dg casa 95200-DSR User manual

3 + 3 DRAWER CHEST
95200-DSR

MAX : 11 lbs
MAX : 66 lbs

IMPORTANT INFORMATION
Seller and Manufacturer disclaim all and any liability for
property damage, personal injury, or loss, direct, indirect, or
incidental, resulting from the incorrect assembly, inadequate
maintenance, improper use, or neglect of this product.
Request a replacement by logging into the marketplace
account in which the purchase was made and sending a
message to the seller. To assist in expediting the request
attach applicable images relevant to the request and/or
part number and quantity.
Keep these assembly instructions for future reference.
Do not use this product if there are missing, damaged,
or broken parts until repairs are made and/or factory
replacement parts are installed.
Check all packing material carefully for small hardware
that may have become loose inside the carton
during shipment.
Identify and count all hardware and parts to compare with
parts and hardware list.
Follow assembly instructions closely. Improper assembly
can result in personal or property damage.
Secure all bolts before use.
Every 90 days check all bolts are secured.
Some parts may have a sharp corner or edge and may
be heavy.
Do not use or store this product near open flames or
around flammable chemicals.
When placing contents on non-carpeted flooring, it’s
recommended to use floor protection such as an area rug
or furniture pads. These are not included with the purchase.
NOTICE
REPLACEMENT PART OR HARDWARE REQUEST:

HARDWARE & TOOL PARTS
HARDWARE REQUIRED:
TOOLS REQUIRED:
HEX WRENCH
MINIFIX X 39 PCS
UNITAR SCREW (6.3 X 40)
X 2 PCS
EURO SCREW (6X9) BACKPLY STOPPER
X 12 PCSX 24 PCS
DRAWER SLIDE (300MM)
X 6 SETS
PAN HEAD SCREW
(M4 X 16) X 1 PCS
PAN HEAD SCREW
(M4 X 52) X 1 PCS
WALL PLUG
(25MM) X 1 PCS
CSK SCREW (3.5 X 15)
X 24 PCS
CSK SCREW (M4.7 X 38)
CSK SCREW (M3.1 X 20)
X 12 PCS
X 24 PCS
CAM 12/15 X 41
PCS
DOUBLE MINIFIX
X 1 PCS
WOOD DOWEL (O6 X 30)
X 89 PCS
(PROVIDED)
L-MOUNTING BRACKET
X 1 PCS
(R)
(R)
(L)
(L)
1
5
8
6
9
7
10
11 12 13
14 15
NAIL LEG X 5 PCS
16
2 3 4
PH1 SCREW DRIVER
(PROVIDED)

3 + 3 DRAWER CHEST PARTS
A........Side Panel...............x 1
B........Side Panel...............x 1
C ........Partition Panel.........x 1
D........Top Panel................x 1
E........Bottom Panel...........x 1
F ........Back Support ..........x 2
G........Front Support..........x 4
H........Bottom Support.......x 1
I ........Front Leg (L)...........x 1
J ........Front Leg (R)...........x 1
K........Front Panel (T)........x 1
L ........Front Panel (B)........x 1
M........Drawer Front...........x 1
N ........Drawer Front...........x 1
O ........Drawer Front...........x 2
P ........Drawer Front...........x 2
T ........Drawer Support........x 6
Y........Backply (L) ..............x 2
Y1........Backply (R)..............x 2
Q........Drawer Side (L)........x 6
R........Drawer Side (R).......x 6
S........Drawer Back............x 6
Z........Drawer Bottom.........x 6
I
K
T
N
M
O
O
P
P
SR
Z
Q
L
J
A
C
E
G
G
G
G
H
B
D
Y1
Y1
Y
YF
F
Q
Q
Q
R

3+3 DRAWER CHEST ASSEMBLY - STEP 1
Insert all wood dowel in each panel as shown.
Note: Make sure all the dowel are insert into all panel without missing any hole.
x 89
Wood Dowel (O6x30mm)
C
F
Q
R
T
E
H
G
4
X2
X6
X6
X6
X4
B
A
K

Insert Minifix on each panel and insert Pan Head screw with L-Mounting Bracket on
Top Panel then use a screw driver to tighten up all.
Note: Do not over tighten the Minifix it will cause issues when assemble all panel.
x 39
Minifix
L
B
D
N
M
P
O
A
J
I
1
3+3 DRAWER CHEST ASSEMBLY - STEP 2
L-Mounting Bracket
x 1 x 1
FPan Head Screw
(M4 X16)
1312
X2
X2

Attached drawer slide on Side panel A and B also Partition panel C then insert Euro
screw and tighten using a screw driver.
Note: Make sure to insert the euro screw into the right hole so the drawer slide
is in correct position.
Euro Screw (6 x 9)
x 24 x 6 SETS
FDrawer Slide (300mm) 118
(R)(L)
CC
B
A
3+3 DRAWER CHEST ASSEMBLY - STEP 3
(L)
(R)
(L)
(R)

Attached drawer side R to drawer back S and use Csk screw and tighten it with a screw
driver and repeat for drawer side Q.
IMPORTANT: Fully tighten all Csk screw on all 6 drawer.
x 24
Csk Screw (M4.7 X 38)
S
R
Q
X6
3+3 DRAWER CHEST ASSEMBLY - STEP 4
7

T
Z
3+3 DRAWER CHEST ASSEMBLY - STEP 5
Insert the Drawer bottom Z first and then next insert the Drawer support T.
IMPORTANT : Make sure panel T and Drawer bottom Z were inserted onto drawer
back for all 6 drawer.
X6

Attach Drawer Front M,N,O,P on the drawer and insert Cam (12/15) on each side of the
drawer side and tighten it with screw driver.
Note: Make sure to refer the picture were shown how to position the Cam correctly.
x 12
Cam (12/15)
2
M
N
O
P
3+3 DRAWER CHEST ASSEMBLY - STEP 6
X6

Attach Drawer slide (300mm) and make sure the drawer slide is in right position as shown
then use ph1 screw driver to tighten Csk screw (3.5 X 15).
Note: Repeat the same step for all 6 drawer and make sure to put the drawer slide
in the right position.
Csk Screw (3.5 X 15)
x 24 x 6 Sets
Drawer Slide (300mm)
116
(R)
(L)
3+3 DRAWER CHEST ASSEMBLY - STEP 7
X6
R
(L) (R)

Attach Partition panel C to Bottom panel E, then insert Unitar screw and tighten it with a
Hex wrench.
Note: Make sure do not over tighten the unitar screw.
x 2
Unitar Screw (6.3 X 40)
5
C
E
3+3 DRAWER CHEST ASSEMBLY - STEP 8

Attach Front Panel L to bottom panel E and insert Cam (12/15) on each hole then tighten
it with screw driver.
x 3
Cam (12/15)
2
3+3 DRAWER CHEST ASSEMBLY - STEP 9
L
E
Note: Make sure to refer the picture were shown how to position the Cam correctly.

3+3 DRAWER CHEST ASSEMBLY - STEP 10
Attach Front leg I to side panel A and insert Cam (12/15) then tighten it with screw
driver, repeat the step for Front leg J and side panel B.
x 6
Cam (12/15)
2
Note: Make sure to refer the picture were shown how to position the Cam correctly.
A
I
J
B

Insert Double minifix on the Partition panel C as shown.
Note: Make sure the end of the double minifix is balance on left and right side.
Double Minifix
x 1
3
3+3 DRAWER CHEST ASSEMBLY - STEP 11
C

3+3 DRAWER CHEST ASSEMBLY - STEP 12
F
G
C
G
x 1
Cam (12/15)
2
Attach Front support G on Partition panel C and Bottom support H , attach Back support
F and insert Cam (12/15) then tighten it with screw driver.
Note: Make sure to refer the picture were shown how to position the Cam correctly.
H

B
J
K
3+3 DRAWER CHEST ASSEMBLY - STEP 13
x 4
Cam (12/15)
2
Attach Side panel B along side Front panel K and insert Cam (12/15) then
tighten it with screw driver.
Note: Make sure to refer the picture were shown how to position the Cam correctly.

3+3 DRAWER CHEST ASSEMBLY - STEP 14
x 1
Cam (12/15)
2
Attach Front support G on Partition panel C, attach Back support F and insert Cam
(12/15) then tighten it with screw driver.
Note: Make sure to refer the picture were shown how to position the Cam correctly.
F
G
G

A
I
3+3 DRAWER CHEST ASSEMBLY - STEP 15
x 4
Cam (12/15)
2
Attach Side panel A and Front leg I and insert Cam (12/15) then tighten it with screw driver.
Note: Make sure to refer the picture were shown how to position the Cam correctly.
