Delta HEH030BB User manual

Specification and Manual
Customer: STD
Description: AC220V 50/60Hz Heater 300W (Din Mountin )
Customer Part No.: Rev.:
Delta Model No.: HEH030BB Rev.: 01
Sample Date Code:
Sample Issue Date: MAY.29 2020
DELTA ELECTRONICS, INC.
TAOYUAN PLANT TEL: [phone]
252, SHANGYING ROAD, GUISHAN INDUSTRIAL ZONE, FAX: [phone]
TAOYUAN CITY 33341, TAIWAN
Please send one copy of this specification back after
you si ned approval for production pre-arran ement
Approved by:
Date:

Part no.:
Delta model no.: HEH030BB
Pa e 2
Table of content
Description .......................................................................................................................................... 3
Packin & Shippin ........................................................................................................................... 3
Safety Notes ....................................................................................................................................... 3
1. Product Instruction .................................................................................................................... 7
1-1. General Description .......................................................................................................... 7
1-2. Main Feature & Model Number ....................................................................................... 7
1-3. Dimension ........................................................................................................................... 8
1-4. Thermal and Airflow .......................................................................................................... 9
2 Electrical Specification.............................................................................................................. 9
2-1. Indicator & Connector ....................................................................................................... 9
2-2 Protection ........................................................................................................................... 10
3. Environmental Condition ........................................................................................................ 10
4. Reliability Table ........................................................................................................................ 11
5. Safety Certification .................................................................................................................. 11
6. Fault analysis and processin ............................................................................................... 11
7. Reclaim ................................................................................................................................... 12
8. Versions .................................................................................................................................... 13

Part no.:
Delta model no.: HEH030BB
Pa e 3
Description
This document is an installation and the characteristics of Delta HEH series.
Before installin the unit, please read this manual thorou hly, and followin
the instructions contained in it. The document is the exclusive property of
Delta Electronics, Inc. it should not be distributed, reproduced, or any other
format without prior permission of Delta. Specifications are subject to
chan e without notice.
Packin & Shippin
Durin handlin or transport, it should be handled and transported with care.
Please Pay attention to the below icons on the packa e. After power on
please make sure there is no abnormal acoustic noise.
Safety Notes
Before installin heater, read these instructions carefully. Failure to follow
these instructions could dama e the product or cause a hazardous condition.
2. Check the ratin s on the heater label to assure the product is suitable for
your application.
Meanin of WARNING and CAUTION notices:
Warning:
To avoid electric shock and equipment dama e, disconnect any power
supplies to the enclosure before installin the electric heater. Do not power
on any circuits before all internal and external electrical and mechanical
clearances are checked to assure that all assembled equipment functions
safely and properly.
1. Installation work and electrical wirin should be done only by qualified
personnel in accordance with all applicable codes, standards and
national wirin re ulations.

Part no.:
Delta model no.: HEH030BB
Pa e 4
2. Use this unit only in the manner intended by the manufacturer. If there
is any question please contact the manufacturer.
3. Install the heater in accordance with the instructions in this installation
manual. Improper installation may result in dama e, electric shock or
fire.
4. Make sure that all wirin is secured, that specified wires are used,
and there is no strain on the terminal connections or wires.
5. Before servin or cleanin unit, switch power off and disconnect
power supply.
6. When cuttin or drillin into wall or ceilin , do not dama e electrical
wirin or hidden utilities.
7. Be sure to use only the specified accessories and parts to complete
installation.
8. Protective roundin connection: The enclosure must be rounded at
the protective round terminal. Use recommended wire and use
sprin washer to avoid loosenin .
9. To reduce the risk of electrical shock: Means for disconnection must
be incorporated in the fixed wirin in accordance with the wirin rules.
10. This appliance is intended for use only by qualified personnel.
Caution:
Do not use these electric heaters in dusty, dirty, corrosive, or hazardous
locations. Adequate protection must be taken to protect people from
potential burns and to protect other components from this heat. Always allow
the heater to cool before touchin it. Thermal sensitive devices or materials
may need to be located further from the heater than the minimum
recommended distance. Heaters must not be installed on wood or other
combustible surfaces. This heater must only be installed in a totally
enclosed enclosure.
1. Do not allow children to touch it. Avoid placin any object on it.
2. Do not block the air inlets or exits.

Part no.:
Delta model no.: HEH030BB
Pa e 5
3. Do not install heater at any place where there is a dan er or
flammable as leaka e.
4. To avoid injury, do not touch exhaust air or surface durin operatin
or just turn off products.
5. This appliance is not to be used by any persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowled e,
unless they have been iven proper supervision or instruction.
6. Children should be prevented from playin with the appliance.

Part no.:
Delta model no.: HEH030BB
Pa e 6
Specification for Approval
Customer :
Description : AC220V 50/60Hz Heater 300W (Din Mountin )
Customer P/N : Rev. :
Delta model no. : HEH030BB Rev. : 01
Sample revision. : Date Code :
Sample issue date : MAY.29 2020 Quantity :1 pc

Part no.:
Delta model no.: HEH030BB
Pa e 7
1. Product Instruction
1-1. General Description
The heater is desi ned for warmin up the air in enclosure. It can avoid
equipment dama ed at lower temperature and water condensation. The
heater can be mounted on the wall of cabinet.
HEH X1 X A - XXX
(1) (2) (3) (4) (5)
No Item Di it Specification
(1) Product Messa e HEH Heater
(2) Coolin Capacity (W) X1 X1=030 (300W)
(3) Operation Volta e B AC input
(4) Product Version B N/A
(5) Customer ID N/A N/A
1-2. Main Feature & Model umber
Dimensions, Wei ht & Mountin method
Dimension (H x W x D) (without flan e) mm (inch) 145 x 75 x 105 (5.7 x 3.0 x 4.1)
Application Indoor
Wei ht K (lbs) 0.6 (1.3)
Mountin Method Din rail
Color (optional) BLK
Environmental Protection & Performance
Operatin Temperature Ran e °C (°F) -40 to +60 (-40 to +140)
Operatin Humidity Internal: 0~90% RH, non-condensin
Stora e Temperature °C (°F) -40 to +75 (-40 to +167)
Stora e Relative Humidity RH Internal: 0~90% RH, non-condensin
Protection for Dust ,Wind and Water
(External) IEC 60529 IP20
Coolin Capacity & Operational Data
Rated Heatin Capacity* W 300 +/-10%
Rated Heatin Current* A 1.65(Max.) (at 220Vac)
Rated Internal Airflow CFM 43 REF.
Power & Ran e
Input Volta e VAC 220
Input Volta e Ran e VAC 200~240
Startup avera e current ** A 9.0(Max.)
Inrush Current *** A 50(Peak)

Part no.:
Delta model no.: HEH030BB
Pa e 8
Key Components
Controller NA
Communication port NA
Fans Delta Hi h Efficiency Fan
* The Heating capacity (W) is defined as W=V*A at 0
o
C
W : power consumption
V: perating Voltage
A : perating current
** Test condition are AC input 220Vac that is cold start at ambient temperature 25
o
C. Please check
the notice at section 2 – Electrical specification
*** Test condition are AC input 220Vac that is cold start at ambient temperature 20
o
C. Please check the
notice at section 2 – Electrical specification.
1-3. Dimension
NOTE :
(1) Material : PBT 94V0
(2) Dimensional tolerance : ± 1.5mm
DIN 35mm RAIL
MOUNTING CLIP
Unit: mm(inch)
Material: Plastic
Dimensional Tolerance: ±1mm

Part no.:
Delta model no.: HEH030BB
Pa e 9
1-4. Thermal and Airflow
The cool air flow into the heater and warmed up by heatin sink inside
the case, then heated air is supplied to the system.
* Minimum gap for both of cool air inlet and warm air exhaust is required to avoid short circulation
2 Electrical Specification
2-1. Indicator & Connector
 Power Supply Connector
Connection
Power input : JST YLR-02V
Pin1: L input
Pin2: N input
WARNING :
1. Do not disconnect and lockup the wire connector while the power
is on.
2. Ensure the power connector polarity matched accurately to avoid
device dama e.

Part no.:
Delta model no.: HEH030BB
Pa e 10
 Startup average current and inrush current：
The startup avera e and inrush current waveform defined as bellow
table. These experiments are all finished at ambient 25˚C at 220Vac.
Tested waveform to startup avera e current and inrush current.
Item Current peak and time Wave form
Startup
avera e
current
Maximum Current : 9A
Max. Duration Time:3sec
Measurin methods: The
PTC element maximum
transient current RMS
value after power on.
Inrush
current
Peak current: 50A Max.
Duration Time: 4msec
Measurin methods:
Power on AC input then
measure the PEAK
current value.
2-2 Protection
 Over Temperature Protection:
Thermal cut-off switcher: 85˚C (heatin stop)
3. Environmental Condition
 Operating Temperature
-40 to +60 (-40 to +140)
 Storage Temperature
-40 °C ~ +75 °C (-40 °F ~ 167 °F)
 Operation Humidity
Internal air loop: 0 ~ 90 % RH, non-condensin
 Ingress Protection Rating
IP20 (IEC60529)

Part no.:
Delta model no.: HEH030BB
Pa e 11
4. Reliability Table
Test item Condition
Hi h temperature IEC 60068-2-2
Low temperature IEC 60068-2-1
Hi h temp. /Hi h humidity IEC 60068-2-14 TEST Nb
Temperature cycle IEC 60068-2-3
Vibration ETSI 300 019-1-4 CLASS 4.1
Packa e bump IEC 60068-2-29
 MTBF
The L10 Fan life is expected to be at least 80,000 hours continuous
operation at 40°Cwith 15 ~ 65%RH .@ label rated volta e.
5. Safety Certification
6. Fault analysis and processing
Fault State Analysis of the Reasons Solutions
Power on, and the
Heater is no
heatin
• Power failure or no
power.
• The tar et
temperature is
hi her than
Thermostat on temp
• Heater failure.
• Check the power supply
and the electric circuit.
• Check the ambient
temperature to define
heater
Is failure or not
• Please contact Delta or
authorized Delta service
a ent.
Power on, Heater
is always at
heatin status.
• The tar et
temperature is lower
than Thermostat off
temp
• Heater failure
• Check the ambient
temperature to define
heater
Is failure or not,

Part no.:
Delta model no.: HEH030BB
Pa e 12
• Please contact Delta or
authorized Delta service
a ent.
Power on, the Fan
is stop but the
heatin is enable
at low temp
condition
• Fan lock
• Heater failure
• Power off product than
check the Fan blade is no
block by
forei n matter
• Please contact Delta or
authorized Delta service
a ent.
Power on, the Fan
is runnin but the
heatin is
disenable at low
temp condition
• Over temperature
protect.
• Heater failure
• Check the heater air input
and output is no block, If
the heater surface is still
hot, wait for surface cold
down and power on a ain
at low temp condition for
check the over protect is
clear or not.
• Please contact Delta or
authorized Delta service
a ent.
7. Reclaim
At the end of the unit workin life, the produce must not be disposed of as
urban waste. It must be taken to a special local authority differentiated waste
collection center or to a dealer providin this service.

Part no.:
Delta model no.: HEH030BB
Pa e 13
8. Versions
REV. DESCRIPTION DRAWN CHECKED APPROVED
ISSUE
DATE
ME EE CE
00 ISSUE SPEC EDWARD.LEE
09/10'18
EDWARD.LEE
09/10'18
ARVIN.HSU
09/10'18 ------
Diamond
CHEN /
CW.CHEN
09/10'18
09/05'18
01
REMOVE
Warranty
EDWARD.LEE
05/29'20
EDWARD.LEE
05/29'20
ARVIN.HSU
05/29'20 ------
Diamond
CHEN /
GAVIN.CHEN
05/29'20
05/29'20
