Delta Embedded Industrial PC
Operation Manual
Core i3/i5 Series
DIAVH-091AG20-02
2021/12/17

Copyright Notice
©Delta Electronics, Inc. All rights reserved.
All information contained in this user manual is the exclusive property of Delta Electronics Inc. (hereinafter
referred to as "Delta ") and is protected by copyright law and all other laws. Delta retains the exclusive rights
of this user manual in accordance with the copyright law and all other laws. No parts in this manual may be
reproduced, transmitted, transcribed, translated or used in any other ways without the prior consent of Delta.
Limitation of Liability
The contents of this user manual are only for the use of the embedded industrial PC manufactured by Delta.
Except as defined in special mandatory laws, Delta provides this user manual “as is” and does not offer any
kind of warranty through this user manual for using the product, either express or implied, including but not
limited to the following: (i) this product will meet your needs or expectations; (ii) the information contained
in the product is current and correct; (iii) the product does not infringe any rights of any other person. You
shall bear your own risk to use this product.
In no event shall Delta, its subsidiaries, affiliates, managers, employees, agents, partners and licensors be
liable for any direct, indirect, incidental, special, derivative or consequential damages ( including but not
limited to the damages for loss of profits, goodwill, use or other intangible losses) unless the laws contains
special mandatory provisions to the contrary.
Delta reserves the right to make changes to the user manual and the products described in the user manual
without prior notice and afterwards.

Warranty Terms and Conditions:
This warranty is valid for 18 months. Consideration for special requirement is based on the contract signed by the
two parties.
Trademarks:
All trademarks mentioned in this manual are registered to the respective companies:
AMI®is the registered trademark of AMI Company.
Intel®, Celeron®are the registered trademarks of Intel.
Windows 7, Windows 10 are the registered trademarks of Microsoft.
Notes On Use:
This is as Class A product and may cause EMI (Electro Magnetic Interference) in the living environment which users
are required to take appropriate measure.
Warning:
Notice (Marked on operating instructions and its packaging):
(1) Operate the device for 30 minutes and take 10-minute break.
(2) Do not let young children less than 2 years old stare at the screen, nor let elder children stare at the screen for
more than 1 hour.
(3) Overuse of devices can affect the eyes.
(4) Risk of explosion may occur when batteries are inaccurately changed. Please handle the batteries based on the
instructions provided by the manufacturer.
Safety Instructions:
We disclaim liability for inadequate installation or use of device that led to direct or indirect damages and with intent
or not.
1. Carefully read the operation manual before using the product, and keep it for future reference.
2. Before connecting power supply to the product, please confirm the voltage is compliant with the
requirement of the device.
3. To avoid electric shock or damage to the product, please unplug the power cord from the socket before
cleaning the device with wet cloth.
4. Do not use liquid or stain remover spray aerosol cleaner to clean up the device.
5. To avoid short circuit or fire, please do not let any liquid get into or splash into the product.
6. For device that needs power cords, there must be an easy-to-reach power socket near the device.
7. Do not use the product in a damp environment.
8. Make sure the device is placed on a solid surface before installation; accidental drop or tipping may cause
malfunction or damage to the device.
9. All power cords need to be unplugged first before connecting or unplugging any signal cables.
10. To avoid unnecessary damage caused by frequent power-on/off, wait at least 30 seconds after restarting the
computer.
11. When product is not used for a long time, please disconnect the power cord to avoid damages caused by
transient voltage.
12. Some precision devices are sensitive to ESD and needs to be installed or dismantled via its workstation for
enhancement.
13. Provide excellent heat dissipation and system ventilation.
14. Do not open or dismantle the device by yourself. Please let professional maintenance person open the device
due to safety concerns.

Delta Embedded Industrial PC Operation
Manual- Core i3/i5 Series
Revision History
Version
Revision
Date
1
st
The first version was published.
2019/02/27
2nd
1.Change the content of chapter 4 in the previous version
to preface.
2.Add description of 8G RAM in chapter 1.1.
3.Add 17 and 21–inch PPCs in chapter 1.2.
2. Revise the applicable models, specification of CPU,
RAM, temperature and humidity as well as adding
information of FCC class A in section 1.2.1.
3. Revise the applicable models, the specification of CPU,
RAM, operating temperature and humidity. Add 17” and
21”PPC to LED screen specification as well as
information of FCC class A in section 1.2.2.
4.Revise the applicable models in section 1.3.1, 1.3.2,
1.3.3, 1.3.4 and 1.3.5.
5.Add 17-inch model dimension image in section 1.3.3.
6.Add 21-inch model dimension image in section 1.3.5
7.Update all the graphs in chapter 3.
8.Add CH4 “Installation of the Operating System”.
9.Add CH5 “Driver Installation”.
7.Update all the graphs in Appendix A .
8.Update all the graphs in Appendix B .
2021/12 / 17

i
Delta Embedded Industrial PC Operation Manual
- Core i3/i5 Series
Table of Contents
Preface
P.1 Unpack and Check the Delivery Package .......................................... P-2
P.2 Transportation.................................................................................. P-2
P.3 Storage Requirements ......................................................................P-2
Chapter 1 Product Specification
1.1 Introduction .................................................................................... 1-2
1.2 Host Controller Specification ........................................................... 1-2
1.2.1 DIAVH-IPC00x1xx（A）Series............................................................ 1-2
1.2.2 DIAVH-PPCxxx1xx（A）Series .......................................................... 1-3
1.3 Dimensions ...................................................................................... 1-6
1.3.1 DIAVH-IPC00x1xx（A）Series .......................................................... 1-6
1.3.2 DIAVH-PPC15x10x（A）Series ........................................................ 1-7
1.3.3 DIAVH-PPC17x10x（A）Series.......................................................... 1-8
1.3.4 DIAVH-PPC19x1xx（A）Series.......................................................... 1-9
Chapter 2 I/O Interface
2.1 Diagrams of I/O Interface ............................................................... 2-2
2.1.1 DIAVH-IPC00x10x (A) Series ........................................................... 2-2
2.1.2 DIAVH-PPC15x10x (A) Series .......................................................... 2-3
2.1.3 DIAVH-PPC19x10x (A) Series .......................................................... 2-4
2.2 I/O Port Pins ................................................................................... 2-5
2.2.1 Standard DB9 Port ........................................................................ 2-5
2.2.2 RJ-45 LAN Port ............................................................................. 2-5
2.2.3 VGA Port...................................................................................... 2-6
2.2.4 USB 2.0 Port ................................................................................ 2-6

ii
2.2.5 USB 3.0 Port ................................................................................ 2-7
2.2.6 HDMI A Type Port ......................................................................... 2-7
2.2.7 DC12V Power Port......................................................................... 2-8
Chapter 3 AMI BIOS Utility
3.1 Starting BIOS .................................................................................... 3-2
3.2 Hotkey Shortcuts ............................................................................... 3-2
3.3 Main Menu ......................................................................................... 3-2
3.4 Advanced Menu ................................................................................. 3-3
3.5 Chipset Menu ..................................................................................... 3-4
3.6 Security Menu.................................................................................... 3-4
3.7 Boot Menu ......................................................................................... 3-5
3.8 Save & Exit Menu............................................................................... 3-5
3.9 Restore AC Power Loss ...................................................................... 3-6
Chapter 4 Installation of the Operating System
4.1 Configure Boot Order with BIOS Settings .......................................... 4-2
4.1.1 Set CD-ROM as the First Option in Boot Order................................... 4-2
4.1.2 Set USB as the First Option in Boot Order......................................... 4-4
4.2 Installing Operating System .............................................................. 4-7
Chapter 5 Driver Installation
5.1 Download Drivers................................................................................ 5-2
5.2 Install Chipset Drivers ........................................................................ 5-3
5.3 Install Graphic Drivers ........................................................................ 5-7
5.4 Install LAN Drivers............................................................................ 5-11
5.5 Install Audio Drivers ......................................................................... 5-15
5.6 Install Trusted Execution Engine (TXE) Driver .................................. 5-18
5.7 Install Touch Panel Driver................................................................. 5-20

iii
Appendix A PPC Touch Screen Usage and Calibration
A.1 Using the Touch Screen ......................................................................A-2
A.2 Four Points Calibration ......................................................................A-2
Appendix B Windows 10 USB Installation Media
B.1 Precautions .........................................................................................B-2
B.2 Creating a Windows 10 USB Installation Media ...................................B-2

iv

P- 1
P
Preface
Table of Contents
P.1 Unpack and Check the Delivery Package .............................................P-2
P.2 Transportation ....................................................................................P-2
P.3 Storage Requirements.........................................................................P-2

Delta Embedded Industrial PC Operation Manual- Core i3/i5 Series
P- 2
P
P.1 Unpack and Check the Delivery Package
Please take note of the following when accepting a delivery:
●Do not dispose the original packaging in case you have to reuse it to transport the device again.
●Please keep the enclosed disc drive containing the documentation in a safe place.
●Check the device for any transport damage at the time of delivery.
●Verify the packing list for the completeness of the packaging contents and any accessories.
●If the contents of the packaging are damaged or do not match your order, please contact our customer
service.
P.2 Transportation
Well-packaged devices are suited for all kinds of transportation. During long-distance transport, pay attention to
the following:
●Do not store the device in open cabin or carriage.
●No device is to keep in an outdoor storage during transit.
●Avoid transporting the products together with flammable, explosive and corrosive chemicals.
●Keep the device dry and do not expose to rain, snow or any liquid substances to avoid damage the device.
P.3 Storage Requirements
In order to store or keep the products, please take the following precautions:
●Store the product in its original packaging. Please refer to the spec sheet for storage temperature and
relative humidity.
●Do not store any harmful gas, flammable, explosive products and corrosive chemicals.
●The device is stored without vibrations, shocks, and strong magnetic interference.
●Keep at least 10cm distance between the packing box and the ground and at least 50cm distance from the
wall, heat source, cooling source, window or air inlet.
CAUTION！！
Risk of damage to the device！
When transporting the device in cold weather, please pay attention to the extreme
changes in temperature. Make sure no water drop (condensation) is build up on the
surface or inside the device. If condensation develops, please wait at least 12 hours
before switching on the device.

1- 1
1
Chapter 1 Product Specification
Table of Contents
1.1 Introduction ................................................................................................1-2
1.2 Host Controller Specification ..........................................................................1-2
1.2.1 DIAVH-IPC00x1xx（A）Series .....................................................................1-2
1.2.2 DIAVH-PPCxxx1xx（A）Series .................................................................1-3
1.3 Dimensions .................................................................................................1-6
1.3.1 DIAVH-IPC00x1xx（A）Series.................................................................. 1-6
1.3.2 DIAVH-PPC15x10x（A）Series................................................................ 1-7
1.3.3 DIAVH-PPC17x10x（A）Series .................................................................1-8
1.3.4 DIAVH-PPC19x1xx（A）Series .................................................................1-9

Delta Embedded Industrial PC Operation Manual-Core i3/i5 Series
1- 2
_1
1.1 Introduction
DIAVH-IPC and PPC series are embedded industrial PCs featuring low power, high-performance and with sealed fan-less
design. In addition, the product adopts excellent high-strength aluminum-alloy material including heat sinks made from
dense aluminum-alloy.
The product is equipped with Intel® chipset Haswell and advanced Intel® Core i3／i5 processors, standard 4G/8G RAM
and extended up to 16GB in memory. It supports operating systems such as Windows 7/10 and Linux.
For IPC product series, the embedded device is applied in solutions such as in-vehicle computing systems, intelligent
transportation and industrial automation control. As for PPC product series, the device is suitable for mechanical rubber,
solar photovoltaic (PV), vehicle control and general industrial automation industries (e.g. paper, environmental related).
1.2 Host Controller Specification
The Core i3／i5 series features three hardware specifications including fan-less IPC and 15/17/19/21-inch PPCs. Below
are details regarding each specification.
1.2.1 DIAVH-IPC00x1xx（A）Series
Applicable
Models
DIAVH-IPC0031x0, DIAVH-IPC0031x0A, DIAVH-IPC0031x2, DIAVH-IPC0031x2A
DIAVH-IPC0031x3, DIAVH-IPC0031x3A, DIAVH-IPC0031x4, DIAVH-IPC0031x4A
DIAVH-IPC0051x0, DIAVH-IPC0051x0A, DIAVH-IPC0051x2, DIAVH-IPC0051x2A
DIAVH-IPC0051x3, DIAVH-IPC0051x3A, DIAVH-IPC0051x4, DIAVH-IPC0051x4A
Item
Specification
CPU 6th Generation Intel dual-core i3-6100U 2.3 GHz／i5-6200U 2.3 GHz processors
RAM 4/8GB DDR4 2400MHz, max. up to 16GB
SSD 512GB mSata SSD, 256GB mSata SSD ( last figure: A)
Network 2x Intel® I211 Gigabit Ethernet Controller
Audio 1x Standard frequency I/O
Expansion Supports mini PCIE interface and Wi-Fi communication modules
External I/O

Serial port: COM 1~2 & 5~6 (RS-232), COM 3~4 (RS-485)
2 x USB 2.0, 4 x USB 3.0（blue）
1 x VGA output

1 x HDMI output
Dimension Rack NOT included: 211.5mm (L) × 200mm (W) × 67mm (H)；
Rack included: 251.9mm (L) × 200mm(W) × 71.6mm (H)
Structure
Case: High-strength aluminum alloy, sand blasting anodizing aluminum
Color: Black
Thermal conductivity: An integrated aluminum case with active heat conduction
design
Material: Aluminum alloy heat sink
Weight Net weight: 2.8Kg; Gross weight: 3.5Kg

Chapter 1 Product Specification
1- 3
1_
Item
Specification
Temperature
Operation temperature: -20°C～60°C (with air flow)
Storage temperature: -40°C～70°C
Humidity 10~95% @ 40°C (non-condensing)
EMC
Level A, and GB9254-1998
GB/T 17618
Reliability
Mean time between failures (MTBF): ≥ 5000h
Mean time to recovery (MTTR): ≤ 0.5h
Certification CE, FCC Class A
Environment

Anti-vibration: 5-19Hz/1.0mm amplitude
；
19-200Hz/1.0g acceleration
Anti-shock: 10g acceleration, 11ms duration
Power
Standard VT:
Input voltage/ frequency: 100~240VAC/ 50~60Hz
Input voltage/ current: 12VDC/5A
Power consumption: 10 W (stand-by); 28 W (running max. power 100%)
1.2.2 DIAVH-PPCxxx1xx（A）Series
Applicable
Models
DIAVH-PPC1531x0, DIAVH-PPC1531x0A, DIAVH-PPC1531x2, DIAVH-PPC1531x2A,
DIAVH-PPC1531x3, DIAVH-PPC1531x3A, DIAVH-PPC1531x4, DIAVH-PPC1531x4A,
DIAVH-PPC1551x0, DIAVH-PPC1551x0A, DIAVH-PPC1551x2, DIAVH-PPC1551x2A,
DIAVH-PPC1551x3, DIAVH-PPC1551x3A, DIAVH-PPC1551x4, DIAVH-PPC1551x4A,
DIAVH-PPC1731x0, DIAVH-PPC1731x0A, DIAVH-PPC1731x2, DIAVH-PPC1731x2A,
DIAVH-PPC1731x3, DIAVH-PPC1731x3A, DIAVH-PPC1731x4, DIAVH-PPC1731x4A,
DIAVH-PPC1751x0, DIAVH-PPC1751x0A, DIAVH-PPC1751x2, DIAVH-PPC1751x2A,
DIAVH-PPC1751x3, DIAVH-PPC1751x3A, DIAVH-PPC1751x4, DIAVH-PPC1751x4A,
DIAVH-PPC1931x0, DIAVH-PPC1931x0A, DIAVH-PPC1931x2, DIAVH-PPC1931x2A,
DIAVH-PPC1931x3, DIAVH-PPC1931x3A, DIAVH-PPC1931x4, DIAVH-PPC1931x4A,
DIAVH-PPC1951x0, DIAVH-PPC1951x0A, DIAVH-PPC1951x2, DIAVH-PPC1951x2A,
DIAVH-PPC1951x3, DIAVH-PPC1951x3A, DIAVH-PPC1951x4, DIAVH-PPC1951x4A,
DIAVH-PPC2131x0, DIAVH-PPC2131x0A, DIAVH-PPC2131x2, DIAVH-PPC2131x2A,
DIAVH-PPC2131x3, DIAVH-PPC2131x3A, DIAVH-PPC2131x4, DIAVH-PPC2131x4A,
DIAVH-PPC2151x0, DIAVH-PPC2151x0A, DIAVH-PPC2151x2, DIAVH-PPC2151x2A,
DIAVH-PPC2151x3, DIAVH-PPC2151x3A, DIAVH-PPC2151x4, DIAVH-PPC2151x4A
Item
Specification
CPU 6th Generation Intel dual-core i3-6200U 2.3 GHz／i5-6200U 2.3 GHz processors
RAM 4/8GB DDR4 2400MHz, max. up to 16GB
SSD 512GB mSata SSD, 256GB mSata SSD ( last figure: A)
Network 2 x Intel® I211 Gigabit Ethernet Controller
Audio 1 x Standard frequency I/O

Delta Embedded Industrial PC Operation Manual-Core i3/i5 Series
1- 4
_1
Item Specification
Expansion Supports mini PCIE interface and Wi-Fi communication modules
External I/O
Serial port: COM 1~3 (RS-232), COM 4 (RS-485)
4 x USB 3.0 (blue)
1 x VGA output
1 x HDMI output
LED Screen
15” PPC

Display: 15
＂
TFT LED
Resolution: 1024x768
Brightness: 300cd/m2
Contrast: 1500：1
Viewing angle (CR≧10): 140° (V) / 140° (H)
17” PPC
Display: 17
＂
TFT LED
Resolution: 1280x1024
Brightness: 250cd/m2
Contrast: 1000：1
Viewing angle (CR≧5): 150° (V) / 140° (H)
19” PPC
Display: 19
＂
TFT LED
Resolution: 1440x900
Brightness: 250cd/m2
Contrast: 1000：1
Viewing angle (CR≧10): 120° (V) / 125° (H)
21” PPC

Display: 21
＂
TFT LED
Resolution: 1920x1080
Brightness: 250cd/m2
Contrast: 1000：1
Viewing angle (CR≧5): 150° (V) / 140° (H)
Touch Screen

Connection: USB
Type: 5-wire resistive touch
Dimensions
15” PPC：380mm (L) × 300mm (W) × 59mm (H)；
17” PPC：400mm (L) × 320mm (W) × 59mm (H)；
19” PPC：475mm (L) × 308mm (W) × 57mm (H)；
21” PPC：525mm (L) × 308mm (W) × 57mm (H)；
Structure
Case: High-strength aluminum alloy, sand blasting anodizing aluminum
Color: Silver
Thermal conductivity: An integrated aluminum case with active heat conduction
design
Material: Aluminum alloy heat sink
Weights
15” PPC: Net weight: 5.2Kg; Gross weight: 6.8Kg
17” PPC: Net weight: 6.1Kg; Gross weight: 8.0Kg
19” PPC: Net weight: 7.3Kg; Gross weight: 8.8Kg
21” PPC: Net weight: 7.5Kg; Gross weight: 8.3Kg
Temperature
Operation temperature: -10°C～50°C (with air flow)
Storage temperature: -20°C～60°C
Humidity 10~95% @ 40°C (non-condensing)

Chapter 1 Product Specification
1- 5
1_
Item Specification
EMC
Level A, and GB9254-1998
GB/T 17618
Reliability

Mean time between failures (MTBF): ≥ 5000h
Mean time to recovery (MTTR): ≤ 0.5h
Certification CE, FCC Class A
Environment
Anti-vibration: 5-19Hz/1.0mm amplitude
；
19-200Hz/1.0g acceleration
Anti-shock:10g acceleration, 11ms duration
Power
Standard VT:
Input voltage/ frequency: 100~240VAC/50~60Hz
Input voltage/ current: 12VDC/5A
15” PPC Power consumption: 10 W (stand-by); 28 W (running max. power
100%)
17” PPC Power consumption: 16 W (stand-by); 35 W (running max. power
100%)
19” PPC 
Power consumption: 20 W (stand-by); 41 W (running max. power
100%)
21” PPC Power consumption: 20 W (stand-by); 42 W (running max. power
100%)

Delta Embedded Industrial PC Operation Manual-Core i3/i5 Series
1- 6
_1
1.3 Dimensions
1.3.1 DIAVH-IPC00x1xx（A）Series
Applicable
Models
DIAVH-IPC0031x0, DIAVH-IPC0031x0A, DIAVH-IPC0031x2, DIAVH-IPC0031x2A,
DIAVH-IPC0031x3, DIAVH-IPC0031x3A, DIAVH-IPC0031x4, DIAVH-IPC0031x4A,
DIAVH-IPC0051x0, DIAVH-IPC0051x0A, DIAVH-IPC0051x2, DIAVH-IPC0051x2A,
DIAVH-IPC0051x3, DIAVH-IPC0051x3A, DIAVH-IPC0051x4, DIAVH-IPC0051x4A
67
71.6 140
200
251.9
236.9
Unit：mm

Chapter 1 Product Specification
1- 7
1_
1.3.2 DIAVH-PPC15x10x（A）Series
Applicable
Models
DIAVH-PPC1531x0, DIAVH-PPC1531x0A, DIAVH-PPC1531x2, DIAVH-PPC1531x2A,
DIAVH-PPC1531x3, DIAVH-PPC1531x3A, DIAVH-PPC1531x4, DIAVH-PPC1531x4A,
DIAVH-PPC1551x0, DIAVH-PPC1551x0A, DIAVH-PPC1551x2, DIAVH-PPC1551x2A,
DIAVH-PPC1551x3, DIAVH-PPC1551x3A, DIAVH-PPC1551x4, DIAVH-PPC1551x4A
Unit：mm

Delta Embedded Industrial PC Operation Manual-Core i3/i5 Series
1- 8
_1
1.3.3 DIAVH-PPC17x10x（A）Series
Applicable
Models
DIAVH-PPC1731x0, DIAVH-PPC1731x0A, DIAVH-PPC1731x2, DIAVH-PPC1731x2A,
DIAVH-PPC1731x3, DIAVH-PPC1731x3A, DIAVH-PPC1731x4, DIAVH-PPC1731x4A,
DIAVH-PPC1751x0, DIAVH-PPC1751x0A, DIAVH-PPC1751x2, DIAVH-PPC1751x2A,
DIAVH-PPC1751x3, DIAVH-PPC1751x3A, DIAVH-PPC1751x4, DIAVH-PPC1751x4A
475
440.4
100
9.8
308
288.4
245
10
21.2
57
100
57
19"
Unit：mm

Chapter 1 Product Specification
1- 9
1_
1.3.4 DIAVH-PPC19x1xx（A）Series
Applicable
Models
DIAVH-PPC1931x0, DIAVH-PPC1931x0A, DIAVH-PPC1931x2, DIAVH-PPC1931x2A,
DIAVH-PPC1931x3, DIAVH-PPC1931x3A, DIAVH-PPC1931x4, DIAVH-PPC1931x4A,
DIAVH-PPC1951x0, DIAVH-PPC1951x0A, DIAVH-PPC1951x2, DIAVH-PPC1951x2A,
DIAVH-PPC1951x3, DIAVH-PPC1951x3A, DIAVH-PPC1951x4, DIAVH-PPC1951x4A
475
440.4
100
9.8
308
288.4
245
10
21.2
57
100
57
19"
