Digisol DG-FS4528E User manual

Installation Guide
MUSTANG 4000 SWITCH SERIES
DG-FS4528E
INSTALLATION GUIDE
V1.0
2013-09-24
As our products undergo continuous development the specifications are subject to change without prior notice

I NSTALLATION G UIDE
DG-FS4528E L2 FAST ETHERNET SWITCH
Layer 2 Switch with
24 10/100BASE-TX (RJ-45) Ports,
and 4 Combination Gigabit (RJ-45/SFP) Ports
DG-FS4528E
092013
R01

– 3 –
ABOUT THIS GUIDE
PURPOSE
This guide details the hardware features of the switch, including the physical and
performance-related characteristics, and how to install the switch.
AUDIENCE
The guide is intended for use by network administrators who are responsible for
installing and setting up network equipment; consequently, it assumes a basic
working knowledge of LANs (Local Area Networks).
CONVENTIONS
The following conventions are used throughout this guide to show information:
RELATED PUBLICATIONS
The following publication gives specific information on how to operate and use
the management functions of the switch:
The Management Guide
Also, as part of the switch’s software, there is an online web-based help that
describes all management related features.
N OTE : Emphasizes important information or calls your attention to
related features or instructions.
C AUTION : Alerts you to a potential hazard that could cause loss of data,
or damage the system or equipment.
W ARNING : Alerts you to a potential hazard that could cause personal
injury.

A BOUT T HIS G UIDE
– 4 –
REVISION HISTORY
This section summarizes the changes in each revision of this guide.
SEPT 2013 REVISION
This was the first revision of this guide.

– 6 –
CONTENTS
ABOUT THIS GUIDE 3
CONTENTS 6
TABLES 10
FIGURES 11
1I
NTRODUCTION 13
Overview 13
Switch Architecture 14
Network Management Options 14
Description of Hardware 14
10/100BASE-T Ports 14
SFP Slots 15
Port and System Status LEDs 15
Power Supply Socket 17
Application Examples 17
Network Aggregation Plan 17
Remote Connection with Fiber Cable 18
2INSTALLING THE SWITCH 21
Selecting a Site 21
Ethernet Cabling 22
Equipment Checklist 23
Package Contents 23
Optional Rack-Mounting Equipment 23
Mounting 24
Rack Mounting 24
Desktop or Shelf Mounting 26

C ONTENTS
– 7 –
Installing an Optional SFP Transceiver 27
Connecting to a Power Source 28
Connecting to the Console Port 29
Wiring Map for Serial Cable 29
3MAKING NETWORK CONNECTIONS 31
Connecting Network Devices 31
Twisted-Pair Devices 31
Cabling Guidelines 31
Connecting to PCs, Servers, Hubs and Switches 32
Network Wiring Connections 33
Fiber Optic SFP Devices 34
Connectivity Rules 35
1000BASE-T Cable Requirements 35
1000 Mbps Gigabit Ethernet Collision Domain 36
100 Mbps Fast Ethernet Collision Domain 37
10 Mbps Ethernet Collision Domain 37
Cable Labeling and Connection Records 37
ATROUBLESHOOTING 39
Diagnosing Switch Indicators 39
Power and Cooling Problems 40
Installation 40
In-Band Access 40
BCABLES 41
Twisted-Pair Cable and Pin Assignments 41
10BASE-T/100BASE-TX Pin Assignments 42
Straight-Through Wiring 42
Crossover Wiring 43
1000BASE-T Pin Assignments 44
Fiber Standards 45
CSPECIFICATIONS 47

C ONTENTS
– 8 –
Physical Characteristics 47
Switch Features 48
Management Features 49
Standards 49
49
GLOSSARY 51
INDEX 57

– 10 –
TABLES
Table 1: Port Status LEDs 15
Table 2: System Status LEDs 16
Table 3: Console Cable Wiring 29
Table 4: Maximum 1000BASE-T Gigabit Ethernet Cable Length 36
Table 5: Maximum 1000BASE-SX Gigabit Ethernet Cable Lengths 36
Table 6: Maximum 1000BASE-LX Gigabit Ethernet Cable Length 36
Table 7: Maximum 1000BASE-LH Gigabit Ethernet Cable Length 36
Table 8: Maximum Fast Ethernet Cable Lengths 37
Table 9: Maximum Ethernet Cable Length 37
Table 10: Troubleshooting Chart 39
Table 11: 10/100BASE-TX MDI and MDI-X Port Pinouts 42
Table 12: 1000BASE-T MDI and MDI-X Port Pinouts 44
Table 13: Fiber Standards 45

– 11 –
FIGURES
Figure 1: Front and Rear Panels 13
Figure 2: Port Status LEDs 15
Figure 3: System Status LED 16
Figure 4: Power Supply Socket 17
Figure 5: Network Aggregation Plan 18
Figure 6: Remote Connections with Fiber Cable 19
Figure 7: RJ-45 Connections 22
Figure 8: Attaching the Brackets 25
Figure 9: Installing the Switch in a Rack 25
Figure 10: Attaching the Adhesive Feet 26
Figure 11: Inserting an SFP Transceiver into a Slot 27
Figure 12: Power Sockets 28
Figure 13: Serial Port (DB-9 DTE) Pin-Out 29
Figure 14: Making Twisted-Pair Connections 32
Figure 15: Network Wiring Connections 33
Figure 16: Making Fiber Port Connections 35
Figure 17: RJ-45 Connector Pin Numbers 41
Figure 18: Straight-through Wiring 43
Figure 19: Crossover Wiring 43

– 13 –
1INTRODUCTION
OVERVIEW
The DG-FS4528E switch is a intelligent switch with 24 10/100BASE-T ports, and
four Gigabit combination ports1that are comprised of an RJ-45 port and an SFP
transceiver slot. There is also an SNMP-based management agent embedded on
the main board. This agent supports both in-band and out-of-band access for
managing the switch.
This switch provides a broad range of powerful features for Layer 2 switching,
delivering reliability and consistent performance for your network traffic. It
brings order to poorly performing networks by segregating them into separate
broadcast domains with IEEE 802.1Q compliant VLANs, and empower
multimedia applications with multicast switching and CoS services.
Figure 1: Front and Rear Panels
1. RJ-45 ports shared with a SFP transceiver slots. If an SFP transceiver is plugged
in, the corresponding RJ-45 port is disabled.
10/100 Mbps RJ-45 Ports
Console
Port
System Indicators
Combination
Gigabit Ports
Power Socket
Port Status
Indicators

C HAPTER 1 | Introduction
Description of Hardware
– 14 –
SWITCH ARCHITECTURE
This switch employs a wire-speed, non-blocking switching fabric. This permits
simultaneous wire-speed transport of multiple packets at low latency on all
ports. This switch also features full-duplex capability on all ports, which
effectively doubles the bandwidth of each connection.
This switch uses store-and-forward switching to ensure maximum data integrity.
With store-and-forward switching, the entire packet must be received into a
buffer and checked for validity before being forwarded. This prevents errors
from being propagated throughout the network.
NETWORK MANAGEMENT OPTIONS
This switch contains a comprehensive array of LEDs for “at-a-glance” monitoring
of network and port status. It also includes a management agent that allows you
to configure or monitor the switch using its embedded management software, or
via SNMP applications. To manage a switch, you can make a direct connection to
the RS-232 console port (out-of-band), or you can manage it through a network
connection (in-band) using Telnet, the on-board Web agent, or Windows-based
network management software.
For a detailed description of the switch’s software features, refer to the
Management Guide.
DESCRIPTION OF HARDWARE
10/100BASE-T PORTS
This switch contains 24 RJ-45 ports that operate at 10 Mbps or 100 Mbps, half or
full duplex. Because all ports on both switches support automatic MDI/MDI-X
operation, you can use straight-through cables for all network connections to
PCs or servers, or to other switches or hubs. (See “Twisted-Pair Cable and Pin
Assignments” on page 41.)
Each of these ports support auto-negotiation, so the optimum transmission
mode (half or full duplex), and data rate (10 or 100 Mbps) can be selected
automatically. If a device connected to one of these ports does not support auto-
negotiation, the communication mode of that port can be configured manually.

C HAPTER 1 | Introduction
Description of Hardware
– 15 –
Each port also supports auto-negotiation of flow control, so the switch can
automatically prevent port buffers from becoming saturated.
SFP SLOTS
The Small Form Factor Pluggable (SFP) transceiver slots are shared with four RJ-
45 ports (combination ports). In its default configuration, if an SFP transceiver
(purchased separately) is installed in a slot and has a valid link on its port, the
associated RJ-45 port is disabled and cannot be used. The switch can also be
configured to force the use of an RJ-45 port or SFP slot, as required.
PORT AND SYSTEM STATUS LEDS
The LEDs, which are located on the front panel for easy viewing, are shown
below and described in the following table.
Figure 2: Port Status LEDs
Table 1: Port Status LEDs
LED Condition Status
RJ-45 Ports
Link/ACT
(Link/Activity)
On/Blinking Green The port has a valid 10 or 100 Mbps link. Blinking
indicates activity.
Off There is no valid link on the port.
Combination Gigabit Ports
Link/ACT
(Link/Activity)
On/Blinking Green The port has a valid 10/100/1000 Mbps link.
Blinking indicates activity.
Off There is no valid link on the port.
RJ-45 Port Status LEDs Combination Gigabit Port Status LEDs

C HAPTER 1 | Introduction
Description of Hardware
– 16 –
Figure 3: System Status LED
1000M On/Blinking Green The port has a valid 1000 Mbps link. Blinking
indicates activity.
Off There is no valid 1000 Mbps link on the port.
Table 2: System Status LEDs
LED Condition Status
PWR (Power) On Green Internal power is operating normally.
Off Power off or failure.
DIAG
(Diagnostic)
On Green System self-diagnostic test successfully completed.
Blinking Green System self-diagnostic test in progress.
Off System self-diagnostic test has failed.
Table 1: Port Status LEDs (Continued)
LED Condition Status
System Status LEDs

C HAPTER 1 | Introduction
Application Examples
– 17 –
POWER SUPPLY SOCKET
There is one standard power socket on the rear panel of the switch for the AC
power cord.
Figure 4: Power Supply Socket
APPLICATION EXAMPLES
This switch is an excellent choice for mixed Ethernet, Fast Ethernet, and Gigabit
Ethernet installations where significant growth is expected in the near future. In
a basic stand-alone configuration, it can provide direct full-duplex connections to
workstations or servers. When the time comes for further expansion, just
connect to another hub or switch using one of the Fast Ethernet ports built into
the front panel or a Gigabit Ethernet port on a plug-in SFP transceiver.
Some typical application examples are described in this section.
NETWORK AGGREGATION PLAN
With 24 parallel bridging ports (i.e., 24 distinct collision domains), the switch can
collapse a complex network down into a single efficient bridged node, increasing
overall bandwidth and throughput.
In the figure below, the 10/100BASE-TX ports on the switch are providing
100 Mbps connectivity through layer 2 switches. In addition, the switch is also
connecting several servers at 1000 Mbps.
Power Socket

C HAPTER 1 | Introduction
Application Examples
– 18 –
Figure 5: Network Aggregation Plan
REMOTE CONNECTION WITH FIBER CABLE
Fiber optic technology allows for longer cabling than any other media type. A
1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a
1000BASE-LX (SMF) link up to 10 km, and a 1000BASE-LH link up to 70 km.
This allows the switch to serve as a collapsed backbone, providing direct
connectivity for a widespread LAN.
A 1000BASE-SX SFP transceiver can be used for a high-speed connection
between floors in the same building, a 1000BASE-LX SFP transceiver can be
used to connect to other buildings in a campus setting, and a 1000BASE-LH SFP
transceiver can be used for a long-haul connection to a remote site.
The figure below illustrates the switch connecting multiple segments with fiber
cable.

C HAPTER 1 | Introduction
Application Examples
– 19 –
Figure 6: Remote Connections with Fiber Cable

– 21 –
2INSTALLING THE SWITCH
SELECTING ASITE
Switch units can be mounted in a standard 19-inch equipment rack or on a flat
surface. Be sure to follow the guidelines below when choosing a location.
The site should:
be at the center of all the devices you want to link and near a power
outlet.
be able to maintain its temperature within 0 to 55 °C (32 to 130 °F)
and its humidity within 5% to 95%, non-condensing
provide adequate space (approximately two inches) on all sides for
proper air flow
be accessible for installing, cabling and maintaining the devices
allow the status LEDs to be clearly visible
Make sure twisted-pair cable is always routed away from power lines,
fluorescent lighting fixtures and other sources of electrical interference,
such as radios and transmitters.
Make sure that a separate grounded power outlet that provides 100 to 240
VAC, 50 to 60 Hz, is within 2.44 m (8 feet) of each device and is powered
from an independent circuit breaker. As with any equipment, using a filter or
surge suppressor is recommended.

C HAPTER 2 | Installing the Switch
Ethernet Cabling
– 22 –
ETHERNET CABLING
To ensure proper operation when installing the switch into a network, make sure
that the current cables are suitable for 10BASE-T, 100BASE-TX or 1000BASE-T
operation. Check the following criteria against the current installation of your
network:
Cable type: Unshielded twisted pair (UTP) or shielded twisted pair (STP)
cables with RJ-45 connectors; Category 3 or better for 10BASE-T, Category
5 or better for 100BASE-TX, and Category 5 or better for 1000BASE-T.
Protection from radio frequency interference emissions
Electrical surge suppression
Separation of electrical wires (switch related or other) and electromagnetic
fields from data based network wiring
Safe connections with no damaged cables, connectors or shields
Figure 7: RJ-45 Connections
RJ-45 Connector

C HAPTER 2 | Installing the Switch
Equipment Checklist
– 23 –
EQUIPMENT CHECKLIST
After unpacking the switch, check the contents to be sure you have received all
the components. Then, before beginning the installation, be sure you have all
other necessary installation equipment.
PACKAGE CONTENTS
DG-FS4528E Fast Ethernet Switch
Four adhesive foot pads
Bracket Mounting Kit containing two brackets and eight screws for attaching
the brackets to the switch
Power Cord
RS-232 console cable
This Installation Guide
Management Guide CD
OPTIONAL RACK-MOUNTING EQUIPMENT
If you plan to rack-mount the switch, be sure to have the following equipment
available:
Four mounting screws for each device you plan to install in a rack—these
are not included
A screwdriver (Phillips or flathead, depending on the type of screws used)

C HAPTER 2 | Installing the Switch
Mounting
– 24 –
MOUNTING
The switch units can be mounted in a standard 19-inch equipment rack or on a
desktop or shelf. Mounting instructions for each type of site follow.
RACK MOUNTING
Before rack mounting the switch, pay particular attention to the following
factors:
Temperature: Since the temperature within a rack assembly may be
higher than the ambient room temperature, check that the rack-
environment temperature is within the specified operating temperature
range. (See page 48.)
Mechanical Loading: Do not place any equipment on top of a rack-
mounted unit.
Circuit Overloading: Be sure that the supply circuit to the rack assembly
is not overloaded.
Grounding: Rack-mounted equipment should be properly grounded.
Particular attention should be given to supply connections other than direct
connections to the mains.
To rack-mount devices:
1. Attach the brackets to the device using the screws provided in the Bracket
Mounting Kit.
