DeLonghi Dragon4 Pro Specification sheet

Better Everyday
TRD50615E
Get Started
This short guide is not
intended to explain
all the functions
of the appliance.
Please read all of the
owner’s instruction booklet
before use.
ELECTRIC
OIL FILLED
RADIATOR

HOW TO SET UP
2
P lug the unit into
an outlet .
Hour digits will blink.
12 3
Set clock: Turn dial to
set current hour in military
time (ex: 13 equals 1pm;
22 equals 10pm ).
Push dial to
confirm hour.
4 5
Minute digits
will blink.
6
Turn dial to set
current minutes.
Push dial to confirm
minutes. A long
beeping sound will
be heard.
7

TRD50615E
MANUAL OPERATION MODE (TEMP/POWER LEVELS)
3
Push the standby/power
button to turn unit ON.
Turn dial to select desired
temperature. New
temperature is now set.*
12 3
If you want to change power
level, press dial twice and
follow steps 4 and 5.
Turn dial to desired power level.
(see chart below)
4 5
Push dial to confirm power
level selection.
* Note:
It is not possible
to switch between
Fahrenheit and
Celsius.

4
SELECTED VERSUS WORKING POWER LEVELS
Min
50°F
Min
50°F
Max
less than T1
Max
83°F
Default
69°F
Default Anti-frost
41°F
Red light
Green light
T1
T2
The unit will automatically switch between the unit’s working power levels depending on
the difference between your desired selected temperature and the actual room temperature.
Note: If none of the working power
level bars are lit, the unit is not
consuming any wattage.
TIMER OPERATION MODE
Note: T2 temperature must not exceed the temperature of T1
Preset daily timer program
The default preset daily timer program is the following:
T1=69°F
42 6 810 12 14 16 18 20 22 0
0
69°F
T2 T2 T2
T1T1
T1
T2
Note: This chart is showing timer
settings as follows:
T2 from midnight to 5am,
T1 from 5am to 8am,
T2 from 8am to 4pm,
T1 from 4pm to 10pm,
T2 from 10pm to midnight.
(24)
Time Intervals
Explaining T1 and T2
NOTE: Green and red indicators differentiate the two timer settings.
They do NOT stand for “go” and “stop”.
In the example above,
T1 T2
shows Timer 1’s MIN (50ºF) and MAX (83ºF) temperature range
as well as the unit’s default temperature setting (69ºF).
T1 T2
shows your choice of Timer 2 set
to unit’s default of OFF, set to anti-freeze function temperature (41ºF), or set between MIN
(50ºF) and any temperature lower than your MAX setting of Timer 1 (green).
Preset Daily Timer Program

TRD50615E
5
PROGRAMMING TIMER OPERATION MODE
Setting Timer Temperatures T1 and T2
To modify red (T2),
turn dial till red light
blinks. Push dial
to confirm. Or, to
modify green (T1
already flashing),
push dial to confirm.
5 6
Display will show the
current setting for
the green or red
temperature.
7
Turn dial to the
desired temperature.
Push dial to confirm.
Push dial to confirm.
Repeat steps 2 to 8
for temperature not
yet set (T1 or T2).
8
Turn unit ON
(display should show
temperature and
power level).
1 2
Push dial once, then
power level will blink.
3
Turn dial till clock
blinks.
Press dial to confirm
(green light will flash).
4

SETTING TIME PERIODS FOR T1 AND T2
6
Turn dial to select
the ending time for
the first or previous
program selected.
Push dial to confirm.
6
The ending time
will appear and
green (T1) or red
(T2) LED indicator
will blink.
8
Turn dial to select
between green (T1)
and red (T2). Push
dial to confirm.
Changing 24 Hour Daily Timer Program
Last time setting will flash.
Turn dial clockwise to next
time setting. Press dial to
confirm. Repeat steps 8
and 9 for additional
settings to cover ALL 24
hours. Last time setting
must be to 00:00
(midnight). If timer set
correctly long beeping
sound will confirm.
9
Turn off unit to
STANDBY mode
(display shows
time).
1 2
Push and hold
the timer button
for 5 seconds.
4
Turn dial to
select green (T1)
or red (T2). Press
dial to confirm.
00:00 will be
blinking and green
(T1) or red (T2) LED
will light.
53
Display will show
00:00 (midnight).
Green LED (T1)
will be blinking.
7

TRD50615E
Push the timer button to
activate the timer program.
ACTIVATING AND DISPLAYING TIMER SETTINGS
7
2
4
The display shows which
temperature settings (green
T1 or red T2) have been
programed starting from
midnight ( 00:00 ).
5
Turn dial clockwise to scroll
thru the programmed time
settings from 00:00 (midnight)
thru 23:45 (11:45pm).
Push STANDBY/ POWER
button to turn on unit.
1
Push and hold the timer
button for 5 seconds.
3
Note for step 4:
A switch from red to
green or green to
red indicates when
programmed timer
settings are scheduled
to change.
General Note:
If you don’t wish to set
your own timer settings,
you can use the preset
settings (see page 4).
Activate Timer Settings (follow steps 1-2)
Display Timer Settings (follow steps 1-5)

Better Everyday
www.delonghi.com
like us: DeLonghi North America – follow us @DeLonghiNA
5711011411 _00_0219
