Dentsply Sirona Orthophos E Ceph User manual

New as of: 03.2019
Orthophos E
Orthophos E Ceph
Operating Instructions
English

Table of contents Dentsply Sirona
Operating Instructions Orthophos E
267 11 001 D3352
D3352.201.12.01.0203.2019
Table of contents
1General data ........................................................................................................... 5
1.1 Dear Customer, … ....................................................................................... 5
1.2 Contact information...................................................................................... 5
1.3 Copyright and trademark ............................................................................. 6
1.4 General information about this operating manual ........................................ 6
1.4.1 Structure of the document.............................................................. 7
1.4.1.1 Identification of the danger levels................................. 7
1.4.1.2 Formats and symbols used .......................................... 7
1.5 Other relevant documents............................................................................ 8
1.6 Warranty and liability.................................................................................... 8
1.7 Obligation of system owner and personnel.................................................. 8
1.8 Intended use ................................................................................................ 9
1.9 Indication and contraindication .................................................................... 9
2Safety instructions .................................................................................................. 10
2.1 Basic safety information............................................................................... 10
2.2 Notes on the unit.......................................................................................... 10
2.3 Ventilation slots............................................................................................ 10
2.4 Condensation............................................................................................... 11
2.5 Qualifications of operating personnel........................................................... 11
2.6 Switch on the unit......................................................................................... 11
2.7 Radiation protection ..................................................................................... 11
2.8 Emergency Stop .......................................................................................... 12
2.9 Laser light localizer ...................................................................................... 12
2.10 Hygiene........................................................................................................ 12
2.11 Trouble-free operation ................................................................................. 13
2.12 Interference with electronic devices............................................................. 13
2.13 Risks of electromagnetic fields .................................................................... 13
2.14 Combination with other equipment .............................................................. 13
2.15 Changes to the unit...................................................................................... 14
2.16 Structural alterations .................................................................................... 14
2.17 Electromagnetic compatibility ...................................................................... 14
2.18 Electrostatic discharge................................................................................. 15

Dentsply Sirona
Operating Instructions Orthophos E
Table of contents
67 11 001 D3352
D3352.201.12.01.0203.2019 3
3Unit description ....................................................................................................... 17
3.1 Certification and registration ........................................................................ 17
3.2 Technical data.............................................................................................. 18
3.2.1 Unit data......................................................................................... 18
3.2.2 Transport, storage, and operating conditions ................................ 20
3.2.3 Diagrams........................................................................................ 21
3.2.4 Requirements on the PC systems ................................................. 22
3.3 Overview of exposure programs .................................................................. 23
3.4 Main components of the product.................................................................. 25
3.4.1 Basic unit ....................................................................................... 25
3.4.2 Cephalometer ................................................................................ 26
3.4.3 Multipad ......................................................................................... 27
3.4.4 Remote control............................................................................... 28
3.5 Spare parts and consumables ..................................................................... 29
3.5.1 Accessory parts ............................................................................. 29
3.5.1.1 Bite blocks and contact segments................................ 29
3.5.1.2 Temple supports, forehead support, and
temporomandibular joint supports ................................ 30
3.5.2 Hygienic protective sleeves ........................................................... 31
3.5.2.1 Protective sleeves for basic unit................................... 31
3.5.2.2 Protective sleeves for cephalometer ............................ 32
3.5.3 Test phantom for acceptance/constancy test................................. 33
4Installation and start-up .......................................................................................... 34
4.1 Replacing accessories on the basic unit...................................................... 34
4.1.1 Replacing the bite block, contact segment, or chin rest................. 34
4.1.2 Changing the temple supports and temporomandibular joint
supports ......................................................................................... 34
4.1.3 Adjusting/inserting accessory parts on the cephalometer.............. 35
4.1.4 Moving the sensor.......................................................................... 36
5Operation ................................................................................................................ 38
5.1 Acquiring the X-ray image............................................................................ 38
5.1.1 Switching the unit on and starting the software ............................. 38
5.1.1.1 Switch on the unit ......................................................... 38
5.1.1.2 Enabling exposure readiness in Sidexis 4.................... 40
5.1.2 Selecting an exposure program..................................................... 41
5.1.2.1 Panoramic and bite wing exposure .............................. 41
5.1.2.2 Temporomandibular joint exposure.............................. 52
5.1.2.3 Sinus view .................................................................... 58

Table of contents Dentsply Sirona
Operating Instructions Orthophos E
467 11 001 D3352
D3352.201.12.01.0203.2019
5.1.2.4 Transversal multi-slice posterior teeth.......................... 62
5.1.2.5 Cephalometric exposures............................................. 67
5.1.2.6 Pediatric exposure........................................................ 78
5.1.3 Releasing the exposure ................................................................. 80
5.1.3.1 Starting the test cycle ................................................... 80
5.1.3.2 Releasing the exposure................................................ 80
5.1.3.3 Data recovery in case of problems with image transfer 84
5.1.3.4 Using the remote control .............................................. 87
5.1.3.5 Canceling an exposure................................................. 88
5.2 Preselecting basic settings .......................................................................... 89
5.2.1 Changing the basic settings and start settings .............................. 89
5.2.1.1 Reprogramming the kV/mA values............................... 89
5.2.1.2 Activating the Info menu............................................... 90
5.2.1.3 Activating the service menu.......................................... 90
6Service.................................................................................................................... 91
6.1 Cleaning and care........................................................................................ 91
6.1.1 Cleaning......................................................................................... 91
6.1.2 Disinfecting .................................................................................... 91
6.1.3 Sterilization .................................................................................... 92
6.2 Inspection and maintenance ........................................................................ 93
7Malfunctions............................................................................................................ 95
7.1 Help messages ............................................................................................ 95
7.2 Error message structure .............................................................................. 97
7.3 Error description........................................................................................... 98
7.3.1 Ex – Error type ............................................................................... 98
7.3.2 yy – Locality ................................................................................... 99
8Program values....................................................................................................... 100
8.1 Panoramic exposure .................................................................................... 100
8.2 Cephalometric exposures ............................................................................ 103
8.3 Dose information.......................................................................................... 104
8.3.1 Dose area product parameters for Panorama images................... 104
8.3.2 Dose area product parameters for Ceph-images........................... 107
8.3.3 Calculate dosage ........................................................................... 108
9Dismantling and disposal........................................................................................ 110
9.1 Dismantling and reinstallation ...................................................................... 110
9.2 Disposal ....................................................................................................... 110

Dentsply Sirona
Operating Instructions Orthophos E
1 General data
1.1 Dear Customer, …
67 11 001 D3352
D3352.201.12.01.0203.2019 5
1General data
1.1 Dear Customer, …
We are pleased that you have equipped your practice with the
Orthophos E X-ray system from Dentsply Sirona.
Dentsply Sirona was one of the first inventors of film-based panoramic
X-ray systems and since 1996 has been a pioneer of digital X-ray
technology. You benefit from the vast experience we have gained
through the thousands of digital panoramic X-ray systems installed
worldwide. This device is characterized by many features including
outstanding image quality, simple operation, and a high day-to-day
reliability.
This operating manual should be of good help to you before use as well
as serve anytime later as a reference material.
We wish you every success with using your Orthophos E system.
Your Orthophos E team,
1.2 Contact information
Customer Service Center In the event of technical queries, please use our online contact form at
the following address:
http://srvcontact.sirona.com
Manufacturer's address Sirona Dental Systems GmbH
Fabrikstrasse 31
64625 Bensheim
Germany
Tel.: +49(0) 6251/16-0
Fax: +49(0) 6251/16-2591
e-Mail: [email protected]
www.dentsplysirona.com

1 General data
1.3 Copyright and trademark
Dentsply Sirona
Operating Instructions Orthophos E
667 11 001 D3352
D3352.201.12.01.0203.2019
1.3 Copyright and trademark
Copyright © Sirona Dental Systems GmbH. All rights reserved.
The information contained in this manual may be changed without
notice.
The software and all related documentation are protected by copyright.
You must therefore handle it in the same way as any other protected
material.
Anyone who copies this software to any medium for any purpose other
than his own personal use without the written permission of Sirona
Dental Systems will be liable to prosecution.
Trademarks Microsoft®, Windows 7®, and Windows 10® are registered trademarks.
WindowsTM is a trademark of Microsoft Corporation.
All other trademarks are the property of their respective holders.
1.4 General information about this operating manual
Observe the Operating Instructions Please familiarize yourself with the unit by reading through these
Operating Instructions before putting it into operation. It is essential that
you comply with the specified warning and safety information.
Always keep the Operating Instructions handy in case you or another
user require(s) information at a later point in time. Save the Operating
Instructions on the PC or print them out.
If you sell the unit, make sure that the Operating Instructions are
included with it either as a hard copy or on an electronic storage device
so that the new owner can familiarize himself with its functions and the
specified warning and safety information.
Online portal for technical documents We have set up an online portal for the Technical Documents at
www.dentsplysirona.com/manuals. From here, you can download these
Operating Instructions along with other documents. Please complete the
online form if you would like a hard copy of a particular document. We
will then be happy to send you a printed copy free of charge.
Help If you continue to have difficulties despite having thoroughly studied the
Operating Instructions, please contact your dental depot.

Dentsply Sirona
Operating Instructions Orthophos E
1 General data
1.4 General information about this operating manual
67 11 001 D3352
D3352.201.12.01.0203.2019 7
1.4.1 Structure of the document
1.4.1.1 Identification of the danger levels
To prevent personal injury and material damage, please observe the
warning and safety information provided in these operating instructions.
Such information is highlighted as follows:
DANGER
An imminent danger that could result in serious bodily injury or death.
WARNING
A possibly dangerous situation that could result in serious bodily
injury or death.
CAUTION
A possibly dangerous situation that could result in slight bodily injury.
NOTE
A possibly harmful situation which could lead to damage of the
product or an object in its environment.
IMPORTANT
Application instructions and other important information.
Tip: Information for simplifying work.
1.4.1.2 Formats and symbols used
The formats and symbols used in this document have the following
meaning:
Prerequisite
1. First action step
2. Second action step
or
➢ Alternative action
Result
➢ Individual action step
Requests you to do something.
See "Formats and symbols used
[→7]"
Identifies a reference to another
text passage and specifies its
page number.
● List Designates a list.
"Command / menu item" Indicates commands / menu
items or quotations.

1 General data
1.5 Other relevant documents
Dentsply Sirona
Operating Instructions Orthophos E
867 11 001 D3352
D3352.201.12.01.0203.2019
1.5 Other relevant documents
The X-ray system includes other components, such as PC software,
which are detailed in separate documents. Instructions and warning and
safety information provided in the following documents must be taken
into account:
● SIDEXIS 4 User Manual
1.6 Warranty and liability
Maintenance In the interest of the safety and health of patients, users and other
persons, inspection and preventive maintenance must be performed at
scheduled intervals to ensure the operational reliability and functional
safety of your product (IEC 60601-1 / DIN EN 60601-1 etc.).
The system owner is responsible for making sure that all scheduled
inspections and preventive maintenance activities are performed.
As manufacturers of medical electrical equipment we can assume
responsibility for the safety-related features of the equipment only if
maintenance and repair are carried out only by ourselves or agencies
expressly authorized by us, and if components affecting safe operation
of the system are replaced with original spare parts upon failure.
Exclusion of liability In the event that the system owner fails to fulfill the obligation to perform
scheduled inspections and preventive maintenance activities or ignores
error messages, Sirona Dental Systems GmbH and its authorized
dealers cannot assume any liability for damages.
Certificate of work We suggest that you request a certificate, showing the nature and
extent of the work performed, from those who carry out such work, and
specify that the certificate show any changes in rated parameters or
working ranges, as well as the date, the name of the firm and a
signature.
1.7 Obligation of system owner and personnel
These operating instructions presuppose that you are familiar with the
use of Sidexis software.
Prior to the exposure, please ask women of a childbearing age as to
whether they are pregnant or not. If the patient is pregnant, a risk/
benefit analysis must be performed.
According to the X-ray Ordinance of Germany, owners of X-ray
equipment must perform constancy tests at regular intervals in order to
ensure the safety of operating staff and patients. Dentsply Sirona
recommends monthly testing.

Dentsply Sirona
Operating Instructions Orthophos E
1 General data
1.8 Intended use
67 11 001 D3352
D3352.201.12.01.0203.2019 9
1.8 Intended use
The Orthophos E / Ceph is designed for producing different
tomographic exposures of the maxillofacial area or of parts of this.
Projections of the skull and carpus exposures for orthodontics are also
possible with the cephalometric arm.
1.9 Indication and contraindication
Indications in dentistry areas:
● Conservative dentistry
● Endodontics
● Periodontology
● Prosthodontics
● Functional diagnosis and therapy of craniomandibular dysfunctions
● Surgical dentistry
● Implantology
● Oral and maxillofacial surgery
● Orthodontics
Contraindications:
● Display of cartilage structures
● Display of soft tissue

2 Safety instructions
2.1 Basic safety information
Dentsply Sirona
Operating Instructions Orthophos E
10 67 11 001 D3352
D3352.201.12.01.0203.2019
2Safety instructions
2.1 Basic safety information
NOTE
This unit must not be operated in areas subject to explosion hazards.
2.2 Notes on the unit
The following symbols are applied to the unit:
This symbol can be found next to the rating plate on the unit.
Meaning: Observe the Operating Instructions when operating the unit.
This symbol can be found on the rating plate on the unit.
Meaning: The accompanying documents are available on the Dentsply
Sirona homepage.
Electrostatic discharge (ESD) Connector pins or sockets bearing ESD warning labels must not be
touched or interconnected without ESD protective measures. See also
‘Electrostatic discharge’ and ‘Electromagnetic compatibility’.
Identification of single use devices Prior to each exposure, the hygienic protective sleeves (single use
devices) must be fitted.
Single use devices are identified with the symbol shown on the left.
They must be disposed of immediately after use. Do not use single use
devices more than once.
2.3 Ventilation slots
Under no circumstances may the ventilation slots on the unit be
covered, since otherwise the air circulation will be obstructed. This can
cause the unit to overheat.
Do not spray into the ventilation slots
Do not spray liquids such as disinfectants into the ventilation slots. This
may lead to malfunctions. Use wipe disinfection only in the vicinity of the
ventilation slots.

Dentsply Sirona
Operating Instructions Orthophos E
2 Safety instructions
2.4 Condensation
67 11 001 D3352
D3352.201.12.01.0203.2019 11
2.4 Condensation
Extreme temperature fluctuations may cause condensation inside the
unit. Do not switch the unit on before it has reached normal room
temperature. See also the chapter Technical data [→18].
2.5 Qualifications of operating personnel
The unit may only be operated by skilled or properly trained personnel.
Personnel, who are to be trained, taught, instructed or are taking part in
a general training, may operate the device only under the supervision of
an experienced person.
To operate the unit, the operating personnel must:
● have read and understood the Operating Instructions
● be familiar with the fundamental structure and functions of the unit
● be able to recognize irregularities in the functioning of the unit and
implement the appropriate measures where necessary
2.6 Switch on the unit
The patient may not be positioned in the unit when starting it and setting
the operating mode (until the sensor has been positioned).
Malfunction may cause injury to the patient.
In case of an error that requires switching the unit off and back on
again, the patient must be removed from the unit, at the latest before
the unit is switched back on.
2.7 Radiation protection
The valid radiation protection regulations and measures must be
observed. The statutory radiation protection equipment must be used. In
order to reduce radiation exposure, Dentsply Sirona recommends using
bismuth or lead shields or aprons, especially for pediatric patients.
During an exposure, the operator should move as far away from the X-
ray tube assembly as the coiled cable of the release button permits.
With the exception of the patient, no other persons without radiation
protection are allowed to stay in the room during an exposure. In
exceptional cases, a third person may provide assistance, but not the
practice staff. Visual contact with the patient and the unit must be
maintained throughout the entire exposure.
In case of malfunctions, cancel the exposure immediately by letting go
of the exposure release button.

2 Safety instructions
2.8 Emergency Stop
Dentsply Sirona
Operating Instructions Orthophos E
12 67 11 001 D3352
D3352.201.12.01.0203.2019
2.8 Emergency Stop
If any parts of the unit touch the patient during the rotary movement, let
go of the exposure release button (X-Ray) immediately or stop the unit
at once by actuating the unit main switch or an Emergency Stop switch
(not included in the scope of supply)!
2.9 Laser light localizer
The system incorporates Class 1 laser products.
The light localizers are intended for correct patient positioning. They
must not be used for any other purposes.
A minimum distance of 10cm (4") is required between the eye and the
laser. Do not stare directly into the laser beam.
Make sure that the laser beam does not meet the eyes of the patient.
Prior to activating the light localizers, the patient must be asked to shut
their eyes.
The light localizers may be switched on only when functioning perfectly.
Repair work must be carried out by authorized staff only.
Do not use the system with any other lasers, and do not make any
changes to settings or processes that are not described in these
operating instructions. This may lead to a dangerous exposure to
radiation.
2.10 Hygiene
The protective sleeves must be reapplied for each patient, all auxiliary
exposure tools must also be disinfected to avoid potential transmission
of pathogens that may cause serious illnesses.
Application components without disposable protective covers must be
disinfected prior to patient positioning in order to prevent cross-
contamination.
Suitable hygienic measures must be taken to prevent cross
contamination between patients, users, and other persons.
The following chapters contain more information about sterilization and
hygienic protective sleeves: “Hygienic protective sleeves [→31]“,
“Preparing the exposure“, “Sterilization [→92]“.

Dentsply Sirona
Operating Instructions Orthophos E
2 Safety instructions
2.11 Trouble-free operation
67 11 001 D3352
D3352.201.12.01.0203.2019 13
2.11 Trouble-free operation
Use of this system is permissible only if it works properly without
malfunctions. If trouble-free operation cannot be ensured, the unit must
be taken out of service, checked by authorized technicians for
malfunctions and, if necessary, repaired.
X-rays of patients may be taken only when the system is working
trouble-free.
The movements of the unit must not be obstructed by physical
constitution, clothing, dressings, wheelchairs, or hospital beds.
The travel range of the unit must be kept free from foreign matter.
Do not leave the patient at the unit unattended.
The device may only be operated with a complete cover and protective
hood.
2.12 Interference with electronic devices
To prevent the malfunctioning of electronic devices and data memories,
these objects must be removed prior to the X-ray exposure.
2.13 Risks of electromagnetic fields
The function of implanted systems (cardiac pacemakers or cochlear
implants, for example) can be affected by electromagnetic fields. Before
commencing treatment, ask if the patient has a cardiac pacemaker or
any other implanted system.
Any prevailing risks are listed in the documentation provided by the
implant manufacturer.
2.14 Combination with other equipment
Putting together or altering a medical electrical system by combining
with other devices in accordance with IEC 60601-1 (safety requirements
for medical electrical systems) is subject to the obligation to ensure
compliance with the requirements of this provision for patient safety, the
operator, and the environment.
If any devices not approved by Dentsply Sirona are connected, they
must comply with the applicable standards:
● IEC60950-1 or IEC 62368-1 for information technology equipment
and
● IEC60601-1 for medical electrical equipment
To this end, refer to the ‘Installation requirements’ and compatibility list/
declaration of conformity by the system integrator.
If in doubt, contact the manufacturer of the system components.

2 Safety instructions
2.15 Changes to the unit
Dentsply Sirona
Operating Instructions Orthophos E
14 67 11 001 D3352
D3352.201.12.01.0203.2019
2.15 Changes to the unit
Modifications to this unit which might affect the safety of the system
owner, patients, or other persons are prohibited by law!
For reasons of product safety, this product may be operated only with
original Dentsply Sirona accessories or third-party accessories
expressly approved by Dentsply Sirona. The user is responsible for any
damage resulting from the use of non-approved accessories.
2.16 Structural alterations
If structural changes are made in the vicinity of the X-ray unit which
result in the device being exposed to very high levels of vibration or
even impact, the device must be inspected by a service engineer and
re-adjusted and re-calibrated if necessary.
2.17 Electromagnetic compatibility
The acquisition unit complies with the requirements of the standard IEC
60601-1-2.
Medical electrical devices are subject to special precautionary
measures with regard to electromagnetic compatibility (EMC). It must
be installed and operated as specified in the “Installation Requirements”
document.
Portable and mobile RF communications equipment may affect medical
electrical equipment.
If the installation requirements and the following recommendations are
not observed, there is a risk that the X-ray images will not have the
correct exposure.
The correctness of the radiation parameters and the repeatability of the
dose values in particular may be affected.
In the case of repairs, only use replacement parts approved by Dentsply
Sirona.
Only use disinfectants approved by Dentsply Sirona so as not to
damage electrical insulation.
Portable HF equipment must not be placed within a 30 cm radius of the
X-ray unit.
HF surgery units and X-ray units must not be operated at the same
time.

Dentsply Sirona
Operating Instructions Orthophos E
2 Safety instructions
2.18 Electrostatic discharge
67 11 001 D3352
D3352.201.12.01.0203.2019 15
2.18 Electrostatic discharge
Protective measures
ESD stands for ElectroStatic Discharge.
Electrostatic discharge from people can damage electronic components
when the components are touched. Damaged components usually have
to be replaced. Repairs must be performed by qualified personnel.
Measures to protect against ESD include:
● Procedures to avoid electrostatic charging via
– air conditioning
– air humidification
– conductive floor coverings
– non-synthetic clothing
● discharging the electrostatic charges from your own body through
contact with
– a metallic unit casing
– a larger metallic object
– any other metal part grounded with the protective earth
● Wearing an antistatic band that creates a connection between the
body and a protective ground wire.
Areas at risk are indicated on the unit with the ESD warning label:
We recommend that all persons working with this system are made
aware of the significance of the ESD warning label. A training course
should also be held to inform users about the physics of electrostatic
charges.
Physics of electrostatic charges
An electrostatic discharge requires prior electrostatic charging.
There is a danger of electrostatic charges building up whenever two
bodies rub against each other, e.g. when:
● walking (soles of shoes against the floor) or
● moving (chair casters against floor).
The amount of charge depends on several factors. The charge is:
● higher at low air humidity than at high air humidity, and
● higher with synthetic materials than with natural materials (clothing,
floor coverings).
The following rule of thumb can be applied to assess the transient
voltages resulting from an electrostatic discharge.
An electrostatic discharge is:
● perceptible at 3,000 V or higher
● audible at 5,000 V or higher (cracking, crackling)
● visible at 10,000 V or higher (arc-over)

2 Safety instructions
2.18 Electrostatic discharge
Dentsply Sirona
Operating Instructions Orthophos E
16 67 11 001 D3352
D3352.201.12.01.0203.2019
The transient currents resulting from these discharges have a
magnitude of over 10 amps. They are not hazardous for humans
because they last for only several nanoseconds.
Note: nanosecond = 1/1,000,000,000second = 1billionth of a second
Voltage differentials exceeding 30,000 volts per centimeter may lead to
a charge transfer (electrostatic discharge, lightning, spark-over).
Integrated circuits (logical circuits and microprocessors) are used in
order to implement a wide variety of functions in a device. The circuits
must be miniaturized to a very high degree in order to include as many
functions as possible on these chips. This leads to structure thicknesses
as low as a few ten thousandths of a millimeter. Integrated circuits that
are connected to wires leading externally are therefore particularly at
risk from electrostatic discharge.
Even voltages that are imperceptible to the user can cause breakdown
of the structures, thus leading to a discharge current that melts the chip
in the affected areas. Damage to individual integrated circuits may
cause malfunction or failure of the unit.

Dentsply Sirona
Operating Instructions Orthophos E
3 Unit description
3.1 Certification and registration
67 11 001 D3352
D3352.201.12.01.0203.2019 17
3Unit description
3.1 Certification and registration
The Orthophos E / Ceph X-ray unit complies with IEC 60601-1:2005 +
A1:2012
The Orthophos E / Ceph X-ray unit complies with IEC 60601-1-3:2008 +
A1:2013
The Orthophos E / Ceph X-ray unit complies with IEC 60601-2-63:2012
+ A1:2017
Original language: German
0123
This product bears the CE marking in accordance with the provisions of
Council Directive 93/42/EEC of June 14, 1993 concerning medical
devices.

3 Unit description
3.2 Technical data
Dentsply Sirona
Operating Instructions Orthophos E
18 67 11 001 D3352
D3352.201.12.01.0203.2019
3.2 Technical data
3.2.1 Unit data
Model name: Orthophos E / Ceph
Nominal voltage: 200 – 240 V
Permissible fluctuation: ± 10%
Permissible drop under
load:
10%
Rated current: 12 A
Nominal power output: 2 kW at 90 kV/12 mA with any radiation
time
Nominal frequency: 50 Hz/60 Hz
Mains resistance: max. 0.8 ohms
Main building fuse: 25 A slow-blow (16 A for single line)
Power consumption: 2 kVA
Power output of tube as-
sembly:
90 kV/12 mA = 1080 W with any radia-
tion time
Tube voltage: 60 – 90 kV (for 90 kV max. 12 mA)
Tube current: 3 – 16 kV (for 16 mA max. 66 kV)
Maximum setting range: 60 kV / 3 mA to 90 kV / 12 mA
High-voltage waveform: High-frequency multipulse
Residual ripple ≤ 4 kV
High voltage generation fre-
quency:
40 – 120 kHz
Program duration: see "Program values" [→100]
Exposure time: see "Program values" [→100]
Image acquisition scale: For P1, normal dental arch (slice cen-
ter) approx. 1:1.19, i.e. the acquired im-
age is magnified by approx. 19% on av-
erage compared to reality.
Exposure time for a
cephalometric image:
14.9 s max.
Image acquisition scale for
a cephalometric image:
approx. 1:1.1, i.e. the acquired image is
magnified by approx. 10% on average
compared to reality.
Total filtration of X-ray tube
assembly:
> 2.5 AI / 90 IEC 60522
Focal spot size as specified
in IEC 60336, measured in
the central X-ray beam:
0.5 mm

Dentsply Sirona
Operating Instructions Orthophos E
3 Unit description
3.2 Technical data
67 11 001 D3352
D3352.201.12.01.0203.2019 19
Marking of focal spot:
Source-skin distance > 200 mm (8“)
Automatic exposure block-
ing:
The duration of automatic exposure
blocking (cooling period) depends on
the set kV/mA level and the actual ex-
posure time. Depending on the tube
load, interval times of 8 s to 300 s are
automatically set by the system.
Example: For program P1 with expo-
sure data of 80 kV/14 mA and a radia-
tion time of 14.1 s, the pause duration
is 150 s.
Equipment class: IPX0
Class I device
Degree of protection
against electric shock: Type B device
Degree of protection
against ingress of water:
Ordinary equipment (without protection
against ingress of water)
Year of manufacture:
20XX
(on the rating plate)
Operating mode: Continuous operation
Long-term power output: 100 W
Anode material: Tungsten
Exposure parameters for
determining leakage radia-
tion:
2 mA / 90 kV
X-ray tube
Siemens SR 90/15 FN or
CEI OCX 100

3 Unit description
3.2 Technical data
Dentsply Sirona
Operating Instructions Orthophos E
20 67 11 001 D3352
D3352.201.12.01.0203.2019
PAN sensor
Digital CCD line sensor, repluggable for panoramic exposure technique
Active sensor area, Pan
type:
138 mm x 6.48 mm
Detail resolution: 0.027 mm pixel size
Focus-sensor distance: 497 mm
Ceph sensor
Digital CCD line sensor, repluggable for panoramic or ceph exposure
technique
Active sensor area, Ceph
type:
230 mm x 6.48 mm
Detail resolution: 0.027 mm pixel size
Focus-sensor distance: 1,714 mm
3.2.2 Transport, storage, and operating conditions
Orthophos E
Transport and storage con-
ditions:
Temperature: -10°C – +70°C
(14°F – 158°F)
Relative humidity: 10% – 95%
+10
+40 95
10
106
70 kPa
Operating conditions: Ambient temperature: +10°C–+40°C
(50°F – 104°F)
Relative humidity: 10% - 95% (no con-
densation)
Operating altitude: ≤ 3,000m above sea level
Cephalometer
-40
+70 106
50 kPa
95
10
°C
Transport and storage con-
ditions:
Temperature: -40°C – +70°C (-40°F –
158°F)
Relative humidity: 10% – 95%
Air pressure: 500 hPa – 1060 hPa
