Dell PowerEdge XR4000r Manual

Dell PowerEdge XR4000r
Installation and Service Manual
Regulatory Model: E98S
Regulatory Type: E98S001
December 2022
Rev. A00

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.

Chapter 1: About this document.................................................................................................... 5
Chapter 2: Dell PowerEdge XR4000r system configurations and features .....................................6
System configurations - front view for PowerEdge XR4000r................................................................................. 6
System configurations - rear view for PowerEdge XR4000r................................................................................... 8
Power supply unit indicator codes...................................................................................................................................8
Locating the Express Service Code and Service Tag............................................................................................... 10
System information label..................................................................................................................................................10
Rail sizing and rack compatibility matrix....................................................................................................................... 11
Chapter 3: Technical specifications............................................................................................. 12
Chassis dimensions ...........................................................................................................................................................13
System weight.................................................................................................................................................................... 14
Witness cooling fan specifications.................................................................................................................................14
PSU specifications............................................................................................................................................................. 14
Power module assembly................................................................................................................................................... 15
Supported operating systems......................................................................................................................................... 16
PowerEdge XR sleds ports and connectors................................................................................................................ 16
PowerEdge XR4510c...................................................................................................................................................16
PowerEdge XR4520c.................................................................................................................................................. 16
PowerEdge XR4000w................................................................................................................................................. 17
Environmental specifications...........................................................................................................................................17
Environmental Considerations...................................................................................................................................17
Thermal restriction matrix..........................................................................................................................................18
Chapter 4: Minimum configuration to POST ............................................................................... 23
Chapter 5: Installing and removing system components.............................................................. 24
Safety instructions............................................................................................................................................................24
Before working inside your system ..............................................................................................................................25
After working inside your system.................................................................................................................................. 25
Recommended tools......................................................................................................................................................... 25
Optional front bezel..........................................................................................................................................................25
Removing the front bezel..........................................................................................................................................25
Installing the front bezel............................................................................................................................................ 26
Bezel filter........................................................................................................................................................................... 27
Removal and installation of the bezel filter........................................................................................................... 27
XR4000r sled......................................................................................................................................................................29
Removing a sled blank................................................................................................................................................29
Installing a sled blank.................................................................................................................................................. 30
Removing a sled............................................................................................................................................................31
Installing a sled ............................................................................................................................................................32
Rear cover...........................................................................................................................................................................34
Removing the rear cover........................................................................................................................................... 34
Contents
Contents 3

Installing the rear cover............................................................................................................................................. 34
Power module assembly.................................................................................................................................................. 35
Removing power module assembly......................................................................................................................... 35
Installing the power module assembly....................................................................................................................36
Cooling fans........................................................................................................................................................................ 37
Removing the witness fan......................................................................................................................................... 37
Installing the witness fan........................................................................................................................................... 38
Power supply unit..............................................................................................................................................................39
Removing a power supply unit blank...................................................................................................................... 39
Removing a power supply unit................................................................................................................................. 39
Installing a power supply unit................................................................................................................................... 40
Installing a power supply unit blank.........................................................................................................................42
Witness sled........................................................................................................................................................................42
Removing a witness sled blank.................................................................................................................................42
Installing a witness sled blank...................................................................................................................................43
Removing the witness sled....................................................................................................................................... 44
Installing the witness sled..........................................................................................................................................45
Chapter 6: Getting help............................................................................................................... 47
Recycling or End-of-Life service information.............................................................................................................47
Contacting Dell Technologies......................................................................................................................................... 47
Accessing system information by using QRL..............................................................................................................47
Quick Resource Locator for PowerEdge XR4000r system...............................................................................48
Receiving automated support with SupportAssist ...................................................................................................48
Chapter 7: Documentation resources...........................................................................................49
4Contents

About this document
This document provides an overview about the system, information about installing and replacing components, diagnostic tools,
and guidelines to be followed while installing certain components.
1
About this document 5

Dell PowerEdge XR4000r system
configurations and features
The PowerEdge XR4000r system is a 2U rackmount chassis that supports:
●Up to four XR4510c 1U single-width compute sleds or up to two XR4520c 2U single-width compute sled or up to two
XR4510c 1U, single -width and one XR4520c 2U, single-width compute sleds and an optional nano-server (witness sled
XR4000w) example vSAN.
●Up to two redundant AC or DC power supply units
Topics:
•System configurations - front view for PowerEdge XR4000r
•System configurations - rear view for PowerEdge XR4000r
•Power supply unit indicator codes
•Locating the Express Service Code and Service Tag
•System information label
•Rail sizing and rack compatibility matrix
System configurations - front view for PowerEdge
XR4000r
Figure 1. Front view of chassis with four 1U sleds and an optional witness sled
Table 1. Features available on the front of the system
Item Ports, panels, and
slots
Icon Description
1 XR4510c 1U sled N/A XR4510c server for computing.
2 XR4000w witness sled N/A Optional witness server with Intel Atom processor.
3 Power supply 1 Indicates PSU 1.
4 Power supply 2 Indicates PSU 2.
5 Information tag N/A Information tag which contains service tag information.
2
6 Dell PowerEdge XR4000r system configurations and features

Figure 2. Front view of chassis with two 2U sleds and an optional witness sled
Table 2. Features available on the front of the system
Item Ports, panels, and
slots
Icon Description
1 XR4520c 2U sled N/A XR4520c server for computing.
2 XR4000w witness sled N/A Optional witness server with Intel Atom processor
3 Power supply 1 Indicates PSU 1.
4 Power supply 2 Indicates PSU 2.
5 Information tag N/A Information tag which contains service tag information.
Figure 3. Front view of chassis with two 1U sleds and one 2U sled and an optional witness sled
Table 3. Features available on the front of the system
Item Ports, panels, and
slots
Icon Description
1 XR4510c 1U sled N/A XR4510c server for computing.
2 XR4520c 2U sled N/A XR4520c server for computing.
3 XR4000w witness sled N/A Optional witness server with Intel Atom processor.
4 Power supply 1 Indicates PSU 1.
5 Power supply 2 Indicates PSU 2.
6 Information tag N/A Information tag which contains service tag information.
Dell PowerEdge XR4000r system configurations and features 7

System configurations - rear view for PowerEdge
XR4000r
Rear view of the system
Table 4. Rear view of the system
Item Ports, panels, or slots Icon Description
1 Blank Filler N/A Blank filler cover the AC-socket opening, when power supply cables
from the front of the chassis.
2 Kensington lock slot N/A Kensington lock slot for securing the chassis.
Power supply unit indicator codes
AC and DC power supply units (PSUs) have an illuminated translucent handle that serves as an indicator. The indicator shows if
power is present or if a power fault has occurred.
Figure 4. AC PSU status indicator
1. AC PSU handle
2. Socket
3. Release latch
Table 5. AC PSU status indicator codes
Power indicator codes Condition
Green Indicates that a valid power source is connected to the PSU
and the PSU is operational.
Blinking amber Indicates an issue with the PSU.
Not powered on Indicates that the power is not connected to the PSU.
Blinking green Indicates that the firmware of the PSU is being updated.
8 Dell PowerEdge XR4000r system configurations and features

Table 5. AC PSU status indicator codes (continued)
Power indicator codes Condition
CAUTION: Do not disconnect the power cord or
unplug the PSU when updating firmware. If firmware
update is interrupted, the PSUs will not function.
Blinking green and powers off When hot-plugging a PSU, it blinks green five times at a rate
of 4 Hz and powers off. This indicates a PSU mismatch due to
efficiency, feature set, health status, or supported voltage.
CAUTION: If two PSUs are installed, both the PSUs
must have the same type of label; for example,
Extended Power Performance (EPP) label. Mixing
PSUs from previous generations of PowerEdge
servers is not supported, even if the PSUs have the
same power rating. This results in a PSU mismatch
condition or failure to power on the system.
CAUTION: If two PSUs are used, they must be of
the same type and have the same maximum output
power.
CAUTION: When correcting a PSU mismatch, replace
the PSU with the blinking indicator. Swapping the
PSU to make a matched pair can result in an error
condition and an unexpected system shutdown. To
change from a high output configuration to a low
output configuration or vice versa, you must power
off the system.
CAUTION: AC PSUs support both 240 V and 120 V
input voltages with the exception of Titanium PSUs,
which support only 240 V. When two identical PSUs
receive different input voltages, they can output
different wattages, and trigger a mismatch.
Table 6. DC PSU status indicator codes
Power indicator codes Condition
Green Indicates that a valid power source is connected to the PSU,
and the PSU is operational.
Blinking amber Indicates an issue with the PSU.
Not powered on Indicates that the power is not connected to the PSU.
Blinking green When hot-plugging a PSU, it blinks green five times at a rate
of 4 Hz and powers off. This indicates a PSU mismatch due to
efficiency, feature set, health status, or supported voltage.
CAUTION: If two PSUs are installed, both the PSUs
must have the same type of label; for example,
Extended Power Performance (EPP) label. Mixing
PSUs from previous generations of PowerEdge
servers is not supported, even if the PSUs have the
same power rating. This results in a PSU mismatch
condition, or failure to power on the system.
CAUTION: If two PSUs are used, they must be of
the same type and have the same maximum output
power.
CAUTION: When correcting a PSU mismatch, replace
the PSU with the blinking indicator. Swapping the
Dell PowerEdge XR4000r system configurations and features 9

Table 6. DC PSU status indicator codes (continued)
Power indicator codes Condition
PSU to make a matched pair can result in an error
condition and an unexpected system shutdown. To
change from a High Output configuration to a Low
Output configuration or conversely, you must power
off the system.
CAUTION: Combining AC and DC PSUs is not
supported.
Locating the Express Service Code and Service Tag
The unique Express Service Code and Service Tag are used to identify the system.
The information tag is located on the rear of the system that includes system information such as iDRAC MAC address, Express
Service Tag label.
Figure 5. Locating the Service Tag of your system
1. Information tag (bottom view)
2. iDRAC MAC address information label
3. Information tag (top view)
4. Express Service Tag label
The Mini Enterprise Service Tag (MEST) label is located on the system. The MEST includes the Service Tag (ST), Express
Service Code (Exp Svc Code), and Manufacture Date (Mfg. Date). The Exp Svc Code is used by Dell EMC to route support calls
to the appropriate personnel.
Alternatively, the Service Tag information is located on a label on the left wall of the system.
System information label
Figure 6. Mechanical overview
10 Dell PowerEdge XR4000r system configurations and features
