Delta Allora 989-DST Series User manual

2 3/8"
(60 mm)
KITCHEN FAUCETS
■Allora®Pull-Down Collection
■Single Handle Deck Mount
■Single, 2, 3 or 4 Hole Sink Applications
■ Optional Soap Dispenser
■ Diamond™ Seal Technology
■ Integrated Supply Tubes
Submitted Model No.:_______________________________________________
Specific Features: __________________________________________________
STANDARD SPECIFICATIONS:
• Centermount or 8" (203 mm) centers with optional 10"
(254 mm) escutcheon.
• 15 9/16" (395 mm) high, 9 7/8" (251 mm) long, spout
swings 360˚.
• Lever handle. Control mechanism is the diamond embedded
ceramic disc cartridge.
• Control shall return to neutral position when faucet is
turned off.
• Touch-Clean® 2 function (stream/spray) sprayhead.
• Quick connect hoses.
• Pull-down wand operates in an aerated or spray mode via an
ergonomic toggle diverter.
• Red/blue graphics on handle button to indicate hot/cold
temperature.
• Magnetic docking system secures sprayer to spout.
• Integral double check valves in sprayer assembly.
• Integrated removable debris screen in sprayer assembly.
• Integral hose lead to aid installation.
• Spacer for mounting nut to reduce number of turns required
for installation.
• Mounting wrench to assist in tightening mounting nut securely.
• Hose travels inside mounting shank so it will not interfere
with deck edges.
• Keyed 10" (254 mm) escutcheon to help alignment and
aid installation.
• 3/8" O.D. straight, staggered PEX supply tubes, 33 1/2"
(851 mm) and 35" (889 mm).
Note: See model 999* for matching bar/prep.
0
1
2
3
4
5
0102030405060708090
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
069 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
989-DST 989-SD-DST
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2008 Masco Corporation of Indiana
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-K-989-DST Rev. A
®
®
UPC
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
WARRANTy
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from defects
in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
989-DST with
optional escutcheon
989-SD-DST with
optional escutcheon
7 3/4"
(197 mm)
15 9/16"
(395 mm)
9 7/8"
(251 mm)
2 1/2"
(64 mm)
Max.
3"
(76 mm)
Max.
1 1/8"
(29 mm)
max.
w/spacer
7 3/4"
(197 mm)
15 9/16"
(395 mm)
9 7/8"
(251 mm)
6"
(152 mm)
6"
(152 mm)
8"
(203 mm)
Centers 10"
(254 mm)
4 1/4"
(108 mm)
7 9/16"
(192 mm)
4 9/16"
(116 mm)
1 3/4"
(45 mm)
