DFI CS636-C246 User manual

CS636-C246/Q370
ATX Industrial Motherboard
User’s Manual
A-579-M-2012

2User's Manual | CS636
Copyright
This publication contains information that is protected by copyright. No part of it may be repro-
duced in any form or by any means or used to make any transformation/adaptation without the
prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions or
changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2020. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.

3User's Manual | CS636
Table of Contents
Chapter 1 - Introduction................................................................................................................6
Specifications ......................................................................................................................... 6
Features .................................................................................................................................. 7
Chapter 2 - Hardware Installation................................................................................................8
Board Layout........................................................................................................................... 8
Standby Power LED................................................................................................................8
System Memory .....................................................................................................................9
Installing the DIMM Module ...........................................................................................9
Removing the DIMM Module........................................................................................10
CPU........................................................................................................................................11
Installing the CPU..........................................................................................................11
Installing the Fan and Heat Sink ..................................................................................13
Jumper Settings ...................................................................................................................14
Clear CMOS....................................................................................................................14
RS232 Power Select......................................................................................................14
Digital I/O (DIO) Power Select......................................................................................15
Digital I/O (DIO) Power Supply .....................................................................................15
PCIE2 Signal Select .......................................................................................................16
Rear I/O Ports.......................................................................................................................17
Graphics Display............................................................................................................17
COM (Serial) ports.........................................................................................................18
RJ45 LAN Ports .............................................................................................................19
USB Ports .......................................................................................................................20
Audio .............................................................................................................................21
Internal I/O Connectors .......................................................................................................22
SATA (Serial ATA) ..........................................................................................................22
Digital I/O .......................................................................................................................22
Cooling Fan Connectors................................................................................................23
Power Connector...........................................................................................................23
Chassis Intrusion...........................................................................................................24
Front Panel.....................................................................................................................24
Expansion Slots .............................................................................................................25
Installing the M.2 Module .............................................................................................25
S/PDIF.............................................................................................................................26
Battery ............................................................................................................................27
SMBus ............................................................................................................................27
LAN LED .........................................................................................................................28
LPC .................................................................................................................................28
Chapter 3 - BIOS Settings...........................................................................................................29
Overview ...............................................................................................................................29
Main.......................................................................................................................................30
Advanced .............................................................................................................................30
RC ACPI Configuration..................................................................................................31
CPU Configuration.........................................................................................................31
Power & Performance ...................................................................................................32
PCH-FW Configuration ..................................................................................................32
Trusted Computing........................................................................................................35
NCT6116D Super IO Configuration ..............................................................................35
NCT6116D HW Monitor ................................................................................................36
Serial Port Console Redirection ...................................................................................37
USB Configuration .........................................................................................................38
CSM Configuration ........................................................................................................39
USB Power Control........................................................................................................39
Network Stack Configuration........................................................................................40
Chipset ..................................................................................................................................41
Graphics Configuration .................................................................................................41
PEG Port Configuration.................................................................................................42
PCH-IO Configuration....................................................................................................43
PCI Express Configuration............................................................................................43
SATA And RST Configuration .......................................................................................44
HD Audio Configuration ................................................................................................44
Security .................................................................................................................................45
Secure Boot....................................................................................................................45
Boot .......................................................................................................................................46
Save & Exit ............................................................................................................................46
Updating the BIOS................................................................................................................47
Notice: BIOS SPI ROM..........................................................................................................47
Chapter 4 - Intel AMT Settings...................................................................................................48
Overview ...............................................................................................................................48
Enable Intel®AMT in the AMI BIOS ....................................................................................48
Entering Management Engine BIOS Extension (MEBX)....................................................49
MEBX.....................................................................................................................................50
Main Menu .....................................................................................................................50
Intel(R) ME General Settings ........................................................................................50
Intel(R) AMT Configuration...........................................................................................52
Chapter 5 - RAID..........................................................................................................................63
RAID Levels...........................................................................................................................63
Setup Procedure...................................................................................................................63
Chapter 6 - Supported Software ................................................................................................65
Auto-run Menu......................................................................................................................65
Intel Chipset Software Installation Utility...........................................................................65
Intel HD Graphics Drivers ...................................................................................................66
Realtek Audio Drivers...........................................................................................................67
Intel LAN Driver ...................................................................................................................68
Intel ME Drivers ....................................................................................................................69
Intel Serial IO Drivers ...........................................................................................................70
Intel Rapid Storage Technology .........................................................................................71
Adobe Acrobat Reader 9.3 ..................................................................................................73

4User's Manual | CS636
About this Manual
This manual can be downloaded from the website, or acquired as an electronic file included in
the optional CD/DVD. The manual is subject to change and update without notice, and may be
based on editions that do not resemble your actual products. Please visit our website or con-
tact our sales representatives for the latest editions.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the product,
inability to use the product, unauthorized replacement or alteration of components and
product specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper in-
stallation, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether in
or out of warranty. It must be returned to the purchase point, factory or authorized ser-
vice agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial damages to
the product that has been modified or altered.
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components or devices even
before installing them in your system unit. Static electrical discharge can damage computer
components without causing any signs of physical damage. You must take extra care in han-
dling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you
are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the components, con-
tacts or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or
connectors by their ends.
Safety Measures
• To avoid damage to the system, use the correct AC input voltage range.
• To reduce the risk of electric shock, unplug the power cord before removing the sys-
tem chassis cover for installation or servicing. After installation or servicing, cover the
system chassis before plugging the power cord.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and other
components. Perform the upgrade instruction procedures described at an ESD
workstation only. If such a station is not available, you can provide some ESD pro-
tection by wearing an antistatic wrist strap and attaching it to a metal part of the
system chassis. If a wrist strap is unavailable, establish and maintain contact with
the system chassis throughout any procedures requiring ESD protection.

5User's Manual | CS636
About the Package
The package contains the following items. If any of these items are missing or damaged,
please contact your dealer or sales representative for assistance.
• One CS636-246/CS636-Q370 motherboard
• One I/O shield
• One Serial ATA data cable (Length: 500mm)
• One COM port cable (Length: 300mm)
• One M.2 standoff (M2X4L, M2.5x4.5L)
• Two M.2 screws (I-head, M2x4)
• One Quick Reference
The board and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Optional Items
• USB 2.0 / USB 3.1 cable
• COM cable
• SATA cable
• Thernal Solution (Heat sink and fan)
• DP-to-HDMI dongle
The board and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Before Using the System Board
When installing the system board in a new system, you will need at least the following internal
components.
• CPU
• Memory module
• Storage device such as hard disk drive, CD-ROM, etc.
• Power adaptor
External system peripherals may also be required for navigation and display, including at least
a keyboard, a mouse and a video display monitor.

6User's Manual | CS636
Chapter 1
INTRODUCTION
Chapter 1 - Introduction
XSpecifications
SYSTEM Processor LGA 1151 Socket
8th Generation Intel® Processors:
• Xeon®E-2176G (6 Cores, 12M Cache, up to 4.7 GHz); 80W
• Xeon®E-2124G (4 Cores, 8M Cache, up to 4.5 GHz); 71W
• Core™ i7-8700K (6 Cores, 12M Cache, up to 4.7 GHz); 95W
• Core™ i7-8700 (6 Cores, 12M Cache, up to 4.6 GHz); 65W
• Core™ i7-8700T (6 Cores, 12M Cache, up to 4.0 GHz); 35W
• Core™ i5-8500 (6 Cores, 9M Cache, up to 4.1 GHz); 65W
• Core™ i5-8500T (6 Cores, 9M Cache, up to 3.5 GHz); 35W
• Core™ i3-8100 (4 Cores, 6M Cache, 3.6 GHz); 65W
• Core™ i3-8100T (4 Cores, 6M Cache, to 3.1 GHz); 35W
• Pentium®G5400 (2 Cores, 4M Cache, 3.7 GHz); 58W
• Pentium®G5400T (2 Cores, 4M Cache, 3.1 GHz); 35W
• Celeron®G4900 (2 Cores, 2M Cache, 3.1 GHz); 54W
• Celeron®G4900T (2 Cores, 2M Cache, 2.9 GHz); 35W
9th Generation Intel®Processors:
• Xeon®E-2278GE (8 Cores, 16M Cache, up to 4.7 GHz); 80W
• Xeon®E-2278GEL (8 Cores, 16M Cache, up to 3.9 GHz); 35W
• Xeon®E-2226GE (6 Cores, 12M Cache, up to 4.6 GHz); 80W
• Core™ i9-9900K (8 Cores, 16M Cache, up to 5.0 GHz); 95W
• Core™ i7-9700K (8 Cores, 12M Cache, up to 4.9 GHz); 95W
• Core™ i7-9700E (8 Cores, 12M Cache, up to 4.4 GHz); 65W
• Core™ i7-9700TE (8 Cores, 12M Cache, up to 3.8 GHz); 35W
• Core™ i5-9500E (6 Cores, 9M Cache, up to 4.2 GHz); 65W
• Core™ i5-9500TE (6 Cores, 9M Cache, up to 3.6 GHz); 35W
• Core™ i3-9100E (4 Cores, 6M Cache, 3.7 GHz); 65W
• Core™ i3-9100TE (4 Cores, 6M Cache, to 3.2 GHz); 35W
Note: Xeon®processors only for C246 SKU
Chipset Intel®Q370/C246 Chipset
Memory Four 288-pin DIMM up to 64GB
Dual Channel DDR4 2400/2666MHz
ECC only supported by C246
BIOS SPI 128Mbit
GRAPHICS Controller Intel®HD Gen 9 Graphics
Feature OpenGL 5.0, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG,
HEVC/H265, VP8, VP9
HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9
Display 1 x VGA, resolution up to 1920x1200 @ 60Hz
2 x DP++, resolution up to 4096x2160 @ 60Hz
Triple
Displays
VGA + DP++ + DP++
EXPANSION Interface 1 PCIe x16 or 2 PCIex8 (Gen 3)
2 x PCIe x4 (Gen 3)
3 x PCIe x1 (Gen 3)
1 x M.2 2242/2260/2280 M key (PCIe x4 NVMe, Intel Optane
Memory Support)
1 x M.2 2230 E key (PCIe x2 NVMe, USB 2.0)
AUDIO Audio Codec Realtek ALC888
ETHERNET Controller 1 x Intel®I211AT PCIe (10/100/1000Mbps)
1 x Intel®I219LM PCIe with iAMT12.0 (10/100/1000Mbps)
(only Xeon Core/ i7/i5 supports iAMT)
REAR I/O Ethernet 2 x GbE (RJ-45)
USB 2 x USB 3.1 Gen1
4 x USB 3.1 Gen2
Serial 1 x RS-232/422/485 (RS-232 w/ power) (DB-9)
1 x RS-232
Display 1 x VGA
2 x DP++
Audio 1 x Line-out, 1 x Mic-in, 1 x Line-in (opt.)
INTERNAL I/O Serial 3 x RS-232 (2.54mm pitch)
1 x RS-232/422/485
USB 2 x USB 3.1 Gen1 (Box header)
4 x USB 2.0 (2.54mm pitch) (4 x Pin Header)
Audio 1 x S/PDIF, 1 x Front Audio Header
SATA 4 x SATA 3.0 (2 for double stack connector; 2 for 7 pin SATA
connectors with power)
RAID 0/1/5/10
DIO 1 x 8-bit DIO
SMBus 1 x SMBus
WATCHDOG
TIMER
Output &
Interval
System Reset, Programmable via Software from 1 to 255
Seconds
SECURITY TPM TPM 2.0 (opt., MOQ required)
POWER Type ATX
Connector 8-pin ATX 12V power
24-pin ATX power
RTC Battery CR2032 Coin Cell
OS SUPPORT Windows 10 IoT Enterprise 64-bit
Linux
ENVIRON-
MENT
Temperature Operating: 0 to 60°C
Storage: -30 to 60°C with RTC Battery; -40 to 85°C without RTC
Battery
Humidity Operating: 5 to 90% RH; Storage: 5 to 90% RH
MECHANICAL Dimensions ATX Form Factor: 305mm (12") x 244mm (9.6")

7User's Manual | CS636
Chapter 1
INTRODUCTION
XFeatures
Watchdog Timer
The Watchdog Timer function allows your application to regularly “clear” the system at the set
time interval. If the system hangs or fails to function, it will reset at the set time interval so that
your system will continue to operate.
DDR4
DDR4 delivers increased system bandwidth and improves performance. The advantages of
DDR4 provide an extended battery life and improve the performance at a lower power than
DDR3/DDR2.
Graphics
The integrated Intel®HD graphics engine delivers an excellent blend of graphics performance
and features to meet business needs. It provides excellent video and 3D graphics with out-
standing graphics responsiveness. These enhancements deliver the performance and compat-
ibility needed for today’s and tomorrow’s business applications.
Serial ATA
Serial ATA is a storage interface that is compliant with SATA 1.0a specification. With speed of
up to 6Gb/s (SATA 3.0), it improves hard drive performance faster than the standard parallel
ATA whose data transfer rate is 100MB/s.
Gigabit LAN
Two Intel®Gigabit LAN controllers (Intel®I211AT and Intel®I219LM PCI Express Gigabit Eth-
ernet controllers) support up to 1Gbps data transmission.
Audio
The Realtek ALC888 audio codec provides high-performance of 7.1+2 channel High Definition
audio output.
Wake-On-LAN
This feature allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. It is
supported via the onboard LAN port or via a PCI LAN card that uses the PCI PME (Power Man-
agement Event) signal. However, if your system is in the Suspend mode, you can power-on the
system only through an IRQ or DMA interrupt.
Wake-On-USB
This function allows you to use a USB keyboard or USB mouse to wake up a system from the
S3 (STR - Suspend To RAM) state.
PCI Express
PCI Express is a high bandwidth I/O infrastructure that possesses the ability to scale speeds
by forming multiple lanes. The x4 PCI Express lane supports transfer rate of 4 Gigabyte per
second (2 directions). The PCI Express architecture also supports high performance graphics
infrastructure by enhancing the capability of a PCIe x16 Gen 3 at 16GB/s bandwidth (8GB/s in
each direction).
ACPI STR
The system board is designed to meet the ACPI (Advanced Configuration and Power Interface)
specification. ACPI has energy saving features that enables PCs to implement Power Manage-
ment and Plug-and-Play with operating systems that support OS Direct Power Management.
ACPI when enabled in the Power Management Setup will allow you to use the Suspend to RAM
function.
With the Suspend to RAM function enabled, you can power-off the system at once by pressing
the power button or selecting “Standby” when you shut down Windows®without having to go
through the sometimes tiresome process of closing files, applications and operating system.
This is because the system is capable of storing all programs and data files during the entire
operating session into RAM (Random Access Memory) when it powers-off. The operating ses-
sion will resume exactly where you left off the next time you power-on the system.
Power Failure Recovery
When power returns after an AC power failure, you may choose to either power-on the system
manually or let the system power-on automatically.
USB
The system board supports the new USB 3.1 Gen 2. It is capable of running at a maximum
transmission speed of up to 10 Gbit/s (1.2 GB/s) and is faster than USB 3.1 Gen 1 (5 Gbit/s, or
625 MB/s), USB 2.0 (480 Mbit/s, or 60 MB/s) and USB 1.1 (12Mb/s). USB 3.1 reduces the time
required for data transmission, reduces power consumption, and is backward compatible with
USB 2.0. It is a marked improvement in device transfer speeds between your computer and a
wide range of simultaneously accessible external Plug and Play peripherals.
RTC Timer
The Real Time Clock (RTC) installed on the system board allows your system to automatically
power-on on the set date and time.

8User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
Chapter 2 - Hardware Installation
XBoard Layout
SATA3 SATA 3.0
DOM supported
SATA2 SATA 3.0
DOM supported
M.2 M Key
LPC
1
13
2
113
12 24
Standby
Power
LED
12
1
7
2
9
ATX Power
8
7
2
1
1
19
10
11
USB 3.1 Gen 1
(USB 5/6)
Clear CMOS (JP5)
1
Buzzer
WGI211AT
WGI219LM
Front
Panel
DDR4_1
DDR4_2
DDR4_3
DDR4_4
Socket LGA1151
GL3523
M.2 E Key
2
9
10
1
System
Fan 3
SPI
Flash
BIOS
CPU FAN
SYS FAN 1
SYS FAN 2
1
1
+12V
Power
JP7
JP24
4
8
1
5
SATA Double Stack
SATA 1 (bottom)
SATA 0 (top)
Intel
C246/Q370
PCIe 4 (PCIe x8 open edge)
PCIe 5 (PCIe x1 open edge)
PCIe 6 (PCIe x4)
PCIe 2 (PCIe x16)
PCIe 3 (PCIe x1 open edge)
PCIe 7 (PCIe x1)
14
JP26 JP27 JP23
JP25
JP28 JP31 JP30
Nuvoton
NCT6106D
Realtek
ALC888S
1
S/PDIF
Chassis
Intrusion
1
Front Audio
1
210
1
210
TPM
(optional)
1
2
SMBus
5
11
PTN3355
Battery
1
SPI Programming
Connector
PCIe 1 (PCIe x4 open edge)
Mic-in
Line-out
Line-in (opt.)
Note: Rear I/O listed
from bottom to top
1
2
9
10
1
22
9
JP29 1
1
2
9 1
2
9 1
2
9
1 1 1
1
56
1
56
1
56
1
6
1
5
6
1
5
6
COM 2
COM 1
DP++ (DP2)
VGA
USB 3.1 Gen 2
(USB 1/2)
LAN 1
USB 3.1 Gen 2
(USB 3/4)
LAN 2
DP++ (DP 1)
USB 3.1 Gen 1
(USB 7/8)
USB
9/10
USB 2.0
USB
11/12
LAN
LED Digital I/O (DIO)
System
Fan 4 COM6COM5COM4COM3
Important:
Electrostatic discharge (ESD) can damage your board, processor,
disk drives, add-in boards, and other components. Perform instal-
lation procedures at an ESD workstation only. If such a station is
not available, you can provide some ESD protection by wearing an
antistatic wrist strap and attaching it to a metal part of the system
chassis. If a wrist strap is unavailable, establish and maintain con-
tact with the system chassis throughout any procedures requiring
ESD protection.
Note:
Some components are optional and only available upon request.
Important:
When the Standby Power LED lit red, it indicates that there is pow-
er on the system board. Power-off the PC then unplug the power
cord prior to installing any devices. Failure to do so will cause se-
vere damage to the motherboard and components.
XStandby Power LED
Standby Power LED

9User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
• CS636-C246: Four 288-pin ECC/Non-ECC DIMM up to 64GB
• CS636-Q370: Four 288-pin Non-ECC DIMM up to 64GB
• Dual Channel DDR4 2400/2666 MHz
XSystem Memory
Features
The system board supports the following memory interface.
Single Channel (SC)
Data will be accessed in chunks of 64 bits from the memory channels.
Dual Channel (DC)
Data will be accessed in chunks of 128 bits from the memory channels. Dual channel provides
better system performance because it doubles the data transfer rate.
Single Channel DIMMs are on the same channel. DIMMs in a channel can be identi-
cal or completely different. However, we highly recommend using
identical DIMMs. Not all slots need to be populated.
Dual Channel DIMMs of the same memory configuration are on different channels.
DDR4_1
DDR4_3
DDR4_2
DDR4_4
Before installing the memory module, please make sure that the following safety cautions are
well-attended.
1. Make sure the PC and all other peripheral devices connected to it has been powered
down.
2. Disconnect all power cords and cables.
3. Locate the DIMM socket on the system board
4. Make sure the notch on memory card is aligned to the key on the socket.
Socket Side View
Socket Top View
DDR4 DIMM
Notch
Key
Eject TabEject Tab
Step 3
Step 2
Step 1 Step 1
Step 2
Step 3
Socket Side View
Socket Top View
DDR4 SO-DIMM
Key
Eject TabEject Tab
Step 3
Step 2
Step 1
Step 1
Step 2
Step 3
Notch
Retention Notch
XSystem Memory
Installing the DIMM Module

10User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
Please follow the steps below to install the memory card into the socket.
Step 1:
Press the eject tabs at both ends of the socket outward and downward to release them from
the locked position.
Step 2:
Insert the memory card into the slot while making sure the notch and the key are aligned.
Press the card down firmly with fingers while applying and maintaining even pressure on both
ends.
Step 3:
The tabs snap automatically to the edges of the card and lock the card in place.
Socket Side View
Socket Top View
DDR4 DIMM
Notch
Key
Eject TabEject Tab
Step 3
Step 2
Step 1
Step 1
Step 2
Step 3
Socket Side View
Socket Top View
DDR4 SO-DIMM
Key
Eject TabEject Tab
Step 3
Step 2
Step 1
Step 1
Step 2
Step 3
Notch
Retention Notch
XSystem Memory
XInstalling the DIMM Module
Socket Side View
Socket Top View
DDR4 DIMM
Notch
Key
Eject TabEject Tab
Step 3
Step 2
Step 1
Step 1
Step 2
Step 3
Socket Side View
Socket Top View
DDR4 SO-DIMM
Key
Eject TabEject Tab
Step 3
Step 2
Step 1
Step 1
Step 2
Step 3
Notch
Retention Notch
Please follow the steps below to remove the memory card from the socket.
Step 1:
Press the eject tabs at both ends of the socket outward and downward to release them from
the locked position.
Step 2:
The memory card ejects from the slot automatically.
Step 3:
Hold the card by its edges and remove it from the slot.
XSystem Memory
Removing the DIMM Module

11User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
XCPU
The system board is equipped with a surface mount LGA 1151 socket. This socket is exclu-
sively designed for installing a LGA 1151 packaged Intel CPU.
Protective cap
Note:
The system board used in the following illustrations may not resemble the actual
board. These illustrations and photos are for reference only.
Important:
1. Before you proceed, make sure (1) the LGA 1151 socket comes with a protec-
tive cap, (2) the cap is not damaged and (3) the socket’s contact pins are not bent.
If the cap is missing or the cap and/or contact pins are damaged, contact your
dealer immediately.
2. Make sure to keep the protective cap. RMA requests will be accepted and pro-
cessed only if the LGA 1151 socket comes with the protective cap.
Installing the CPU
1. Make sure the PC and all other peripheral devices connected to it have been powered
down.
2. Disconnect all power cords and cables.
3. Locate the LGA 1151 CPU socket on the system board.
4. Unlock the socket by pressing
the load lever down, moving it
sideways until to escape the
retention tab. Lift the load lever
up when it’s released.
Retention tab
Load lever
Important:
The CPU socket must not come in contact with anything other than the CPU. Avoid
unnecessary exposure. Remove the protective cap only when you are about to in-
stall the CPU.

12User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
6. Remove the protective cap from
the CPU socket. The cap is
used to protect the CPU socket
against dust and harmful par-
ticles. Remove the protective
cap only when you are about to
install the CPU.
5. Lift the load lever and the load
plate all the way up as shown in
the photo.
Load lever
Load
plate
Protective cap
7-1.Insert the CPU into the
socket. The gold tri-
angular mark on the
CPU must align with
the chamfer corner of
the CPU socket shown
in the photo.
Golden triangular
mark
XCPU
XInstalling the CPU
Important:
The CPU will fit in only one orientation and can easily be seated without exerting
any force.
7-2.Two keys on the sock-
et and notches on the
CPU also facilitate
alignment.
7-3.The CPU’s notch will
fit into the socket’s
alignment key when it’s
seated in the correct
orientation.
Alignment key
Alignment key
XCPU
XInstalling the CPU
8. Close the load plate
then push the load le-
ver down.
While closing the load
plate, make sure the
front edge of the load
plate slides under the
retention knob.
9. Press down the load
lever and hook it under
the retention tab.
Retention knob
Load lever

13User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
Installing the Fan and Heat Sink
The CPU must be kept cool by using a CPU fan with heat sink. Without sufficient air circula-
tion across the CPU and heat sink, the CPU will overheat damaging both the CPU and system
board.
1. Before you install the fan / heat sink, you must apply a thermal paste onto the top of
the CPU. The thermal paste is usually supplied when you purchase the fan / heat sink
assembly. Do not spread the paste all over the surface. When you later place the heat
sink on top of the CPU, the compound will disperse evenly.
Some heat sinks come with a patch of pre-applied thermal paste. Do not apply thermal
paste if the fan / heat sink already has a patch of thermal paste on its underside. Peel
the strip that covers the paste before you place the fan / heat sink on top of the CPU.
2. Place the heat sink on top of the CPU. The 4 spring screws around the heat sink, which
are used to secure the heat sink onto the system board, must match the 4 mounting
holes around the socket.
3. Orient the heat sink so that the CPU fan’s cable is nearest the CPU fan connector.
XCPU
4. Screw tight two of the spring screws at opposite corners into the mounting holes. And
then proceed with the other two spring screws.
Heat sink
“Locked” position of
push-pin
5. Connect the CPU fan’s cable to the CPU fan connector on the system board.
“Unlocked” position of push-pin
Note:
A boxed Intel®processor already includes the CPU fan and heat sink assembly. If
your CPU was purchased separately, make sure to only use Intel®-certified fan and
heat sink.
Mounting
holes
CPU fan
connector

14User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
XJumper Settings
Clear CMOS
JP5
If any anomaly of the followings is encountered —
a) CMOS data is corrupted;
b) you forgot the supervisor or user password;
c) failure to start the system due to BIOS mis-configuration
— it is suggested that the system be reconfigured with default values stored in the ROM BIOS.
To load the default values stored in the ROM BIOS, please follow the steps below.
1. Power-off the system and unplug the power cord.
2. Put a jumper cap on pin 2 and pin 3. Wait for a few seconds and set it back to its de-
fault setting, i.e. jumper cap on pin 1 and pin 2.
3. Plug the power cord and power-on the system.
2-3 On: Clear CMOS1-2 On: Normal (default)
31 2 31 2
RS232 Power Select
All the six COM ports support the three power configurations — Standard RS232 (default),
RS232 with 5V power, RS232 with 12V power. These power modes are configured via jumper
settings as illustrated. Each of the 6-pin jumpers corresponds to one of the COM ports — JP24
(COM1), JP7 (COM2), JP25 (COM3), JP23 (COM4), JP26 (COM5), JP27 (COM6).
3-4 On: Standard
RS232 (default)
5-6 On: 5V
power
1-2 On: 12V
power
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
JP7 (COM 2)
JP25 (COM 3)
JP26 (COM 5)
JP27 (COM 6)
JP23 (COM 4)
JP24 (COM 1)

15User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
JP28 is used to select the power of Digital I/O: +5VDU (default) or +5V. The Digital I/O can be configured to use the power bus of the Digital I/O connector for power
supply or not. JP30 is used to select for DIO0~DIO3. JP31 is used to select for DIO4~DIO7.
Digital I/O (DIO) Power SupplyDigital I/O (DIO) Power Select
1-2 On: +5VDU (default) 1-2 On: DIO power used (default)2-3 On: +5V 2-3 On: GND
XJumper Settings
XJumper Settings
3
1
2
3
1
2
3
1
2
3
1
2
JP31
JP28
JP30
11 1

16User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
The PCIe x16 channel can be configured as one PCIe x16 slot or two PCIe x8 slots via a jump-
er, i.e. JP29. The configurations are listed and illustrated below.
JP29
PCIe 2 Slot PCIe x16 PCIe x8
PCIe 4 Slot disabled PCIe x8
PCIE2 Signal Select
XJumper Settings
31 2 31 2
JP29
2-3 On: Two PCIe x81-2 On: One PCIe x16

17User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
XRear I/O Ports
VGA
DP 2 (DP++)
Line-out
Line-in (optional)
Mic-in
USB 4 (USB 3.1 Gen 2)
LAN 2
USB 2 (USB 3.1 Gen 2)
LAN 1
USB 3 (USB 3.1 Gen 2)USB 1 (USB 3.1 Gen 2)
COM 1
COM 2
USB 8 (USB 3.1 Gen 1)
USB 7 (USB 3.1 Gen 1)
DP 1 (DP++)
Rear I/O Connectors
PCB
I/O Connectors
Graphics Display
The display ports consist of the following:
• 1 VGA port
• 2 DP++ ports
VGA Port
The VGA port is used for connecting a VGA monitor. Connect the monitor’s 15-pin D-shell cable
connector to the VGA port. After you plug the monitor’s cable connector into the VGA port, gen-
tly tighten the cable screws to hold the connector in place.
DP++ Port
The DP++ port which carries both digital audio and video signals is used to connect a LCD
monitor or a digital TV that has the DP++ port.
Driver Installation
Install the graphics driver. Refer to the chapter 4 for more information.
VGA (DB15)
DP 2 (DP++)
DP 1 (DP++)

18User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
When set to RS232, power supply modes — standard RS232, RS232 with +5V, or RS232 +12V —
can be configured via jumper settings as instructed in previous sections in this chapter.
Connecting External Serial Ports
Your COM port may come mounted on a card-edge bracket. Install the card-edge bracket to
an available slot at the rear of the system chassis then insert the serial port cable to the COM
connector. Make sure the colored stripe on the ribbon cable is aligned with pin 1 of the COM
connector.
BIOS Setting
Configure the serial COM ports in the Advanced menu (“NCT6116D Super IO Configuration” >
“Serial Port Configuration”) on the BIOS. Refer to the chapter 3 for more information.
Jumper Setting
RS232 with or without power can be configured via jumper settings as previously instructed in
the RS232 Power Select section.
COM (Serial) ports
COM 1 (DB9)
COM 2 (DB9)
Internal Ports COM 3-6
(from left to right)
The serial ports are asynchronous communication ports with 16C550A-compatible UARTs that
can be used with modems, serial printers, remote display terminals, and other serial devices.
COM 1 (Rear Port) and COM 3 (Internal Port) support three serial modes, i.e. RS232, RS422,
and RS485. COM 2 (Rear Port) and COM 4 - 6 (Internal Ports) support only RS232 as summa-
rized in the table below. Serial modes of all the COM ports are configured via BIOS settings as
instructed in the BIOS chapter.
The pin assignment of each mode mentioned above is listed below.
RS232 Standard RS232 with +5V/+12V RS422 RS485
Pin DB9 Box header DB9 Box header DB9 Box
header DB9 Box header
1DCD DCD DCD DCD TX- TX- D- D-
2SIN DSR SIN DSR TX+ N.C. D+ N.C.
3SOUT SIN SOUT SIN RX+ TX+ N.C. D+
4DTR RTS DTR RTS RX- N.C. N.C. N.C.
5GND SOUT GND SOUT GND RX+ GND N.C.
6DSR CTS DSR CTS N.C. N.C. N.C. N.C.
7RTS DTR RTS DTR N.C. RX- N.C. N.C.
8CTS RI CTS +5V/+12V N.C. N.C. N.C. N.C.
9RI GND +5V/+12V GND N.C. GND N.C. GND
COM Port Pin Assignment
COM Port’s Serial Mode Availability
COM Port RS232 RS422 RS485
1 O O O
2 O X X
3 O O O
4 O X X
5 O X X
6 O X X
XRear I/O Ports
19
2

19User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
RJ45 LAN Ports
• LAN1: Intel®I219LM LAN Phy with iAMT12.0 (only supported by Core i7/i5)
• LAN2: Intel®I211AT PCIe
LAN 2 (RJ45)LAN 1 (RJ45)
The LAN port allows the system board to connect to a local area network (LAN) by means of a
network hub.
BIOS Setting
Configure the onboard LAN ports in the Chipset menu (“PCH-IO Configuration” submenu) of the
BIOS. Refer to the chapter 3 for more information.
Driver Installation
Install the LAN drivers. Refer to the chapter 4 for more information.
Features
XRear I/O Ports

20User's Manual | CS636
Chapter 2
HARDWARE INSTALLATION
USB Ports
The USB device allows data exchange between your computer and a wide range of simultane-
ously accessible external Plug and Play peripherals. The system board is equipped with mul-
tiple USB ports as listed below:
• 4 x USB 2.0 internal ports, pin headers (USB 9/10 & 11/12)
• 2 x USB 3.1 Gen 1 rear ports (USB 7/8)
• 2 x USB 3.1 Gen 1 internal ports, box headers (USB 5/6)
• 4 x USB 3.1 Gen 2 rear ports (USB 1/2/3/4)
BIOS Setting
Configure these onboard USB devices in the Advanced menu (“USB Configuration” submenu) of
the BIOS. Refer to the chapter 3 for more information.
Driver Installation
You may need to install the proper drivers in your system operation to use the USB device. Re-
fer to your operating system’s manual or documentation for more information.
The internal USB ports may be mounted on a card-edge bracket. Install the card-edge bracket
to an available slot at the rear of the system chassis and then insert the USB port cables to a
connector.
Wake-On-USB Keyboard/Mouse
The Wake-On-USB Keyboard/Mouse function allows you to use a USB keyboard or USB mouse
to wake up a system from the S3 (STR - Suspend To RAM) state.
USB 4 (USB 3.1 Gen 2)USB 2 (USB 3.1 Gen 2)
USB 3 (USB 3.1 Gen 2)USB 1 (USB 3.1 Gen 2)
USB 9/10 (left) & 11/12 (right)
(USB 2.0)
1
210
9
USB 5/6 (USB 3.1 Gen 1)
1
1011
19
USB 8 (USB 3.1 Gen 1)
USB 7 (USB 3.1 Gen 1)
Pin Assignment Pin Assignment
1VCC 2VCC
3D- 4D-
5D+ 6D+
7GND 8GND
9KEY 10 N.C.
Pin Assignment Pin Assignment
1PWR 11 D2+
2SSRX1- 12 D2-
3SSRX1+ 13 GND
4GND 14 SSTX2+
5SSTX1- 15 SSTX2-
6SSTX1+ 16 GND
7GND 17 SSRX2+
8D1- 18 SSRX2-
9D1+ 19 PWR
10 N.C. 20 Key
USB 2.0 Box Headers USB 3.1 Box Headers
XRear I/O Ports
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB ports, the
+5V_standby power source of your power supply must support ≥1.5A. For 3 or
more USB ports, the +5V_standby power source of your power supply must support
≥2A.
