Operation...................................................................................................................20
Operation ..........................................................................................................................................................21
Control Panel –Receiver ................................................................................................................................21
Main Menu Options ...............................................................................................................................22
Group ...................................................................................................................................................23
Channel ...............................................................................................................................................23
Frequency............................................................................................................................................23
Scan ......................................................................................................................................................24
Synchronization ..................................................................................................................................24
Lock.......................................................................................................................................................25
Transmitter Gain..................................................................................................................................25
Receiver Gain .....................................................................................................................................26
Low Cut ................................................................................................................................................26
Squelch ............................................................................................................................................27
Tone Key ..........................................................................................................................................27
Color .................................................................................................................................................28
Name................................................................................................................................................28
Antenna Power Supply .................................................................................................................29
Control Panel –Transmitter.............................................................................................................................30
Mute..........................................................................................................................................................30

3
EDGE EHS-1
Product code: D1475B
Main Menu Options ...............................................................................................................................30
Group ...................................................................................................................................................31
Channel ...............................................................................................................................................31
Frequency............................................................................................................................................31
Gain ......................................................................................................................................................32
RF Output Power ................................................................................................................................32
Lock.......................................................................................................................................................33
Channel and Frequency Overview..............................................................................................................34
6. Troubleshooting .................................................................................................................................................35
Adjusting the Microphone Gain....................................................................................................................35
7. Maintenance .....................................................................................................................................................36
Preventive Maintenance................................................................................................................................36
Basic Cleaning Instructions ...................................................................................................................36
Corrective Maintenance................................................................................................................................36
8. Deinstallation, Transportation and Storage ....................................................................................................36
9. Disposal ..............................................................................................................................................................37
10. Approval.............................................................................................................................................................37

4
EDGE EHS-1
Product code: D1475B
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
●DAP EDGE EHS-1 (receiver + transmitter)
●2 x antenna
●AC power adapter (1,4 m)
●Mono jack cable (1 m)
●Windshield cap
●Leather bag
●Microphone stickers
●User manual
Mounting kit:
●Long mounting bracket
●Short mounting bracket
●Mounting plate
●4 x mounting screw for the device
●4 x mounting screw for the 19-inch rack
Fig. 01
Intended Use
This device is intended for use as a wireless microphone system. It is suitable only for indoor installation.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Product Lifespan
This device is not designed for permanent operation. Disconnect the device from the electrical power
supply when the device is not in operation. This will reduce the wear and will improve the device’s
lifespan.
Text Conventions
Throughout the user manual the following text conventions are used:
●Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons”
●References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “press the power switch (03)”
●0–255: Defines a range of values
●Notes: Note: (in bold lettering) is followed by useful information or tips

5
EDGE EHS-1
Product code: D1475B
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates an imminently hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the bottom plate of
the device.
The information label contains the following symbols:
This device shall not be treated as household waste.

6
EDGE EHS-1
Product code: D1475B
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
●Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
Attention
Incorrect handling of the AC power adapter may result in hazardous situations
This device is delivered with an AC power adapter. Incorrect handling of the AC power adapter may
result in hazardous situations.
●Use only the AC power adapter delivered with the device.
●Do not wrap the power cable around the power adapter or any other object. This can damage the
internal wires.
●Do not cover the power adapter with anything when it is plugged into the socket-outlet. This may
cause overheating.
●Do not expose the power adapter to water or other liquids.
Do not use the power adapter:
●If it shows signs of overheating, for example the plastic is damaged
●If the AC input pins show signs of corrosion or overheating
●If the power cable is damaged or shows signs of material fatigue.
Attention
General safety
●Do not shake the device. Avoid brute force when installing or operating the device.
●If the device is dropped or struck, disconnect the device from the electrical power supply
immediately.
●If the device is exposed to extreme temperature variations (e.g. after transportation), do not switch it
on immediately. Let the device reach room temperature before switching it on, otherwise it may be
damaged by the formed condensation.
●If the device fails to work correctly, discontinue the use immediately.

7
EDGE EHS-1
Product code: D1475B
Attention
This device shall be used only for the purposes it is designed for.
This device is designed to be used as a wireless microphone system. Any incorrect use may lead to
hazardous situations and result in injuries and material damage.
●This device is not designed for permanent operation.
●This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Maintenance and installation may be carried by ordinary
persons. Service shall be carried out only by instructed or skilled persons. Contact your Highlite
International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the service of this product, so that they can
identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the service of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.

8
EDGE EHS-1
Product code: D1475B
3. Description of the Device
The EDGE EHS-1 is a wireless handheld system. The set consists of a handheld transmitter and a receiver.
The EDGE is suitable for voice transmission. The transmitter is powered by 2 x AA LR6 (alkaline) batteries
(not included).
Receiver –Front View
LCD display
Control (Menu/Select)
Return button
IR sensor
Power button
Fig. 02
Receiver –Back View
Fig. 03
Power cable safety eye
Ground/lift switch
3-pin XLR AF balanced OUT
12–15 V DC BNC connector (antenna A,
150 mA)
Mic/line switch
¼”/6,3 mm jack AF connector OUT
USB C connector (for firmware updates)
12–15 V DC power connector OUT (800 mA)
12–15 V DC power connector IN (800 mA)
12–15 V DC BNC connector (antenna B, 150 mA))

9
EDGE EHS-1
Product code: D1475B
Microphone (Handheld Transmitter)
Fig. 04
Microphone head
OLED display
Power button (on/off)
Battery cover
20) DOWN button
IR sensor
Transmitter antenna
Battery housing (2 x AA LR6)
SET button
25) UP button

10
EDGE EHS-1
Product code: D1475B
Product Specifications
Model:
EDGE EHS-1
Receiver
Electrical:
Input voltage:
100–240 V AC, 50/60 Hz
Output voltage:
12–15 V DC
Power consumption:
5,3 W
AC power adapter:
Input voltage:
100–240 V AC, 50/60 Hz
Output voltage:
15 V DC
Physical:
Dimensions:
205 x 225 x 44,5 mm (L x W x H), 1U
Installation depth:
220 mm
Weight:
1,24 kg
Audio specifications:
Frequency range:
610–668 MHz
Wireless stability:
0,0015 %
RF bandwidth:
60 MHz
THD level:
< 1,0 %
Signal-to-noise ratio:
> 100 dB
RF antenna input impedance:
50 Ω
Max. balanced audio output:
48 dBu
Receiver output impedance:
50 Ω
RF receiver antenna output voltage:
15 V
RF receiver antenna output current:
150 mA
Connections:
Power connection:
DC connectors IN/OUT
Output connections:
1 x 3-pin XLR connector OUT, balanced
1 x TS 6,3 mm jack connector OUT, unbalanced
Input RF connections:
2 x BNC connector (RF antenna input)
Operation and control:
Receiver type:
True diversity
Display:
OLED
Construction:
Housing:
Aluminum/metal
Color:
Black
IP rating:
IP20
Transmitter
Physical:
Dimensions:
Ø51 mm x 255 mm (WxH)
Diameter:
36 mm
Weight:
0,38 kg
Audio specifications:
Microphone type:
Condenser
Sensitivity:
2,2 mV

11
EDGE EHS-1
Product code: D1475B
Gain range:
30 dB
Polar pattern:
Cardioid
Frequency response:
60–18000 Hz
Maximum SPL:
130 dB
Frequency range:
610–668 MHz
Wireless stability:
0,0015 %
RF power:
30 mW
RF bandwidth:
60 MHz
Frequency deviation:
± 75 kHz
Spurious rejection:
≤ 50 dBC
Operation and control:
Display:
OLED
Construction:
Housing:
Aluminum
Color:
Black
IP rating:
IP20
Batteries:
Batteries:
2 x AA LR6 (alkaline) 1,5 V (not included)
Average runtime:
10 h
Thermal:
Maximum ambient temperature ta:
50 °C
Minimum ambient temperature:
0 °C
Optional Accessories
You can additionally purchase the following accessories:
●D1476B (EDGE EBS-1, 1-channel wireless bodypack system)
●D1477B (EDGE EHM-1, handheld condenser microphone)
●D1478B (EDGE EBT-1, bodypack)
●D1479B (EDGE EHS-2, 2-channel wireless handheld system)
●D1480B (EDGE EBS-2, 2-channel wireless bodypack system)
●D1485 (EDGE ED-1, antenna distributor)
●D1486 (EDGE EUA-1, set of 2 unidirectional antennas)
●D1487 (EDGE EOA-1, set of 2 omnidirectional antennas)

12
EDGE EHS-1
Product code: D1475B
Dimensions
Fig. 05

13
EDGE EHS-1
Product code: D1475B
4. Installation and Setup
Ambient Conditions
●The device can be used only indoors.
●The maximum ambient temperature ta= 50 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 50 °C.
Installation
The receiver can be put on a stable, flat surface, or can be mounted in a standard 19-inch rack. The
receiver requires 1 rack unit (U) of space, which is 44,45 mm high. Make sure that the rack is sufficiently
secured to prevent it from becoming unstable or falling over.
The device is supplied with 2 mounting brackets and mounting screws. It is possible to mount a single or
two receivers in a 19-inch rack.
To mount the receiver, you need a Phillips screwdriver.
To mount the receiver in a two-post rack, follow the steps below:
Attach the mounting brackets and/or the mounting plate to the receiver(s). See 4.2.1. Single
Receiver or 4.2.2. Two Receivers on pages 13–14 for more information.
Insert 4 cage nuts in the openings on the rack posts where you want to mount the receiver(s).
Position the receiver(s) in front of the rack posts so that the 4 x mounting openings on the mounting
brackets face the openings on the rack posts with cage nuts.
Use a screwdriver to mount the receiver(s) to the rack posts with 4 screws.
Single Receiver
Attach the supplied long and short mounting brackets with the mounting screws to the receiver.
Use a Philips screwdriver to tighten the mounting screws.
Fig. 06

14
EDGE EHS-1
Product code: D1475B
Two Receivers
Attach the supplied short mounting brackets with the mounting screws to the receivers. Use a Phillips
screwdriver to tighten the mounting screws.
Fig. 07
Attach the supplied mounting plate with the mounting screws to the bottom of both receivers. Use a
Phillips screwdriver to tighten the mounting screws.
Fig. 08

15
EDGE EHS-1
Product code: D1475B
Setup
To set up the wireless handheld system, follow the steps below:
Install the antennas. See 4.3.1. Installation of the Antennas on page 15.
Connect the receiver to power supply. See 4.3.2. Connecting to Power Supply and 4.3.2.1. Power
Linking of Multiple Devices on page 16.
Connect other EDGE devices to the receiver(s). See 4.3.3. Setup Examples on pages 17–18.
Connect a mixer/amplifier to the receiver(s). See 4.3.4. Connecting the Receiver to Mixer/Amplifier
on page 18.
Switch on the receiver. See 4.3.5. Switching ON/OFF - Receiver on page 19.
Install the batteries in the transmitter. See 4.3.6. Installation of the Batteries on page 19.
Switch on the transmitter. See 4.3.7. Switching ON/OFF - Transmitter on page 20.
Pair the transmitter with the receiver. See 4.3.8. Pairing on page 20.
Switch on the connected mixer/amplifier.
Installation of the Antennas
The device is delivered with 2 antennas. The antennas are not connected. To install the antennas:
Insert the 1st antenna into the 12–15 V DC BNC connector (09).
Insert the 2nd antenna into 12–15 V DC BNC connector (15).
Point the antennas away from each other at an angle of 45° (Fig. 09).
Fig. 09
Note:
●Do not use the antennas near metal surfaces or other obstructions.
●Make sure that the antennas do not cross when multiple wireless systems are used.
Attention
Connect all data cables before supplying power.
Disconnect power supply before connecting or disconnecting data cables.

16
EDGE EHS-1
Product code: D1475B
Connecting to Power Supply
Attention
Incorrect handling of the AC power adapter may result in hazardous situations
This device is delivered with an AC power adapter. Incorrect handling of the AC power adapter may
result in hazardous situations.
●Connect the receiver to the socket-outlet with the delivered AC power adapter. Use only the AC
power adapter delivered with the device.
●Make sure that the socket-outlet is easily accessible.
●Disconnect the AC power adapter from the socket-outlet when the device is not in use.
Power Linking of Multiple Devices
This receiver supports power linking. Power can be relayed to another receiver via the 12–15 V DC power
connector OUT (13).
Power linking of multiple devices must be carried out only by instructed or skilled persons.
To prevent overload of the electrical circuit, when power linking multiple devices:
Use cables with sufficient current-carrying capacity. The power adapter supplied with the device is
not suitable for power linking of multiple devices.
Make sure that the total current draw of the device and all connected devices does not exceed the
rated capacity of the power adapter, power cables and the circuit breaker.
Do not link more devices on one power link than the maximum recommended number.

17
EDGE EHS-1
Product code: D1475B
Setup Examples
It is possible to connect multiple receivers and transmitters and to install accessories. See 3.5. Optional
Accessories on page 11 for more information.
4 x EDGE EHS-1
In a setup with 4 receivers, you can use a single antenna distributor and 1 set of
unidirectional/omnidirectional antennas.
The antennas receive the signal from the transmitter(s) and send it to the antenna distributor. The
antenna distributor sends the signal to each connected receiver.
The unidirectional/omnidirectional antennas and the antenna distributor are not supplied with the
device. See 3.5. Optional Accessories on page 11.
Fig. 10

18
EDGE EHS-1
Product code: D1475B
8 x EDGE EHS-1
In a setup with 8 receivers, you can use 2 antenna distributors and 1 set of unidirectional/omnidirectional
antennas.
The antennas receive the signal from the transmitter(s) and send it to the antenna distributor. The
antenna distributor sends the signal to the other connected antenna distributor. Both antenna distributors
send the signal to each connected receiver.
The unidirectional/omnidirectional antennas and the antenna distributor are not supplied with the
device. See 3.5. Optional Accessories on page 11.
Fig. 11
Connecting the Receiver to Mixer/Amplifier
Attention
Connect all data cables before supplying power.
Disconnect power supply before connecting or disconnecting data cables.
The receiver has a balanced 3-pin XLR output connector and an unbalanced ¼ ʺ/6,3 mm jack output
connector.
To connect the receiver to a mixer or an amplifier:
01) Make sure that the receiver is not connected to power supply and the volume is turned down.
02) Make sure that the mixer or the amplifier are switched off and the volume is turned down.
03) Use a 3-pin XLR audio cable to connect the 3-pin XLR AF balanced OUT (08) of the receiver to the
XLR input connectors of the mixer, or use a ¼ ʺmono jack cable to connect the ¼”/6,3 mm jack AF
connector OUT (11) of the receiver to the input connector of the amplifier.

19
EDGE EHS-1
Product code: D1475B
Switching ON/OFF –Receiver
The receiver has a power button.
●Press and hold down the power button (05) for 2 seconds to switch on the receiver. The LCD display
(01) lights up.
●Press and hold down the power button (05) for 2 seconds to switch off the receiver. The receiver
remains energized.
Note:
The mains plug is used as a disconnect device. Disconnect the AC power adapter from the socket-outlet
to disconnect the receiver from the power supply.
Installation of the Batteries
The transmitter is delivered without batteries. It accepts 2 x AA LR6 (alkaline) batteries.
To install the batteries:
Turn the battery cover (19) counterclockwise to remove it.
Insert the batteries into the battery housing (23) (Fig. 12). The transmitter operates with 2 x AA LR6
(alkaline) batteries. The batteries are not delivered with the product.
Install the battery cover (19) again on the transmitter. Do not overtighten.
Note:
Make sure that you install the batteries with correct polarity orientation.
Fig. 12
