Dell E-Port Plus II User instructions

CAUTION: Before you set up
and use your E-Port Plus II, see the
support documentation that shipped
with your computer or go to
dell.com/regulatory_compliance for
regulatory and safety information.
NOTE: Before you initially connect
your laptop to the E-Port Plus II, the
operating system must complete its
setup process. For further information
see the Dell™ E-Port Plus II User’s
Guide on support.dell.com/support/
systemsinfo/documentation.aspx.
Setting Up Your Dell™ E-Port Plus II
1Connect power 2Slide switch left if battery extends from back of laptop
4Center laptop with E-Port Plus II and push down to click into place
3Adjust lock/unlock switch
XOOOOO
RMSD
XOXOOO
XOXOOO
