dg casa 12350-Q User manual

ARGO STORAGE BED
ASSEMBLY INSTRUCTION
12350-Q / 12350-K

WARNING
Seller and Manufacturer disclaim all and any liability for
property damage, personal injury, or loss, direct, indirect, or
incidental, resulting from the incorrect assembly, inadequate
maintenance, improper use, or neglect of this product.
Request a replacement by logging into the marketplace
account in which the purchase was made and sending a
message to the seller. To assist in expediting the request
attach applicable images relevant to the request and/or
part number and quantity.
• Keep these assembly intructions for future reference.
• Do not use this product if there are missing parts,
damaged, or broken until repairs are made and/or factory
replacement parts are installed.
• Check all packing material carefully for small hardware
that may have become loose inside the carton
during shipment.
• Identify and count all hardware and parts to compare with
parts and hardware list.
• Follow assembly instructions closely. Improper assembly
can result in personal or property damage.
• Secure all bolts and screws before use.
• Every 90 days check all bolts and screws are secured.
• Some parts may have sharp corner or edges and may
be heavy.
• Do not use or store this product near open flames or
around flammable chemicals.
• When placing contents on non-carpeted flooring, it’s
recommended to use floor protection such as an area rug
or furniture pads. These are not included with the purchase.
NOTICE
REPLACEMENT PART OR HARDWARE REQUEST:
TOOLS REQUIRED:
ALLEN WRENCH
(PROVIDED)
PHILLIPS SCREWDRIVER
(NOT PROVIDED)
HAMMER/MALLET
(NOT PROVIDED)

HARDWARE
SPRING WASHER
6 PCS
M6 x 40
3 PCS
M6 x 50
9 PCS ALLEN KEY 100MM
1 PC
ALLEN KEY 70MM
1 PC
SUPPORT LEG ADJUSTER
3 PCS
WOOD DOWEL
8 PCS
DRAWER STOPPER
8 PCS
CASTER
16 PCS
SCREW
16MM
64 PCS
SCREW
25MM
8 PCS
SCREW
32MM
46 PCS
SCREW
50MM
32 PCS
5
9
11 12
10
13
6 7 8
21 3 4

ARGO STORAGE BED PARTS
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
HEADBOARD 1 PC
FOOTBOARD 1 PC
SIDE RAIL 2 PCS
HEADBOARD LEG 2 PCS
FOOTBOARD
SIDE LEG 2 PCS
FOOTBOARD
CENTER LEG 1 PC
SIDE RAIL SUPPORT LEG 4 PCS
DRAWER FRONT PANEL 4 PCS
DRAWER BACK PANEL 4 PCS
DRAWER LEFT SIDE
PANEL 4 PCS
DRAWER RIGHT SIDE
PANEL 4 PCS
DRAWER BOTTOM
PANEL 4 PCS
DRAWER BOTTOM
PANEL BIG SUPPORT
WOOD 8 PCS
DRAWER BOTTOM
PANEL SMALL SUPPORT
WOOD 4 PCS
SLAT 3 PCS
SUPPORT LEG 3 PCS

FABRIC PANEL INDICATES
FRONT OF DRAWER
BOTTOM DRAWER VIEWSTEP 2STEP 1
8x8
KM
J
L
7
O
PJ
O
N
x10
TAPPED HOLE INDICATES
BACK OF DRAWER
BOTTOM DRAWER VIEW
13
5
ALIGN CASTER MOUNTING
HOLE TO NOTCHES ON
PART O THEN INSTALL CASTER
x16
BOTTOM DRAWER VIEW
N
J
STEP 4STEP 3
ASSEMBLY INSTRUCTION
N
SLIDE PART N TOWARDS THE FRONT DRAWER

3
92
D
E2
3
B
AD
F
STEP 5
x6 2
3
*BACK OF HEADBOARD
STEP 6
11
C
LIGHTLY TAP INTO PLACE
x2
11
STEP 7
6
I
C
x2
ATTACH PART I BY ALIGNING PRECUT HOLES LOCATED ON
ONE SIDE OF THE PART TO PART 11, THEN INSTALL PART ITO PART C
11

A
C
B
x4
12
x8
STEP 8
STEP 9

10
3
1
G
H
STEP 10
ROTATE PART 10 CLOCKWISE OR COUNTER CLOCKWISE
TO ADJUST SLAT HEIGHT FOR PROPER BOX SPRING SUPPORT
4
7
STEP 11
x6
SCREW SLAT ONTO
WOOD SLAT
SUPPORT ON
THE SIDE RAIL
