Dell MS5320W User manual

Regulatory model: MS5320Wc/RG-1216
Dell Multi-device Wireless Mouse
MS5320W
User’s Guide

NOTE: A NOTE indicates important information that helps you make
better use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss
of data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
Copyright © 2020 Dell Inc. All rights reserved. Dell, EMC, and other trademarks are trademarks of
Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
2020 – 01
Rev. A00
Notes, Caution, and Warnings

What’s in the box ........................... 4
Features .................................. 5
Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Top view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Bottom view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Setting up your wireless mouse .................7
Installing batteries . . . . . . . . . . . . . . . . . . . . . .7
Pairing your wireless mouse . . . . . . . . . . . . . . . . .9
Pairing with a USB device. . . . . . . . . . . . . . . . . . . . . . .9
Pairing your mouse using Bluetooth . . . . . . . . . . . . . . . . 10
Pairing device three using Bluetooth . . . . . . . . . . . . . . . . 12
Specifications..............................14
Troubleshooting ............................15
Statutory information........................19
Contents

4 │What’s in the box
What’s in the box
1 Wireless mouse
2 Documents
3 Dongle
4 AA-type battery
1
234

Features │5
Features
Mouse
Top view
Left button
Right button
Scroll wheel
Forward button
Backward button
1
2
3
4
5
6 Connection-mode lights
7 Connection-mode button
8 PPID label
8
7
6
4
5
2
1
3
• White LED Blinking: Device is not connected to computer
• LED Lighting Solid White: Device is connected to computer
• Amber LED Blinking: Device battery is low

6 │Features
Mouse
Bottom view
1 Optical sensor 2 Power switch
1
2
Features

Setting up your wireless mouse │7
1. Locate the slot on the side of the mouse cover. Using your ngertip, pry open the cover.
Setting up your wireless mouse
Installing the battery
2. Remove the USB dongle from its compartment.
3. Install the AA battery into the battery compartment.

8 │Setting up your wireless mouse
NOTE: Ensure that the distance between your computer and mouse is within
ten meters.
Setting up your wireless mouse
4. Replace the mouse cover.
5. Slide the power switch down to turn on the mouse.

Pairing your wireless mouse │9
2. The connection-mode light ( ) on the mouse turns on to indicate the Dell Universal
pairing, and then turns o.
Your Dell wireless mouse can be paired with devices using USB and Bluetooth.
You can pair and switch between a laptop, desktop, and a compatible mobile device.
Pairing with a USB dongle
1. Install the Dell Universal USB dongle to the USB port on your computer.
Pairing your wireless mouse
Laptop Desktop
NOTE: You can connect a device to your wireless mouse using the Dell Universal
pairing.
3. The mouse is paired with your USB device.
NOTE: The RF device is pre-paired in the factory.

10 │Pairing your wireless mouse
Pairing your mouse using Bluetooth
You can connect up to two devices with your wireless mouse using Bluetooth.
1. Press the connection-mode button twice on your mouse (within 3 seconds) until the
connection-mode light ( ) turns on indicating that the second-bluetooth connection
is selected.
2. The connection-mode light ( ) blinks for 3 minutes, indicating your mouse is in the
pairing mode.
3. Pair your mouse with your Bluetooth-enabled computer.
a. In Windows Search, type Bluetooth.
b. Click Bluetooth and other devices settings. The Settings window appears.
c. Click Bluetooth & other devices. Ensure that the Bluetooth is turned on.
d. From the list of devices, click Dell Mouse.
