Display
Model number P2714T
Viewable image size (diagonal) 68.6 cm (27 inches)
Active display area
Horizontal
Vertical
597.9 mm (23.54 inches)
336.3 mm (13.24 inches)
Maximum resolution Full HD 1920 x 1080 at 60 Hz
Aspect ratio 16:9
Pixel pitch 0.3114 (H) mm x 0.3114 (V) mm
Brightness (typical) 270 cd/m²
Color gamut (typical) 83%6
Color depth 16.77 million colors
Contrast ratio (typical)
Dynamic contrast ratio (typical)
1,000:1 (typical)
8 Million:1 (DCR)
Viewing angle (typical)
(vertical/horizontal) 178°/178°
Response time (typical) 8 ms with overdrive (gray to gray)
Panel technology, surface Plane to line switching, glossy
Backlight LED
Connectivity
Connectors VGA, DisplayPort, 2x HDMI (including MHL), 2x USB 3.07,
2x USB 2.0
Features
Stand Tilts up to 60°
Security Security lock slot (security lock not included)
VESA mounting support
(wall mount sold separately) Dell Quick Release mount, 100 mm x 100 mm
Power
AC input
voltage/frequency/current
100 to 240 VAC/50 or 60 Hz
± 3 Hz/1.5 A (maximum)
Power consumption (normal
operation, typical) 19 W
Power consumption (active-o mode) <0.5 W
Dimensions (with stand)
Height (compressed ~ extended) 475.5 mm (18.72 inches) ~ 246.5 mm (9.70 inches)
Width 665.0 mm (26.18 inches)
Depth (compressed ~ extended) 79.7 mm (3.14 inches) ~ 421.3 mm (16.59 inches)
Weight
Weight (panel only – no stand) 7.11 kg (15.64 lbs)
Weight (with stand) 9.39 kg (20.66 lbs)
Shipping weight 11.49 kg (25.28 lbs)
Environmental compliance ENERGY STAR®, EPEAT®Gold, TCO Certified Displays,
China Energy Label, CEL, WEEE, ErP (EuP) Standards,
Korea E-Standby
Standard service plan
• 3 years Advanced Exchange Service5& Limited Hardware Warranty4
• Premium Panel Guarantee3
Dell 27 Monitor — Touch | P2714T
(27", 68.6 cm VIS)
*DisplayPort, VGA, and MHL cables not included.
**Registered in US and Canada only.
1Microsoft, Windows, Windows Vista and the Windows logo are trademarks of Microsoft group of companies.
2 MHL connectivity works with smartphones and tablets with MHL out and that are in compliance with MHL standards.
3 Even if only one bright pixel is found on our select range of monitors, a free panel exchange is guaranteed during
the Limited Hardware Warranty period (see pixel panel info located on dell.com web page for complete details):
http://support.dell.com/support/topics/global.aspx/support/kcs/document?docid=414288
4For a copy of the Limited Hardware Warranty, write to Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX
78682 or see dell.com/warranty.
5Advanced Exchange Service: Replacement part/unit dispatched, if needed, following completion of phone/online
diagnosis. Fee charged for failure to return defective unit. Availability varies. Other conditions apply.
6 Color gamut (typical) is based on CIE1976 (83%) and CIE1931 (72%) test standards.
7 USB 3.0 does not support graphics output. USB 3.0 rate of data transfer can only be achieved with a computer that
supports USB 3.0
Product availability varies by country. Please contact your Dell representative for more information.
Based on Dell document Ad#A13001708 dell.com/monitors
Dell 27 Monitor — Touch | P2714T (27", 68.6 cm VIS)
A boldly reimagined monitor experience —
the Dell 27 Touch Monitor can meet your
needs and budget
v.1 08/2013
Unique stand design allows you
to simultaneously slide the panel
toward you while tilting it up to 60°.
What's in the box?
Monitor with stand, power cable (varies by
country), power adapter, HDMI cable, USB 3.0
upstream cable, screen cleaning cloth,
Velcro strap, Quick Setup Guide, Drivers and
Documentation media, Product and Safety
Information Guide.
Back view
Connectors
A DisplayPort
B HDMI
C VGA
D Audio out
E USB upstream
F USB downstream
G Security cable slot
H USB downstream
E
A
C
D
B
FG
H
**
Dell 27 Monitor — Touch
Model P2714T
27" monitor

Dell 27 Monitor — Touch
Model P2714T
27" monitor
An aordable touch monitor with
unmatched reliability
• Choose a touch monitor that can meet your needs,
from affordability to usability.
• Rest assured that Dell's Premium Panel Guarantee3
offers a free panel exchange in the event that you
discover even one bright pixel during the Limited
Hardware Warranty4period.
• Enjoy peace of mind with Dell’s Limited Hardware
Warranty4and Advanced Exchange Service5to minimize
your downtime.
• Minimize environmental impact with the Dell 27 Monitor
which meets the latest regulatory and environmental
standards like ENERGY STAR®, EPEAT®Gold and TCO
Certified Displays.
• Control power consumption with power management
features like PowerNap.
An engaging touch experience
• Natural, direct and intuitive, the touch interface of the
Dell 27 Monitor offers you a fast and easy way to use
your applications. Tap, slide, swipe, turn, pinch and
stretch images on the screen with your fingers thanks
to the Dell 27 Monitor's 10-point multi-touch
capability — it's that simple and intuitive when used with
Windows®81.
- Connect a USB cable from your PC to the monitor's
USB upstream port to enable touch, and use either an
HDMI, DisplayPort* or VGA* cable to project images
onscreen.
• Enjoy amazing screen clarity and pin sharp details
with the 16:9 Full High Definition 1920 x 1080 (max)
resolution, and high 8 million:1 dynamic contrast ratio.
• View images on the monitor from virtually any angle and
still enjoy the same superb visual experience with the
178°/178° ultra-wide viewing angle.
• Sleek and stylish edge-to-edge glass gives the Dell 27
Monitor a clean finish that boasts of fine craftsmanship,
enhancing your overall viewing experience.
Seamless connectivity to smart phones,
tablets, and other devices for great
usability and convenience
• Easily project content from your smart phone or tablet
directly onscreen via HDMI (including MHL*2); you can
even transform your touch monitor into a thin client
solution with the Dell Wyse personal cloud stick.
• Enjoy seamless connectivity with various devices via a
versatile array of VGA, USB, DisplayPort, and HDMI ports.
• Experience additional convenience with stand
viewing options.
- Easily slide the monitor toward yourself to touch and
type and tilt it up to 60° to suit your viewing needs.
- VESA compatibility — Enjoy the flexibility of mounting
the panel on the wall, or attaching it to the Dell Single
Monitor Arm via the VESA adaptor plate. (Wall mount
kit and Dell Single Monitor Arm both sold separately).
The Dell 27 Touch Monitor | P2714T (27", 68.6 cm VIS) oers you:
The Dell 27 Touch Monitor
Bringing a boldly re-imagined monitor experience to
you with:
• Natural and intuitive 10-point multi-touch
• Enhanced and extensive connectivity with MHL,
DisplayPort, HDMI, VGA, and USB ports
• Amazing screen experience with Full HD resolution
and an ultra-wide viewing angle
• Innovative design with sleek, edge-to-edge glass
and unique stand design
• An affordable touch monitor solution
• Unmatched reliability
Dell 27 Monitor — Touch | P2714T (27", 68.6 cm VIS)
Perfect for:
• Connectivity to smart devices, easy access
to information in the cloud, previewing touch
applications on a larger screen.
• Movies, games, surfing the Internet and other
multimedia entertainment.
