D51 200 Steam Locomotive: STEP BY STEP
41
™
The motion frame
Fitting the left motion plate
1
The motion frame
Required tools
Phillips screwdriver
Flat-head screwdriver
Left motion plate
Reverse shaft
Right motion plate
Reverse link left
Reverse link right
2 × 2.6mm set screws × 3
2 × 6mm screws × 9
Place the left crosshead
into position.
Locate the three holes
on the motion frame side
plates and the three holes
on the left motion plate.
Align the two sets of holes
and tighten a 2 x 6mm
screw into each of them.
Secure the motion bars
to the underside of the
motion frame with a
2 x 6mm screw.
Your parts
Stage 21

D51 200 Steam Locomotive: STEP BY STEP
42
™
Fitting the reverse shaft Assembling the motion plate
2 3
Fitting the reverse link
4
Assembled parts
Rear
Front
Crosshead
Reverse shaft
Align the holes
Align the holes
Hold the shaft
over the motion
frame and turn
it so the hole at
the end (circled,
left) is facing
towards
the rear.
Re-t the right crosshead
into position.
Half-tighten a
2 x 6mm screw
into each of the
circled holes.
Place the left
reverse link
over the left
side of the
reverse shaft,
aligning the
holes of both.
Tighten one of the 2 x 2.6mm
screws into the hole of the link
to secure it to the shaft.
Tighten a 2 x 2.6mm screw into
the hole of the link.
Place the right
reverse link
over the right
side of the
shaft, aligning
the holes.
Place the right
motion plate over
the right side of the
motion frame, so
that the screw holes
align and the shaft
protrudes through
the hole.
Ensure that the
shaft can rotate
smoothly, then
tighten all the
screws fully.
Insert the end of the shaft into the hole
in the left motion plate (circled, above).

D51 200 Steam Locomotive: STEP BY STEP
43
™
Nuts × 16
Bushes (short) × 4
Bushes (medium) × 2
Bushes (long) × 4
2 × 8mm screws × 12
Equalising bars × 2
2 × 6mm screws × 9
Links (long) × 4
2 × 4mm screws × 18
Equaliser brackets A × 2
Equaliser brackets B × 2
Leaf springs × 4
Links (short) × 4
The suspension
Assembling the leaf springs
1
Required tools
Pliers
Phillips screwdriver
Useful to have:
Contact adhesive
or PVA glue
Link (long)Link (short)
Front side
Tip
Nuts
Leaf spring
Screws (2 × 6mm)
A B
Back side
Leaf springs and equalisers
Tighten the screws
through the ends of
the spring, the two
links and into a nut.
Position a short link, a long link, two nuts,
a leaf spring and two 2 x 6mm screws, as
shown in the photo above.
Use contact adhesive
or PVA to improve
the grip of the nut
on the screw.
Make two sets of
each type of spring
assembly, as shown.
Bush (medium)
Bush (long)Bush (short)
Your parts
Stage 22

D51 200 Steam Locomotive: STEP BY STEP
44
™
Fitting the leaf spring 2
4Fitting the leaf spring 3 5Assembled parts
Fitting the leaf spring 1
3
Equaliser bar
A Spring
Spring B
Equaliser bar
Links (long) Link (short)
Bush (short)
Nut
Screw
Fitting the equaliser
2
Left side
Insert one medium bush into the hole in the
centre of one of the equalising bars. Then place
a 2 x 8mm screw through the central hole of
an equaliser bracket B and into the bush of the
equalising bar.
Holding the bracket and bar
together, insert the screw into the
circled hole in the motion frame,
and tighten into place.
Position an A spring over the
underframe so it is either side of the
equaliser bar, holding the bush in place.
Insert a 2 x 8mm screw through
the side of the link and through
to the other side.
Hold a nut at the other end of
the screw and turn the screw
into the nut.
Insert a long bush into
the hole at the end of
the equaliser bar and
hold in place.
Tighten a 2 x 4mm
screw into each of
the circled holes of
the bracket.
Screw an A bracket
into place below
the rear end of the
motion frame.
Turn the model over
and place a short bush
between the underframe
and the short link. Then
insert a 2 x 8mm screw
through the link, from
one side to the other.
Hold a nut at the end of
the screw, and tighten the
screw into it.
Put a long bush in the hole of the
equaliser bar. Position a B spring over it,
and tighten a 2 x 8mm screw through
the link and into a nut.
Place the short link of the B
spring over the underframe
and a short bush, and secure
with a 2 x 8mm screw and nut.
Repeat Steps 2-5 for the right side of the model.

D51 200 Steam Locomotive: STEP BY STEP
45
™
The suspension Assembling the leaf springs
1
Fitting the equaliser
2
Medium link Long link
Short link
Left
front
Right
front
Left
rear
Right
rear
Tighten the screws
through the ends
of the spring, the
two links and
into a nut.
Position a short link, a long link, two nuts,
a leaf spring and two 2 x 6mm screws as
shown in the photo above.
Make one of each of
the types of spring
assembly shown.
Insert one medium bush into the hole in the centre of one of
the equalising bars. Then place a 2 x 8mm screw through the
central hole of the equaliser bracket B and into the bush of
the equalising bar.
Holding the bracket and
bar together, insert the
screw into the circled
hole in the motion frame,
and tighten into place.
Tighten a 2 x 4mm
screw into each of
the circled holes of
the bracket.
The bracket and bar will be
attached to the underframe,
either side of the brace.
2 × 8mm screws × 12
Nuts × 16
Bushes (short) × 2
Bushes (medium) × 2
Bushes (long) × 4
2 × 4mm screws × 9
Links (medium) × 4
2 × 6mm screws × 9
Equalising bars × 2
Links (short) × 2
Links (long) × 2
Equaliser brackets × 2
Leaf springs × 4
Bush (medium)
Bush (long)Bush (short)
Required tools
Pliers
Tweezers
Phillips screwdriver
Useful to have:
Contact adhesive
or PVA glue
Your parts
Link (long)
Link (short)
Front side
Nuts
Leaf spring
Screws (2 × 6mm)
Back side
Stage 23

D51 200 Steam Locomotive: STEP BY STEP
46
™
Fitting the leaf spring 3
5
Assembled parts
34
Fitting the leaf spring 1 Fitting the leaf spring 2
Position the left
front spring either
side of the equaliser
bar, holding the
bush in place.
Insert a 2 x 8mm screw
through the link and
tighten into a nut to the
other side.
Place the short link over
the underframe, aligning
the holes of both.
Insert a long bush in the hole of the
equaliser bar.
Insert a long bush
into the hole at
the end of the
equaliser bar.
Turn the model over and place
a short bush between the
underframe and the short link.
Then insert a 2 x 8mm screw
through the link, from one
side to the other. Hold a nut
at the end of the screw and
tighten the screw into it.
Tighten a 2 x 8mm screw
through the link and into a nut.
Position the left rear spring over
the equaliser bar, holding the
bush in place.
Temporarily tighten a 2 x 8mm screw into
the end of the long link, as shown.
Repeat Steps 2-5 for the right side of the model.

D51 200 Steam Locomotive: STEP BY STEP
47
™
Right connecting rod
Left connecting rod
Wheels
Nuts × 2
Bushes (small) × 2
Bushes (large) × 2
2 × 6mm rod pins × 2
2 × 6mm screws × 14
3 x 8mm rod pins × 2
Axle box guards × 4
Axle boxes B × 4
Axle boxes A × 4
Fitting the wheels
Required tools
Tweezers
Phillips screwdriver
Masking tape
The wheels
Preparing the parts
1
Long part of axle box A
Axle box B
Axle box A
Long part of
axle A
Long part of axle box
A is closer to the wheel
Assemble axle boxes A and B. Place some
masking tape on the area outlined in red on
the temporarily assembled axle boxes, as
shown above. Place the assembled boxes over the axles of the two
wheels, inside of the bush at each end of the axle,
with the long part of axle box A closer to the wheels.
Your parts
Stage 24

D51 200 Steam Locomotive: STEP BY STEP
48
™
Assembled parts
2Fitting the wheels
3Fitting the guards
Tip!
Turn the assembly over and locate the two
U-shaped cut-outs on the underframe. Fit the wheel assembly from this stage into
the second cut-out. Remove the tape.
Position the wheels so that the
underframe rests in the groove of
the axle boxes.
If the wheels don’t
rotate smoothly,
then check the
inside edges of the
axle boxes for any
burrs. Remove any
found with a half-
round le.
Place the wheel assembly from
Stage 4 into the cut-out at the
front of the underframe.
Once both wheel sets are in position,
rotate them to check that the movement
is smooth. Be careful of the coupling rod.
Place an axle box guard onto
the underframe, aligning the
holes with those circled.
Tighten a 2 x 6mm
screw into the two holes
on the axle guard, securing it in
place. Repeat this process for the
remaining three guards.
Turn the assembly
back over and
tighten a screw
into the circled
holes on the leaf
springs to secure
them to the
ends of the long
parts of the
axle boxes.

D51 200 Steam Locomotive: STEP BY STEP
49
™
The following two pages show you the variations
for the wheels, if you are choosing to paint them or
to leave them as they are.
Paint – (Matt black) Acrylic is used in these images, however, the body is
sprayed with a lacquer-based paint.
Paint thinner – one that is appropriate for the paint used.
Brush
Masking tape
Degreasing agent
Primer
The wheels are made
from a zinc alloy. If they
are left unpainted, you
are able to see the full
texture and details.
If you choose to paint
the wheels, the nished
model will more closely
resemble the real
locomotive.
Painted nish
Tools and materials required
Unpainted
Painted
D51 Paintwork Some parts, such as the
wheels, can be painted
even when xed to the
rest of the assembly.
The steps will continue
with assembling a non-
painted model.
You can choose to leave your model in its bare metal state, as
shown in the assembly steps, or to paint it black to match the
original locomotive.
There are three options for how to nish the wheels:
You can leave them unpainted, to showcase the zinc alloy
metal nish and the detail
You can paint just the inner area of each wheel, minus the
‘tyre’ area, to give a sense of depth to the model
Or you can paint everything but the outer surface, where the
wheels are in contact with the track.
Examples of wheels on the real train.

D51 200 Steam Locomotive: STEP BY STEP
50
™
Bare metal nish
Spray the entire surface of the wheel with
a degreasing agent.
Apply masking tape to the axle between
the two wheels to protect it from the
paint. You don’t have to cover it, but it may
make it easier to paint the wheels.
Wipe away any paint that has run onto
areas of the wheel that you don’t want to
have painted.
Paint the wheel with black paint. If
you choose to prime the wheel before
painting, glue mixed with paint will
work well.
As the surface of the wheel isn’t perfectly
smooth, you will need to apply more than
one coat of paint.
Paint the inner surfaces of the wheels,
as shown above. When the paint is dry,
remove the masking tape.
Painted wheel,
without 'tyre' paint
Painted wheel,
with 'tyre' paint
1 2 3 4
56
