Digi Hubport Series User manual

Hubport®
USB Hub
Installation Guide

Revision history—90000664
Revision Date Description
D January 2009 Updated homologation information.
E April 2009 Added China RoHS information.
F January 2010 Updated specification information.
G September 2017 Updated branding and added documentation for Hubport/Super
Speed.
H October 2018 Updated references to SuperSpeed.
Trademarks and copyright
Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United
States and other countries worldwide. All other trademarks mentioned in this document are the
property of their respective owners.
© 2018 Digi International Inc. All rights reserved.
Disclaimers
Information in this document is subject to change without notice and does not represent a
commitment on the part of Digi International. Digi provides this document “as is,” without warranty of
any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or
merchantability for a particular purpose. Digi may make improvements and/or changes in this manual
or in the product(s) and/or the program(s) described in this manual at any time.
Warranty
To view product warranty information, go to the following website:
www.digi.com/howtobuy/terms
Send comments
Documentation feedback: To provide feedback on this document, send your comments to
[e-mail].
Customer support
Digi Technical Support: Digi offers multiple technical support plans and service packages to help our
customers get the most out of their Digi product. For information on Technical Support plans and
pricing, contact us at +1 952.912.3444 or visit us at www.digi.com/support.
Hubport® USB Hub Installation Guide 2

Contents
Get started
Introduction to Hubs 5
Connect to your Hubport 6
Installing Hubport drivers 6
Hardware specifications and device LEDs
Hubport/4c/7c and Hubport/4c/7c DC (Industrial) 8
Hubport/14 8
Hubport/SuperSpeed 9
Hubport® USB Hub Installation Guide 3

Get started
Introduction to Hubs 5
Connect to your Hubport 6
Installing Hubport drivers 6
Hubport® USB Hub Installation Guide 4

Get started Introduction to Hubs
Hubport® USB Hub Installation Guide 5
Introduction to Hubs
This installation guide covers the following models:
nHubport/4c
nHubport/7c
nHubport/4c DC
nHubport/7c DC
nHubport/14
nHubport/SuperSpeed
Thank you for purchasing the Hubport, a self-powered Universal Serial Bus (USB) hub designed to
provide a convenient and effective means of bringing USB connectivity to your PC, server, or laptop.
Hubs, which are critical components in the USB architecture, are wiring concentrators that enable the
attachment of multiple devices, thus converting a single attachment point into multiple attachment
points. USB architecture allows a cascaded multiple hub configuration with certain power limitations
(explained later in this section).
Digi’s Edgeport product, which is a USB-to-serial converter, can be connected to your Hubport device,
enabling you to install one or more Edgeports.
See the following figure.
Example of a typical hub configuration
Each hub has an upstream port, connecting to the host, and multiple downstream ports, connecting to
downstream devices, possibly including other hubs. A hub can detect attachment and detachment of
downstream devices and enable and monitor the distribution of the power to downstream devices via
their integral hardware and the operating system.
Each USB device reports its power requirements to the operating system, which then enables and
disables the device as a function of its power requirements and the amount of available power. High-
powered devices typically need to be connected to a self-powered hub, such as the Hubport, which
obtains power from its external power supply and provides up to 500 mA for each downstream port.
Only low-powered devices, such as a mouse, can be connected to a bus-powered hub, which obtains
power from its upstream host and provides up to 100 mA for each downstream port.
Due to the limited available power for bus-powered hubs, cascading two bus-powered hubs is an
illegal topology, and devices connected to the second hub will not function. USB specifications limit the
connection of a bus-powered hub to a self-powered hub or host only. All Hubports, except the
Hubport/4c in bus-powered mode, operate as self-powered hubs, and are not affected by this
limitation.

Get started Connect to your Hubport
Hubport® USB Hub Installation Guide 6
According to the USB specification, the maximum limit of hubs cascaded in a series cannot exceed five.
In other words, you may have a maximum of five hubs between any device and the host. This does not
mean that the maximum number of hubs in a system is five; up to seven hubs can be connected
parallel at any given level.
You must tally both external and embedded hubs when counting downstream hubs.
Connect to your Hubport
To connect the cables included with your Hubport:
1. Plug one end of the power supply into the back of your Hubport and the other end into an AC
outlet.
Note Power to this product may be supplied by a UL Listed Direct Plug-In Power Unit marked
“Class 2” with a minimum rating listed in the Hardware specifications and device LEDs section
if used in the U.S. and Canada, or you use a power supply with a similar rating approved by
your local safety code, in other locations.
2. Connect the Hubport device to a PC or standard USB device.
nTo connect the Hubport to a PC, plug the Type A end of the USB cable into one end of
the PC's USB Type A slots and the Type B end of the USB cable into the back of the
Hubport.
nTo connect the Hubport to a standard USB device, plug the Type A end of the USB cable
into the Hubport and the Type B end into the device.
3. DC power/polarity:
nFor units equipped with a pigtail connection, follow the polarity markings on the cable.
nHubport/SuperSpeed units may be equipped with a removable terminal connec tor for
DC power. Follow the polarity marking on the device.
Current Hubport models
Legacy and obsolete Hubports
Installing Hubport drivers
Once you have connected the Hubport hardware, the operating system will detect the Hubport device
and will provide a notification that it is installing the Hubport drivers.
After the driver installation is complete, your new communication ports are ready and are numbered
sequentially following the existing ports in your system.

Hardware specifications and device LEDs
Hubport/4c/7c and Hubport/4c/7c DC (Industrial) 8
Hubport/14 8
Hubport/SuperSpeed 9
Hubport® USB Hub Installation Guide 7

Hardware specifications and device LEDs Hubport/4c/7c and Hubport/4c/7c DC (Industrial)
Hubport® USB Hub Installation Guide 8
Hubport/4c/7c and Hubport/4c/7c DC (Industrial)
Dimensions
Length: 2.61 in (6.63 cm)
Width: 3.00 in (7.62 cm)
Height: 1.00 in (2.54 cm)
Weight: 6.20 oz. (175.80 g)
Environmental
nHubport/4c/7c:
Operating temperature: 0° C F to 55° C (32° F to 131° F)
Relative humidity: 0% to 95% (non-condensing)
nHubport/4c/7c DC (Industrial)
Operating temperature: -40° C to 70° C (-40° F to 158° F )
Relative humidity: 0% to 95% (non-condensing)
Power requirements
nThe Hubport/4c/7c requires 5.0 VDC @ 15 W.
nThe Hubport/4c/7c DC requires 5.5 V to 30 VDC @ 15 W.
Hardware interface features
The unit provides a single upstream (standard B-type receptacle) and 4/7 downstream (standard A-
type receptacles) USB 2.0 compliant ports. The unit will attach to the upstream device as a full/high-
speed hub. The downstream ports support low-speed, full-speed and high-speed downstream devices.
Each downstream facing port provides a green LED status indicator. Color definitions are as follows:
Off Port out of operation.
Green Port fully operational.
The unit features a green system status LED with the following color definitions:
Off Unit out of operation.
Green Unit is powered.
Hubport/14
Dimensions
Length: 4.97 in (12.62 cm)
Width: 17.00 in (43.18)
Height: 1.74 in (4.42 cm)
Weight: 35.00 oz. (1134 g)
Environmental
Operating temperature: 32° F to 131° F (0° C to 55° C)
Relative humidity: 0% to 95% (non-condensing)

Hardware specifications and device LEDs Hubport/SuperSpeed
Hubport® USB Hub Installation Guide 9
Power requirements
The Hubport/14 uses a single 120/230 VAC 50/60 Hz power input through the rear IEC 60320 inlet.
The maximum power requirement of the Hubport/14 is 40 W.
WARNING! HAZARDOUS VOLTAGE(Hubport/14 only). This unit contains an internal power
supply. Before servicing the device, make sure the power is disconnected.
Hardware interface features
The unit provides a single upstream (standard B-type receptacle) and 14 downstream (standard A-
type receptacles) USB 2.0 compliant ports. The unit will attach to the upstream device as a full/high-
speed hub. The downstream ports support low-speed, full-speed and high-speed downstream devices.
Each downstream facing port provides a green LED status indicator. Color definitions are as follows:
Off Port out of operation.
Green Port fully operational.
Blinking off/green Port needs attention.
The unit features a green system status LED with the following color definitions:
Off Unit out of operation.
Green Unit is powered.
Hubport/SuperSpeed
Dimensions
Length: 2.61 in (6.63 cm)
Width: 3.00 in (7.62 cm)
Height: 1.00 in (2.54 cm)
Weight: 6.20 oz. (175.80 g)
Environmental
Operating temperature: -40° F to 158° F (-40° C to 70° C)
Relative humidity: 0% to 95% (non-condensing)
Power requirements
The Hubport/SuperSpeed requires 6 V to 28 VDC. The maximum power requirement of the
Hubport/SuperSpeed is 35 W.
Hardware interface features
The unit provides a single upstream (standard B-type receptacle) and 7 downstream (standard A-type
receptacles) USB 3.0 compliant ports. The unit will attach to the upstream device as a
full/high/SuperSpeed hub. The downstream ports support full-speed, high-speed, and SuperSpeed
(Gen 1) downstream devices.
Each downstream facing port provides a dual LED status indicator. Color definitions are as follows:

Hardware specifications and device LEDs Hubport/SuperSpeed
Hubport® USB Hub Installation Guide 10
Off Port out of operation.
Blue SuperSpeed (Gen 1).
Yellow Full/high speed.
The unit features a green system status LED with the following color definitions:
Off Unit out of operation.
Green Unit is powered.
