DELTA DORE DRIVER 620 User manual

Because of changes in standards and equipment, the characteristics given in
the text and the illustrations of this document are not binding unless confirmed
by our services.
• Carefully read these instructions prior to installation.
• The unit must be installed in compliance with
current standards.
• Always switch off the mains before installing or
servicing the unit.
• Do not attempt to repair the unit yourself;
an after-sales service is available.
• Check that the fastenings are suited to the surface to
which the unit will be attached (plasterboard, brick, etc.).
• The diagrams provided are simplified for greater
clarity. Protections and other accessories required
by standards are not illustrated.
Standard NF C15-100 and good practice must be com-
plied with. Connected or nearby units must not generate
excessive interference (directive 2004/108/EC).
1. Technical characteristics
3. Connection
• 230 V, 50 Hz power supply, ±10%
• Consumption: 2 VA
• Class II insulation
• 1 or 2 pilot wires output 0.1A / 230V
• Clock backup in the event of a blackout:
2 hours (per capacitor)
• Dimensions: WxHxD = 80 x 103 x 16 mm
• Protection index: IP 30
• Installation in an environment with normal pollution
levels
• Storage temperature: -10°C to +70°C
• Operating temperature: 0°C to +40°C
Put all of the installation’s convectors on Comfort
(with the set-point on its maximum setting).
When the unit is switched on, a test lasting about
1 minute 30 seconds checks that the outputs are
correctly connected.
If the display remains “normal”, this means there
are no problems.
If a problem exists, the DRIVER displays Pb - - .
Sortie et relance
du mode test
Choix de la sortie à tester
Lancement du test
sortie par sortie
Validation et démarrage
du test de la sortie choisie
Exemple : test de la sortie 2
Output 2 test underway.
Repeat the operations for zone 1.
Check the incorrect connections.
To exit test mode, press the init button.
Checking the pilot wire connections
DRIVER 610 DRIVER 620
Terminal 3 Convectors
zone 1
Convectors
zone 1
Terminal 4 Non Connected Convectors
zone 2
NL NL
Non
connected
Zone 1
Pilot Wire
Convectors
Zone 2
Pilot Wire
Convectors
Zone 1
Pilot Wire
Convectors
DRIVER
610
The room unit must be installed at a height of
approximately 1.5 m, so that it is within arm’s reach
for ease of use. To attach the unit to the wall, you
must separate it from its base. To do so, unlock the
casing.
Unscrew the terminal box cover and
lift it up as high as it will go to block it,
then position the base on the wall
running the wires out through the hole in the cover.
Secure the base using suitable screws
and screw anchors or fit
onto a flush-mounted box
(distance between
centres 60 mm).
Connect the control wires.
Close the box and tighten
the terminal box cover
screw.
DRIVER
620
DRIVER
Room unit mounting
Installation guide
www.deltadore.com
DRIVER 610 - 620
Pilot wire programmer 1 or 2 zones
DELTA DORE - 08/18
Exit and relaunch
test mode
Launch the test
output by output
Choose the output to test
Raccordement de la
sortie 2 correct
Raccordement de la
sortie 2 incorrect
OU
Le numéro de la
sor
tie devient fixe
Le numéro de la
sortie disparaît
Connection of output 2
incorrect
The output’s number
becomes fixed
The output’s
number disappears
Connection of output 2
correct
Approve and restart the test
for the chosen output
Example: test for output 2
