DeView D410-THRE3V12L User manual

COLOUR VANDAL PROOF CAMERA
D410-THRE3V12L / D410-THRN3V12L
D410-THRE3V12LHTR / D410-THRN3V12LHTR
Dimensions : mm
INSTRUCTION MANUAL
■Do not open or modify
Do not open the cabinet exit during maintenance and
installation, as it may be dangerous and cause damages.
■Do not put objects inside the unit
Make sure that no metal objects or flammable substances
get insdie the camera. It could cause fire, short-circuits or
damages.
■Be careful when handling the unit
To prevent damage, do not drop the camera or subject
it to strong shock or vibration.
■Install away from electric or magnetic fields
■Protect from humidity and dust
■Protect from high temperature
Be careful when installing close to the ceiling , in a kitchen
or boiler room, as the temperature may raise to high levels.
■Cleaning
Dirt can be removed from the cabinet only by wiping it
with a soft cloth moistened with a soft detergent solution.
■Mounting Surface
The mounting surface material must be strong enough to
secure the camera.
■Ingress Protection
Ensure all cable entry points are sealed with silicone sealent
ii
About this Manual
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for later reference.
PRECAUTIONS
■CONNECTIONS
to prevent moisture ingress.
TROUBLESHOOTING
Before sending the camera out for repair, check the items
below. If the problem persists after checking these items,
contact your service center.
■If no image appears
Is the coaxial cable attached securely?
Are the power and voltage normal?
Has the iris of the lens inside the camera been
adjusted correctly (with the level volume) ?
Is there adequate illumination?
■If the image is unclear
Is the lens in focus?
Is the lens dirty?
Dirt of fingerprints on the lens can adversely affect the
images. Gently wipe any dirt or fingerprints off the lens
with a soft cloth or lens cleaning paper and cleaning
fluid (commercially available).
Is the monitor adjusted correctly?
WARNING:
TO PREVENT THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE. ENSURE ALL CABLE
ENTRY POINTS ARE SEALED
TO PREVENT
CAUTION :
Check for polarity when using a DC 12V or AC 24V power supply.
CONNECTOR AND CAMERA SETTING
DC12V / AC24V
DC12V / AC24V
ENTRY
POINTS
ARE
SEALED
TO
PREVENT
MOISTURE INGRESS

■LENS ADJUSTMENTS
Rotation 360˚
■CAMERA SETTINGS
●OSD SWITCH FUNCTION
Rotation 360˚Tilt 70˚
1. Adjust the panning(360˚), rotation (360°) and tilt(70˚)
position.
2. Set the zoom position using the Zoom Lever Screw.
3. Set the focus using the Focus Lever Screw.
CONNECTIONS AND CAMERA SETTINGS
Focus
Zoom
Loosen grub screw for rotation of camera
module using the small allen key
SETUP
FUNTION
SUMMARY
OSD
SETUP
FUNTION
SUMMARY
when using BUILT-IN lens, selecting
MANUAL will allow the aperture to be fixed
SHUTTER ESC, MANUAL, FLK, OFF MANUAL: 1/60(50) ~ 1/120,000sec, x2~ x128
WHITE BAL. ATW, MANUAL, AWC ATW: 1,800 ~10,500 ˚K
BACKLIGHT OFF, LOW, MIDDLE, HIGH Backlight compensation
AGC NORMAL, HIGH,OFF the Brightness can be adjusted(1 ~ 70)
DNR MIDDLE, HIGH, OFF, LOW when AGC is turned off, DNR does not operate.
SENS-UP AUTO(=X6), OFF when AGC is turned off, SENS-UP does not
operate.
SPECIAL Refer to the section below
EXIT Save the settings then exit
SPECIAL FUNTION SUMMARY
OFF, uppercase or lowercase, maximum length for the name
/numeral 0~9/-, null display is limited 15 characters
AUTO :
daytime →colour mode ,
night-time→B/W mode
B/W : Always in B/W mode
COLOUR: Always colour mode
EXTERN : CDS EXTERNAL SIGNAL INPUT
SYNC INT, LL (n/a for 12VDC model) LL mode: you can adjust desired phase from 0˚
~ 359˚, auto detection
MOTION DETECTION OFF, ON ON mode: AREA (4 programmable zones
/SIZE), the words 'MOTION DETECTED"
appear on the screen when movement is
dt td
PRIVACY OFF, ON ON mode:AREA(4x programmable zones)
/SIZE/TONE
MIRROR OFF, ON set a horizontal image inversion.
CAMERA ID
DAY NIGHT AUTO, B/W, EXTERN, COLOR
LENS DC(=25), MANUAL
SHARPNESS OFF, ON(=8) the available range of level is 0 ~ 31.
RESET Reset all settings to factory defaults
RETURN save the SPECIAL MENU and then return to the
SETUP MENU

SPECIFICATION
MODEL
General Spec NTSC PAL
CCD Type 1/3" 410K Pixels Color 1/3" 470k Pixels Color
Total number of pixels 811(H) X 508 (V) 795(H) X 596(V)
Min illumination
Video Output
Resolution
S/N Ratio
Shutter speed x128 : 1/60~1/120,000sec x128 : 1/50~1/120,000sec
Sync System
White Balance
OSD Built-in
DAY / NIGHT AUTO / B/W / COLOR
DNR LOW, MIDDLE, HIGHT,OFF
Power Input
Video Output
Voltage
Power Consumption
Lens
Dimension
Weight
Case Color
Operation temp -10Ԩ׽ +55 Ԩ
900g
Ivory
Max [DC12V : 5.7 W, AC24V : 5.3 W, with Heater DC12V : 18W, AC24V :
12W]
Mechanical Spec
3.3~12.0 mm
140(ø) X 105(H)mm
Wire
BNC Cable
Electric Spec
DC 12V(10 - 20V) or AC24V(20 - 28V)
50dB (AGC off, weight ON)
Internal / External
ATW/AWC/MANUAL (1800 ˚K ~ 10,500 ˚K)
Connector
D410-THRN3V12L (+HTR) / D410-THRE3V12L (+HTR)
0.3 Lux/F1.2(50 IRE, AGC HIGH, DNR HIGH)
1.0Vp-p/75 ohm Composite
520 TV Lines(Min)
Models e
q
ui
pp
ed with heater: -40°C ~ +55°C
INSTALLATION
1. Use the supplied L-wrench to remove the four fixing
screws (B) of dome cover (A).
2. Align the camera unit with the surface of the ceiling,
make marks on the ceiling in the places where the screw
holes are to be drilled, and then drill the four holes.
3. Cut a hole (diameter2.9in.73mm) in the ceiling for routing
the cables.
4. Pass the power cable (E) and video cable (F) from the
camera unit through the cable hole in the ceiling.
5. Align the four screw holes in the camera unit (D) with
the screw holes in the ceiling, and then secure the
camera in place by tightening the four or more screws
(C) through the washers. Remember to use the base
gasket.
6. Carry out the settings and adjustments for the camera.
7. Ensure all cable entry points (rear or side) are sealed
with silicone sealent to prevent moisture ingress.
Failure to observe this may result in condensation
deposits that will reduce the IR response of the camera
In storage temp
Operation humidity
-20Ԩ׽ +70 Ԩ
Under 90％(Non-condensing)
qpp
A
D
C
E F
deposits
that
will
reduce
the
IR
response
of
the
camera
.
8. Secure the dome cover (A) by tightening the screws (B).
B
