DeLonghi HCX3120FS User manual

CONVECTOR

67
B
A
B
A
B
B
A
AD
D
C
C
A
B
C
D
E
Fig. 1 Fig. 2
Fig. 3

7
IMPORTANT WARNINGS
Safety warnings
Important!
- This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
- Children of less than 3 years should
be kept away unless continuously
supervised.
- Children aged from 3 years and less
than 8 years shall only switch on/
o the appliance provided that it
has been placed or installed in its
intended normal operating position
and they have been given supervision
or instruction concerning use of the
appliance in a safe way and understand
the hazards involved. Children aged
from 3 years and less than 8 years shall
not plug in, regulate and clean the
applianceorperformusermaintenance.
CAUTION — Some parts of this product
can become very hot and cause burns.
Particular attention has to be given
where children and vulnerable people
are present.
- WARNING: In order to avoid
overheating, never under
any circumstances cover the
appliances during operation, as this
would lead to dangerous overheating.
- The appliance must not be located
immediately below a xed socket-
outlet.
- When the heater is used with feet do
not use in the vicinity of bathtubs, wash
basins, showers, sinks and swimming
pools.
- If you intend to x your appliance to the
wall, make sure that the switch or other
control devices are not within reach of
persons in the bath or shower.
- If the power cable has been damaged, it
must be replaced by the manufacturer
or the technical service centre or by a
qualied person so as to avoid all risks.
- ATTENTION:in ordertoavoidanydanger
caused by an accidental resetting of the
safety system, this appliance must not
be powered through an external timer.
- Do not use the appliance in small rooms
when they are occupied by persons that
are not capable of leaving the room,
unless constant supervision is provided.
Please note:
- Never use the heater to dry laundry.
- Never place the power cable on top of the heater while it
is hot.
- We recommend that you not place the heater in a
draught, because strong draughts of air may adversely
aect the equipment’s operational eciency.
- Only use the heater in an upright position.
- The heater must be positioned at least 80cm from
furniture or other objects.
- The rst time you use the appliance, operate it of at
least 15 minutes with the thermostat at maximum to
eliminate the “new” smell. A little smoke due to the
protective substances applied to the heating element
before transport may be given o.
- Do not position the appliance on long hair carpets, in
order to avoid obstruction to the air intake grille located
under it.
- Do not obstruct the hot air outlet grilles or the air intake
grille on the bottom of the appliance.
- Position the appliance so that the plug and the outlet can
be easily reached even after installation.
- Do not use the appliance in rooms less than 4m2in

8
area.
-A tip over safety device turns the appliance o if it falls
over or is positioned inappropriately in such a way as to
jeopardise safety.
The appliance emits a beep and turns o. The appliance
resumes operation after being placed in an upright posi-
tion again.
- The appliance is tted with a safety device which will
switch the appliance o in case of accidental overheating.
To reset, disconnect the plug from the power socket for
a few minutes, remove the cause of overheating then
plug the appliance in again. If this abnormal situation
happens several times, please contact the customer
service.
Danger of burns!!
- The use of an extension lead is not recommended, as
overheating of the extension lead may occur during the
operation of the heater.
The appliance complies with the following EC directives:
- Low Voltage Directive 2006/95/EC and subsequent
amendments;
- EEC Directive 2004/108 on electromagnetic compatibility
(EMC) and subsequent amendments;
Disposing of the appliance
In compliance with European directive 2002/96/EC,
the appliance must not be disposed of with household
waste, but taken to an authorised waste separation
and recycling centre.
INTRODUCTION
Thank you for choosing a De’Longhi product.
Please take a few moments to read the instructions to avoid
risks or damage to the appliance.
Symbols used in these instructions
Important warnings are identied by the symbols below.
It is important to respect the warnings.
Failure to respect the warnings could lead to electric shock,
serious injury, burns, re or damage to the appliance.
Important!
Failure to observe the warning could result in injury or damage
to the appliance.
Danger of burns!!
Failure to observe the warning could result in burns or scalds.
Please note:
This symbol indicates recommendations and important
information for the user.
DESCRIPTION
A Max + Fan indicator light
B Thermostat
C Power selector
D Timer
E Slider
General instructions
Remove the heater from the packaging. Check that neither
the heater nor the power cable has been damaged during
transport. Do not operate the heater if damaged. Remove all
publicity material present on the appliance. The appliance
is suitable for free-standing or wall-mounted usage. Do not
assemble the feet if wall-mounted.
Electrical connection
- Before connecting the appliance to the current outlet,
check that the voltage indicated on the appliance rating
plate is the same as your electric plant and that it can
stand the power consumption (Watt) indicated by the
labelling.
- If more than one appliance is used at once, it is important
to ensure that the electric plant is able to support the
power required.
Mounting the feet
Turn the appliance upside down on a rug or soft surface in
order to prevent damaging the paint nish.
Fix the feet to the appliance with the nr. 4 screws B supplied
(see g. 1), 2 screws for each foot.
Wall-Mounting Installation
The wall mounting kit contains:
4 metal brackets (A)
2 screws 4,8x13 PH (B)
4 screws 4,5x25 PH (C)
4 plastic anchors 6x30 (D)
Required tools for assembly and estimated assembly
time
Screwdriver PH 2 x 100 (Phillips type)
Estimated assembly time: 30 minutes
Before installing the unit , make sure of the following:
a. The appliance must not be located directly

9
beneath a current outlet.
b. The plug and outlet must be easy to reach after
installation.
c. No electric cables or other pipes could be damaged
during the installation.
d. Keep away from curtains or ammable materials.
To wall-mount, proceed as follows:
Turn the appliance upside down on a at stable surface . Using
a screwdriver, x the 2 brackets A with the 2 screws B as shown
in Fig. 2.
For brick walls use a 6 mm concrete drill bit.
For plaster board or false (hollow) walls, it is recommended to
use appropriate screws and anchors (not supplied).
1. Before drilling the wall, mark the exact points, respecting
the minimum distances as shown in g. 3.
2. Drill the wall where previously marked, and insert the
plastic anchors D.
3. Fix the 2 metal brackets A using the two screws C
provided.
4. Hang the appliance on the bracket.
5. Mark out the 2 lower xing points. Remove the appliance,
drill the lower holes and insert the wall anchors D.
6. Now, you can hang back the heater on the bracket and
x the lower part of the appliance with the 2 remaining
screws C.
USE
Operation and use
Plug into the mains, turn the thermostat dial (B) to maximum
and turn the appliance on by means of the power selector (C)
(see description) as described below:
• Turn the power selector knob to the Min position to
select minimum power.
• Turn the power selector knob to the Med position to
select medium power (only in some models).
• Turn the power selector knob to the Max position to
select maximum power.
• Turn the power selector knob to the Max position to
select maximum power with the fan (the MAX + FAN
indicator light comes on).
• To turn the appliance o completely: turn the power
selector to the "0" position and the thermostat to the "
" position, then unplug from the mains.
Adjusting the thermostat
When the room has reached the required temperature, turn
the thermostat dial (B) slowly anticlockwise until you hear a
click and no further.
The thermostat will automatically regulate the temperature
set and keep it constant. In spring or autumn or on mild days,
you can save energy by using minimum power.
Frost prevention mode
With the thermostat dial (B) in the position and one of
the power levels selected, the appliance maintains room
temperature at about 5°C, preventing freezing with minimal
energy consumption.
Models with ventilation
The appliance has 2 fans for faster more even heating. To start
this function, turn the power selector (C) to Max .
Models with 24 hour timer
When the appliance is plugged to the mains the timer is
always in turning movement, in order to stay synchronized
with the local time. To operate the appliance without the
timer, place the timer slider (E) in the position. To
operate the appliance at set times, position the slider in the
position and proceed as follows:
• Check the time on your clock or watch. If it is 10.00 for
example, turn the numbered programmer disk until the
number 10 coincides with the pointer marked on the
programmer.
• Set the periods of time during which you want the
appliance to operate
by pushing the
teeth outwards (see
gure). Each tooth
corresponds to a
period of 30 min.
At the end of this
procedure, sectors
corresponding to the
operating periods can be seen.
• In this way, the appliance will function automatically
each day at the times set. (Important: the appliance must
always be plugged into the socket)
• To modify programming, return the teeth to the initial
position and set the new operating periods.
• To turn the appliance o, turn the power selector to the
"0" position.
MAINTENANCE
Before carrying out any maintenance, unplug the heater from
the mains and wait for it to cool o completely. This heater
requires no particular maintenance. It is sucient to remove
the dust with a soft, dry cloth. Never use abrasive powders or
solvents. If necessary remove concentrated areas of dirt with a
vacuum cleaner.

10
PROBLEM CAUSE SOLUTION
The appliance doesn’t work Be sure it is plugged in and that the electrical
outlet is working.
Check for any obstruction.
The power selector is in the ”0”position.
The thermostat may be set too low.
Setting the timer
Plug into the outlet.
Remove the obstruction, unplug the heater
and let the appliance cool down. If the appli-
ance doesn’t work please contact the nearest
service center.
Turn the power selector to the position MIN,
MED, MAX, MAX .
Turn the thermostat clockwise to a higher
setting until the heater restarts.
Make sure the timer is correctly set to local
time and check the position of the teeth.
TROUBLESHOOTING
TECHNICAL CHARACTERISTICS
Power supply See rating label
Absorbed power “
ELECTRICAL CONNECTION (UK ONLY)
A) If your appliance comes tted with a plug, it will incorporate a 13 Amp fuse. If it does not t your socket, the plug should
be cut o from the mains lead and an appropriate plug tted, as below. With alternative plugs not incorporating a fuse,
the circuit must be protected by a 15 Amp fuse. If the plug is a moulded-on type, the fuse cover must be re-tted when
changing the fuse using a 13 Amp Asta approved fuse to BS 1362. In the event of losing the fuse cover, the plug must.
NOT be used until a replacement fuse cover can be obtained from your nearest electrical dealer. The colour of the correct
replacement fuse cover is that as marked on the base of the plug.
WARNING: Very carefully dispose of the cut o plug after removing the fuse: do not insert in a 13 Amp socket elsewhere in
the house as this could cause a shock hazard.
B) UK Plug specications: please follow the instructions provided below.
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The blue wire must be connected to the terminal marked with the letter N or coloured black.
The brown wire must be connected to the terminal marked with the letter L or coloured red.
If you have a 3-pins plug, do not connect any wire to the "earth" terminal.

5711310391/06.15_00
