Demco Hijacker 6005 UMS User manual

8-12
HJ26005 rev 0

6005 UMS Side Rail Assembly Instructions
Place the base rails on a flat level surface and insert and lock the side rail plates into the base rail1.
holes as shown in drawing # 1.
Loosely bolt the saddle bracket (5990) to the side rails using the 1/2” x 1 1/2” bolts, flat washers,2.
and lock nuts provided in the 6005 bolt package.
Loosely bolt the cross braces to the side rails using only 1/2” x 1 1/2” bolts and lock nuts (no flat3.
washers). NOTE: A flat washer under the head of the bolts would prevent the locking pins from
pivoting around far enough to allow the pins to release from the base rails.
Tighten all the bolts.4.
Unlock and remove the hitch assembly from the base rails and put to the side for later.5.
IMPORTANT NOTE: Apply a little grease or lubricant to the part of the pins that insert into the base
rails to help maintain smooth operation and rotation of pins and to protect from the elements. Turn the
pins occasionally to prevent them from seizing.
Drawing #1
Apply grease or lubricant
Unlocked Locked

6005 Parts Breakdown
6005 Parts Breakdown
Please order replacement parts by PART NO. and DESCRIPTION.
11
8
6
7
10
2
1
3
4
9
5
ITEM PART # DESCRIPTION QTY
1 00085 .50 FLAT WASHER
16
2 01254 BOLT, .50 NC X 1.50 GR.5 HEX
20
3 02178 NUT, .50NC LOCK, NY. INSERT
20
4 07225 SPLIT RING 4
5
14262-30 UMS SIDE RAIL BRACE
2
6 14263-95 UMS LOCK PIN ASSEMBLY, RIGHT
2
7 14264-95 UMS LOCK PIN ASSEMBLY, LEFT
2
8 14309-30 UMS SIDE RAIL 2
9
14342-95 CLEVIS SAFETY PIN 4
10 14350
HAIR PIN, .093 WIRE X 1.63 OL 4
11
14352-30 UMS 21K BRACE 2
ITEM PART # QTY DESCRIPTION
100085 16 .50 FLAT WASHER
201254 20 BOLT, .50 NC X 1.50 GR.5 HEX
302178 20 NUT, .50NC LOCK, NY. INSERT
407225 4 SPLIT RING
514262-30 2 UMS SIDE RAIL BRACE
614263-95 2 UMS LOCK PIN ASSEMBLY, RIGHT
714264-95 2 UMS LOCK PIN ASSEMBLY, LEFT
814309-30 2 UMS SIDE RAIL
914342-95 4 CLEVIS SAFETY PIN
10 14350 4 HAIR PIN, .093 WIRE X 1.63 OL
11 14352-30 2 UMS 21K BRACE
