Delta HEH080BB User manual

Specification and Manual
Customer:
Description: Heater for Equipment (Wall Mounting)
Customer Part No.: Rev.:
Delta Mo el No.: HEH080BB Rev.: 04
Sample Date Co e:
Sample Issue Date: MAY.29 2020
DELTA ELECTRONICS, INC.
TAOYUAN PLANT TEL: [phone]
252, SHANGYING ROAD, GUISHAN INDUSTRIAL ZONE, FAX: [phone]
TAOYUAN CITY 33341, TAIWAN
Please sen one copy of this specification back after
you signe approval for pro uction pre-arrangement
Approve by:
Date:

Part no.:
Delta mo el no.: HEH080BB
Page 2
Table of content
Description .......................................................................................................................................... 3
Packing & Shipping ........................................................................................................................... 3
Safety Notes ....................................................................................................................................... 3
1. Pro uct Instruction .................................................................................................................... 7
1-1. General Description .......................................................................................................... 7
1-2. Main Feature & Mo el Number ....................................................................................... 7
1-3. Dimension ........................................................................................................................... 9
1-4. Thermal an Airflow ........................................................................................................ 10
2 Electrical Specification............................................................................................................ 11
2-1. In icator & Connector ..................................................................................................... 11
2-2 Protection ........................................................................................................................... 12
3. Environmental Con ition ........................................................................................................ 12
4. Reliability Table ........................................................................................................................ 12
5. Safety Certification .................................................................................................................. 12
6. Fault analysis an processing ............................................................................................... 13
7. Reclaim ................................................................................................................................... 14
8. Versions .................................................................................................................................... 14

Part no.:
Delta mo el no.: HEH080BB
Page 3
Description
This ocument is an installation an the characteristics of Delta HEH series. Before
installing the unit, please rea this manual thoroughly, an following the instructions
containe in it. The ocument is the exclusive property of Delta Electronics, Inc. it shoul
not be istribute , repro uce , or any other format without prior permission of Delta.
Specifications are subject to change without notice.
Packing & Shipping
During han ling or transport, it shoul be han le an transporte with care. Please Pay
attention to the below icons on the package. After power on please make sure there is
no abnormal acoustic noise.
Safety Notes
Before installing heater, rea these instructions carefully. Failure to follow these
instructions coul amage the pro uct or cause a hazar ous con ition. 2. Check the
ratings on the heater label to assure the pro uct is suitable for your application.
Meaning of WARNING an CAUTION notices:
Warning:
To avoi electric shock an equipment amage, isconnect any power supplies to the
enclosure before installing the electric heater. Do not power on any circuits before all
internal an external electrical an mechanical clearances are checke to assure that all
assemble equipment functions safely an properly.
1. Installation work an electrical wiring shoul be one only by qualifie personnel
in accor ance with all applicable co es, stan ar s an national wiring
regulations.
2. Use this unit only in the manner inten e by the manufacturer. If there is any
question, please contact the manufacturer.

Part no.:
Delta mo el no.: HEH080BB
Page 4
3. Install the heater in accor ance with the instructions in this installation manual.
Improper installation may result in amage, electric shock or fire.
4. Make sure that all wiring is secure , that specifie wires are use , an there is
no strain on the terminal connections or wires.
5. Before serving or cleaning unit, switch power off an isconnect power supply.
6. When cutting or rilling into wall or ceiling, o not amage electrical wiring or
hi en utilities.
7. Be sure to use only the specifie accessories an parts to complete installation.
8. Protective groun ing connection: The enclosure must be groun e at the
protective groun terminal. Use recommen e wire an use spring washer to
avoi loosening.
9. To re uce the risk of electrical shock: Means for isconnection must be
incorporate in the fixe wiring in accor ance with the wiring rules.
10. This appliance is inten e for use only by qualifie personnel.
Caution:
Do not use these electric heaters in usty, irty, corrosive, or hazar ous locations.
A equate protection must be taken to protect people from potential burns an to protect
other components from this heat. Always allow the heater to cool before touching it.
Thermal sensitive evices or materials may nee to be locate further from the heater
than the minimum recommen e istance. Heaters must not be installe on woo or
other combustible surfaces. This heater must only be installe in a totally enclose
enclosure.
1. Do not allow chil ren to touch it. Avoi placing any object on it.
2. Do not block the air inlets or exits.
3. Do not install heater at any place where there is a anger or flammable gas
leakage.
4. To avoi injury, o not touch exhaust air or surface uring operating or just turn
off pro ucts.

Part no.:
Delta mo el no.: HEH080BB
Page 5
5. This appliance is not to be use by any persons with re uce physical, sensory
or mental capabilities, or lack of experience an knowle ge, unless they have
been given proper supervision or instruction.
6. Chil ren shoul be prevente from playing with the appliance.

Part no.:
Delta mo el no.: HEH080BB
Page 6
Specification for Approval
Customer :
Description : Heater for Equipment (Wall Mounting)
Customer P/N : Rev. :
Delta mo el no. : HEH080BB Rev. : 04
Sample revision. : Date Co e :
Sample issue ate : MAY.29 2020 Quantity :1 pc

Part no.:
Delta mo el no.: HEH080BB
Page 7
1. Product Instruction
1-1. General Description
The heater is esigne for warming up the air in enclosure. It can avoi equipment
amage at lower temperature an water con ensation. The heater can be mounte on
the wall of cabinet.
HEH X1 X A - XXX
(1) (2) (3) (4) (5)
No Item Digit Specification
(1) Pro uct Message HEH Heater
(2) Cooling Capacity (W) X1 X1=080 (800W)
(3) Operation Voltage B AC input
(4) Pro uct Version B N/A
(5) Customer ID N/A N/A
1-2. Main Feature & Model umber
Dimensions, Weight & Mounting metho
Dimension (H x W x D) (without flange) mm (inch) 187 x 108 x 79.5 (7.4 x 4.3 x 3.1)
Application In oor
Weight Kg (lbs) 0.8 (1.8)
Mounting Metho Door/Si e
Color (optional) Silver
Environmental Protection & Performance
Operating Temperature Range °C (°F) -30 to +40 (-22 to +104)
Operating Humi ity Internal: 0~90% RH, non-con ensing
Storage Temperature °C (°F) -40 to +75 (-40 to +167)
Storage Relative Humi ity RH Internal: 0~90% RH, non-con ensing
Protection for Dust ,Win an Water
(External) IEC 60529 IP20
Cooling Capacity & Operational Data
Rate Heating Capacity* W 800
Rate Heating Current* A 3.5 (at 230Vac)
Rate Internal Airflow CFM 35 REF.
Power & Range
Input Voltage VAC 230
Input Voltage Range VAC 207~253
Inrush Current ** A 42

Part no.:
Delta mo el no.: HEH080BB
Page 8
Key Components
Controller NA
Communication port NA
Fans Delta High Efficiency Fan
* The Heating capacity (W) is defined as W=V*A at 0
o
C
W : power consumption
V: perating Voltage
A : perating current
** Test condition are AC input 230Vac that is cold start at ambient temperature 25
o
C. Please check the
notice at section 2 – Electrical specification.

Part no.:
Delta mo el no.: HEH080BB
Page 9
1-3. Dimension
1. Heaters shoul be installe at center an low position in the enclosure for optimum
heat istribution.
2. Heater can not be installe on woo or other combustible surfaces.
3. The heater shoul be mounte in a vertical position with the terminal connect at
the bottom an the air outlet at the top as shown.
4. The recommen e clearances shown by the sha owe area in icates the space
that shoul be kept free for optimum operation of the heater an safe of components in
the enclosure components must not be place closely the heater ischarge area.
Please refer Temperature rise chart, the recommen e istance is 200mm as usual.
Vertial Surface Mounting Optional Horizontal Surface Mounting
Unit: mm(inch)
Material: Case AL sheet
Dimensional Tolerance: ±1mm

Part no.:
Delta mo el no.: HEH080BB
Page 10
1-4. Thermal and Airflow
Airflow circulation is shown in below iagram. An internal temperature sensor has been
place in the return air for safe operation.
Cool air flows into the heater, an warme up by PTC heating element insi e of case,
then supplie to the system.
* Minimum gap for both of cool air inlet and warm air exhaust is required to avoid short circulation
 Temperature rise
Temperature rise vs. distance above heater

Part no.:
Delta mo el no.: HEH080BB
Page 11
2 Electrical Specification
2-1. Indicator & Connector
 Power Supply Connector
Power input: AC power input with bla e terminal.
(1) AC Power Connect
：
(2) Electrical connection
：
Power input: Terminal block 2P with AC L & N input.
(Mate with AWG 12~28 300V 20A)
*Thermostat 1: Off temperature operation range: -20~40°C
Fuse: Cut-out temperature: 167°C
Note: DC Fan is powere by a apter (AC/DC convert.)
* The on/off temperature by user to setup
 Startup average current and inrush current：
The startup average an inrush current waveform are efine as bellow table.
These test are all finishe at ambient 25˚C at 230Vac.
Teste waveform to startup average current an inrush current.
Item Current an time Wave form
Inrush
current
Typical current: 41.6A
Duration Time: 280usec
Measuring met ods:
Power on AC input t en
measure t e peak current
value.

Part no.:
Delta mo el no.: HEH080BB
Page 12
2-2 Protection
 Over Temperature Protection:
Thermostat 1: Off temperature operation range: -20~40°C
Fuse: Cut-out temperature: 167°C
3. Environmental Condition
 Operating Temperature
-30 °C ~ +40 °C (-22 °F ~ +104 °F)
 Storage Temperature
-40 °C ~ +75 °C (-40 °F ~ 167 °F)
 Operation Humidity
Internal air loop: 0 ~ 90 % RH, non-con ensing
 Ingress Protection Rating
IP20 (IEC60529)
4. Reliability Table
Test item Con ition
High temperature IEC 60068-2-2
Low temperature IEC 60068-2-1
High temp. /High humi ity IEC 60068-2-14 TEST Nb
Temperature cycle IEC 60068-2-3
Vibration ETSI 300 019-1-4 CLASS 4.1
Package bump IEC 60068-2-29
 MTBF
The L10 Fan life is expecte to be at least 80,000 hours continuous operation
at 40°Cwith 15 ~ 65%RH .@ label rate voltage.
5. Safety Certification
UL File E358666

Part no.:
Delta mo el no.: HEH080BB
Page 13
6. Fault analysis and processing
Fault State Analysis of the Reasons Solutions
Power on, an the
Heater is no heating
• Power failure or no
power.
• The target temperature
is higher than
Thermostat on temp
• Heater failure.
• Check the power supply an
the electric circuit.
• Check the ambient
temperature to efine heater
Is failure or not
• Please contact Delta or
authorize Delta service
agent.
Power on, Heater is
always at heating
status.
• The target temperature
is lower than
Thermostat off temp
• Heater failure
• Check the ambient
temperature to efine heater
Is failure or not,
• Please contact Delta or
authorize Delta service
agent.
Power on, the Fan is
stop but the heating
is enable at low temp
con ition
• Fan lock
• Heater failure
• Power off pro uct than check
the Fan bla e is no block by
foreign matter
• Please contact Delta or
authorize Delta service
agent.
Power on, the Fan is
running but the
heating is isenable
at low temp con ition
• Over temperature
protect.
• Heater failure
• Check the heater air input an
output is no block, If the
heater surface is still hot, wait
for surface col own an
power on again at low temp
con ition for check the over
protect is clear or not.
• Please contact Delta or
authorize Delta service
agent.

Part no.:
Delta mo el no.: HEH080BB
Page 14
7. Reclaim
At the en of the unit working life, the pro uce must not be ispose of as urban waste.
It must be taken to a special local authority ifferentiate waste collection center or to a
ealer provi ing this service.
8. Versions
REV. DESCRIPTION DRAWN CHECKED APPROVED
ISSUE
DATE
ME EE CE
00 ISSUE SPEC VIC.PAN 04/26'19
VIC.PAN
04/26'19
Te .Tu
04/26'19 ------
Diamon
CHEN /
CW.CHEN
04/26'19
09/05'18
01 Mo ify mo el no VIC.PAN 01/28'19
VIC.PAN
04/18'19
Te .Tu
04/18'19 ------
Diamon
CHEN /
CW.CHEN
04/18'19
04/18'19
02 Mo ify Format VIC.PAN 04/30'19
VIC.PAN
04/30'19
Te .Tu
04/30'19 ------
Diamon
CHEN /
CW.CHEN
04/30'19
05/04’19
03 Mo ify SAFTY VIC.PAN 11/06'19
VIC.PAN
11/06'19
Te .Tu
11/06'19 ------
Diamon
CHEN /
CW.CHEN
11/06'19
11/06’19
04
REMOVE
Warranty
EDWARD.LEE
05/29'20
EDWARD.LEE
05/29'20
Te .Tu
05/29'20 ------
Diamon
CHEN /
GAVIN
.CHEN
05/29'20
05/29'20
