Dentalux DAZ 2.4 A1 User manual

KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: DAZ 2.4 A1-09/11-V1
IAN: 71085
ELECTRIC TOOTHBRUSH DAZ 2.4 A1
ELECTRIC TOOTHBRUSH
Operating instructions
ΗΛΕΚΤΡΙΚΗ ΟΔΟΝΤΟΒΟΥΡΤΣΑ
Οδηүίες χρήσης
CV_71085_DAZ2.4A1_LB6.indd 1-3CV_71085_DAZ2.4A1_LB6.indd 1-3 10.11.2011 16:37:27 Uhr10.11.2011 16:37:27 Uhr

5
6
1
3
9
8
7
0
4
2
DAZ 2.4 A1
CV_71085_DAZ2.4A1_LB6.indd 4-6CV_71085_DAZ2.4A1_LB6.indd 4-6 10.11.2011 16:37:28 Uhr10.11.2011 16:37:28 Uhr

- 1 -
Index Page
Intended use 2
Safety Notices 2
Items supplied 3
Technical data 3
Appliance description 4
Set-up / Wall holder 4
First use 5
Fitting / removing brush heads 6
Operation 6
Brushing one's teeth 6
Cleaning and care 9
Travelling case 10
Disposal 11
Warranty and Service 11
Importer 12
Read these operating instructions carefully before using the
appliance for the first time and preserve this booklet for later
reference. Pass this booklet on to whoever might acquire the
appliance at a future date.
IB_71085_DAZ24A1_LB6.indb Abs1:1IB_71085_DAZ24A1_LB6.indb Abs1:1 18.11.2011 10:03:08 Uhr18.11.2011 10:03:08 Uhr

- 2 -
Intended use
This appliance is intended for personal dental care in domestic
situations. The appliance is not intended for use in commercial,
industrial or medical environments. It is not suitable for animal
care.
Safety Notices
To avoid damage, do not permit liquids of any kind to•
enter the appliance and do not submerse it in water.
Avoid also a possible penetration by foreign objects.•
In the event of malfunction or apparent damage, make•
contact with our Customer Services.
Ensure that the power cable never becomes wet or damp•
during operation. Place the power cable such that it cannot
become trapped or damaged in any way. Risk of electric
shock!
The power cable on this appliance cannot be replaced. In•
the event of it being damaged the whole appliance must
be disposed of.
NEVER touch the charging station if it has fallen into water.•
First of all remove the plug from the wall socket! Risk of
electric shock!
This appliance is not intended for use by individuals (in-•
cluding children) with restricted physical, physiological or
intellectual abilities or deficiences in experience and/or
knowledge unless they are supervised by a person respon-
sible for their safety or receive from this person instruction
in how the appliance is to be used.
Children should be supervised to ensure that they do not•
play with the appliance.
The electric toothbrush may only be recharged with the•
supplied charging station. Otherwise, the appliance could
be irreparably damaged.
Do not submerse the hand element or the charging station•
in water or other liquids. This would cause irreparable
damage to the appliance.
IB_71085_DAZ24A1_LB6.indb Abs1:2IB_71085_DAZ24A1_LB6.indb Abs1:2 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 3 -
Items supplied
Before using the appliance for the first time, check to ensure
that the following items are available and undamaged.
Hand element
8 Brush heads
Charging station
Travelling case
2 Screws
2 Plugs
Operating instructions
Remove all packaging materials and foils from the appliance.
Technical data
Power supply: 100 - 240 V ˜, 50 - 60 Hz
Power consumption : 2 W
Protection rating
(Charging station): IP X7
Protection class: II /
Charging time: approx. 14 - 16 hours
(first charging)
Protection type
(Hand element): IP X4
IB_71085_DAZ24A1_LB6.indb Abs1:3IB_71085_DAZ24A1_LB6.indb Abs1:3 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 4 -
Appliance description
1Brush head
2Brush holder
3Charging station
4Wall holder
5Charge indicator
6Pulse LED (yellow)
7Soft LED (green)
8"Clean" LED (orange)
9On/Off switch
0Travelling case
Set-up / Wall holder
The charging station 3may only be operated free-standing
in dry rooms.
In moist rooms, especially in the vicinity of water (bath), the
charging station 3must be firmly fixed to the wall, to protect
it from falling into water.
•Pull the wall holder 4downwards from underneath the
charging station 3.
•Using the screw openings of the wall holder 4, mark the
spacing for the boreholes on the wall. Check to ensure that
there is a mains power socket in close vicinity.
• Before boring the holes, check to ensure that there are no
electrical or water conduits behind the markings.
• Using a 5 mm drill, drill the marked holes and insert the
supplied wall plugs.
• Secure the wall holder 4using the screws.
• When you have attached the wall holder 4, guide the
power cable through the right or left recess in the wall
holder 4(see magnification on the fold-out side).
Using the guide rails, slide the charging station 3onto the
wall holder 4.
• Ensure that the power cable is not trapped and that it lies
properly in the recesses.
IB_71085_DAZ24A1_LB6.indb Abs1:4IB_71085_DAZ24A1_LB6.indb Abs1:4 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 5 -
First use
Before taking the appliance into use check to ensure that it is
in a fault-free condition. If it is not, it may not be used.
• Insert the power plug into a wall socket.
•Before the first use, clean the new brush heads 1with
clear water.
•Place a replacement brush head on the brush holder 2,
open the cover of the charging station 3and slide the
brush holder 2in.
•Place the hand element on the charging station 3so that
it slides onto the spike in the base.
•Allow the hand element to charge up for approx. 14 -
16 hours before using it for the first time. The charging
light 5on the front of the hand appliance glows red
during the charging process.
•Use the hand element repeatedly, and without charging
the battery, until the performance is noticeably weaker or
the toothbrush stops working and the charge indicator 5
blinks red. First then recharge the battery for 14 - 16 hours.
When the appliance is fully charged, the charge indicator 5
glows green.
• Charge and discharge the toothbrush completely 3 times.
The battery will have then reached its full capacity.
•You can now leave the hand element in the charging
station 3after every use, so as to always have full power
available.
For care of the batteries, we recommend the following:
When the hand element is fully charged, remove the plug
of the charging station 3from the mains power socket. First
reinsert the plug into the mains power socket and recharge
the hand element when the movement of the toothbrush is
noticeably weaker or the charge indicator 5blinks.
IB_71085_DAZ24A1_LB6.indb Abs1:5IB_71085_DAZ24A1_LB6.indb Abs1:5 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 6 -
Fitting / removing brush heads
To remove the brush head 1, turn it clockwise and then pull
it upwards.
To fit the brush head 1place it slightly offset on the hand
element and then turn it anti-clockwise.
The brush head 1must engage on being put back on. To
avoid damage to the appliance, use only original brush heads.
(For replacement brush heads, see the order card)
Operation
This toothbrush has 3 different performing levels:
- "Clean": normal speed level, orange LED 8
For cleaning the teeth.
- "Soft": slow speed level, green LED 7
For cleaning the teeth of people with sensitive gums.
- "Pulse": variable speed levels, yellow LED 6
For massaging the gums.
•Press the on/off switch 9once to switch the level "Clean"
on. The "Clean" LED 8glows.
•Press once more to switch to the level "Soft". The "Soft"
LED 7glows.
•Press it a third time to switch to the level "Pulse".
The "Pulse" LED 6glows.
•To switch the toothbrush off, press once more on the on/
off switch 9.
Brushing one's teeth
Warning:
Due to the unaccustomed operation some gum bleeding may
initially occur, this is normal. Should this continue for more
than two weeks, consult your dentist.
IB_71085_DAZ24A1_LB6.indb Abs1:6IB_71085_DAZ24A1_LB6.indb Abs1:6 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 7 -
•Place the brush head 1on the hand element.
• Moisten the brush under flowing water.
• Apply some toothpaste to the moistened brush.
Notice
Wait until the appliance is in the mouth before switching it on,
to avoid spray.
•With the on/off switch 9select the desired operating
level.
Notice
This toothbrush has a 30 second interval timer, so that all four
jaw quandrants can be cleaned equally.
• Divide your jaw into four sections (quadrants): upper left,
upper right, lower left and lower right.
•Begin in one quadrant:
Place the brush head 1on your gums and move the brush
upwards/downwards from the gums to over the crown of
the tooth.
Proceed in this manner on both the inside and the outside
surfaces of the tooth. Start again from the gums for each
individual tooth.
IB_71085_DAZ24A1_LB6.indb Abs1:7IB_71085_DAZ24A1_LB6.indb Abs1:7 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 8 -
Do not forget the back surfaces of the rear molars.
To clean the chewing surfaces, direct the rotating brush
head with light pressure over the chewing surfaces.
• After 30 seconds the toothbrush interrupts its operation
briefly twice, to signalise to you that you should start to
clean the next quadrant. Clean all jaw quadrants with the
same technique.
• After two minutes the toothbrush stops its operation briefly
4 times. This informs you that you have complied with the
dental recommendation of two minutes cleaning.
•Press the on/off switch 9repeatedly until the toothbrush
stops.
• First take the toothbrush out of your mouth when it has
stopped.
• After use, clean the brush head 1thoroughly under run-
ning water.
• Remove the brush head 1from the hand element.
Clean the drive shaft on the hand element, into which the
brush head is inserted, under running water.Hold the hand
element so that the water from the top can drip out of the
rear outlet openings.
• Afterwards, clean the rear outlet openings: Let the water
run over the handle from the rear, so that the outlet open-
ings are free of contamination.
Notice
Regularly massage your gums. This promotes blood circulation
and thus the health preservation of the gums. Set the level at
"Pulse" and guide the moistened brush over your gums with a
light pressure.
IB_71085_DAZ24A1_LB6.indb Abs1:8IB_71085_DAZ24A1_LB6.indb Abs1:8 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 9 -
Cleaning and care
Warning:
First remove the plug from the mains power socket before
cleaning the charging station 3. There is a risk of receiving
an electric shock!
•NEVER open the housing of the charging station 3or the
toothbrush! They cannot be resealed in a water-tight manner.
•Clean the charging station 3only with a soft, lightly
moistened cloth. Do not use detergents or solvents. They
can damage the plastic surfaces.
• Remove the brush head 1from the hand element. After
use, clean the brush heads 1 thoroughly under running water.
We recommend cleaning the brush heads 1in a standard
commercial cleaning fluid for dental prosthetics every 2 - 4
weeks. After about 3 months, at the latest however when
the bristles bend outwards, you should fit a new brush head 1.
• Clean the drive shaft on the hand element, into which the
brush head is inserted, under running water. Hold the hand
element so that the water from the top can drip out of the
rear outlet openings:
IB_71085_DAZ24A1_LB6.indb Abs1:9IB_71085_DAZ24A1_LB6.indb Abs1:9 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 10 -
• Afterwards, clean the rear outlet openings:
Let the water run over the handle from the rear, so that the
outlet openings are free of contamination:
• The brush holder 2can be cleaned without problem with
water and a little liquid soap. To do this, simply lift the
brush holder 2upwards.
Travelling case
Should you wish to take the toothbrush with you on a tour, you
can pack both the hand element and two brush heads in the
travelling case 0.
IB_71085_DAZ24A1_LB6.indb Abs1:10IB_71085_DAZ24A1_LB6.indb Abs1:10 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 11 -
Disposal
Do not dispose of the appliance in your normal
domestic waste. This product is subject to the
provisions of European Directive 2002/96/EC.
Dispose of the appliance through a registered specialist disposal
firm or through your community waste disposal department.
Observe the currently applicable regulations.
In case of doubt, contact your local waste disposal facility.
Disposal of batteries/accumulators
Used batteries/rechargeable batteries may not be disposed
of in household waste. Every consumer is statutorily obliged
to dispose of batteries at a collection site of his community/
city district or at a retail store.
The purpose of this obligation is to ensure that batteries are dis-
posed of in a non-polluting manner. Only dispose of batteries/
-cells when they are fully discharged.
Dispose of the packaging materials in an environ-
mentally responsible manner.
Warranty and Service
The warranty for this appliance is for 3 years from the date
of purchase. The appliance has been manufactured with care
and meticulously examined before delivery. Please retain your
receipt as proof of purchase. In the event of a warranty claim,
please make contact by telephone with our Service Depart-
ment. Only in this way can a post-free despatch for your goods
be assured. The warranty covers only claims for material and
maufacturing defects, but not for transport damage, for wear-
ing parts or for damage to fragile components, e.g. buttons
or batteries. This product is for private use only and is not in-
tended for commercial use. The warranty is void in the case of
abusive and improper handling, use of force and internal tam-
pering not carried out by our authorized service branch. Your
IB_71085_DAZ24A1_LB6.indb Abs1:11IB_71085_DAZ24A1_LB6.indb Abs1:11 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

- 12 -
statutory rights are not restricted in any way by this warranty.
The warranty period will not be extended by repairs made un-
der warranty. This applies also to replaced and repaired parts.
Any damage and defects extant on purchase must be reported
immediately after unpacking the appliance, at the latest, two
days after the purchase date. Repairs made after the expira-
tion of the warranty period are subject to payment.
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
IAN 71085
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: k[email protected]
IAN 71085
Service Cyprus
Tel.: [phone]
E-Mail: k[email protected]
IAN 71085
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_71085_DAZ24A1_LB6.indb Abs1:12IB_71085_DAZ24A1_LB6.indb Abs1:12 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

Quantity
ordered
(max. 3 sets per
order)
Name of article Cost p.
Unit
Total sum
8-piece Set of
Toothbrush Heads
for Toothbrush
DAZ 2.4 A1
7,50 £ £
Add. £ 3,50 p&p. £
Total sum: £
Payment method: Bank Transfer
Location, Date Signature
Order card
DAZ 2.4 A1
IB_71085_DAZ24A1_LB6.indb Abs1:13IB_71085_DAZ24A1_LB6.indb Abs1:13 18.11.2011 10:03:09 Uhr18.11.2011 10:03:09 Uhr

How to order:
1. Enter under “Sender/orderer” your name, address and
telephone number (for possible queries) in block capitals.
2. Bank Transfer (BACS): Please transfer the complete amount
to our account below:
Natwest Bank Plc
Hammersmith Branch
Sort Code: 60-50-06
Account No: 37758829
Account Name: Domestic Electrical Solutions UK Limited
On your transfer, please provide the article(s) you ordered
as well as your complete name and address. Then post your
completed order card to our postal address below.
DES UK LTD
Unit B7
Oxford Street Industrial Park
Vulcan Road
Bilston/ West Midlands
WV14 7LF
Please affix sufficient postage to the letter.
Write your name as the sender on the envelope.
Sender / Orderer
(please complete in block captals)
Surname, first name
Street
Post code, town
Country
Telephone
IB_71085_DAZ24A1_LB6.indb Abs1:14IB_71085_DAZ24A1_LB6.indb Abs1:14 18.11.2011 10:03:10 Uhr18.11.2011 10:03:10 Uhr

Quantity
ordered
(max. 3 sets per
order)
Name of article Cost p.
Unit
Total sum
8-piece Set of
Toothbrush Heads
for Toothbrush
DAZ 2.4 A1
8 € €
Add. 4 € p&p. €
Total sum: €
Payment method: Bank Credit Transfer
Location, Date Signature
Order card
DAZ 2.4 A1
IB_71085_DAZ24A1_LB6.indb Abs1:15IB_71085_DAZ24A1_LB6.indb Abs1:15 18.11.2011 10:03:10 Uhr18.11.2011 10:03:10 Uhr

How to order:
1. Enter under “Sender/orderer”your name, address and
telephone number (for possible queries) in block capitals.
2. Bank Credit Transfer: Transfer the whole amount in advance
to our account:
Kompernaß Handelsgesellschaft mbH
IBAN: DE03440100460799566462
SWIFT (BIC): PBNKDEFF 440
Bank: Postbank Dortmund AG
If you pay by bank credit transfer, on the remittance form
please tick „shared“ (shared costs) in the box under the item
`Costs´. Otherwise, we can not process your order.
Our postal address:
Kompernaß Handelsgesellschaft mbH
Burgstraße 21
44867 Bochum
Germany
Please affix sufficient postage to the letter.
Write your name as the sender on the envelope.
Sender / Orderer
(please complete in block captals)
Surname, first name
Street
Post code, town
Country
Telephone
IB_71085_DAZ24A1_LB6.indb Abs1:16IB_71085_DAZ24A1_LB6.indb Abs1:16 18.11.2011 10:03:10 Uhr18.11.2011 10:03:10 Uhr

Quantity
ordered
(max. 3 sets per
order)
Name of article Cost p.
Unit
Total sum
8-piece Set of
Toothbrush Heads
for Toothbrush
DAZ 2.4 A1
8 € €
Add. 4 € p&p. €
Total sum: €
Payment method: Bank Credit Transfer
Location, Date Signature
Order card
DAZ 2.4 A1
IB_71085_DAZ24A1_LB6.indb Abs1:17IB_71085_DAZ24A1_LB6.indb Abs1:17 18.11.2011 10:03:10 Uhr18.11.2011 10:03:10 Uhr

How to order:
1. Enter under “Sender/orderer”your name, address and
telephone number (for possible queries) in block capitals.
2. Transfer the whole amount in advance to our account:
Kompernaß Handelsgesellschaft mbH
IBAN: DE03440100460799566462
SWIFT (BIC): PBNKDEFF 440
Bank: Postbank Dortmund AG
If you pay by bank credit transfer, on the remittance form
please tick „shared“ (shared costs) in the box under the item
`Costs´. Otherwise, we can not process your order.
On your transfer, please provide the article(s) you ordered
as well as your complete name and address. Then post your
completed order card to our postal address below.
Our postal address:
Kompernaß Handelsgesellschaft mbH
Burgstraße 21
44867 Bochum
Germany
Please affix sufficient postage to the letter.
Write your name as the sender on the envelope.
Sender / Orderer
(please complete in block captals)
Surname, first name
Street
Post code, town
Country
Telephone
IB_71085_DAZ24A1_LB6.indb Abs1:18IB_71085_DAZ24A1_LB6.indb Abs1:18 18.11.2011 10:03:11 Uhr18.11.2011 10:03:11 Uhr
