WARNING: To reduce the risk of injury, read the
instruction manual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
DWE314 DWE315
Voltage VAC 230 230
UK & Ireland VAC 230/115 230/115
Type 1 1
Power intput W250 300
Power output W170 170
Oscillating frequency min-1 0–22000 0–22000
Oscillating angle 1.6˚ 1.6˚
Weight kg 1.5 1.5
Noise values and vibration values (triax vector sum) according to EN62841:
LPA (emission sound
pressure level)
dB(A) 89 89
LWA (sound power level) dB(A) 100 100
K (uncertainty for the
given sound level)
dB(A) 3 3
Vibration emission value
a
h
=
m/s218.4 18.4
Uncertainty K = m/s28.7 8.7
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
English (original instructions)
OSCILLATING MULTI-TOOL
DWE314, DWE315

6
ENGLISH
General Power Tool Safety Warnings
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.

7
ENGLISH
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
Additional Safety Rules for Oscillating
Multi-Tool
WARNING: Take special care when sanding some woods
(e.g. beech, oak) and metal which may produce toxic dust.
Wear a dust mask specifically designed for protection
against toxic dust and fumes and ensure that persons
within or entering the work area are alsoprotected.
WARNING: Use this tool in a well-ventilated area when
sanding ferrous metals. Do not operate the tool near
flammable liquids, gases or dust. Sparks or hot particles
from sanding or arcing motor brushes may ignite
combustiblematerials.
Sanding Paint
WARNING: Observe the applicable regulations for
sanding paint. Pay special attention to the following:
• Whenever possible, use a vacuum extractor for dustcollection.
• Take special care when sanding paint which is possibly lead
based:
-Do not let children or pregnant women enter the
workarea.
-All persons entering the work area should wear a mask
specially designed for protection against lead paint dust
andfumes.
-Do not eat, drink or smoke in the workarea.
• Dispose of dust particles and any other removal debrissafely.
• Hold power tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring or its own cord. Contact with a "live"
wire will make exposed metal parts of the tool "live" and shock
theoperator.
• Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by hand or against your body leaves it unstable and may
lead to loss ofcontrol.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
Residual Risks
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the ratingplate.
Your
DeWALT
tool is double insulated in accordance
with EN62841; therefore no earth wire isrequired.
WARNING: 115 V units have to be operated via a fail-safe
isolating transformer with an earth screen between the
primary and secondarywinding.
If the supply cord is damaged, it must be replaced only by
DeWALT
or an authorised serviceorganisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1.5 mm2; the maximum length
is30m.
When using a cable reel, always unwind the cablecompletely.
Package Contents
The package contains:
1 Adaptor for all blades (DWE315SF, DWE315B, DWE315KT,
DWE314K)
1 Dust extraction adaptor (DWE315KT)
1 Cutting guide (DWE315KT)
1 31mm x 43mm fastcut wood blade (DWE314K, DWE315KT)
1 31mm x 43mm wood with nails blade (DWE315SF,
DWE315KT, DWE315B, DWE314K)
1 100mm Semicircle blade (DWE314K, DWE315KT)
1 Sanding-pad (DWE314K, DW315, DWE315B, DWE315KT)
25 Assorted sandpaper pieces (DWE314K, DW315, DWE315B,
DWE315KT)
1 9.5mm x 43mm wood detail blade (DWE315KT)
1 3mm Carbide grout removal blade
(100mm half moon) (DWE315KT)
1 Rigid scraper blade (DWE315SF, DWE315B, DWE315KT,
DWE314K)
1 Hex key (DWE315SF, DWE315B, DWE315KT, DWE314K)
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.

8
ENGLISH
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Wear respiratoryprotection.
Date Code Position (Fig. A)
The date code 20 , which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Variable speed trigger
2 LED Worklight
3 Accessory clamp lever
4 Lock-on button
5 Accessory side mount slots
6 Cut guide block
7 Cut guide arm
Intended Use
This oscillating multi-tool is designed for professional detail
sanding, plunge cutting, flush cutting, removal of excess
materials and surface preparationapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This oscillating multi-tool is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can causeinjury.
Installing/Removing Accessories (Fig. B–F)
Tool-free Accessory clamp (Fig. B–D)
The DWE314, DWE315 features a quick change accessory
system. This allows for faster accessory changes without the
need for wrenches or hex keys like other oscillating toolsystems.
1. Grasp the tool and squeeze the accessory clamping lever3
as shown in figureB.
2. Clean any residual debris from the tool shaft and the
accessoryholder.
3. Slide the accessory between the shaft8 and the accessory
holder making sure the accessory engages all eight pins on
the holder and is flush with the shaft. Ensure the accessory is
oriented as shown in FigureC.
4. Release the accessory clamplever.
NOTE: Some accessories, such as scrapers and blades can be
mounted at an angle if required as shown in figureD.
Installing/Removing Sanding Sheets
(Fig. E)
A diamond shaped platen uses a hook and loop adhesion
system to attach the sanding sheets. The platen allows you to
use it on large flat surfaces and tight spots orcorners.
1. Attach the sanding platen9 as described under Installing/
RemovingAccessories.
2. Align the edges on the sanding sheet, with the edge of
the sanding platen and press the sanding sheet10 onto
theplaten.
3. Firmly press the base with the sanding sheet attached
against a flat surface and briefly switch the tool on. This
provides for good adhesion between the platen and the
sanding sheet and also helps to prevent prematurewear.
4. When the tip of the sanding sheet becomes worn, detach
the sheet from the platen, rotate andreapply.
Attaching Accessories Using The Universal
Adapter (Fig. F)
CAUTION: To avoid injury, do not use any accessory
for an application where the adaptor may fail to hold
theaccessory.
CAUTION: Read and follow all manufacturers' safety
warnings for any accessories used with thistool.
CAUTION: To avoid injury, ensure adaptor and accessory
are securelytightened.
Non-
DeWALT
accessories can be attached using the
universaladaptor.
1. Place the washer11 on thetool.
2. Place accessory on towasher.
3. Tighten and secure adaptor nut12 using a hexwrench.

9
ENGLISH
Attaching the Cut Guide (Fig. G–L)
The depth/cut guide allows you to precisely cut material at a
specified depth and more accurately track a marked cutline.
1. Attach the cut guide block6 by inserting the accessory
tabs13 on the guide into the accessory side mount slots5
on the main body of thetool.
2. Secure the block to the main body with the supplied screw
assembly15. Tighten with the supplied hex key16.
Depth Guide
This feature allows you to precisely cut material at a
specifieddepth.
1. Insert the guide arm7 as shown in figureH into the front
slot on the guide block6.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired cut depth as shown in figureI.
3. Secure the guide in place by turning the depth/cut
adjustment knob14 clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
Cut Guide
This feature allows you to more accurately track a marked
cutline.
1. Insert the guide arm7 as shown in figureJ into the slots on
the left and right sides of the guide block6.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired length as shown in figureK.
3. Secure the guide in place by turning the depth/cut
adjustment knob14 clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
NOTE: The guide arm can also be placed in the guard assembly
vertically in order to set the height off a cut. Refer to figureL.
Attaching the Dust Extraction Adaptor
(Fig. P)
The Dust Extraction Adaptor allows you to connect the tool to
an external dust extractor, either using the AirLock™ system
(DWV9000-XJ), or a standard 35mm dust extractorfitment.
1. Attach the dust extraction adaptor17 by inserting the
tabs13 in to the accessory side mount slots5.
2. Insert screw assembly15 into the dust extraction
adaptor17 and tighten with the supplied hex key16.
OPERATION
Instructions for Use (Fig. M, N)
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can causeinjury.
WARNING: Ensure switch is fully OFF before plugging in
the powercord.
1. Plug in powercord.
2. To turn the tool ON, hold it as shown in figureM and press
the variable speed trigger1.
NOTE: The further the trigger switch is depressed the faster
the tool will operate. If in doubt about the proper speed
for your operation, test the performance at low speed and
gradually increase until a comfortable speed isfound.
3. To turn the tool OFF, release the variable speed trigger1.
Lock-on Button (Fig. N)
For more comfort in extended use applications, the
lock-on button4 can lock the trigger trigger1 in the
depressedposition.
LED Worklight (Fig. O)
The LED worklight2 will activate when the trigger is depressed
Proper Hand Position (Fig. M)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires the tool to be held as shown in
FigureM.
Using the Dust Extraction Adaptor with the
Sanding Platen (Fig. Q)
1. Attach the dust extraction adaptor17. Refer to Attaching
the Dust ExtractionAdaptor.
2. Attach the sanding platen9 as described under Installing/
RemovingAccessories.
3. Attach sanding sheet as described under Installing/
Removing SandingSheets.
Using the Dust Extraction Adaptor with
Plunge Cutting Accessory (Fig. R)
1. Attach the dust extraction adaptor. Refer to Attaching the
Dust ExtractionAdaptor.
2. Push dust extraction arm19 into the lower aperture of the
dust extraction adaptor17.
3. Attach plunge cutting bit as described under Installing/
RemovingAccessories.
4. Adjust the dust extraction arm19 for bestresults.
Helpful Hints
• Always ensure the workpiece is firmly held or clamped to
prevent movement. Any movement of the material may
affect the quality of the cutting or sandingfinish.
• Do not start sanding without having the sandpaper
attached to sandingplaten.
• Use coarse grit paper to sand rough surfaces, medium grit
for smooth surfaces and fine grit for the finishing surfaces. If
necessary, first make a test run on scrapmaterial.

10
ENGLISH
• Excessive force will reduce the working efficiency and cause
motor overload. Replacing the accessory regularly will
maintain optimum workingefficiency.
• Do not allow the sandpaper to wear away, it will damage
the sandingpad.
• If the tool overheats, especially when used at low speed,
set the speed to maximum and run it with no load for 2–3
minutes to cool the motor. Avoid prolonged usage at very
low speeds. Always keep the bladesharp.
MAINTENANCE
Your
DeWALT
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can causeinjury.
Lubrication
Your power tool requires no additionallubrication.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by
DeWALT
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
DeWALT
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Compatible accessories
Oscillating sanding pad
Oscillating wood w/ nails blade
Wide titanium oscillating wood w/ nails blade
Oscillating hardwood blade
Oscillating fastcut wood blade
Wide oscillating fastcut wood blade
Oscillating wood detail blade
Oscillating titanium metal blade
Oscillating semicircle blade
Oscillating titanium semicircle blade
Oscillating flush cut blade
Titanium oscillating flush cut blade
Oscillating multi-material blade
Oscillating rigid scraper blade
Oscillating flexible scraper blade
Oscillating carbide grout removal blade
Oscillating fastcut carbide grout removal blade
Oscillating carbide rasp
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
TROUBLESHOOTING
Problem Possible
Cause
Possible Solution
Unit will notstart. Cord not
pluggedin.
Plug tool into a workingoutlet.
Circuit fuse
isblown.
Replace circuit fuse. (If the product repeatedly causes the circuit fuse to blow,
discontinue use immediately and have it serviced by an authorised D
e
WALT repair
agent.)
Circuit breaker
istripped.
Reset circuit breaker. (If the product repeatedly causes the circuit breaker to trip,
discontinue use immediately and have it serviced by an authorised D
e
WALT repair
agent.)
Cord or switch
isdamaged.
Have cord or switch replaced by an authorised D
e
WALT repairagent.




14
Belgique et
Luxembourg België en Luxemburg
DeWALT - Belgium BVBA
Egide Walschaertsstraat 16
2800 Mechelen
Tel: NL 32 15 47 37 63
Tel: FR 32 15 47 37 64
Fax: 32 15 47 37 99
www.dewalt.be
Danmark DeWALT (Stanley Black&Decker AS)
Roskildevej 22
2620 Albertslund
Tel: 70 20 15 10
Fax: 70 22 49 10
www.dewalt.dk
Deutschland DeWALT
Richard Klinger Str. 11
65510 Idstein
Tel: 06126-21-0
Fax: 06126-21-2770
www.dewalt.de
Ελλάς DeWALT (Ελλάς) Α.Ε.
EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 166 74, Αθήνα
SERVICE : Ημερος Τόπος 2 (Χάνι Αδάμ) – 193 00 Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
España DeWALT Ibérica, S.C.A.
Parc de Negocios “Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820 El Prat de Llobregat (Barcelona)
Tel: 934 797 400
Fax: 934 797 419
www.dewalt.es
France DeWALT (Stanley Black & Decker France SAS)
62 Chemin de la Bruyère
CS 60105,
69574 DARDILLY Cedex
Tel: 04 72 20 39 20
Fax: 04 72 20 39 00
www.dewalt.fr
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902 Urdorf
Tel: 044 - 755 60 70
Fax: 044 - 730 70 67
www.dewalt.ch
Ireland DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: 00353-2781800
Fax: 01278 1811
www.dewalt.ie
Italia DeWALT
via Energypark 6
20871 Vimercate (MB), IT
Tel: 800-014353
39 039-9590200
Fax: 39 039-9590311
www.dewalt.it
Nederlands DeWALT
Netherlands BVPostbus 83,
6120 AB BORN
Tel: 31 164 283 063
Fax: 31 164 283 200
www.dewalt.nl
Norge DeWALT
Postboks 4613
0405 Oslo, Norge
Tel: 45 25 13 00
Fax: 45 25 08 00
www.dewalt.no
Österreich DeWALT
Werkzeug Vertriebsges m.b.H
Oberlaaerstrasse 248, A-1230 Wien
Tel: 01 - 66116 - 0
Fax: 01 - 66116 - 614
www.dewalt.at
Portugal DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2º Esq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770 071 Paço de Arcos
Tel: +351 214667500
Fax: +351214667580
www.dewalt.pt
Suomi DeWALT
PL47
00521 Helsinki, Suomi
Puh: 010 400 4333
Faksi: 0800 411 340
www.dewalt.fi
Sverige DeWALT
BOX 94
43122 Mölndal
Sverige
Tel: 031 68 61 60
Fax: 031 68 60 08
www.dewalt.se
Türkiye Sanayi ve Ticareet Bakanlığı tebliğince kullanim ömrü 7 yıldır.
Stanley Black & Decker Turkey Alet Üretim San. Tic. Ltd.Şti.
Kozyataği Mh Değirmen Sk.
Nida Kule No: 18 Kat: 6, 34742
Kadıköy, İstanbul, Türkiye
Tel: +90 216 665 2900
Faks: +90 216 665 2901
www.dewalt.com.tr
United
Kingdom
DeWALT, 210 Bath Road;
Slough, Berks SL1 3YD
Tel: 01753-567055
Fax: 01753-572112
www.dewalt.co.uk
Australia DeWALT
810 Whitehorse Road Box Hill
VIC 3128 Australia
Tel: Aust 1800 338 002
Tel: NZ 0800 339 258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa DeWALT
P.O. Box - 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: 971 4 812 7400
Fax: 971 4 2822765
www.dewalt.ae
N656852 02/19
Table of contents
Other DeWalt Power Tools manuals

DeWalt
DeWalt XR Li-Ion DCF813 User manual

DeWalt
DeWalt DW621 User manual

DeWalt
DeWalt DW861 User manual

DeWalt
DeWalt DWE315SF-GB User manual

DeWalt
DeWalt DCS355 User manual

DeWalt
DeWalt DCF899H User manual

DeWalt
DeWalt DW625 User manual

DeWalt
DeWalt DCF898 User manual

DeWalt
DeWalt P3600 User manual

DeWalt
DeWalt DCD792 User manual

DeWalt
DeWalt DW725 User manual

DeWalt
DeWalt Patmi P3500 User manual

DeWalt
DeWalt DW682 User manual

DeWalt
DeWalt DCF680G2 User manual

DeWalt
DeWalt DCS551 User manual

DeWalt
DeWalt DCS389X2 User manual

DeWalt
DeWalt D25901 User manual

DeWalt
DeWalt DCD710 User manual

DeWalt
DeWalt XR DCD1623 User manual

DeWalt
DeWalt DC820, DC830, DC840 User manual
