Digimerge DPV14W User manual

V I S I O N
POLARIS
model: DPV14W

- ii -
WARNINGS AND CAUTIONS:
CAUTION:
CAUTIONCAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel before operating it any further.
Unplug the unit from the wall oulet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials(curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the
rear panel are for special adjustments by qualified
personnel only.
Do not install the unit in an extremely hot or
humid place or in a place subject to excessive
dust, mechanical vibration.
The unit is not designed to be waterproof.
Exposure to rain or water may damage the unit.
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use
strong solvents such as thinner or benzine as
they might damage the finish of the unit.
Retain the original carton and packing
materials for safe transport of this unit in the
future.
Safety ----------------------------------------- Installation -----------------------------------
Cleaning --------------------------------------
PRECAUTIONS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.

FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED
AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE
LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS
OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT
GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH
THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE
TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN
A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL
INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE
COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN
ICES-003.
NORME NMB-003 DU CANADA.
WARNING
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be required
to take adequate measures.
CE COMPLIANCE STATEMENT
FCC COMPLIANCE STATEMENT
- iii -

IMPORTANT SAFEGUARDS
1 -1 Class 2 power source only.
7
-2 Do NOT use power source other than
17
that specified.
17. CAUTION-these servicing instructions are
for use by qualified service personnel only.
to reduce the risk of electric shock do not
perform any servicing other than that contained
in the operating instructions unless you are
qualified to do so.
5. ACCESSORIES
- iv -

- 1 -
The camera provides high-quality images using PIXIM DPS(Digital Pixel System) 1/3" Wide
Dynamic Range Sensor.
Features:
High resolution and high performance 1/3" CMOS(PIXIM DPS) technology
Wide Dynamic Range(WDR)
Excellent picture quality
Minimal blooming
Zero smear
Built-in NTSC/PAL video encoder
540 lines(Color) of resolution
0.5 Lux(Color) @ F1.2 Sensitivity
Upto 1/22,000sec electronic shutter at f/1.2
OSD (On Screen Display)
Auto white balance modes
Day & Night (Auto / OFF)
AGC (Auto Gain Control)
VIDEO OUT(BNC)
Internal/AC line lock
Operates in 12VDC or 24VAC
Use Certified / Listed Class 2 power supply only.
2.8-12mm Day/Night A/I Varifocal Lens F1.4
Camera Mount : camera mount directily to the wall or ceiling
Test Monitor Output
INTRODUCTION
IMPORTANT : The user of this camera is responsible for
checking and complying with local, state, and federal laws
and statutes concerning the recording and monitoring of
audio signals.
PACKAGE CONTENTS
The package contains the following.
Camera in Housing 1
Instruction Manual (This Document) 1
Accessory Kit for Installing 1
1Drilling guide label

INSTALLATION
1. Loosen the four torx screws located midway up the front of the housing leave the screws
intact in the front portion. (Fig. 1)
2. Drill the mounting location, using the bottom of the housing as a Drilling guide label. (Fig. 2)
3. Attach the housing to the ceiling using suitable fasteners, M6x35 tapping screws are
supplied only use if they are suitable. (Fig. 2)
4. Closing the housing using the loosen torx screws. (Fig. 3)
Torx screws
M5x10 (4x)
Figure 1 Figure 2
Torx screws
M5x10 (4x)
Seal around
the housing
base tightly using
the silicon rubber
- 2 -
1. Lens : 2.8-12mm D&N A/I Vari-focal lens for wide area monitoring.
2. Power : 24V AC input / 12V DC input
power source from a DC 12V or AC 24V ac +/-10% 60/50Hz +/-1Hz
Use Certified/Listed Class 2 power supply transformer only.
*If using DC 12V power adaptor,
use a power supply capable of supplying 6 Watts.
3. Video : BNC connector used to connect the camera to a monitor, switcher, etc.
13 213
2
CAMERA CONNECTIONS

OPERATING CAMERA
Down Button
Up
Enter
Right
Left
Spot Video Out
1
2
3
4
5
The housing can also
be mounted on a 4s
electrical box.
MOUNTING HOUSING TO
AN ELECTRICAL BACK BOX
Electrical box
Torx screws
UNC 8-32 x 0.75
Rubber
Washers(4x)
12345
Figure 3
CEILING
Drilling
Guide Label
Plastic Anchor(4x)
Rubber Washers(4x)
Mounting Screw
M6X35(4x)
- 3 -
Note: Electrical box is not supplied.
6
6

CAMERA SETUP
-4 -
PRESETS
NORMAL
INDOOR
OUTDOOR
WD NORMAL
AGC LOW
NORMAL
HIGH
WHITE BALANCE
ATW Normal
ATW Xtnd
AWB
SYNC
INTERNAL
LINELOCK
AUTO
OFF
D/N CONTROL
SAVE. EXIT. CANCEL
PUSH AWB CONFIRM
> Save AWB & ALL Chngs.
CANCEL
''' WARNING '''
will
ALL User
be written to ROM
properties
LINELOCK MENU
V PHASE
DAY/NIGHT THRESHOLD SETUP
IN
OUT

CAMERA ADJUSTMENT
<SETTINGS>
Setting can be made using the 5 buttons located on the back of the camera.
<CAMERA SETUP>
1) PRESETS
1) The CAMERA SETUP is displayed on the monitor when press and hold
the ENTER button for more than 1 second.
2) Press the UP and DOWN buttons in the vertical direction and move the cursor(>)
to the desired submenu.
3) ".." indicated submenus.
- NORMAL
- WD NORMAL Standard video with Wide Dynamic Range Limit Max
- INDOOR To brighten the video taken indoors
Standard video
Auto Gain Control selected (LOW / NORMAL / HIGH)
2) AGC
- DEFAULT
Standard video
- INDOOR
To brighten the video taken indoors
- OUTDOOR
3) WHITE BALANCE
hite balance is automatically followed up
- A T W Normal W
(Limits the range of auto tracking by the value of two properties).
When shooting in a bright area outdoors
W
- ATW Xtnd hite balance is automatically followed up.
- AWB One-push automatic white balance control.
Shoot a target white subject and press the ENTER button,
and the white balance will be adjusted.
4) SYNC
- OUTDOOR When shooting in a bright area outdoors
- INTERNAL This mode is necessary for using the internal synchronization.
- LINELOCK This mode is necessary for the operation of multi camera because
it synchronizes the camera phase by using the external signal
(AC Signal).
5) D/N CONTROL
- AUTO This camera has a function which automatically changes to
the appropriate mode for daytime or night-time.
- OFF In this mode, the camera outputs the video image only in color.
- 5 -
