Stage 73
Side stand pivot
Side stand
Side stand spring
Screws (type N) × 2
Footrest rubbers × 2
Footrests × 2
Test the
electronics, and
t the side stand
and footrests
Phillips screwdriver
Allen key
Pliers
Tweezers
AAA batteries x 6
Semi-transparent
plastic (see Step 5 on
the next page)
Remove the ignition key from the
ignition before tting any batteries.
Remove the cover from the battery box
on top of the frame.
Insert three AAA batteries into the
battery box. Refer to the diagrams
moulded inside the box to make sure
that you insert the batteries the right
way round.
Remove the cover from the control
box in the display base. Insert another
three AAA batteries into the battery
compartment, again making sure that
you t them the right way round.
Preparing the electronics
Tools Prepare
Your parts
1 2
34
355
Honda CB750 FOUR: Assembly Guide

Place a suitably sized piece of strong,
semi-transparent plastic, such as a
storage box lid, on top of the display
base, and put your model on top of it.
Align the IR sensor in the oil pan with the
IR receiver in the base.
Insert the large ignition key into the
keyhole in the display base control
panel, in the orientation shown.
Turn the ignition key to the right, until it
is horizontal, aligned with the red dot on
the lock cylinder.
Insert the smaller ignition key into the
ignition switch. Make sure you insert it
the right way round.
Checking the lights and sounds
The interactive functions of
the model will be tested over
the following pages. If any of
them do not work, refer to the
assembly steps to check the
connections.
The headlight
The instruments
Move the right-hand slider on the
display base to the ‘L’ position. The
headlight should shine dimly. Then
return the slider to the ‘o’ position.
If you need to remove a
connector, carefully open
the socket a little with
tweezers before removing
the connector with pliers.
When the right-hand slider is in either the ‘L’ or ‘H’ position,
the speedometer and tachometer should light up as well as
the headlight.
Move the slider to the far end, the ‘H’
position. The headlight should now
shine brightly. Then return the slider to
the ‘o’ position.
Red●
Note the position of the hole
The various parts of your
model’s lighting (the
headlight, instrument
lights, brake light and
indicators) will only work
when the ignition key
in the display base is in
the red dot position and
the right-hand slider is in
either the ‘L’ or ‘H’ position.
56
7 8
356
Honda CB750 FOUR: Assembly Guide

The brake light
Turn the headlight on (use either the ‘L’ or ‘H’ slider positions). Press down lightly
on the brake pedal until the brake light illuminates, as shown above. Turning the
key further to the right, so that it is aligned with the black dot (park position),
should also make the brake light come on.
The indicators
Move the left-hand slider on the display
base to the left, into the ‘L’ position. The
front and rear indicators on the left side
of the model should come on and blink.
Return the slider to the centre.
Move the slider to the ‘R’ position. The
indicators on the right side of the model
should now come on and blink.
Push the brake
pedal down
The starter switch and kick starter
Pressing the button below the right-
hand slider once will activate the sound
of the engine starting when the electric
starter is used. Pressing it a second time
will change the sound to that of the
engine idling. Turn the ignition key on
the control panel to the ‘o’ position to
stop it.
Your model will also simulate the sound
that is heard when the kick starter is used.
Pulling the starter out and pushing it
down will activate the sound. This sound
should be slightly dierent to the electric
starter eect. Again, turn the key to the
‘o’ position to stop it.
The horn
The knob at the right-hand end of the
display base control panel adjusts the
volume of your model’s sound eects.
Turning the knob to the right will
increase the volume, turning it to the left
will reduce it.
To activate the horn, press the button
below the left-hand slider.
357
Honda CB750 FOUR: Assembly Guide

Fixing the fuel tank
Once you have veried that the parts work without any problems, return the sliders and ignition switch to their ‘o’ positions. If any of
the functions aren’t working properly, make sure that the sliders and the switch are o, then work through the relevant assembly steps
to rectify the problem. Then install the fuel tank, following the steps below.
Move the fork assembly forward by around 5mm.
Remove the Honda badges from the sides of the
fuel tank.
Gather all of the cables together and place the
fuel tank over the top of them.
Remove the steering stem holding the front fork
assembly in position.
Move the front fork assembly back to its original
position, and replace the steering stem (see
Stage 72).
12
5
3
4
358
Honda CB750 FOUR: Assembly Guide

Tighten a type A screw into the hole on the other side
of the fuel tank.
Ret the badges removed in Step 1.
89
Insert a type A screw (Stage 68) into the indicated
hole in the side of the fuel tank. This hole is aligned
with the hole in the mounting post behind it (inset,
red circle).
Tighten the screw into place.
67
359
Honda CB750 FOUR: Assembly Guide

The indicators The shock absorbers
The rear fender
Remove the indicators, and use a toothpick to place a
small amount of multi-purpose adhesive to the insides of
the indicator mounting holes. Put the indicators back into
their holes and x them in place with masking tape until
the glue has dried.
Remove the screw holding the shock absorber in place.
Apply some multi-purpose adhesive to the inside of the hole,
and then retighten the screw. When the glue has dried, it will
x the screw in place.
If there are gaps between the rear fender and the adjacent parts, replace the type R
screws with type W screws, which are slightly longer.
If one of the screw holes
has been damaged, apply
some instant adhesive to
the end of the screw from
inside the fender.
Fixing and adjusting the indicators, shock absorbers and rear fender
360
Honda CB750 FOUR: Assembly Guide

Line up the ring end of the side stand spring with the
hook on the side stand, as shown.
Loop the end of the spring onto the side stand hook.
The forked end of the side stand ts over the lug on the
left side of the model, below the gearchange pedal.
Place the side stand pivot onto the end of the Allen
key, and insert it into the aligned holes.
Align the holes at the top of the side stand with the
larger of the two holes in the lug on the frame.
Screw the pivot into place until it is ush with the
surface of the stand.
The side stand and footrests
1
2
3
4
5
6
361
Honda CB750 FOUR: Assembly Guide

Pass a type N screw through the free end of the spring. Tighten the screw into the hole until the spring is in
contact with the frame lug.
Insert the end of the screw into the indicated hole.
Take one of the footrests and one of the footrest
rubbers, and line up the at side of the thin end of the
footrest with the at side of the hole in the rubber.
Swivel the side stand up and down to check that it is
free to move but properly secured.
Push the footrest fully into the rubber. Once that is
done, repeat the process for the second footrest.
7
8
9
10
11
12
362
Honda CB750 FOUR: Assembly Guide

Locate the indicated hole in the left-hand side of the
frame. Line up the shaped end of the footrest with the
shape of the hole.
Move the brake pedal and oil hose out of the way, and
push the footrest into the hole.
The two assembled footrests are identical. Push the footrest into the hole.
Align the end of the second footrest with the
indicated hole in the right-hand side of the frame,
behind the oil hose.
13
14
15
16
17
Stage complete
363
Honda CB750 FOUR: Assembly Guide

Pillion footrest bracket
Pillion footrest
Pillion footrest pivot
Pillion footrest rubber
Screw hole cover (left)
Screw hole cover (right)
Screws (type P) × 2
The left pillion
footrest
Phillips screwdriver
Pliers
Masking tape
Tweezers
Multi-purpose adhesive
Main frame assembly (Stage 73)
Place the left and right screw hole covers
in front of you, as shown, with the letters
‘L’ and ‘R’ the right way up. Locate the
cutouts (green lines). Locate the screw hole behind the front
left indicator, and look for the projection
outlined above in green. Its shape
matches that of the cutout in the left
screw hole cover.
Using tweezers, hold the left screw hole
cover next to the hole and align the
cutout and projection. Push the cover into place in the screw
hole. If it doesn’t stay in place, remove
it and apply a little multi-purpose
adhesive to the edge of the hole, then
replace it.
Stage 74
Tools Prepare
Your parts
1
2
3
4
364
Honda CB750 FOUR: Assembly Guide

Repeat Steps 2 to 4 to t the screw
hole cover to the hole behind the front
right indicator.
Push the footrest fully into the rubber.
Take the pillion footrest and the pillion
footrest rubber, and line up the at side
of the thin end of the footrest with the
at side of the hole in the rubber.
Push the end of the footrest between the sides of the
bracket, aligning the holes of both parts.
Insert the pillion footrest pivot into the hole in the
bracket, and push it through as far as you can.
Use pliers wrapped in masking tape to squeeze the
pivot all the way through the footrest and bracket.
Line up the exposed end of the pillion
footrest with the open side of the pillion
footrest bracket, as shown.
5
6
7
8
910 11
365
Honda CB750 FOUR: Assembly Guide

Swivel the footrest up and down, as indicated above, to
check that it is free to move.
Tighten the screw to x the bracket in place.
Align the hole in the pillion footrest bracket with the
hole in the silencer.
Check that the footrest is free to move.
Insert a type P screw into the hole in the bracket.
12
13
14
15
16
Stage complete
366
Honda CB750 FOUR: Assembly Guide

Restoring the tyre colour
Over time, the front and rear tyres may gather dust and take on
a whitish appearance. To restore them to their original colour,
follow the steps below: these steps show the front tyre, but they
also apply to the rear tyre.
Tools
Silicone-based oil spray
Newspaper
Cross wrench
Grease (Stage 6)
Brush
Paper towel
If the front tyre has whitened, remove the front wheel
from the assembly.
Twist the tyre to loosen up the dust. Brush the surface of
the tyre with an old toothbrush to dislodge any dust that
is caught in the tread.
Remove the tyre from the wheel.
Wipe the oil from the tyre with a paper
towel. Make sure there is no oil left on
the tyre.
Use a paper towel to rub the grease into
the surface of the tyre, and then wipe
away any excess.
Apply a light mineral-based grease –
such as the grease that was supplied
with Stage 6 – to the outer surface of
the tyre.
Place the tyre on an old newspaper
and spray with a silicone-based oil to
clean it.
12 3
45 6 7
367
Honda CB750 FOUR: Assembly Guide

The right pillion
footrest
Take the pillion footrest and the pillion
footrest rubber, and line up the at side
of the thin end of the footrest with the
at side of the hole in the rubber. Push the footrest fully into the rubber.
Hold the pillion footrest with the
rounded corner of the exposed end
facing up. Line up the end with the
open side of the pillion footrest
bracket, as shown.
Push the end of the footrest between the
sides of the bracket, aligning the holes of
both parts.
Stage 75
Tools Prepare
Your parts
1
2
3
4
Pillion footrest rubber
Pillion footrest
Screws (type P) × 2
Pillion footrest pivot
Pillion footrest bracket
Phillips screwdriver
Pliers
Masking tape
Main frame assembly (Stage 74)
368
Honda CB750 FOUR: Assembly Guide

Insert the pillion footrest pivot into the
hole in the bracket, and push it through
as far as you can.
Swivel the footrest up and down, as
indicated above, to check that it is free
to move.
Use pliers wrapped in masking tape to
squeeze the pivot all the way through
the footrest and bracket.
Align the hole in the pillion footrest
bracket with the hole in the silencer.
Insert a type P screw into the hole in
the bracket.
Check that the footrest is free
to move.
Tighten the screw to x the bracket
in place.
5
9
6
10
7
11
8
Stage complete
369
Honda CB750 FOUR: Assembly Guide

Seat base
Seat hinge A
Seat hinge B
Screws (type G) × 3
Screws (type T) × 3
The seat base
Prepare the seat base and seat hinges
A and B. Hinge A will be tted at the
front of the base (red circle) and hinge B
towards the rear (green circle).
Insert a type G screw into the hole
indicated in seat hinge A.
Place seat hinge A into position on the
seat base, aligning the hole in it with
the hole in the base. Tighten the type G
screw into the holes. Insert a type G screw into the hole in seat
hinge B.
Seat hinge A
Type G screw
Seat hinge A
Mounting position
Seat hinge B
Mounting position
Seat hinge B
Stage 76
Tools Prepare
Your parts
1
2
3
4
Phillips screwdriver Main frame assembly (Stage 75)
370
Honda CB750 FOUR: Assembly Guide

Fix seat hinge B to the seat base, in the
same way that you tted hinge A.
Align the holes in the hinges with those
circled in the frame.
Adjust the positions of hinges A and B to
match those shown above.
Place a type T screw into the aligned
holes of hinge B and the frame.
Tighten the type T screw to x hinge B to
the frame.
Test the movement of the seat base
by lifting it up and then placing it at
against the top of the frame. You may
need to tighten the screws a little more if
the movement feels loose.
Tighten a type T screw into the aligned
holes of hinge A and the frame.
Type T screw
5
9
6
10
7
11
8
Stage complete
371
Honda CB750 FOUR: Assembly Guide

20
Honda CB750 FOUR:
TM
