devinci DJANGO CARBON 2021+ User manual

LEGEND
Sheath outside the frame
Sheath inside the frame
Seatpost housing
Speed housing
Brake housing
CABLE ROUTING
DJANGO CARBON 2021+
Step 1 | Thread the brake housing from back to front in the chainstay straw.
Step 2 | Clip the brake hose in the middle of the pivot.
Step 3 | Thread the brake housing in the left opening of the shock plates
cable organiser/spacer.
Step 4 | Thread the brake housing in the cable guide and the down tube’s
opening.
Step 5 | Remove the guide’s cap on the left side of the down tube and
sh out the housing through the upper opening.
Step 6 | Slide the anti-impact foam tube over the housing.
BRAKE HOUSING
Step 1 | Thread the shifter housing from back to front in the chainstay
straw.
Step 2 | Fix the housing under the chainstay and zip tie it in place.
Step 3 | Thread the housing in the right side opening of the shock
plates cable organiser/spacer.
Step 4 | Thread the housing in the cable guide and the down tube’s
opening.
Step 5 | Remove the guide’s cap on the left side of the down tube and
fish out the housing through the upper opening.
Step 6 | Slide the anti-impact foam tube over the housing. Put back
the guide cap.
SPEED HOUSING
Step 1 | Thread the dropper housing through the guide on the right side
of the down tube.
Step 2 | Bring out the dropper housing through the bottom bracket.
Slide the anti-impact foam tube over the housing.
Step 3 | Create a loop with the housing in order to reinsert the housing
through the seat tube. Pull out the dropper cable at the end of the tube.
SEATPOST SHEATH
Step 1
Step 2
Step 5 & 6 | Step 5 & 6
Step 2, 3 & 4 | Step 3 & 4
Step 2 &3
Step 1 Step 1

DO PIVOT
(22 N∙m)
REAR AXLE
(20 N∙m)
6.7 N∙m
1
1
COLLAR
6 N∙m
BL PIVOT
(14 N∙m)
UPPER SHOCK BOLT
(14 N∙m)
1
1
3
WL PIVOT
(14 N∙m)
4
CL PIVOT
(14 N∙m)
LOWER SHOCK BOLT
(14 N∙m)
8
8
8
8
8
87 4
74
4
5
5
5
8
7
4
47
5
4
7
4 4
7 4
6
2
