Detecto D231 User manual

7 in1
BODY FAT SCALE
With Body Water and Muscle Mass
MODEL D231
USER MANUAL
O V E R 100 Y E A R S
OF MEDIC A L A C C U R A C Y

Table of Contents
PREPARATION BEFORE USE .............................................................................................. 3
NOTES ON SAFETY ............................................................................................................ 4
INTENDED USE................................................................................................................... 4
PRECAUTION NOTICE ...................................................................................................... 5
IMPORTANT NOTICE TOUSERS ........................................................................................ 5
PRODUCT DESCRIPTION .................................................................................................. 5
FRONT VIEW ................................................................................................................ 5
BACK VIEW ................................................................................................................. 6
LCDREADOUT ............................................................................................................ 6
OPERATION....................................................................................................................7-8
BODY FAT ANDTOTAL BODY WATER ESTIMATING OPERATION WITH USER
MEMORY........................................................................................................................... 9
A. TORECALL SETTINGS FROM MEMORY FOR BODY FAT
ANDTOTAL BODY WATER ESTIMATION ................................................................. 9
B. TOTURN OFF THE SCALE ........................................................................................ 9
PROBLEM-SOLVING AND QUESTIONS........................................................................... 10
CAREANDMAINTENANCE ........................................................................................... 11
PRODUCT SPECIFICATION .............................................................................................11
EDUCATION INFORMATION ......................................................................................12-15
LIMITED LIFETIME WARRANTY ......................................................................................... 16

Congratulations! You have purchased a precision health monitoring
product that should provide you with years of accurate use. To assure
you obtain the best performance please read the following set-up and
use instructions carefully before using the scale.
PREPARATION BEFORE USE
1. Insert the Battery
This scale operateson two CR2032 lithium batteries (included).
Open the batterycover on the back of the scale unit. Remove
replacement. Be sure the polarity of the battery is set correctly
for the scale to function properly. If you do not intendto use this
unit for a prolonged period of time, it is advisable to remove the
battery before storing.
Open the battery door Direction of the CR2032 batteries
2. Tact Switch
This scale is set to pounds. You can set the "kg/cm, lb/in” unit of measure switch
locatedon the back of the scale for kilograms or pounds.
TIPS
Replace battery
when "Lo" is
displayed.
3

4
PRECAUTION !
The scale must be
startedup after
battery insertion/
replacement of
batteryor each time it
is moved or bumped.
5. Start-up the Scale
Press lightly on the scale platform to start-up
the scale, the display shows and then
turns off. The scale is ready for use.
INTENDED USE
3. Some models have a static cling label on the LCD
lens to prevent scratching. Remove before use.
4. Set the Right Position
surface. Do not use on carpets.
PRECAUTION !
Do Not stepon scale
unevenly (X)
To avoid injury, do not
step with wet feet or on
the edge of the platform.
NOTES ON SAFETY
Please read this section carefullytofamiliarize yourself withfeatures and operations
before using the unit.
• The warning signs and the sample icons shown here are listed in order for you
to use this product safely and correctly as well as to prevent product damage,
risk and injury to you and others.
• The icons and meanings are as follows:
PRECAUTION NOTICE
Indicates the right conditions to use the
product and to prevent damage, risk
and injury.
IMPORTANT NOTICETO USERSIndicates important notices users should
read before using the product.
CARE ANDMAINTENANCE
Indicatesmatters in which the possibility
of damage may happen as a result
of incorrect handling and improper
maintenance.
This scale is intended to measure body weight, impedance and estimate percentage
of body fat and body water and muscal mass using BIA (Bioelectrical Impedance
Analysis). It is intended for use by healthy children, 10 -17 years old, and healthy adults
with active, moderately active, to inactive lifestyles for body composition assessment
in the home environment.

SET
5
PRECAUTION NOTICE
Do not use the scale on people who have body implants such as a
pacemaker, artificial limbs, contraceptive devices, or metal plates
or screws. It may cause the device to malfunction or produce an
inaccurate result. When in doubt, consult your physician.
Do not disassemble the scale as incorrect handling may cause injury.
LCDReadout
ON/OFF ButtonSET Button
& Buttons
Platform with
Electrodes
PRODUCT DESCRIPTION
FRONT VIEW
• This product is intended for adults and children (ages 10 to 85).
•Make sure to use only the type of battery stated (see Section “PREPARATION
BEFORE USE”).
•The “Athlete” mode is applicable only to people 15-85 years of age. (See
section: “Why is the Athlete Mode necessary in a Body Fat Analyzer!”)
•Body fat percentage estimates will vary with the amount of water in the
body, and can be affected by dehydration or over-hydration due to such
factorsasalcohol consumption, menstruation, illness, intense exercise, etc.
•Do not use on pregnant women. The result is inaccurate and effects on the
fetus are unknown.
•For body fatand body water estimates, always estimate in bare feet.
IMPORTANT NOTICE TO USERS

6
1. Age
2. Body Water %
3. Height Displayed in Feet/Inches
4. Height Displayed in CM
5. Body Fat % Reading
6. Female Icon
7. Male Icon
8. Weight Readout in Kilograms (KG),
Pounds (LB)
9. Athlete Mode
10. Normal Mode
11. Muscle Mass %
12. POWER Button
13. Forward Button
14. Back Button
15. SET Button
16. Bone Mass%
17. Calorie
2
16
10
12 15
4
5
6
7
9
3
8
11
17
Know Your Readout
FUNCTION KEYS
ON/OFF
• Turn the scale on or off
• Enter boby Fat and total body water estimation mode
SET
[ ] or [ ]
• Changes value of height and age, toggle between Male and Female, toggle
between Normal and Athlete mode in Body Fat function
• Select memory 1 - 12 in Memory mode & Recall mode
• Recall settings of memory locations
BACK VIEW
TACT SWITCH
Adjust the conversion switch located at the bottom of the scale to
change the measuring unit between kg/cm or lb/in. User selectable unit:
kg/cm or lb/in.
Battery Compartmet
1
13 14
SET

SET
7
The accuracy of the results depends on how you stand on the scale. Position your feet with
maximum contact on the metal electrodes on the platform. This ensures the best contact
between your feet and the metal contacts. Stay on the scale until the body fat estimation is
completed and the result is displayed. Clean, slightly moist feet will provide the best results.
OPERATION
Fig. 1
Fig. 2
1. Press the ON/OFF key to turn the scale on.
2. Set Memory
Press the [ ] or [ ]key to select a memory location (1-12 users). Press [SET] to confirm.
WEIGHING-ONLY OPERATION
1. Step onto the scale and stand still while
the weight is being measured (Fig.1).
2. The screen displays the weight (Fig.2).
3. The scale turns off automatically after use.
Feet centered on platform Feet not centered on platform

8
6. Select Normal or Athlete Mode
Press the [ ]or [ ]key totoggle between normal or athlete. Press [SET] to confirm all settings.
NOTE: Athlete mode is only available for those 15-85 years of age. For those aged 14 or under,
this step is automatically by-passed. (See section: “Why is the Athlete Mode necessary in a
Body Fat Analyzer?”)
7. After step 6 been done, all personal information will be displayed again, one screen at a
time then your personal information is saved in memory.
8. Repeat steps 1-7 to set other pre-programmed user numbers.
5. Select Gender
Press the [ ] or [ ]key to toggle between the male ( ) and female ( ) icons.
Press [SET] to confirm gender.
3. Set Height
Press the [ ] or [ ] key to adjust the height. Press [SET] to confirm.
4. Set Age
Press the [ ] or [ ] key to adjust the age. Press [SET] to confirm.

9
The scale features 12 personal memory settings. This allows users to store and recall their own
height, age, gender and normal/athlete mode selection. Follow steps in the previous section
“Program Personal Data” to input your personal information into a memory location.
A. To Recall Settings from Memory for Body Fat and Total Body Water Estimation
You must have bare feet for estimation results. Remove your shoes and socks before proceed-
ing. Clean, slightly moist feet will provide the best results. Position your feet for maximum
contact with the metal electrodes on the platform.
1. Press the ON/OFF key to turn the scale on.
2. Press the [ ]or [ ]key to toggle between memory locations (1-12). The screen will show the
previous reading, then “0.0”. (Note: The previous reading for that user number will appear
after first use.)
BODY FAT AND TOTAL BODY WATER ESTIMATING
OPERATION WITH USER MEMORY
3. When “0.0” appears on screen, step on the scale with bare feet, positioning your feet evenly
on the scale platform with maximum contact with the metal electrodes.
4. Stand still while the scale measures your weight and estimates your body composition.
5. Your weight, body fat % (BF), total body water % (BW), muscle mass % (MM), bone mass (BM)
and then calorie (KCAL) are displayed one by one. Then the readings are repeated again.
B. TO TURN OFF THE SCALE
To turn the scale off, press the ON/OFF key while programming data.
Or, if no key has been pressed for a few seconds, the scale turns off automatically.

10
1. No weight is displayed?
Check if the scale is powered up and started up. If not, please refer to the
Section “Preparation Before use”.
2. Why does the display read “Lo”?
Battery is running low. Replace the battery.
3. The message displays “Err 0”….
Initialization error. Step off the scale and wait until the scale automatically switches off.
Start the scale again by pressing lightly on the scale platform to re-initialize the scale.
The display shows “0000” and then turns off. The scale is ready for use again.
4. The message displays “Err 1”….
Instability error. Step off the scale and wait until the scale automatically switches off. Step
on the scale to repeat the measurement again, standing still while computation is in process.
5. The message displays “Err 2” when measuring…
Overload warning. Remove the weight immediately; otherwise, permanent damage to the scale
will occur.
6. The message displays “Err 3” when estimating body fat and body water values…
Measurement error. Impedance cannot be measured. Please make sure that you are standing still
on the scale and maintaining maximum contact between your feet and the metal contacts. If not,
please refer to “Operation” section. You may need to moisten your feet to improve the electri-
cal contact.
7. After I tried the corrective actions from Err 1 to Err 3, I still can’t solve the problem …
If Err 1 to Err 3 persists after following the corrective actions, remove and re-insert
battery after one minute.
8. I have tried all corrective actions, but still can’t solve the problem …
Please contact the Detecto Customer Service at 1-800-336-5282.
9. Why do I get a different body fat reading when I use a different brand of body fat scale?
Different body fat scales take estimations around different parts of the body and use different
mathematic algorithum to estimate the percentage of body fat. The best advice is not to make
comparisons from one device to another, but to use the same device each time to monitor any
change.
PROBLEM SOLVING AND QUESTIONS

11
1. Do not disassemble the scale other than for replacing the battery; it contains no
user serviceable parts. Damage to the scale may occur as a result of improper
handling.
2. Remove the battery when the scale is not used for a prolonged period of time.
3. Clean the scale after use with a dampened cloth. Do not use solvents or
immerse the unit in water.
4. Avoid excessive impact or vibration to the scale, such as dropping it onto the
replacing batteries, if there is more than one battery in the scale, replace
all batteries at the same time; do not mix old and new batteries. Do not mix
alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
Remove the batteries if the scale will not be used for a long period of time.
6. Do not store anything on the scale, as it is a sensitive weighing device.
7. Do not store the scale where you store cleaning chemicals. The vapors from
some household products may affect the electronic components of your scale.
CARE AND MAINTENANCE
1. Bioelectrical Impedance Analysis(BIA)
technology for body fat and body
water percentage, muscle estimations.
2. High precision STRAIN GAUGE
technology for weight measurement
3. Athlete (for ages 15-85 years)
or Normal Mode selection
4. 12 - user memories
5. 4 - button operation
6. Auto-on and auto-off functions
7. Power saving LCD readout
8. Low battery indicator
9. Capacity: 400 lb, 180 kg
10. Graduation: 0.2lb, 0.1kg
11. Body fat graduation: 0.1%
12. Body water graduation: 0.1%
13. Muscle mass graduation: 0.1%
14. Age range from 10 to 85 years
15. Height range from 2'5.5"- 7'4.5" (75 to 225cm)
16. Body fat range: 4 to 60%
17. Total body water range: 29 to 70%
18. Operates with two CR2032 lithium
batteries included
19. Accuracy of weight measurement: ±1.3 lb
(16.5 lb ~ 176.3 lb); ±2.6 lb (176.3 lb ~ 330 lb)
20. Output power for Body Fat Analyzer: <300uA
PRODUCT SPECIFICATIONS

12
Standard for Women
(Source: University of Illinois Medical Center, Chicago, USA)
Rating Age
20-29 30-39 40-49 50-59 60+
Low <19 <20 <21 <22 <23
Optimal 20-28 21-29 22-30 23-31 24-32
Moderate 29-31 30-32 31-33 32-33 33-35
High > 31 >32 >33 >34 >35
1. Why is it important to monitor percentage body fat (%BF)?
The absolute weight traditionally determines whether or not a person is obese. Weight
change in itself does not indicate whether it was the weight of body fat or muscle that
had changed. In weight management, it is desirable that muscle mass be maintained
while body fat is lost. Thus, monitoring the percentage of fat in the body is an important
step toward successful weight management and body health.
The optimal %BF of an individual varies according to age and gender.
The table as follows may be used as a guide:
EDUCATION INFORMATION
Before using the scale, you should know ...
Standard for Men
(Source: University of Illinois Medical Center, Chicago, USA)
Rating Age
20-29 30-39 40-49 50-59 60+
Low <13 <14 <16 <17 <18
Optimal 14-20 15-21 17-23 18-24 19-25
Moderate 21-23 22-24 24-26 25-27 26-28
High > 23 >24 >26 >27 >28

13
2. How is percentage body fat (%BF) estimated?
The percentage of BF is measured by a method called Bioelectrical Impedance Analysis
(BIA). The use of BIA to estimate body fat has been pioneered since the seventies. It was
only in the past decade that the estimation of body fat using BIA technology was successfully
offered to the consumer as a compact bathroom scale. With BIA technology, a low intensity
electrical signal is sent through the body. The signal is very low and causes no bodily harm.
Depending on the amount of body fat of the individual, the electrical signal will flow with
a different degree of difficulty. The difficulty with which a signal flows through the body is
called electrical impedance. Hence, by measuring the electrical impedance and applying
to the data a proprietary algorithm, %BF can be estimated. Please note that the
percentage of body fat and body water will not add up to 100%.
Please be reminded that the %BF estimated with the scale represents only a good
approximation of your actual body fat. There exist clinical methods of estimating
body fat that can be ordered by your physician.
3. Why is it important to monitor percentage Total Body Water (%TBW) in the body?
Water is an essential component of the body and its level is one of the health indicators. Water
makes up approximately between 50-70% of the body's weight. It is present proportionally more
in lean tissue compared to fat tissue. Water is a medium for biochemical reactions that regulate
body functions. Waste products are carried in water from cells for excretion in urine and sweat.
Water provides form to cells; helps to maintain body temperature; provides moisture to skin and
mucosa; cushions vital organs; lubricates joints and is a component of many body fluids. The amount
of water in the body fluctuates with the hydration level of the body and state of health. Monitoring
the level of body water can be a useful tool for one's health maintenance. Similar to body fat
estimation, the %TBW function provided in this scale is based on BIA. The estimated %TBW may vary
according to your hydration level, that is, how much water you have drunk or how much you
have sweated immediately prior to the estimation. For better accuracy, avoid fluctuation in
hydration level prior to the estimation. The accuracy of the scale in estimating TBW will also
decrease with individuals suffering from diseases that tend to accumulate water in the body.
%BF Range Optimal % TBW Range
Men
4 to 14% 70 to 63%
15 to 21% 63 to 58%
22 to 24% 58 to 56%
25 to 60% 56 to 29%
Women
4 to 20% 70 to 59%
21 to 29% 59 to 52%
30 to 32% 52 to 50%
33 to 60% 50 to 29%
Average %SM Range
Skeletal muscle
52 to 41%
46 to 38%
42 to 37%
46 to 37%
38 to 33%
34 to 31%
32% or below
41% or below
The optimal %TBW of an individual varies according to age and gender. The table as
follows may be used as a guide: (Source: University of Illinois Medical Center, Chicago, USA)

14
Please be reminded that the %TBW estimated with the scale represents only a good
approximation of your TBW. There are clinical methods of estimating total body water
that can be ordered by your physician.
4. When should I use the scale’s body fat and total body water functions?
For maximum accuracy and repeatability, it is recommended that the scale’s body fat
and total body water functions be used at approximately the same time of the day, e.g.
before breakfast in the morning. It is also a good practice to avoid swings in hydration
level of the body prior to the estimation. Establishing your own baseline value of %BF and
%TBW and tracking their changes is better than merely comparing your %BF and %TBW value
to the population’s “normal” value.
The estimates provided are not substitutes for physician assessments. Consult your physician
to determine what body fat percentage, total body water percentage, muscle mass
percentage, bone mass percentage and daily calorie intake are most ideal for you.
5. Why is the Athlete Mode necessary in a Body Fat Analyzer?
It has been found that body fat estimation using BIA could overestimate the percentage
body fat of adult elite athletes. The physiological variation of athletes in bone density
and level of hydration are two of the reasons said to account for the difference. The
Athlete mode is selectable only for people 15-85 years old.
6. Definition of an Athlete
The general consensus among researchers is that a quantitative dimension could be used
in defining an athlete. For example, an athlete could be defined as a person who consistently
trains a minimum of three times per week for two hours each time, in order to improve
specific skills required in the performance of their specific sport and/or activity.
7. What is Muscle Mass?
Our Body Fat Scale estimates the weight of Skeletal Muscle Mass in your body.
You have around 650 muscles in your body, and they make up roughly half of your body
weight. These muscles can be divided into three different groups:
skeletal, smooth and cardiac. All of these muscles can stretch and contract, but they
perform very different functions.
Skeletal muscle: Produces movement, maintains posture, stabilizes joints and generates heat
Smooth muscle: Found in the walls of hollow organs
Cardiac muscle: Exists only in your heart
8. Skeletal muscle (SM)
The tissue most commonly thought of as muscle is skeletal muscle. Skeletal muscles cover
your skeleton, giving your body its shape. They are attached to your skeleton by strong,
springy tendons or are directly connected to rough patches of bone. Skeletal muscles are
under voluntary control, which means you consciously control what they do.

15
Just about all body movement, from walking to nodding your head, is caused by skeletal
muscle contraction. Your skeletal muscles function almost continuously to maintain your
posture, making one tiny adjustment after another to keep your body upright. Skeletal
muscle is also important for holding your bones in the correct position and prevents your
joints from dislocating. Some skeletal muscles in your face are directly attached to your skin.
The slightest contraction of one of these muscles changes your facial expression.
9. What is Bone Mass?
Our Body Fat Scale estimates the weight of non-living bone mineral content. This is
important for monitoring and maintaining healthy bones through exercise and
calcium-rich diet.
An adult skeleton is made up of 206 bones, which come in several different shapes and
sizes and have specific structure. Your bones contain blood vessels, nerve cells and living
bone cells known as osteocytes. These are held together by a framework of hard, non-living
material containing calcium and phosphorous. A thin membrane called the periosteum
covers the surface of your bones.
Bone Mineral Content differs according to age and sex.
(Source: Rico et al. 1993)
The typical range of percentage bone mass (mineral content) of average men and
women is between 4.0 to 5.3% (Rico 1993).
10. What is the Calorie predictor daily calorie intake estimator?
The Calorie predictor function estimate the number of calories required based on your
body composition and user entered personal data. This tool can be used as a guide
when setting calorie goals during weight loss and exercise programs.

LIMITED LIFETIME WARRANTY
Your DETECTO product is warranted to the original consumer only, for the lifetime of the product, to be free
from defects in materials and workmanship under normal use. This product is designed for personal use only.
DETECTO, used under license by Lifespan Brands LLC, has the right to nullify the Warranty Agreement should the
product be used in a commercial environment. This warranty is void if the product has been tampered with,
misused, abused or modified. Our obligation under this Warranty is limited solely to the charge of repairing the
product, including the cost of parts, or, at our option, replacing the product with an equivalent model. There are
no express or implied warranties except as listed above. DETECTO, USED UNDER LICENSE BY LIFESPAN
BRANDS LLC, IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR FAILURE OR
MALFUNCTION OF THE PRODUCT AND ANY RECOVERY MAY NOT BE GREATER THAN THE PURCHASE
PRICE PAID FOR THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED
TO A PERIOD OF ONE (1) YEAR FROM THE PURCHASE DATE. Some states do not allow limitations on how long
an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above
limitations may not apply to you. This Warranty gives you specific legal rights and you may have other rights
which vary from state to state.
To obtain warranty service, you must return the product freight pre-paid, in either its original packaging
or packaging affording an equal degree of protection, to DETECTO, used under license by
Lifespan Brands LLC, at 1200 Thorndale Avenue, Elk Grove Village, IL 60007.
For additional information regarding this
product or its warranty, please contact us:
DETECTO is a registered trademark of
Cardinal Scale Manufacturing Co. and
used under license by Lifespan Brands LLC.
Lifespan Brands LLC
1200 Thorndale Ave., Elk Grove Village, IL 60007.
1-800-336-5282
email: [email protected]
© 2016 Lifespan Brands LLC. All rights reserved.
