Digisol RANGER SERIES User manual

1
RANGER SERIES
LOAD BALANCING ROUTER WITH 2xFE
WAN, 1x3G/4G ENABLED USB, 3xFE LAN
DG-LB1054UV
V2.0
2018-08-28

2
Copyright
Copyright 2018 by DIGISOLSystems Ltd.All rights reserved.
Company has an ongoing policy of upgrading its products and it may be
possible that information in this document is not up-to-date.
Please check with your local distributors for latest information.
No part of this document can be copied or reproduced in any form
without written consent from the company.
Trademark
DIGISOLTM is a trademark of DIGISOL Systems Ltd. All other
trademarks are the property of the respective manufacturers.

3
The following items should be present in your package:
DG-LB1054UV (1 No.)
PowerAdapter
Patch Cord
Quick installation guide
Installation software CD (includes User Manual & QIG)
Make sure that the package contains above items.If any of the listed
items is damaged or missing,please contact your retailer immediately.
Congratulations on your purchase of this outstanding product DG-
LB1054UV. This device is specifically designed for SMB & SOHO
offices, small shops and chain stores. No matter offices are located at
wire unreachable area, it can connect to Intranet of headquarter
instantly via fixed line and/or cellular network. No need to apply for
expensive leased line in advance. With multiple WAN load balance and
fail-over, it guarantees non-interrupt operation.
By IPSec/PPTP/L2TP VPN tunneling and failover technology, it can
establish a secure non-stop connection with headquarter even IP is
changing all the time. Firewall protection is useful to avoid hackers
attacking. With embedded robust security and firewall function, it’s
suitable for remote branch offices to access the corporate database &
servers located in headquarter data center through internet. Besides,
this device also provides VoIP feature to enable secure and cost
effective Intranet voice communication through internet.
Instructions for installing and configuring this product can be found in
this manual. Before you install and use this product, please read this
manual carefully for fully exploiting the functions of this product.

4
Safety Instructions
Attention
Do not use the product in high humidity or
high temperatures.
Only use the power adapter that comes with
the package. Using a different voltage rating
power adaptor may damage the product.
Do not open or repair the case yourself. If the
Product is too hot, turn off the power
immediately and have it repaired at a
qualified service center.
Place the Product on a stable surface and
avoid using this product and all accessories
outdoor.

5
Network Requirements
An Ethernet RJ-45 Cable or DSL modem.
3G/4G cellular service subscription.
IEEE 802.11n or 802.11b/g wireless clients.
10/100/1000 Ethernet adapter on PC / NB.
Web-based Configuration
Utility Requirements
Computer with the following:
Windows®, Macintosh, or Linux-based
operating system.
An installed Ethernet adapter.
Browser Requirements:
Internet Explorer 6.0 or higher.
Chrome 2.0 or higher.
Firefox 3.0 or higher.
Safari 3.0 or higher.
CD Installation Wizard
Requirements
Computer with the following:
Windows® 7 / 8, Vista®, or XP with Service
Pack 2.
An installed Ethernet adapter.
CD-ROM drive.

6
Hardware Installation
FRONT VIEW
REAR VIEW
USB
Auto MDI/MDIX RJ-45 Ports
Receptor
for Power
Adapter
Reset
Button
Power
ON/OFF
Switch

7
LED Indicators
LED
Symbol
Description
Power
OFF: Device is powered down.
Orange: Device is booting up.
Green (Steady): Device is powered on.
Orange in flash: Device is in recovery mode
or abnormal.
WAN
Green: Ethernetconnection is established.
Green in flash: Data packet transferred
through WAN.
OFF: No Ethernet cable attached or Device
not linked.
LAN1 ~
LAN4
Green: Ethernetconnection is established.
Green in flash: Data packet transferred via
Ethernet.
OFF: No Ethernet cable attached or Device
not linked.

8
System Login
Browse to Activate the Setup Wizard
Type in the IPAddress (http://192.168.123.254) *
Preview
Type the default Password ‘admin’ in the
System Password and then
click ‘login’ button.
Remark:
* 1. The default LAN IP address of this gateway is 192.168.123.254. If you
change it,you need to type the new IP address.
*2. It’s strongly recommended that you change this login password from
default value.
Select your language.
Select “Wizard” for basic settings in a simple way.
Or, you can go to Basic Network /Advanced Network / System to setup
the configuration by your own selection.

9
Following are the solutions to problems that may occur during the
installation and operation of the DIGISOL DG-LB1054UV.
1) I cannot configure the router even when the cable is plugged and the
LED is Lit.
Do a Ping test to make sure that the load balancing Router is
responding.
Go to Start > Run.
Type cmd.
Note: It is recommended that you use
an Ethernet connection to configure it

10
Press OK.
Type ipconfig to get the IP of default gateway.
Type “ping 192.168.123.254”. Assure that you ping the correct IP
Address assigned to the load balancing Router. It will show four
replies if you ping correctly.

Ensure that your Ethernet Adapter is working, and that all network
drivers are installed properly. Network adapter names will vary
depending on your specific adapter. The installation steps listed
below are applicable for all network adapters.
Go to Start > Right click on “My Computer” > Properties.
Select the Hardware Tab.
Click Device Manager.
Double-click on “Network Adapters”.
Right-click onWired Card bus Adapter or your specific network
adapter.
Select Properties to ensure that all drivers are installed properly.
Look under Device Status to see if the device is working properly.
Click “OK”.

11
2) My Ethernet connection does not work properly.
Make sure the RJ45 cable connects with the router.
Ensure that the setting on your Network Interface Card adapter is
“Enabled”.
If settings are correct, ensure that you are not using a crossover
Ethernet cable, not all.
Network Interface Cards are MDI/MDIX compatible, and using a
patch cable is recommended.
If the connection still doesn’t work properly, then you can reset it to
default.
3) How to reset to default.
Ensure the load balancing Router is powered on.
Find the Reset button on the right side.
Press the Resetbutton for 8 seconds and then release.
After the Router reboots, it gets back to the factory default settings.
