DeviceWell HDS9106 User manual

6-CH SWITCHER
Users’ Manual
HDS9106（2022）
VER:2.0

2
HDS9106
Caution
Danger
Preparation Before Installation
●During transportation, handling, and installation of switchboard equipment, avoid collisions
between the switchgear equipment and doors, walls, shelves, etc.
●When the equipment is unpacked and transported, it is strictly forbidden to put it down and
drag it gently to avoid damage to the switchboard equipment.
●Do not place the switcher equipment in a flammable, explosive atmosphere or smoke
environment. Do not perform any operation in this environment.
●Operating equipment should be kept away from water and moisture. The water in the
switchgear or moisture willcause damage to the circuit of the switchgear equipment.
●A certain amount of heat will be generated during the operation of the switcher. Ensure that
the switchgear equipment is ventilated and the switcher device can operate normally.
●It is a fatal hazard that indirect contact with the power supply by wet objects is prohibited.
Unregulated, incorrect high-voltage operation can cause accidents such as fire or electric shock.
●It is forbidden to install and remove the switchgear equipment and power cord. When the power
cord is in contact with the conductor, an arc or spark may be generated, which may result in fire
or electric shock.

3
HDS9106
Contents
1. Overview……………………………………………………………………………………04
1.1 Introduction……………….…………………………………………………………..….04
2. Functional characteristics………….…………………………………………......05
2.1 Size……………………………..………………………….………………….…………..….06
3. Interface Specification……………………………………………………………….06
3.1 Interface Introduction……………..…….…….………………….……………..…..06
3.2 TALLY Interface……………………..………….….………………….……………..…..07
3.3 Parameter……………………….……….……….…………………….……………..…..08
4. Control Panel and Interface………..…………………..………………………...09
4.1 Control Panel.………………………..…………….………………….…………………..09
4.1.1 Area Description……………..………………………….…….……………….....09
4.1.2 Key Description……………..………….……………….…….……………………10
4.1.2.1 Audio Control Area……………….……….……………….…..………10
4.1.2.2 Transition Effect Control Area………………….……….……......13
4.1.2.3 Integrated Control Area.……………….……….……….……........15
4.1.2.4 PGM & PVW Selection…………………….……….………………….17
5. System menu settings……..……………..…………………………………………..19
6. Failure and Maintenance…..……………………………………………………….21
7. More switcher options……………………………………………………………….22

4
HDS9106
DeviceWell HD Video Switcher HDS9106 adopts portable integrated design, Clamshell metal
casing, standard size: 384*250*76.5 mm, which can be used for video special effects switching in small
outdoor scenes. The device integrates common components such as multiview processor, special effects
generator, audio processor, and control keyboard.
The HDS9106 supports 4 channels of broadcast SDI and 2 channels of HDMI for a total of six
video signals. The external preview signal can be output synchronously. The HDS9106 supports SDI
embedded audio + external analog audio. After mixing, it can be embedded in the output SDI signal or
output from the analog port. The resolution of all input signals is automatically adapted, and the output
signal resolution can be selected as required, which is quite flexible. For the video switching needs of
broadcast TV, outdoor sports events, school courseware production, etc., the functions of HDS9106 can
be fully satisfied.
1.Overview
1.1 Introduction

5
HDS9106
◆Portable integrated design
◆Advanced black metal body, high strength
◆Integrated control keyboard
◆Supports up to 4 SDI and 2 HDMI inputs
◆3.5mm analog audio input and output
◆1-channel lotus seat audio input and output
◆Support PIP/POPscreen windowing function
◆Audio support follow and mix assignment mode
◆PGM output: 2-CH SDI and 1-CH HDMI
◆Multiview output: 1 CH HDMI and 1 CH SDI
◆Support special effects switching such as MIX / FADE/WIPE
◆Support CUT hard support for AUTO effect switching
◆Transition rate adjustable
◆Support Tally / network remote control
◆Support 1 channel SDI output custom PGM/PVW
◆Built-in chassis temperature detection and fan intelligent
control system
◆Support software online upgrade
The DeviceWell HDS9106 6-channel HD video switcher is a multi-function switcher that requires no
special knowledge and can be used for video switching and audio mixing with simple operation. This unit
can be used in radio and television, live broadcast and various activities.
2. Functional characteristics

6
HDS9106
接口规格说明
2.1 Size：384*250*76.5mm
3.Interface Specification
3.1 Interface Introduction

7
HDS9106
NO.
Definition
Description
1
TALLY/RS232( reserved)
TALLY / serial port control (reserved)
2
LAN
Network upgrade
3
AUDIO IN/OUT
3.5mm audio input and output
4
AUDIO IN/ OUT
RCA audio input and output
5
HDMI OUT
PGM live output
6
MULTIVIEW OUT
HDMI and SDI multiview output
7
AUX
Auxiliary output, custom PGM/PVW
8
SDI OUT
PGM live output
9
SDI IN
4-CH SDI video source input
10
HDMI IN
2-CH HDMI video source input
11
DC 12V
Power input
12
Power
Power switch
13
AC 110-240V
Power input
3.2 TALLY Interface
PIN
Function
PIN
Function
11
PGM-IN1
6
PVW-IN1
12
PGM-IN2
7
PVW-IN2
13
PGM-IN3
8
PVW-IN3
14
PGM-IN4
9
PVW-IN4
15
PGM-IN5
10
PVW-IN5
3
PGM-IN6
4
PVW-IN6
5
GND
TALLY : Online schematic：
Note：Tally LED: for external display devices
Tally output : Active low (Tally LED is lit) High level is invalid
(Tally out is off)
Note：PIN1 PIN2 not used.

8
HDS9106
3.3Parameters
Name
6-CH Portable Switcher
Model
HDS9106(2022)
Video
Signal
Input
Input signal
SDI/HDMI video signal
Rate
270Mbps~3Gbps
Connector
Standard
Reflection loss
>15dB 5MHz~3GHz
Signal amplitude
800mV±10%(SDI/HDMI)
Impedance
100Ω (HDMI) 75 Ω(SDI)
Balance
Adaptive
DVD input
HDMI support
480i/576i,480p/576p,720p,1080i,1080p,
Computer HDMI
input support
1920x1080,1680x1050,1600x900,1440x1050,1366x768,
1360x768,1360x768,1280x1024,1280x960,1280x800,
1280x768,1280x720,1280x600,1152x864,1024x768,800x600
Video
Signal
Output
output signal
SDI/HDMI video output
Code rate
270Mbps~3Gbps
Connector
Standard
Return Loss
>15dB 5MHz~3GHz
Signal amplitude
800mV±10%(SD /HDMI)
impedance
100Ω (HDMI) 75 Ω(SDI )
DC offset
0V±0.5V
Clock recovery
Support
Control
Parameter
Serial
RS232( reserved)
Control
9600 baud, 8 bits, 1 stop bit, no parity
Connection
15-pin D-port, 2-RX, 3-TX, 5-GND
Network control
RJ45,100M
General
Parameter
power supply
12V/DC
Power rate
22w
control panel
Support on-site production, integration of
a variety of buttons.
Host weight
About 1.28KG
Operating temperature
0℃~50℃, No condensation
Storage temperature
-20℃~75℃
Working humidity
20%~70%RH
Storage humidity
0%~90%RH，No condensation

9
HDS9106
4
6
4.Control Panel and Interface
Before using the HD Mini Switcher , please take a few minutes to read this section. This chapter will
introduce you the panel and interface of the HD switcher to facilitate your subsequent use and operation.
The new high-strength characteristics of the new aluminum alloy with high-strength characteristics
improve the anti-drop, anti-shock and shock-proof capabilities of the whole machine, and effectively
protect the internal components of the equipment. Ultra-lightweight features make the unit easier to
transport and maintain without the need for additional equipment; it also offers unparalleled thermal
performance.
In addition to the innovation of the case, the HD switcher has also been completely optimized for the
interface connector. Environmentally friendly materials with new RoHS standards are More demanding in
terms of durability and environmental protection, to provide customers with more stable, more
environmentally friendly, more cost-effective products.
4.1 Control Panel
NO.
Name
Description
1
Audio Control
Mainly for Audio Follow and mix settings.
2
Transition Effect Control
Select transition effects
3
Integrated control area
PIP and POP effects
4
Knob Control
Use the knob to set menu information
5
Audio fader
Main control output volume
6
PVW& PGM Select
Live broadcast and preview selection
7
T-Bar
Manual control of transitions
4.1.1 Area Description
1
2
3
4
5
6
7

10
HDS9106
1. Press the AFV button on the operation panel. The button
will light green at this time. The corresponding multi-screen
menu will also display the current audio status. In the menu,
Audio Mode displays Follow, indicating that the audio is in
follow mode; as shown on the right.
Under the audio follow mode, CH1, CH2, CH1_VOL and
CH2_VOL in the menu will change to light gray, and the
option is unusable, as shown in the image to the right.
3. The volume adjustment of the audio follow mode is
controlled by the mixer of the operation panel; pressing
the AFV button of the following mode, the
corresponding CH1 light will also be lit, and the audio
fader is pushed up, the volume is higher. Big.
The position of the audio fader of CH1 is continuously
adjusted up and down, and the corresponding menu
portion can also display the current volume.
2. The channels of the audio follow mode are IN1-SDI1, IN2-SDI2, IN3-SDI3, IN4-SDI4,
IN5-HDMI5, IN6-HDMI6, and the corresponding operation panel buttons (the button panel 2
lights up at this time, indicating that Operate the IN2-SDI2 signal source as shown below.)
4.1.2 Key Description
4.1.2.1 Audio Control Area
How to use the audio follow mode:

11
HDS9106
The menu corresponding to the multi-screen will also display the
current audio status. In the menu, Audio Mode displays Mixing,
indicating that the audio is in the mix assignment mode; (the CH1
and CH2 options are available in the menu) as shown on the
right.
3.5mm Audio Interface
RCAAudio Interface
3. The audio channel adjustment of the mix assignment: through
the control panel knob MENU to adjust, corresponding to the
multi-screen menu to monitor the adjusted state
How to use the mix assignment:
1. Press the MIX button on the operation panel,the button will
light green at this time.
2. The channels assigned by the mix are IN1-SDI1, IN2-SDI2, IN3-SDI3, IN4-SDI4, IN5-HDMI5,
IN6-HDMI6, XLR_IN, RCA_IN. The mix assignment mode is followed by two additional audio
add-on functions. XLR stands for 3.5mm audio interface, RCAstands for RCA audio interface; PGM
live output can mix two channels of audio at the same time, the volume of two channels of audio can
also be adjusted separately.

12
HDS9106
The knob rotates clockwise once, and the background color
appears in the CH1 character in the menu, indicating that the first
channel audio is currently adjusted; press the knob to enter the
channel selection of the first channel audio IN1-SDI1, IN2-SDI2,
IN3-SDI3, IN4-SDI4, IN5-HDMI5, IN6-HDMI6, Phone_IN
(formerly device XLR_IN), RCA_IN, make sure to press the
knob to exit;
The CH2 audio channel is selected in the same way as the CH1.
The knob rotates clockwise once, and the background color
appears in the CH2 character in the menu. It indicates that the
second channel audio is currently adjusted. Press the knob to
enter the second channel and select IN1-SDI1. IN2-SDI2,
IN3-SDI3, IN4-SDI4, IN5-HDMI5, IN6-HDMI6, Phone_IN
(formerly device XLR_IN), RCA_IN, make sure to press the
knob to exit.
4. The volume adjustment of the audio mixing mode is also
controlled by the mixer of the operation panel; pressing the MIX
button of the mixing mode, the corresponding CH1 and CH2
lights will be illuminated. CH1 corresponds to the volume
adjustment of the first mix, and CH2 corresponds to the volume
adjustment of the second mix. The more the audio fader is
pushed up, the louder the volume.
Constantly adjust the position of the audio faders of CH1 and
CH2 up and down, and the corresponding menu section can also
display the current volume.

13
HDS9106
4.1.2.2 Transition Effect Control Area
There are 4 transition modes:
MIX transitions, FADE, and Wipes and INV mirror
transition
MIX Transition
The MIX effect is a transition effect. After setting the transition, the original live
screen will be lightened at the main output and then know that the transition to the new live
screen is complete.
Click on the effect control area (press the green light afterwards), and then click
CUT or use the T-bar or AUTO to switch. The effect is as follows.
FADE Transition
Click on the effect control area (press the green light afterwards), and then click
CUT or use the T-bar or AUTO to switch, under the effect diagram.
FADE in and out, and A gradually darkens until it is completely black,
and then gradually changes from black to B.
MIX transition effect, superimposed and superimposed B picture in A
picture until the transition to the end, the picture is completely replaced
with B picture

14
HDS9106
WIPE Transitions
There are 4 types of wipe transition modes
Up transition: Click on the effect control area (press the green light afterwards),
Click on the effect control area (press the green light after pressing),and then click
CUT or use the T-bar or AUTO to switch. The effect is as follows.
Downward transition effect, the Apicture is unchanged, and the B picture is
gradually drawn in the downward direction until the picture
completely becomes B.
INV Transitions
The INV mirror transition is opposite to the original WIPE transition direction. When the
WIPE and INV in the button panel are pressed, and then the direction of the upward
transition is pressed , the screen that appears will be the downward transition
, and the effect diagram is as follows.
Transition rate adjustment
When operating the transition effect control area, you can control the transition rate by
operating RATE1, RATE2, RATE3 in the button panel.Note: Only when using AUTO
transition is effective.
Up transition effect, the Apicture is unchanged, and the B picture is
gradually drawn in the upward direction until the picture completely
becomes B.

15
HDS9106
4.1.2.3 Integrated Control Area
PIP Effect
Picture-in-picture effects: Press the control panel (press the green light
afterwards), and then click CUT or use the T-Bar or AUTO to switch. The effect is as
follows.
At this time, the information on the LCD
screen will be switched to the PIP setting.
After pressing the knob, it can be set
according to the requirements, as shown
below.
You can use the knob to set the parameters of the PIP picture-in-picture, as follows (the
horizontal/vertical position below is the smallest display image)
Horizontal position setting: The value from the top left to the top right is 0-1440, and the value of one
rotation per knob is increased/decreased by 10.
Vertical position setting: The value from the top left to the bottom left is 0-810, and the value of one
rotation per knob is increased/decreased by 10.
Display size setting: Small/medium/large settings can be selected.
Border switch setting: You can select the on/off setting.
Border width setting: The border width can be selected from 2-7 thickness borders, and the value of
each rotation knob is increased/decreased by 1.
Border color setting: You can choose white/red/green/green to set the bordercolor.
PIP size and position

16
HDS9106
POP Effect
Picture-out-Picture effects: Press the control panel (press the green light), then
click CUT or use the T-Bar or AUTO to switch. The effect is as follows.
At this time, the information of the multi-screen monitor output will be switched to the
POP picture-out-picture setting. After pressing the knob, it can be set according to the
requirements, as shown below.
At this time, the information on the LCD screen
will be switched to the POP picture drawing
setting. After pressing the knob, it can be set
according to the requirements, as shown below.
You can use the knob to set the parameters of the POP, as follows
Screen selection setting: You can select 1/2 two screens.
Horizontal position setting: The value from the top left to the top right is 0-960, and the value
of each rotation knob is increased/decreased by 10.
Vertical position setting: The value from the top left to the bottom left is 0-540, and the value
of one rotation per knob is increased/decreased by 10.
Border switch setting: You can select the on/off setting.
Border width setting: The border width can be selected from 2-7 thickness borders, and the
value of each rotation knob is increased/decreased by 1.
Border color setting: You can choose white/red/green/green to set the bordercolor.
POP size and position
STILLscreen freeze effects
The STILL button is defined as the screen freeze function. Press the button to turn on the green light to turn
on the screen freeze function, press the button to turn off the green light, and the screen freeze function to turn
off;
FTB emergency black field
The FTB button is defined as the emergency black field screen output, press the button and the green light
flashes to turn on the FTB emergency black field output function, press the button to turn off the green light, and
the FTB emergency black field function is off；

17
HDS9106
4.1.2.4 PGM & PVW Selection
Multiview output window introduction
PVW and PGM are the preview and live output respectively, as shown below.
PVW
PGM
There are 6 windows below which correspond to input source monitoring, corresponding
to buttons 1 –6 on the control panel of the switcher.

18
HDS9106
PGM &PVW Output Signal
After the device is connected to the video source, press 1 (PGM) and 2 (PVW) in the button
panel. The live and preview signals in the output multi-screen monitor are 1 (PGM) and 2
(PVW) respectively. The signal sources are SDI IN1 and SDI IN2, respectively.
The effect chart is as follows
PGM &PVW Source Switching
If you want to switch between PGM and PVW source in Multiview
Suppose you want to convert live signal source 1 (PGM) and preview source 2 (PVW) into
2 (PGM) and 1 (PVW) in multiple pictures, just press 2 (PGM) and 1 in the button panel
( PVW), then use the T-bar to switch. The live PGM signal source 1-6 can be arbitrarily
switched with the preview PVW signal source.
The effect chart is as follows:

19
HDS9106
5. System menu settings
In the menu bar, you can perform IPsettings on the device, restore the system to factory
settings, and change the language.
In the default state of power on, press the knob to enter the main menu, as shown below.
Menu display
The color bar willbe output when the button in the button panel is pressed.

20
HDS9106
Press the knob
In the system setting menu, you can choose between language selections: Chinese or English.
In the time display: select analog or digital display always; if you encounter an unknown error
during use, you can choose to restore the factory. Set to reset.
IP Setting
In the network settings menu, you can select in the IP acquisition: dynamic IP or static IP. After
selecting the static IP, you can also set the IP address, subnet mask, and network management
settings accordingly, and then save and return.
Device Info
Press the knob
Press the knob
Press the knob
