PowerEdge T410 Technical Guidebook
Dell
DELLTM
POWEREDGETM T410
TECHNICAL GUIDEBOOK
INSIDE THE POWEREDGE T410

PowerEdge T410 Technical Guidebook
Dell
Table of Contents
1Product Comparison...................................................................................................................1
1.1 Overview/Description ........................................................................................................... 1
2New Technologies......................................................................................................................3
2.1 New Technologies Used in the PowerEdge T410................................................................. 3
3System Overview .......................................................................................................................3
3.1 Overview/Description ........................................................................................................... 3
3.2 Product Features Summary ................................................................................................. 4
4Mechanical................................................................................................................................. 7
4.1 Chassis Description ............................................................................................................. 7
4.2 Dimensions and Weight ....................................................................................................... 7
4.3 Front Panel View and Features............................................................................................ 8
4.4 Back Panel View and Features .......................................................................................... 11
4.5 Power Supply Indicators..................................................................................................... 12
4.6 NIC Indicators.................................................................................................................... 12
4.7 Side Views and Features ................................................................................................... 13
4.8 Internal Chassis Views....................................................................................................... 14
4.9 Rails and Cable Management............................................................................................ 16
4.10 Fans................................................................................................................................... 17
4.11 Control Panel/LCD............................................................................................................. 17
4.12 Security.............................................................................................................................. 17
4.12.1 Cover Latch................................................................................................................. 17
4.12.2 Bezel........................................................................................................................... 19
4.12.3 Hard Drive................................................................................................................... 19
4.12.4 Trusted Platform Management.................................................................................... 20
4.12.5 Power-Off Security...................................................................................................... 20
4.12.6 Intrusion Alert.............................................................................................................. 20
4.12.7 Secure Mode............................................................................................................... 20
4.13 USB Peripherals................................................................................................................. 20
4.14 Battery ............................................................................................................................... 21
4.15 Field Replaceable Units (FRU)........................................................................................... 21
5Electrical .................................................................................................................................. 22
5.1 Volatility ............................................................................................................................. 22
5.2 ePPID ................................................................................................................................ 22
6Power, Thermal, and Acoustic.................................................................................................. 23
6.1 Power Supplies.................................................................................................................. 23
6.2 Power Supply Specifications.............................................................................................. 24
6.3 Environmental Specifications ............................................................................................. 26
6.4 Maximum Input Amps......................................................................................................... 27
6.5 Energy Star Compliance .................................................................................................... 27
6.6 Acoustics............................................................................................................................ 27
7Block Diagram.......................................................................................................................... 28
8Processors............................................................................................................................... 31
8.1 Overview............................................................................................................................ 31

PowerEdge T410 Technical Guidebook
Dell
8.2 Supported Processors........................................................................................................ 31
8.3 Processor Configurations................................................................................................... 32
8.4 Processor Installation......................................................................................................... 33
8.5 Overview/Description ......................................................................................................... 33
8.6 DIMM Types Supported ..................................................................................................... 33
8.7 Slots/Risers........................................................................................................................ 33
8.8 Mirroring............................................................................................................................. 34
8.9 RAID.................................................................................................................................. 34
9Chipset..................................................................................................................................... 34
9.1 Overview/Description ......................................................................................................... 34
10 BIOS........................................................................................................................................35
10.1 Overview/Description ......................................................................................................... 35
10.2 Supported ACPI States...................................................................................................... 36
10.3 11G BIOS Power Management.......................................................................................... 36
10.4 I2C (Inter-Integrated Circuit) ............................................................................................... 37
11 Embedded NICs/LAN on Motherboard (LOM).......................................................................... 37
11.1 Overview/Description ......................................................................................................... 37
12 I/O Slots................................................................................................................................... 38
12.1 Overview/Description ......................................................................................................... 38
12.2 Quantities and Priorities..................................................................................................... 38
12.3 Boot Order ......................................................................................................................... 39
13 Storage .................................................................................................................................... 39
13.1 Overview/Description ......................................................................................................... 39
13.2 Drives................................................................................................................................. 40
13.3 RAID Configurations .......................................................................................................... 40
13.4 Storage Controllers............................................................................................................ 42
13.5 LED Indicators ................................................................................................................... 42
13.6 Optical Drives..................................................................................................................... 42
13.7 Tape Drives........................................................................................................................ 42
14 Video........................................................................................................................................ 42
14.1 Overview/Description ......................................................................................................... 42
15 Audio........................................................................................................................................ 43
15.1 Overview/Description ......................................................................................................... 43
16 Rack Information...................................................................................................................... 43
17 Operating Systems................................................................................................................... 43
18 Virtualization ............................................................................................................................ 45
18.1 Overview/Description ......................................................................................................... 45
19 Systems Management.............................................................................................................. 45
19.1 Overview/Description ......................................................................................................... 45
19.2 Server Management........................................................................................................... 46
19.3 Embedded Server Management......................................................................................... 46
19.4 Lifecycle Controller and Unified Server Configurator.......................................................... 46
19.5 iDRAC Express.................................................................................................................. 47
19.6 iDRAC6 Enterprise............................................................................................................. 47
20 Peripherals............................................................................................................................... 49

PowerEdge T410 Technical Guidebook
Dell
20.1 USB Peripherals................................................................................................................. 49
20.2 External Storage ................................................................................................................ 49
21 Packaging Options................................................................................................................... 49

PowerEdge T410 Technical Guidebook
1
Dell
1 Product Comparison
1.1 Overview/Description
The PowerEdge T410 is a two-socket tower server that delivers the most flexible configuration options
to fulfill different business and customer needs and maximize their IT budget.
T410 provides:
• Up to 2 sockets of Intel Xeon 5500 series processors.
• Dell’s Lifecycle Contoller available via optional iDRAC Express or iDRAC Enterprise
• Competitive security features with TPM, internal USB and IPv6
• Competitive storage expandability and with up to 6 x 3.5” hard disk drives
• Excellent serviceability and diagnostics with optional interactive LCD
• A chassis depth of only 24” for deployment flexibility.
Table 1. Comparison of T410 to T605 and T610
Feature/Spec T410 T605
(Predecessors) T610 (Next level up)
Processor 2S Intel® Xeon®
processor 5500 series AMD Opteron 2XXX series 2S Intel Xeon processor 5500 series
Front Side Bus QPI @ 6.4 GT/s 1GBz HyperTransport QPI @ 6.4 GT/s
# Procs 1 to 2 1 or 2 1 to 2
# Cores Dual or Quad Dual or Quad Dual or Quad
L2/L3 Cache 4 MB or 8 MB 4 MB or 8 MB
Chipset Intel 5500 chipset HT2100 + HT1000 Intel 5520 chipset
DIMMs
4+4 DDR3
Unbuffered w/ECC or
Registered w/ECC
1333/1066/800MHz
8 DDR2
Registered w/ECC
667MHz
6+6 DDR3
Unbuffered w/ECC or
Registered w/ECC
1333/1066/800MHz
Min/Max RAM 1 GB/64 GB 512 MB/32 GB 1 GB/96 GB
HD Bays
6 x 3.5”
Optional Hot-swap
Support 2.5" Hard disk
drives via Hot-swap tray
4 x 3.5”
Optional Hot-swap 8 x 2.5”/3.5” Hot-swap
HD Types Default SATA. Optional
SAS and SSD via add-in
controller
Default SATA. Optional
SAS via add-in controller Default SATA or SAS
Ext Drive Bay(s) 2 x 5.25” bay 2 x 5.25” bay
1x 3.5” bay 2 x 5.25” bay
Embedded HD
Controller Chipset based SATA Chipset based SATA SAS 6/iR

PowerEdge T410 Technical Guidebook
2
Dell
Feature/Spec T410 T605
(Predecessors) T610 (Next level up)
Optional Storage
Controller
NON-RAID:
SAS 5/E
LSI 2032 (For TBU only)
SAS 6/E
RAID:
SAS 6/iR Adapter
PERC 6/i
PERC 6/E
SAS 5/iR
SAS 6/iR
PERC 6/i
NON-RAID:
SAS 5/E
LSI 2032 (For TBU only)
RAID:
SAS 6/iR (Default)
PERC 6/i
PERC 6/E
Availability
Hot-swap hard disk drives;
Redundant PSU; Quad-
pack LED diagnostic/LCD
with Hot-swap hard disk
drives chassis; Memory
mirroring
Tool-less chassis; LCD
diagnostic
Hot-swap hard disk
drives; Redundant PSU;
LCD diagnostic; Memory
mirroring or sparing;
Internal SD card for
embedded Hypervisor
Server Mgt.
BMC, IPMI 2.0 compliant;
Full Open Manage suite
Optional; iDRAC6
Express, iDRAC6
Enterprise, Vflash
BMC, IPMI 2.0 compliant;
Dell Server Assistant
Optional; DRAC5
iDRAC 6 Express, BMC,
IPMI 2.0 compliant; Full
Open Manage suite
Optional; iDRAC6
Enterprise, Vflash
I/O Slots
Slot 1: PCI-E x8
connector(x4 routing, half
length → Gen 2.)
Slot 2: PCI-E x8
connector(x4 routing, full
length → Gen 2.)
Slot 3: PCI-E x8
connector(x4 routing, full
length → Gen 1.)
Slot 4: PCI-E x8
connector(x4 routing, half
length → Gen 2.)
Slot 5: PCI-E x16
connector(x8 routing, half
length → Gen 2.)
1 x PCIe x8
3 x PCIe x4
1 x PCI-X 64/133
2x PCIe x8;
3x PCIe x 4 Gen 2
RAID See optional Storage
Controller See optional Storage Controller See optional Storage Controller
NIC/LOM 2x GbE LOM
Optional: various NIC
available
1x GbE LOM
Optional: various NIC
available
2x GbE LOM w/ TOE
Optional: various NIC
available
USB Two front/four rear/two
internal Two front/five rear Two front/two rear/one
internal
Hypervisor (via internal
SD card) No No Yes

PowerEdge T410 Technical Guidebook
3
Dell
Feature/Spec T410 T605
(Predecessors) T610 (Next level up)
Power Supplies
Non-Redundant, 525W
(80+ SILVER)
Optional Redundant,
580W (80+ GOLD)
Auto Ranging
(100V~240V)
Non-Redundant, 650W
Optional Redundant,
675W (1+1)
Redundant,
870W High Efficiency
PSU or 570W High
capacity PSU
Fans Non-redundant, non-hot
swappable Non-redundant, non-hot swappable Redundant, Hot swappable
Form Factor Tower Tower Tower
Dimension (HxWxD) 444.9 x 217.9 x 616.8
(mm) (w/ foot, bezel)
17.52 x 8.58 x 24.28 (in)
456 x 272 x 635 (mm) (w/
foot, bezel)
17.97 x 10.71 x 25 (in)
441.0 x 274.0 x 621.0
(mm) (w/foot, bezel,
PSU)
17.40 x 10.80 x 24.40
(in)
Weight Max: 62.61lbs (28.4Kg) Max: 59.5lbs (27Kg) Max: 77lbs (35Kg)
2 New Technologies
2.1 New Technologies Used in the PowerEdge T410
• Intel 5500 chipset along with Intel Xeon 5500 series processors
• DDR3 memory configuration
• iDRAC6 (new Dell server remote management controller)
• SSD Drive options (support SSD drives)
3 System Overview
3.1 Overview/Description
The T410 is a two-socket tower product that delivers the most competitive feature set below the $750
entry-level cost point. It is positioned to compete against the HP ML150 and IBM x3400 servers.
The T410 provides:
• Outstanding price and feature set combination
• Industry leading feature flexibility and configurability
• Industry leading server management with LifeCycle Controller available via optional iDRAC
Express or iDRAC Enterprise
• Industry leading security features with TPM, internal USB and IPv6
• Competitive storage expandability and $/GB with 6 x 3.5”/2.5” HDD
• Industry leading serviceability and diagnostics with optional interactive LCD
• Industry leading chassis depth of only 24” in its class for SMB closets, back office and under the
desk environment

PowerEdge T410 Technical Guidebook
4
Dell
3.2 Product Features Summary
Table 2. T410 Product Features
Features Descriptions
Chipset Intel 5500 chipset
CPU Intel Xeon 5500 series processors
DIMM 4+4 DDR3
Unbuffered w/ECC or Registered w/ECC
1333/1066/800MHz
Memory Modules 1 GB UDIMM/RDIMM
2 GB UDIMM/RDIMM
4 GB RDIMM
8 GB RDIMM
TPM TPM
TCM/NO TPM
Expansion Slots
5 PCI slots
Slot 1: PCIe x8 (x4 routing, Gen2), half length
Slot 2: PCIe x8 (x4 routing, Gen2), full length
Slot 3: PCIe x8 (x4 routing, Gen 1), full length
Slot 4: PCIe x8 (x4 routing, Gen2), half length
Slot 5: PCIe x16 (x8 routing, Gen2), half length
LOM Two GbE (5716 dual port) w/o TOE
Management Full Open Manage
BMC, IPMI2.0 compliant
Optional: iDRAC6-Express, iDRAC6-Enterprice and Vflash
USB Two front/four rear/four internal
PSU Non-Redundant, 525W (80+ BRONZE)
Optional Redundant, 580W (80+ GOLD)
Auto Ranging (100V~240V)
Availability Quad-pack LED diagnostic/LCD with hot-swap hard disk drives chassis
Embedded
Graphics Matrox G200eW with up to 8 MB memory
Resolution and
Colors 1280x1024@85Hz for KVM and 1600x1200@60Hz for video out
640x480 (60/72/75/85 Hz; 8/16/32-bit color)
800x600 (60/72/75/85 Hz; 8/16/32-bit color)
1024x768 (60/72/75/85 Hz; 8/16/32-bit color)
1152x864 (75 Hz; 8/16/32-bit color)
1280x1024 (60/75/85 Hz; 8/16-bit color)
1280x1024 (60 Hz, 32-bit color) (32 bit color is only supported at 60 Hz for this resolution)
Audio No Speaker/No Buzzer
Form Factor Tower (5U rack via 3rd party tray)
Dimension
(HxWxD) 444.9 x 217.9 x 616.8 (mm) (w/ bezel, w/ tower foot)
17.52 x 8.58 x 24.28 (in)
Max Weight 28.4 Kg/62.61 lbs

PowerEdge T410 Technical Guidebook
5
Dell
Features Descriptions
Bezel Plastic (Default)
Hard Disk Drives
Bay Options 6x 3.5" Optional Hot-Swap
Support 2.5" hard disk drives via Hot-swap tray
Hard Disk
Drives/SATA
Options
3.5"/7.2 K
160 GB
250 GB
500 GB
750 GB
1000 GB
2000 GB (POST-RTS)
Hard Disk
Drives/Near Line
SAS
Options
3.5"/7.2 K
500 GB
750 GB
1000 GB
2000 GB (POST-RTS)
Hard Disk
Drives/SAS
Options
3.5"/15 K
146 GB
300 GB
450 GB
3.5"/10 K
600 GB
2.5"/10 K (in 3.5" Hot Plug HDD Carrier)
73 GB
146 GB
300 GB
HARD DISK
DRIVE/SSD
Options
2.5" (in 3.5" Hot Plug HDD Carrier)
25 GB SATA SSD
50 GB SATA SSD
100 GB SATA SSD (POST-RTS)
Media Bay 2x 5.25"
Remote Drive
Options DVD-ROM DVD+/-RW
USB DVD-ROM
Backup Device
Options RD1000 (Internal and External)
DATA-72 (Internal and External)
LTO2-L (Internal and External)
LTO3-060 (Internal and External)
LTO3FH (External)
LTO4-120 HH (Internal and External)
LTO4-120 FH (External)
PV114T (External, 2U)
Tape Automation
Options TL2000/TL4000 ML6000
PV124T

PowerEdge T410 Technical Guidebook
6
Dell
Features Descriptions
TBU Software
Options CommVault Galaxy Symantec Backup Exec including Backup Exec System Recovery
Yosemite/Little Man
PV DAS/SAN
Options MD1000
MD1120
MD3000/MD300i
Storage HBA
Options NON-RAID:
SAS 5/E
SAS 5/iR (For TBU only)
LSI 2032 (For TBU only)
RAID:
SAS 6/iR
PERC 6/i
PERC 6/E
NICs/Single Port Intel PRO/1000 PT Server Adapter
NICs/Dual Port Intel Gigabit ET Dual Port Server Adapter
Broadcom NetXtreme II 5709 Dual Port Ethernet PCIe Card with TOE
Broadcom NetXtreme II 5709 Dual Port Ethernet PCIe Card with TOE and iSCSI Offload
NICs/Quad Port Intel Gigabit VT Quad Port Server Adapter
Intel Gigabit ET Quad-Port Server Adapter
Broadcom NetXtreme II® 5709 Quad Port Ethernet PCIe Card with TOE/iSCSI Offload
Infiniband NIC N/A
FC HBA N/A
Solutions
Support Database:
SQL2008
Virtualization:
VMware®vSphere™ Version 4.0
VMware Virtual Infrastructure 3 ESX/EXSi 3.5 Update 4 (Classic version will be DIB;
embedded version is available for download from VMware website and can be installed to the
hard drive. Hypervisor is not supported.)
Hyper-V (Veridian and standalone Viridian)
Operating
System
Options
Microsoft:
Essential Business Server (Centro) 64-bit Standard(DIB) and Premium(DIB)
SBS2008 64-bit Standard and Premium (FI)
WS2008 32-bit Standard, Enterprise (FI)
WS2008 64-bit Standard, Enterprise, Datacenter (FI)
SBS2003 R2 32-bit Standard and Premium(DIB)
WS2003 R2 32-bit Standard, Enterprise
WS2003 R2 64-bit Standard, Enterprise, Datacenter(DIB)
Linux:
RHEL 4.7 ES/AS x86(DIB, NFI) (POST-RTS at Q2 block)
RHEL 4.7 ES/AS 64-bit(DIB, NFI) (POST-RTS at Q2 block)
RHEL 5.2 Standard/AP x86(DIB, NFI)
RHEL 5.2 Standard/AP 64-bit
SLES 10 SP2 64-bit(DIB, NFI)
SLES 11 64-bit (POST-RTS at Q2 block)

PowerEdge T410 Technical Guidebook
7
Dell
4 Mechanical
4.1 Chassis Description
The PowerEdge T410 chassis offers the optimum size for growing businesses and large organizations
with remote locations.
The new chassis design of the PowerEdge 410 offers cabled hard disk drives (HDDs) or hot-plug hard
disk drives. Each is available with redundant Power Supply Units (PSUs) or non-redundant PSUs are
options.
The PowerEdge T410 chassis is user friendly. Many of the T410 components devices are tool-less.
These tool-less components include HDDs (cabled and hot-plug), fans, extension cards, planar, back
plane, and redundant PSUs. The non-redundant PSU uses only three screws to reduce the assembly
and service time.
4.2 Dimensions and Weight
Figure 1. T410 Top and Side Views
Table 3. T410 Dimensions
Dimension (HxWxD)
(w/foot, w/ bezel)
444.9 x 217.9 x 616.8 (mm)
17.52 x 8.58 x 24.28 (in)
Max Weight
28.4 Kg/62.61 lbs
Zb
Zc
Za
Bezel or Outer
Most Feature
SIDE VIEW
Tower Foot
Optional Caster
Yb
Yc
Ya
Xa
Xb
TOP VIEW

PowerEdge T410 Technical Guidebook
8
Dell
Table 4. T410 Detailed Dimensions
Development
Name
Model
Number
Xa Xb Ya Yb Yc
Za
w/ bezel
Za
w/o bezel
Zb* Zc
Max Sys
Weight
T410
PE
T410
217.9
282.5
433.3
444.9
NA
37.0
21.5
574.8
579.8
28.4 Kg/
62.61 lbs
Note
Zb goes to the nominal rear wall external surface where the motherboard I/O connectors reside.
4.3 Front Panel View and Features
Figure 2. T410 Transparent Side View

PowerEdge T410 Technical Guidebook
9
Dell
Figure 3. Front Panel Views With and Without Bezel
Figure 4. LCD Model View
Front Panel
view with
Bezel
Hot-swap HDD
Front Panel view
without Bezel
Cabled HDD
Front Panel view
without Bezel
LCD model (with hot-
swap HDD chassis
configuration)
System ID
Button
USB
connector
Power Button and
NMI button

PowerEdge T410 Technical Guidebook
10
Dell
Figure 5. LED Model View
Figure 6. LED Descriptions
Quad Pack LED (with
cabled HDD chassis
configuration)
System ID
Button
USB
connector
Power Button and
NMI button

PowerEdge T410 Technical Guidebook
11
Dell
4.4 Back Panel View and Features
Figure 7. Back Panel Views of Redundant and Non-redundant PSUs
Non-redundant PSU
Back Panel view
with redundant PSU
Power cord
holder

PowerEdge T410 Technical Guidebook
12
Dell
4.5 Power Supply Indicators
Figure 8. Close-up of Redundant PSU Option
Light indicators:
• Not lit – AC power is not connected.
• Green – In standby mode, a green light indicates a valid AC source is connected to the power
supply and it is operational. When the system is on, a green light also indicates the power
supply is providing DC power to the system.
• Amber – Indicates a problem with the power supply.
• Alternating green and amber – When hot-adding a power supply, this indicates that the power
supply is mismatched with the other power supply (Ex. a High Output 500-W power supply and
a 400-W power supply are installed in the same system). Replace the power supply that has the
flashing indicator with a power supply that matches the capacity of the other installed power
supply.
4.6 NIC Indicators
Figure 9. NIC Indicators
Table 5. LED States
State Link LED
(Green/Yellow) Activity LED (Green)
No link Off Off
D0uninitalized (out of
box), D3cold, S4
(hibernation)
WOL disabled Off Off
WOL enabled, link, no
activity Green if the port is operating at maximum
port speed; Yellow
otherwise
Off
WOL enabled, link,
activity On (blinking at speed related to packet density)

PowerEdge T410 Technical Guidebook
13
Dell
State Link LED
(Green/Yellow) Activity LED (Green)
Pre-OS POST or OS
without driver Link, no activity Green if the port is
operating at maximum
port speed; Yellow
otherwise
Off
Link, activity On (blinking at speed
related to packet density)
OS with driver Link, no activity Off
Link, activity On (blinking at speed
related to packet density)
4.7 Side Views and Features
Figure 10. Standard Coin Lock Shown

PowerEdge T410 Technical Guidebook
14
Dell
4.8 Internal Chassis Views
Figure 11. Cabled HDD Configuration with Air Shroud
Figure 12. Hot-swap HDD Configuration with Air Shroud
Figure 13. Hot-swap Hard Disk Drives Configuration without Air Shroud

PowerEdge T410 Technical Guidebook
15
Dell
Figure 14. Backplane for Hot-swap Hard Disk Drives Configuration Option
Figure 15. Power Distribution Board (PDB) for Redundant PSU

PowerEdge T410 Technical Guidebook
16
Dell
4.9 Rails and Cable Management
The PowerEdge T410 is a flexible stand-alone tower and is not rackable.
Figure 16. Power Cord Cable Management for Redundant PSU
Figure 17. Power Cord Cable Management for Non-redundant PSU
Power cord
holder
