Blazer 9000 Lube Lift
Operator’s Manual
Note: Instructions must be read thoroughly before installing, operating, or maintaining the lift.
BLAZER 9000 LUBE LIFT
OPERATOR AND PARTS MANUAL
Devon Industries
800-468-1970 Fax: [phone]
01-01-2021

2
Safety Instructions
1. Always work on the vehicle with the lift on the safety locks.
2. Never allow unauthorized or non-trained personnel to operate lift. Thoroughly train new employees
in the use, care and safe operation of the lift.
3. Always lift the vehicle with four points of contact using either the lift frame, rubber pads or lifting arm
pads. Ensure that the four points of contact will not shift during operation.
4. Never use the lift to raise only one end or one side of the vehicle.
5. Always keep hands and feet clear of the lift when raising or lowering.
6. Keep area clean of tools, debris, grease and oil. Keep water from gathering on lift base.
7. Passengers should not be allowed inside the vehicle when in operation. Prohibit non-authorized
personnel from being in service area while in use.
8. Capacity of the Blazer 9000 is 9000 lbs. Do not exceed the 9000 lb. capacity.
Placing a Vehicle on the Blazer 9000
Note: It is critical that the operator positions the lift points per the vehicle manufacturers recommended
lift points. Some vehicle manufacturers have identified the proper lift points with triangular markings on
the undercarriage of the vehicle or have placed a label inside the front right door. If neither of these are
present, refer to the “Lifting It Right” Guides published by ALI or the “Vehicle Lifting Points for
Frame Engaged Lifts”, ALK/LP Guide.
1. The lift must be completely lowered before bringing the car over the lift. Install the rubber pads or
the lifting arms as required after the vehicle is centered over the lift and the vehicle lifting points
have been identified.
2. The lifting arms have extra height adapters that can be used depending on how high the vehicle
lifting point is from the top of the standard size lifting pad. The height adapters are 2-5/8” and 5”
and can be inserted into the adapter holes in the swing arms. Once the desired height is
determined, the standard lifting pad is set on the top height adapter.
3. To raise lift, press the green raise button on the power unit. When you get to the desired height,
lower until it rests on the safety lock by pressing the red lower button on the power unit. When
you are ready to lower the lift, raise the lift off of the safety locks and press the air release
button releasing the safeties. While holding down on the air release button, press the red lower
button on the power unit. Swing arms out from under the vehicle and place them out of the way.
4. Be sure that the vehicle is stable on the lift and neither front nor rear heavy. With some vehicles,
the removal (or installation) of components may cause a critical shift in the balance and result in
vehicle instability. Refer to the vehicle manufacturer’s service manual for recommended
procedures when performing these services.
5. Be sure that arm pads and any adapters used are in secure contact with frame at vehicle
manufacturer’s recommended lift points.
7
.
P
assen
g
ers s
h
ou
ld
not
b
e a
ll
owe
d
i
ns
id
e t
h
e ve
hi
c
l
e w
h
en
i
n operat
i
on.
P
ro
hibi
t non-aut
h
or
i
ze
d
personnel
f
rom bein
g
in service area while in use.

3
WARNINGS: When using Lifting Arms, Arms must not be rotated beyond the line decal
on the top plate as shown. The Arm Extensions must not be extended
beyond the arm stops as shown.
(A) - CAUTION, WHEN AREM IS EXTENDED BEYOND THIS LINE TOTAL LIFT CAPACITY IS
REDUCED TO 4,600 POUNDS.
(B) - WARNING, NEVER EXTEND ARM BEYHOND THE STOPS.
II. Installation Instructions
1. The maximum pit width for the Blazer 9000 is 43”.
2. The Blazer 9000 may be mounted on several types of surfaces including regular concrete, pre-cast
concrete and other configurations that may utilize metal beams, etc.
3. There should be adequate space on all sides of the lift. Note that the lift and vehicle will move
approximately 14” backward as the lift rises to its full height.
4. The bases must be aligned perfectly and the same distance apart.
5. Shim as required to level both sides of the lift.
6. The Blazer 9000 can be surface mounted or recessed mounted. Optional ramps are required if the
unit is to be surface installed.
7. See layout dimensions later in this manual.

4
Layout Dimensions

5
Layout Dimensions

6

7
Regular Concrete Installation
1. Concrete must be level and uniform and have a thickness of 4” with a rating of 3000PSI. The
concrete should be reinforced with wire and rebar.
2. When installing the Blazer 9000 on a concrete floor that has a basement, you should check with
the building architect or manufacturer to determine the proper support for the lift.
3. Utilize 5/8” anchor bolts when anchoring in regular concrete floors per the above specifications.
Pre-Cast Concrete Installation
1. Pre-cast concrete requires a different anchoring system. Consult with the manufacturer or call for
more information before anchoring the lift on a pre-cast concrete system.
2. Never use regular 5/8” anchor bolts on a pre-cast floor.
Other Floor Materials
1. When installing the Blazer 9000 on floor materials other than those mentioned above, consult with
the manufacturer for best type of anchoring system.
Electrical Connection and Power Unit Installation
1. The power unit will normally be mounted on the optional power unit stand that also includes the air
valve mounting. Other type mountings, such as pole or wall mounting are possible, but may
require special adapters for the motor mount. The unit owner or manager should approve the
location.
2. If used, the power unit stand will require (four) 3/8” anchor bolts which are provided with the stand.
3. 230-Volt Electrical Operation: The power unit comes wired and ready to plug into a 230-volt, single
phase, 60 Hz circuit. Use dedicated, single phase, 25-AMP breaker with time delay fuse or
circuit breaker. Wiring must comply with local electrical codes.
Hydraulic Connections
1. Reference the hydraulic diagram for instructions on connecting the hydraulic hose on the Blazer
9000. The lift comes standard with small connector hoses that can be used with any length
hose depending on how far the power unit is mounted from the lift. The standard length
hydraulic hose supplied with the unit is 1 @ 26' and 1 @ 14'. Additional hose lengths can be
purchased as required. The hose length does not have to be the same as long as the air is
properly bled from the system during installation. See page 13 for further instructions.
2. The power unit operates at high pressure and adequate care must be taken to make sure all hose
fittings are securely tightened. Severe leaking will occur if the hose fittings are not properly
tightened.
3. The power unit requires 7-1/2 - 8 quarts of Dexron III Automatic Transmission Fluid or an equivalent.
4. Make sure breather cap is functional and not broken.

8
Air Connections
1. The Blazer 9000 has air safety releases, which require that an air system be installed.
2. The air valve can be mounted on the optional power unit stand referenced above.
3. Maximum air pressure on the system is 50-60 PSI. Use regulator to control pressure and water
filter to keep system dry.
4. Reference page #11 for the air schematic and required connections.
Surface Mounting
1. Lifts that cannot be recessed must utilize the optional ramps that will be anchored to the concrete
floor. Each ramp is anchored utilizing two 5/8” anchor bolts. The ramp is butted against the lift
base, which provides the means for the vehicle to roll on the lift.
II. Owner/Employer Responsibilities
The owner/employer shall:
1. Ensure that lift operators are instructed in the safe use and operation of the lift using the
manufacturer instructions and safety tips.
Display a copy of the manual in a location convenient to the lift so the operators can refer to it
as required.
2. Establish procedures to maintain, inspect and care for the lift in accordance with the
manufacturers recommended procedures to ensure its continued safe operation.
3. Provide necessary lock out/tagouts of energy sources per ANSI Z244.1-1982 before beginning any
lift repairs.
4. Not modify the lift in any manner without prior written consent of the manufacturer.
5. Ensure that there is adequate drainage around the lift so water will not accumulate on the base of
the lift.
6. In the unlikely event that one side of the lift will not lower all the way to the floor, slowly crack the
hydraulic line (at the power unit) on the line coming from that side of the lift and allow oil to
escape until it reaches he floor.

9
AIR BLEEDING PROCEDURE FOR BLAZER 9000
Step #1 Fill the power unit reservoir with Dexron III Mercon Automatic Transmission Fluid or equivalent,
approximately 7.5 quarts to start with, check all connections for proper security and clearances around and
under both of the lifting surfaces, example,…. binding, chafing, and pinching. :DUQLQJ6DIHW\H\HZHDULV
UHTXLUHGSULRUWRHTXLSPHQWRSHUDWLRQ.
Step #2 Prior to connecting the hydraulic hoses to the cylinders, press and hold the green “lifting” button on
the power unit, this will flow fluid through the hydraulic lines/hoses, flushing any foreign material along with
any air from the system and allow you to inspect for possible leaks. Cycle the pump until clear fluid is coming
out of both lift pad hydraulic hoses + approximately 1 quart1RWH'RQRWUHXVHWKLVIOXLGLWLVOLNHO\
FRQWDPLQDWHG
Step #3 You will need to manually raise each lifting pad to the KLJKHVW safety lock setting, making sure that it
is securely latched into the latch bar on the base plate. :DUQLQJ3ODFHDVDIHW\EORFNRURWKHUPDWHULDO
XQGHUHDFKOLIWLQJVXUIDFHSULRUWRPDNLQJWKHVHFRQQHFWLRQV'LVFRQQHFWWKHK\GUDXOLFF\OLQGHUIURPWKH
OLIWLQJSDGFRPSUHVVF\OLQGHUFRPSOHWHO\1RWHK\GUDXOLFIOXLGDQGDLUZLOOEHHYDFXDWHGIURPWKHF\OLQGHU
5HSHDWWKLVSURFHVVIRUERWKOLIWLQJSDGV&RQQHFWWKHK\GUDXOLFKRVHVWRWKHERWWRPRIWKHF\OLQGHU'HSUHVV
DQGKROGWKHDLUORFNUHOHDVHEXWWRQWKLVVKRXOGUDLVHWKHORFNVRXWRIWKHODWFKEDURQERWKOHIWULJKWVLGH
EDVHSODWHVVLPXOWDQHRXVO\GHSUHVVLQJWKHUHGORZHULQJEXWWRQWKHSDGVVKRXOGEHJLQWRORZHUZLWKLQDIHZ
PRPHQWV
1RWH7KHGHJUHHFRQQHFWLRQWRWKHOLIWF\OLQGHUQHHGVWREHVHFXUHGDWVXFKDQDQJOHWKDWWKHKRVH
FRPHVFORVHWRWKHEDVHSODWHZLWKPLQLPDOFRQWDFWRIWKHEDVHSODWH
Step #4 Press and hold the green “lifting” button until both pads are elevated enough to clear the first set of
locks, then release. 1RWH,WLVFRPPRQIRUWKHSDGVWRUDLVHDQGORZHUDWGLIIHUHQWHOHYDWLRQVRQWKHLQLWLDO
VWDUWXSWKH\ZLOOHYHQRXWDVWKLVSURFHVVXQIROGV. Depress and hold the air lock release button, this should
raise the locks out of the latch bar on both left & right side base plates, simultaneously depressing the red
lowering button, the pads should begin to lower within a few moments. Allow the pads to lower all the way to
bottom. Duplicate this process numerous times, 5 to 6 cycles, increasing the lifting height by one extra lock
per cycle. Each completed operation should facilitate a more even pad elevation and smoother equipment
function. Some installations may require more or less cycles to accomplish this stage of the bleeding process.
1RWH$IWHUFRPSOHWLQJWKLVSURFHVVILOOWKHUHVHUYRLUWRWKHSURSHUIOXLGOHYHO
1RWH'RQRWUDLVHWKHOLIWSDGVWRWKHLUKLJKHVWSRLQWXQWLOFRPSOHWLQJWKHHQWLUHEOHHGLQJSURFHVV
Step #5. Once you have both lifting services raising/lowering evenly and smoothly you now are ready to put a
load on the system to complete the bleeding process. As in Step #1 an inspection around and under each lifting
surface for possible leaks and clearances is required. A mid-size vehicle of approximately 4500 + lbs will be
needed to finish this process. :DUQLQJ$OOXQQHFHVVDU\SHUVRQQHOQHHGWREHUHPRYHGIURPWKHWHVWDUHD
IRUVDIHW\. Stage the vehicle for lifting, utilizing necessary adapters as required, announce the lift operation,
and then when all is clear depress the green “lifting” button. Raise the vehicle until the tires are clear of the
floor surface, at this point you will release the green button and depress the lock release button, :DUQLQJ$V
LQSUHYLRXVVWHSVPDNHVXUHEHIRUHGHSUHVVLQJWKHUHG³GRZQ´EXWWRQYLVXDOO\LQVSHFWWKDWWKHORFNVRQ
ERWKSDGVDUHFOHDURIWKHODWFKEDURQWKHEDVHSODWH. Now you can depress the red “down” button allowing
the vehicle to lower down. Make sure that for each cycle you allow the pads to bottom out before starting up
again. Continue this process for a few cycles until the vehicle is coming up and going down level/smooth.
Note: Do not adjust any valves on the power unit pump without prior contact and instructions to do so
from DEVON. @ 1-800-468-1970

MAINTENANCE
DAILY
1. Keep all movement points clean, dry and lightly lubricated.
2. Always keep bolts tight.
3. Check for oil leaks.
4. Keep air regulator set @ maximum 50-60 PSI.
5. Remove any accumulated moisture from air line filter.
6. Raise lift pads at day’s end and remove any standing water or moisture.
7. Use air blow gun to keep moving parts clean & dry.
MONTHLY
1. Wipe clean & lightly oil movement parts & lift pad stacking extensions.
2. Re-Torque the anchor bolts if necessary. (See CAUTION Below)
3. Check all connectors, bolts & pins to insure proper mounting & alignment.
4. Make a visual inspection of hydraulic hoses & lines for possible wear or
interference.
5. Check fluid level of power unit (use Dexron III or equivalent).
CAUTION !
ALL ANCHOR BOLTS SHOULD ALWAYS BE TIGHT.
Check the bolts periodically and tighten if necessary to 60-90 ft. lbs.
If any of the bolts do not function for any reason, the lift should be
shut down until the bolt has been replaced.
10

11
TROUBLESHOOTING THE LIFT
1. Motor does not run: A. Breaker or fuse blown.
B. Motor thermal overload tripped.
C. Defective UP switch. Replace
D. Faulty wiring connections. Call
electrician.
————————————————————————————————————————————-
2. Motor runs but lift will not raise: A. Trash is under the release valve. Push
Down button and push Up button at
the same time. Hold for 15 seconds.
B. Oil level low. Oil level should be
just under the fill cap port when the
lift is down.
——————————————————————————————————————
3. Motor runs but lift picks up partial load only: A. Faulty relief valve. Replace.
B. Oil is coming out of breather on
cylinder.
C. Seals damaged.
——————————————————————————————————————
4. Oil blows out of breather: A. Oil reservoir overfilled.
——————————————————————————————————————
5. Motor hums and will not run: A. Impeller fan cover is dented in.
Take off and straighten.
B. Faulty wiring-call electrician.
C. Bad capacitor-call electrician.
D. Low voltage-call electrician.
E. Lift overloaded.
——————————————————————————————————————
6. Lift jerks up and down: A. Air in system - bleed the system.
(See installation instructions
bleeding the system).

%OD]HU/XEH/LIW
<($5/,0,7(':$55$17<
The structural components of Blazer 9000 Lube Lift are warranted to the original owner to be free from
defects in material and workmanship under normal use for a period of years from invoice date.
Devon Industries, Inc. will replace those parts returned to the factory which prove to be defective for the
two year warranty period. Devon Industries, Inc. will pay reasonable VWDQGDUGRXWERXQGVKLSSLQJcostV
for the first 12 months and purchaser will bear the cost of transportation for the remainder of the
warranty.
/LPLWDWLRQV LQFOXGH Power unit, hydraulic cylinders, and air cylinders WR EH warranted for one year
from invoice date against defective material when the product is installed and used according to
manufacturer¶s specifications. Warranty obligation is limited to the repair or replacement of parts
returned to the factory, freight prepaid which prove upon inspection to have been defective and have not
been misused.$OOSDUWVPXVWEHUHWXUQHGIUHLJKWSUHSDLGDQGDGHTXDWHO\SDFNDJHGWRSUHYHQWGDPDJHLQ
WUDQVLW'HYRQ,QGXVWULHVUHVHUYHVWKHULJKWWRUHIXVHUHLPEXUVHPHQWIRULWHPVSXUFKDVHGWKURXJKDUG
SDUW\IRUUHSDLU
'HYRQ ,QGXVWULHV ,QF ZLOO UHLPEXUVH ODERU FKDUJHV WR DQ\ $/, FHUWLILHG OLIW LQVWDOOHU IRU WKH UHSDLU RI
PDQXIDFWXUHU GHIHFWV 1RQ$/, FHUWLILHG OLIW LQVWDOOHU UHSDLU ZLOO QRW EH FRQVLGHUHG IRU UHLPEXUVHPHQW
ZLWKRXW SULRU DXWKRUL]DWLRQ E\ 'HYRQ ,QGXVWULHV ,QF FXVWRPHU VHUYLFH 1R ODERU
UHLPEXUVHPHQWZLOOEHSDLG IRU UHSDLUVSHUIRUPHGE\LQGLYLGXDOV/LPLWDWLRQV IRU ODERU
UHLPEXUVHPHQWV ZLOO EH  IRU WKH LQLWLDO UHSDLU LQVSHFWLRQ LI DSSOLFDEOH DQG KRXU IRU D
UHDVRQDEOH WLPHIUDPH IRU UHSDLU 1R PLOHDJH UHLPEXUVHPHQW ZLOO EH SDLG IRU LQLWLDO UHSDLU LQVSHFWLRQ
0LOHDJHZLOOEHUHLPEXUVHGIRUUHSDLUWULSVRYHUPLOHVURXQGWULS0LOHDJHZLOOEHSDLGDWWKH,56
SXEOLVKHG PLOHDJH UDWH [  7KH VWDQGDUG PLOHDJH UDWH FDQ EH IRXQG DW KWWSVZZZLUVJRYWD[
SURIHVVLRQDOVVWDQGDUGPLOHDJHUDWHV
This warranty does not cover normal maintenance, damage as a result of improper
installation, abuse, misuse, overloading, negligence, normal wear and tear, concrete floor related
problems, or defects caused by lack of required maintenance. This warranty does not cover equipment
when repairs have been attempted SUHYLRXV WR QRWLI\LQJ 'HYRQ ,QGXVWULHV ,QF RI DQ\ SRVVLEOH
PDQXIDFWXUHUGHIHFWV
In no event will the sales representative, wholesale dealer, Devon Industries, Inc or any
company affiliated with it or them be liable for incidental or consequential damages or injuries,
including but not limited to the loss of profit, rental or substitute equipment or other commercial loss
purchaser¶s sole and exclusive remedy being as provided here in above.
This warranty may not be enlarged or modified in any manner except in writing signed by
an executive officer of Devon Industries, Inc. It is the policy of Devon Industries, Inc. to improve it
products whenever possible and practical to do so. Devon Industries, Inc. reserves the right to make
changes and or add improvement at any time without incurring any obligation to make such changes
or add such improvements to products SUHYLRXVO\ sold.
7KH%OD]HU/XEH/LIWPXVWRQO\EHRSHUDWHGE\SHUVRQVZKRKDYHEHHQWUDLQHGLQLWVVDIHDQGSURSHU
XVH7KHPDQXIDFWXUHUVZDUUDQW\LVH[FOXVLYHDQGLVLQOLHXRIDOORWKHUZDUUDQWLHVH[SUHVVHGRULPSOLHG

12
————————————————————————————————————————————
WARRANTY REGISTRATION
0RGHO1RBBBBBBBBBBBBBBBBBBBBBB 6HULDO1RBBBBBBBBBBBBBBBBBBBBBBB
'DWH3XUFKDVHGBBBBBBBBBBBBBBBBB ,QYRLFH1RBBBBBBBBBBBBBBBBBBBBBB
1DPHRI3XUFKDVHUBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
0DLOLQJ$GGUHVVBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
3K\VLFDO$GGUHVVRI/LIWBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
&LW\BBBBBBBBBBBBBBBBBBBBBBBBBB6WDWHBBBBBBBBBBBBB=LSBBBBBBBBBBB
7HOHSKRQH1RBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
1DPHRI6HOOHUBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
&LW\BBBBBBBBBBBBBBBBBBBBBBBBB6WDWHBBBBBBBBBBBBBBB=LSBBBBBBBBBB
7HOHSKRQH1RBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
5HWXUQWR
'(921/8%(&(17(5(48,30(17
32%R[
2./$+20$&,7<2.

13
'(921/8%(&(17(5(48,30(17
PARTS MANUAL – BLAZER 9000


14

15
PARTS LIST - BLAZER 9000
Only use manufacturer supplied replacement parts
ITEM# PART# Description QTY
1 92422 TOP PLATE STRUCTURE LH 1
1 92423 TOP PLATE STRUCTURE RH 1
292402 BASE STRUCTURE - LH 1
292403 BASE STRUCTURE - RH 1
# 95169 ANCHOR BOLTS 5/8X3-3/4 12
392429 LIFTING LEG 4
4 101047 SHOULDER BOLT 3/4-4 10
5 101048 NYLOCK NUT-THIN 5/8-11NC 10
6 92477L TOP SAFETY TUBE STR.- LH 1
6 92477R TOP SAFETY TUBE STR.- RH 1
#92411 MASTERLINK 4
7 92442 SAFETY BAR STRUCTURE- LH 1
7 92443 SAFETY BAR STRUCTURE- RH 1
892433 RAMP STRUCTURE- LH 1
8 92434 RAMP STRUCTURE- RH 1
992439 MAIN PIN 4
10 101002 NYLOCK NUT-THIN 3/4-16NF 4
11 92413LH HYDRAULIC CYLINDER - LH 1
11 92413RH HYDRAULIC CYLINDER - RH 1
12 92449 OUTER LIFT ARM STR. 4
13 92452 INNER LIFT ARM STR. 4
14 91555 LIFT PAD ASSEMBLY 4
# 91559 LIFT PAD - BOLT ON 4
#91556 LIFT PAD STRUCTURE 4
# 100179 HEX SCREW 3/8-16NC X 3/4 8
# 100082 FLATWASHER 3/8" SAE 8
#92492 ARM RETAINER PLUG 4
15 91562 LIFT PAD EXTENSION 5" 4
16 91560 LIFT PAD EXTENSION 2-5/8" 4
17 101049 3/8 LOCK WASHER 12
18 101051 HEX SCREWS - 3/8X16NC x 1/2" 8
19 101050 HEX SCREWS - 3/8X16NC x 5/8" 4
20 92448 RUBBER PAD 2
#101004 ELEVATOR BOLT 12
# 100131 HEX NUT 1/4 X 20NC 12
21 92460 RUBBER BLOCKS 4
22 95170 POWER UNIT 1
23 92459 POWER UNIT STAND STR. 1
# 95082 ANCHOR BOLTS 3/8 X 3-3/4 4
24 92469 DRIVE ON RAMP STRUCTURE 4
# 95169 ANCHOR BOLT 5/8" X 3-3/4" 8
25 95171 POWER SWITCH - RAISE 1
26 95172 POWER SWITCH - LOWER 1
# 95047 ALI SAFETY REQUIREMENTS FOR OPER. 1
# 95048 ALI LIFTING POINT QUICK REF. 1
# 95049 LIFTING IT RIGHT MANUAL 1
#95045 ETL DECAL 1
# 95046 ALI UNIFORM WARNING LABELS 1
#95007 CAUTION DECAL 1
#95056 SERIAL NAME PLATE 1

16

195170 Power Unit1
2(OERZ137[-,&
 2
1
924 HYD. Hose - Long (RH or LH)
3
1
924 HYD. Hose - Long (RH or LH)

192413RH HYD. Cylinder - RH

92413RH

PART NAMEPART#
SYS QTY
HYDRAULIC SCHEMATIC
+<'&\OLQGHU/+ 1
