DeviceWell UHS6610 User manual

Users’ Manual
VER 1.0
4K UHD Switcher

2
SWITCHER
●To avoid serious damage caused by possible electric shock, before moving the product, please temporarily
remove the power cord from the power port of the product.
●When you need to add new hardware to the product or remove existing hardware from the product, be sure to
power off the product first. If conditions permit, it is recommended to temporarily remove the power cord from the
product interface.
●Before use, confirm whether the product is grounded and whether the power supply voltage has been adjusted
to the applicable range of the product. Failure to do so may result in damage to the product, reduced performance, or
unpredictable results.
●Do not use loose or damaged power sockets or touch the power sockets with wet hands, otherwise there is a risk
of electric shock and fire.
●If you hear noises from the power cord and the power interface, please unplug the power cord immediately and
seek help from your sales representative, otherwise there willbe a risk of fire or electric shock.
●If foreign objects or liquids enter the product or need to clean the product, please remove the power cord and
any other cables from the product, otherwise there will be danger of electric shock, fire and damage to the product.
●If the power supply is damaged, please do not try to repair it yourself. Please contact professional technical
service personnel or distributors to deal with it.
Electrical Safety Features
Precautions
Failure to observe these precautions could result in personal
injury or death, possibly resulting in damage to equipment, loss of
data, reduced equipment performance, or unpredictable results。
Due to the continuous update of product functions, the user manual in your hand may be different from the
actual application. Please download the latest user manual from the Devicewell official website. The update date
of this user manual is March 31, 2023.
Note: Different models correspond to different product functions. Please match the parameters of the purchased
model according to the model comparison table in the user manual according to the model you purchased. This
manual takes the functional parameters of UHS9610R as an example to explain.
There are technical changes in the future without notice.

3
SWITCHER
目录
Precautions…………………………………………………………………2
1. Overview……………………………………………………………...6
1.1 Product Introduction............................................................. 6
2. Function Features……………………………………………………..7
2.1 Size：384*252*92mm ....................................................... 10
3. Interfaces…………………………………………………………….10
3.1 Interface Introduction ......................................................... 10
3.2 Parameters ..........................................................................12
4. Control Panel & Interfaces…………………………………………..13
4.1 Control Panel...................................................................... 13
4.2 Area Description ................................................................. 14
Button Description.............................................................. 144.2.1.
Audio Mixer.................................................................... 144.2.1.1.
Knob and Key Menu....................................................... 154.2.1.2.
Camera Control............................................................... 164.2.1.3.
Camera Lens Control .................................................... 174.2.1.4.
Transition Control ........................................................... 174.2.1.5.
PGM & PVW....................................................................174.2.1.6.
Integrated Control Area................................................... 174.2.1.7.
T-Bar...............................................................................194.2.1.8.
5. Button Operation Instructions……………………………………….19

4
SWITCHER
5.1 Multiview Output Window Introduction............................. 19
5.2 PGM&PVW Switching....................................................... 20
5.3.1. T-bar Calibration ................................................................ 20
5.3.2. PGM and PVW Channel Selection by Panel....................... 22
5.3.3. Transition control................................................................ 23
5.3.4. PGM Output Black Field.................................................... 24
5.3 Audio Settings .................................................................... 24
Audio Introduction.............................................................. 245.4.1.
Audio description of mixer control area.............................. 255.4.2.
5.4.2.1. Audio Introduction................................................ 25
5.4.2.2. Audio Follow........................................................ 25
5.4.2.3. Audio Embedding ................................................. 25
5.4.2.4. Mixing mode......................................................... 25
5.4.2.5. Audio Source Switching........................................ 26
Audio usage analysis .......................................................... 265.4.3.
5.4.3.1. Audio mode switching........................................... 26
5.4.3.2. How to use the audio follow mode ........................ 27
5.4.3.3. Function analysis of the mixer................................ 27
5.4.3.4. How to use the mix assignment ............................. 28
5.4 Special effects instructions ................................................. 30
5.5.1. MIX Transition Effects....................................................... 30
5.5.2. FADE In and Out Transition Effects................................... 30

5
SWITCHER
5.5.3. WIPE Transition Effects..................................................... 31
5.5.4. INV mirror transition effects...............................................31
5.5.5. PIP Picture-In-Picture Special Effects ................................ 32
5.5.6. POP Picture-Out-Picture Special Effect.............................. 33
5.5.7. Luma KEY.......................................................................... 35
5.5.8. Chroma KEY......................................................................36
5.5 System Menu Settings ........................................................ 37
5.6.1. Menu Display ..................................................................... 37
5.6.2. System Settings................................................................... 37
5.6.3. Network Settings ................................................................ 38
5.6.4. GPI Settings........................................................................38
5.6.6. Device Info. ........................................................................ 39
6. Failure and Maintenance…………………………………………….40
6.1 Common Faults and Solutions............................................ 40
6.2 Maintenance........................................................................ 40
6.2.1. Warranty information ......................................................... 40

6
SWITCHER
1. Overview
1.1 Product Introduction
Devicewell 4K UHD switcher UHS9610R/UHS9610/UHS9508R/UHS9508 integrates a variety of control
methods, comes with a 15.6-inch HD monitor screen, can setspecial effects and transition methods through the
keyboard, and the knob can control the LCD display The LCD screen will display various states of the current
device in real time, the built-in menu display function can set the device more intuitively and efficiently, and
the camera joystick can control the distance and distance of the camera.
A dedicated director switcher for Broadcast&TV supports up to 10channels of 4K60 signals. The device
integrates SDI decoder, HDMI decoder, DP decoder, the highest resolution supports 4K60HZ, backward
compatible with 3G SDI and other 1080P/720P high-definition video signals, built-in format converter,
adaptive front-end different video signal input. Built-in special effects generator, audio processor and video
streaming media processing and other common switcher components.
The video signal interface supports 2-CH SDI + 4-CH HDMI + 4-CH DP, a totalof 10-CH video input,
2–CH SDI output + 4-CH HDMI output + LCD display + recording, a total of 7-CH video signal output.
Audio signal interface supports 2-way microphone input, 1-way LINE input, a total of 3-way audio input,
1-way Line output
Support DCB control system and tally output.
Optional H.26x encoding module, video stream can be output through UVC and RTMP network stream,
and can also be recorded to internal EMMC, external SSD or TF card.
It adopts high-strength aluminum alloy shell and comes with a 15.6-inch display screen, which is easy to
carry. It can be applied to the needs of special effects switching in radio and television studios and on-location
video. For professional users, the control keyboard can be extended through the DCB interface.
It is suitable for live performances, course recording and in-studio broadcasting. TF card recording, RJ45
streaming, RS422 control, etc., with remote upgrade capability. Users can perform video switching and audio
mixing functions with additional effects with simple operation.

7
SWITCHER
2. Function Features
DeviceWell switcher UHS9610R is a directing system with up to 6 cameras. It is suitable for many event
projects. With the development of the times, especially in remote live broadcast of sports games, large-scale
concerts or evening parties Especially in the event. If you want to use super multi-camera live directing
operations in large-scale events, you must reach more than 6 sets of inputs on the directing system, so as to be
able to present the wonderful program content to the audience from time to time, and there are so many live
broadcast pictures and special effect transition. It can meet the needs of live production in various occasions
and create exciting and wonderful pictures.
The UHS9610R switcher is super multi-camera directing equipment that requires no professional
knowledge, and can perform video switching and audio mixing with simple operations. This unit can be used
in broadcasting, live broadcasting and various event venues.
◆Portable all-in-one body design
◆Metal aluminum alloy material,
high strength and light weight
◆15.6-inch LCD screen
◆Industrial-grade mechanical keys
◆Hall sensor T-Bar
◆Support RJ45 remote control
◆DCB2 control + video expansion
◆Broadcast&TV standard tally interface
◆Support GPI control
◆Support joystick, camera control
◆Foot pedal, control handle , etc. input
◆3840x2160p60/50/30/25/24, H.264 encoding
◆Support CBR fixed bit rate mode
◆Support High profile encoding
◆Recording file format MP4, support EDIUS
non-editing software
◆Storage device interface supports USB3.0 and
SATA hard disk recording
◆Support screen freeze function
◆Audio follow, mix function
◆Support SDI audio de-embedding
◆4HDMI+4DP+2SDI input
◆MULTIVIEW output: 2 HDMI
◆PGM output: 3-CH HDMI+2-CH SDI
◆2-CH MIC input
◆1 LINE IN input
◆1 LINE OUT output
◆Support 4K HDR
◆Support HDMI audio de-embedding
◆Thedevice comes with color bar output screen
◆PIP & POP function
◆Support MIX/FADE/WIPE/INV transition effects;
◆CUT hard cutting, AUTO automatic switching and FTB
black field emergency switching
◆1 set of KEY, support Luma key, Chroma key
◆Support RS422 interface to control camera
◆Support PC software remote upgrade
◆Support 220V or DC12V dual power redundant input
◆Configured LCD panel, which can be controlled by knob,
◆It is convenient to set and real-time various parameters of the equipment
◆Display the working status of the device

8
SWITCHER
2.1 UHS Series 4K Switcher Function Comparison
4K Switcher Comparison Table
Model
Tyoe
Specifications and Parameters
Video signal input
Video signal output
Max
Resolution
Channel
(not real-time)
Channel
(real time)
SDI
HDMI
DP
PGM
PVW
LCD
UHS6610
OEM
4K@60HZ
10
6
2
4
4
H*2+S*2
H*2
UHS6508
OEM
4K@60HZ
8
6
4
2
2
H*2+S*2
H*2
UHS6512
OEM
4K@60HZ
12
6
0
6
6
H*2+S*2
H*2
UHS6106
OEM
4K@60HZ
6
6
6
0
0
H*2+S*2
H*2
UHS6108
OEM
4K@60HZ
8
8
8
0
0
H*2+S*2
H*2
UHS6610R
OEM
4K@60HZ
10
6
2
4
4
H*2+S*2
H*2
UHS6508R
OEM
4K@60HZ
8
6
4
2
2
H*2+S*2
H*2
UHS6512R
OEM
4K@60HZ
12
6
0
6
6
H*2+S*2
H*2
UHS6106R
OEM
4K@60HZ
6
6
6
0
0
H*2+S*2
H*2
UHS6108R
OEM
4K@60HZ
8
8
8
0
0
H*2+S*2
H*2
UHS9610
DeviceWell
4K@60HZ
10
6
2
4
4
H*2+S*2
H*2
15.6"
UHS9508
DeviceWell
4K@60HZ
8
6
4
2
2
H*2+S*2
H*2
15.6"
UHS9512
OEM
4K@60HZ
12
6
0
6
6
H*2+S*2
H*2
15.6"
UHS9106
OEM
4K@60HZ
6
6
6
0
0
H*2+S*2
H*2
15.6"
UHS9108
OEM
4K@60HZ
8
8
8
0
0
H*2+S*2
H*2
15.6"
UHS9610R
OEM
4K@60HZ
10
6
2
4
4
H*3+S*2
H*2
15.6"
UHS9508R
OEM
4K@60HZ
8
6
4
2
2
H*3+S*2
H*2
15.6"
UHS9512R
OEM
4K@60HZ
12
6
0
6
6
H*2+S*2
H*2
15.6"
UHS9106R
OEM
4K@60HZ
6
6
6
0
0
H*2+S*2
H*2
15.6"
UHS9108R
OEM
4K@60HZ
8
8
8
0
0
H*2+S*2
H*2
15.6"

9
SWITCHER
Model
Stream & Record
Control
Others
RTMP
stream
UVC
stream
Record
Playback
Tally
GPI
Remote
Extension
Style
Key
T-Bar
UHS6610
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6508
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6512
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6106
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6108
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6610R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6508R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6512R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6106R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS6108R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
desktop
Mechanical
Hall
UHS9610
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9508
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9512
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9106
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9108
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9610R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9508R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9512R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9106R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall
UHS9108R
TBD
TBD
Y
Y
Y
Y
RJ45
DCB
Portable
Flip
Mechanical
Hall

10
SWITCHER
2.1 Size：384*252*92mm
Interfaces
3.1 Interface Introduction
DeviceWell UHS9610R/UHS9508R interface is as shown below.

11
SWITCHER
NO.
Definition
Description
NO.
Definition
Description
1
HDMI OUT
4K Player
11
HDMI OUT
2HDMI PGM OUT
2
USB
External storage device
12
LINE IN/OUT
3.5mm Stereo audio in/out
3
STREAM OUT
Network Stream（reserved）
13
MIC IN
2-ch microphone input
4
USB
Mouse/keyboard
14
RJ45
Network upgrade
5
AC 220V
AC 220V power input
15
DC 12V
DC 12V power input
6
HDMI IN
4-CH HDMI input
16
RS422
PTZ control
7
DP IN
4-CH DP input
17
GPI
GPI control
8
SDI IN
2-CH SDI input
18
DCB
DCB interface, supporting
cascade equipment, supporting
TALLY light module (reserved)
9
SDI OUT
2SDI PGM OUT
10
HDMI OUT
MultiView OUT
19
Tally
wirel ess TALLY s ys tem（DB-15）
20
EXT HDD
HDD/SDD/4K Recoder
UHS9508R
NO.
Definition
Description
NO.
Definition
Description
1
HDMI OUT
4K Player
11
HDMI OUT
2HDMI PGM OUT
2
USB
External storage device
12
LINE IN/OUT
3.5mm Stereo audio in/out
3
STREAM OUT
Network Stream（reserved）
13
MIC IN
2-ch microphone input
4
USB
Mouse/keyboard
14
RJ45
Network upgrade
5
AC 220V
AC 220V power input
15
DC 12V
DC 12V power input
6
HDMI IN
2-CH HDMI input
16
RS422
PTZ control
7
DP IN
2-CH DP input
17
GPI
GPI control
8
SDI IN
4-CH SDI input
18
DCB
DCB interface, supporting
cascade equipment, supporting
TALLY light module (reserved)
9
SDI OUT
2SDI PGM OUT
10
HDMI OUT
MultiView OUT
19
Tally
wirel ess TALLY s ystem（DB-15）
20
EXT HDD
HDD/SDD/4K Recoder

12
SWITCHER
3.2 Parameters
Name
4K UHD Switcher
Model
UHS9610R/UHS9508R/UHS9610/UHS9508
Video
Signal
Input
Input signal
HDMI/DP/SDI video signal
Code rate
270Mbps~12Gbps
Connector
Standard
Signal amplitude
800mV±10%( HDMI/SDI/DP)
Impedance
100Ω(HDMI) 100Ω(DP) 75Ω(SDI)
Balance
Adaptive
DVD input
HDMI support
480i/576i,480p/576p,720p,1080i,1080p,2160p
HDMI/DP
input support
3840x2160,1920x1080,1680x1050,1600x900,1440x1050,1366x768,1360x768,1280x1024,
1280x960,1280x800,1280x768,1280x720,1280x600,1152x864,1024x768,800x600
Video
Signal
Output
output signal
HDMI/SDI video signal
Code rate
6Gbps ~12Gbps
Connector
Standard
Return Loss
>15dB 5MHz~3GHz
Signal amplitude
800mV±10%( HDMI/SDI/DP)
Impedance
100Ω(HDMI) 100Ω(DP) 75Ω(SDI)
DC offset
0V±0.5V
Clock recovery
Support
General
Parameter
power supply
12V/DC 220V/AC
Power rate
50W
Size
384*252*92mm
Control Panel
Support on-site production, integration of a variety of buttons.
Operating
temperature
0℃~50℃, No condensation
Storage temperature
-20℃~75℃
Working humidity
20%~70%RH
Storage humidity
0%~90%RH，No condensation

13
SWITCHER
4. Control Panel & Interfaces
Please take a few minutes to read this chapter before using DeviceWell HD switcher equipment. This
chapter will give you a detailed introduction to the panels and interfaces of the DeviceWell HD switcher, so as
to facilitate your subsequent use and operation.
The high-strength feature of DeviceWell HD switcher equipment improves the anti-drop, pressure and
shock resistance of the whole machine, and effectively protects the components inside the equipment. The
ultra-thin and light characteristics make the equipment more convenient during transportation and maintenance
without the need for other equipment; at the same time, it also has unparalleled heat dissipation performance.
In addition to the innovation of the shell, the DeviceWell HD switcher has also made a new optimization of
the interface connector. Using the new RoHS standard environmental protection materials, the requirements for
durability and environmental protection are more stringent, providing customers with more stable,
cost-effective and more environmentally friendly products.
4.1 Control Panel
Audio Mixer
Transition Control
Menu Setting Information
Camera Control
Camera Lens Control
Overlay Effect
Control
Manually Control
Transitions
PGM & PVW Selection

14
SWITCHER
4.2 Area Description
Button Description4.2.1.
Audio Mixer4.2.1.1.
Audio channel control:
IN PUT1/IN PUT2/IN PUT3 means that 3 kinds of input audio can be controlled,
MASTER:Adjusts the output master volume.
Audio Source switch:
Where SRC is the audio channel binding selection, press SRC1/SRC2/SRC3
Cycle through and select the desired audio channel.
Audio Mode:
When the button light is on, it means that the audio is currently in follow mode, and when the button light
is off, it means that the audio is currently in mixing mode.
NO.
Name
Description
1
Mixer
Mainly for audio follow, embedded and mix settings
2
Knob control area
Use the knob to display menu information and various states of the switcher system
3
Camera control area
Switch 1-6 camera
4
Camera lens control area
Control camera distance
5
Transition effect control area
Select transition effects
6
PGM & PVW
Live broadcast and preview selection
7
Integrated control area
Mainly to control the switcher overlay effects
8
T-bar
Manual control of transitions
AFV
MIX

15
SWITCHER
Knob and Key Menu4.2.1.2.
UHS9610R can be set by knob
2. Rotate counterclockwise to the up to decrease value.
3. Press to select.
1. Rotate clockwise to down to increase the value.
Press the key to start recording
Press the key to pause recording
Press the key to start streaming
Turn the SSD device on or off
Press the key to play start/pause
View the direction key of the recorded file
View the recorded file under the direction key
Turn USB device on or off
On the recording file page, double-click the file to play and select the file to delete
directly during mouse operation; If you can play/pause with the key operation, select
the file with the direction key, and press the EXIT key to return to the previous level.
In the recording interface, USB/SSD device can be selected for recording. Select with the
mouse, click SSD, and the background color of the icon changes to white, that is, the
selected state.

16
SWITCHER
Camera Control4.2.1.3.
The UHS9610R switcher supports 6-channel camera control, and the distance and distance of
the 6-channel cameras can be controlled through the joystick. When the CAMCTRL key is on,
press any key from 1 to 6 again, and after the number key is on, you can control the
corresponding camera.
Press to select camera 1
Press to select camera 2
Press to select camera 3
Press to select camera 5
Press to select camera 6
Press to select camera 4
Press STLLY on the control panel (the green light will be displayed after pressing it), then the
output PGM video animation will enter the freezing phenomenon, press the button again to
unfreeze the picture
Mic
Mic Volume 32dB
Mic Type Passive
Exit
CAM
Address 1
Baud 9600
Protocol PELCOD
Rotation Rate 16
Exit
After pressing the button, the setting menu of the MIC willpop up, and the volume and type of the
MIC can beselected by the knob.
Press the color bar key, when the light is on, the corresponding PVM window and PGM
window will generate an internal color bar signal.
When the CAMCTRL key is off, the number keys 3, 4, 5, and 6 correspond to the 3, 4, 5, and 6
windows in the multi-screen window. These 4 buttons correspond to the channels of these 4
windows, because these 4 windows are multiplexed windows, which can display the pictures input
by HDMI and DP channels. Each time these 4 numeric keys are pressed, the corresponding window
will switch the screen.

17
SWITCHER
Camera Lens Control4.2.1.4.
Push the camera rocker up: the lens is up
Push the camera rocker down: the lens is down
Push the camera rocker left: rotate the lens counterclockwise
Push the camera rocker right: rotate the lens clockwise
Transition Control4.2.1.5.
PGM & PVW4.2.1.6.
Mainly choose PGM (live) and PVM (preview)
The output channel, red means PGM Live, green means preview.
Integrated Control Area4.2.1.7.
There are three transition modes:
MIX, WIPE, FADE
INV key are mirrored transitions.
Before using the INV mirror button, press the arrow button and then press the INV mirror button. The
wipe direction is opposite to the direction of the arrow.
Luma key, press button to deduct the black and background source overlay.
Zoom in/increase the shooting distance
Zoom out/ reduced shooting distance

18
SWITCHER
Transition rate selection: RATE1, RATE2, RATE3 can be customized through the menu
(Note: only when using AUTO transition)
The rotation rates are:
rate1：640ms
rate2：1280ms
rate3：2560ms
Chroma key, press the button to deduct the specified color and overlay it with
the background source.
POP special effects button, open picture-out-picture
function
PIP special effects button, open picture-in-picture
function
Level adjustment of the KEY, long press can quickly increase the level
Level adjustment of the KEY, long press can quickly decrease the level

19
SWITCHER
T-Bar4.2.1.8.
5. Button Operation Instructions
5.1Multiview Output Window Introduction
The switcher T-Bar system consists of a pusher module and an indicator light. Pushing the
T-bar up can complete the transition.
When the T-bar is pushed, the indicator light will follow the movement to the top 1 (the
pusher pushes to the bottom and the top is a light).
Auto transition, with transition effects.
Hard cuts, no transition effects.
Black field, flashing after clicking, indicates that the main output
is outputting a black field.

20
SWITCHER
Preview and Program are PVW and PGM output respectively; as shown below:
There are 6 windows below that correspond to the input source monitoring, corresponding to the 1 - 6 buttons
on the control panel.
5.2 PGM&PVW Switching
5.3.1. T-bar Calibration
When the switcher is in use, the fader misalignment may occur, and the origin of the switcher fader is
offset. Therefore, the switcher pushrod system should be calibrated before use.
First press the 1 and 2 buttons in the PGM area simultaneously with the device turned off. As shown
below:
Note: The 1 and 2 keys cannot be released during the calibration process.
Turn on the power switch again, and the indicator light next to the push rod will light up in sequence after
the power is turned on, as shown below.
Preview
Program
