1. Replacement of the combined Input/Output Module (IOM 4.1)
General instruction
Before replacing any modules, please refer to the General Instruction for replacement of Delomatic
4 modules.
Please do not switch over modules from one DGU to another before consulting the
documentation provided by DEIF A/S, and preferably consulting DEIF A/S.
Please let us know if you do switch modules permanently, this will help us keep our records
updated. Call us or send a fax to DEIF A/S, for the attention of the service department:
Tel.: + 45 9614 9614 Fax: [phone]
When modules are replaced due to updating or due to any malfunctions, please let us know
the exact location of new modules.
Replacement of module
Handle: For replacement, please notice that the replacement unit is given the same I/O
address (rotation switch) as the unit to be replaced, and all output channels are set
to the right format.
- Switch all equipment into switchboard control
- Remove the power supply from the defective DGU
- Remove other connections/plugs on the IOM
- Exchange the module after securing the correct settings of the jumpers and rotation switch
- Connect the plugs and power supply again
- Make a test to secure that the system works as predetermined
Input channels
DIP switches: For each input channel, there is a DIP switch to select the format of the input. There
are three different formats: binary, voltage or current. On the board, it is illustrated
how the DIP switches should be placed for the three signal formats.
Be aware of static electricity when handling!

DM-4 Land/DM-4 Marine 4189340467B Replacement Instructions, IOM 4.1
DEIF A/S Page 4 of 4
The I/O address for the backplane bus is to be set. Please notice that all IOM 4.1 modules must
have different I/O addresses starting with zero (null). The I/O address is set by means of the I/O
address switch.
Output channels
No DIP switches are to be set on the output channels.
Analogue output channels
No DIP switches are to be set on the analogue output channels.
DEIF A/S reserves the right to change any of the above.
Address switch on the IOM module
