Digital Equipment DECpc AXP 150 Operation manual

DECpcAXP150and
DEC2000Model300AXP
UserInformation
Order Number: EK-A0634-OM.001
July 1993
This guide describes how to operate the DECpc AXP 150 and DEC 2000
Model 300 AXP systems.
Revision Information: This is a new manual.
Digital Equipment Corporation
Maynard, Massachusetts

First Printing, July 1993
Possession, use, or copying of the software described in this documentation is
authorized only pursuant to a valid written license from Digital, an authorized,
sublicensor, or the identified licensor.
While Digital believes the information included in this publication is correct as
of the date of publication, it is subject to change without notice.
Digital Equipment Corporation makes no representations that the
interconnection of its products in the manner described in this document
will not infringe existing or future patent rights, nor do the descriptions
contained in this document imply the granting of licenses to make, use, or sell
equipment or software in accordance with the description.
© Digital Equipment Corporation 1993.
All Rights Reserved.
The postpaid Reader’s Comments forms at the end of this document request
your critical evaluation to assist in preparing future documentation.
The following are trademarks of Digital Equipment Corporation: Alpha
AXP, AXP, DEC, DECchip 21064, DECconnect, DECpc, Digital, OpenVMS,
RRD42, RX, RZ, ThinWire, VAX DOCUMENT, the Alpha AXP logo, and the
DIGITAL logo.
OSF and OSF/1 are registered trademarks of the Open Software Foundation,
Inc.
IBM and PS/2 are registered trademarks of International Business Machines
Corporation.
Microsoft is a registered trademark and Windows NT is a trademark of
Microsoft Corporation.
Centronics is a trademark of Centronics Data Computer Corporation.
Xerox is a registered trademark of Xerox Corporation.
All other trademarks and registered trademarks are the property of their
respective holders.
This document was prepared using VAX DOCUMENT, Version 2.1.

FCC Notice: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
Any changes or modifications made to this equipment may void the user’s
authority to operate this equipment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
To comply with the FCC rules part 15B for a class B computing device,
use only properly shielded interface cables for the systems described in this
document.
VCCI Class 2 ITE Notice:
This document was prepared using VAX DOCUMENT, Version 2.1.

Für Bundesrepublik Deutschland
For Federal Republic of Germany
Pour la République féderale d’Allemagne
BESCHEINIGUNG DES HERSTELLERS/IMPORTEURS
Dieses Gerät ist in Übereinstimmung mit den Bestimmungen der BMPT
Vfg.243/1991 und Vfg.46/1992 in Verbindung mit EN55022:1987 (DIN VDE
0878-3:11.89), oder Vfg.1046/1984 mit Vfg. 483/1986, funkentstört. Es trägt als
Nachweis der EMV-Konformität entweder eine Konformitätskennzeichnung oder
das freiwillige VDE-Funkschutzzeichen.
Der vorschriftsmäßige Betrieb mancher Geräte (z.B. Meßsender) kann
allerdings gewissen Einschränkungen unterliegen. Beachten Sie deshalb
die unten aufgeführten Hinweise.
Dem Bundesamt für Zulassungen in der Telekommunikation (BZT) wurde
das Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung zur
Überprüfung der Serie auf Einhaltung der Bestimmungen eingeräumt.
Betreiberhinweis
Wir sind verpflichtet, Sie auf folgende Fakten hinzuweisen (BMPT-
Amtsblattverfügung 243/91 bzw. 1046/84 §2, Abschnitt 5):
Dieses Gerät wurde funktechnisch sorgfältig entstört und geprüft. Wird dieses
Gerät innerhalb einer Anlage zusammen mit anderen Geräten betrieben, muß
bei Inanspruchnahme der "Allgemeinen Betriebsgenehmigung" nach BMPT-
AmtsblVfg. 243/91 bzw. 1046/84 die gesamte Anlage den unter §2, Abschnitt 1,
genannten Voraussetzungen entsprechen.
Externe Datenkabel
Sollte ein Austausch der von Digital spezifierten Datenkabel nötig werden,
muß der Betreiber für eine einwandfreie Funkentstörung sicherstellen, daß
Austauschkabel im Aufbau und Abschirmqualität dem Digital Originalkabel
entsprechen.
This document was prepared using VAX DOCUMENT, Version 2.1.

Contents
Preface ..................................................... xv
1 System Description
Introduction . . . ................................... 1–1
In This Chapter ................................... 1–1
Operating System Support . . . ........................... 1–2
Summary ........................................ 1–2
System Architecture................................ 1–2
Supported Operating Systems ........................ 1–2
Visual Display Unit ................................ 1–2
Client/Server Use . . ................................... 1–3
Summary ........................................ 1–3
Client Systems . ................................... 1–3
Server Systems ................................... 1–3
System Features . . ................................... 1–4
Summary ........................................ 1–4
System Features .................................. 1–4
Front Panel Controls and Indicators . . . ................... 1–6
Summary ........................................ 1–6
Controls and Indicators . . ........................... 1–6
Front Panel Illustration . . ........................... 1–7
Back Panel Ports and Connectors ........................ 1–8
Summary ........................................ 1–8
Ports and Connectors ............................... 1–8
Ports and Connectors Illustration . . ................... 1–9
Back Panel Controls and Indicators ....................... 1–10
Summary ........................................ 1–10
Controls and Indicators . . ........................... 1–10
Controls and Indicators Illustration . ................... 1–11
Internal Options. . . ................................... 1–12
Summary ........................................ 1–12
Storage Options ................................... 1–12
v

Ordering Information ............................... 1–12
Storage Options Illustration . . ........................ 1–13
Internal Options, continued ............................. 1–14
EISA and ISA Options .............................. 1–14
Ordering Information ............................... 1–14
EISA Option Illustration ............................ 1–15
Internal Options, continued ............................. 1–16
Memory Options. . . ................................ 1–16
Ordering Information ............................... 1–16
Memory Option Illustration . . ........................ 1–16
System Unit Key Information . . . ........................ 1–17
Summary ........................................ 1–17
Important Information .............................. 1–17
Recording the Key Number and Letter . ................ 1–17
Key Number and Letter Location...................... 1–17
2 Using the System
Introduction ...................................... 2–1
In This Chapter . . . ................................ 2–1
Choosing a Location for the System Unit . . . ................ 2–2
Summary ........................................ 2–2
Physical Orientation ............................... 2–2
Environmental Conditions . . . ........................ 2–2
Unsuitable Locations ............................... 2–3
Cable Considerations ............................... 2–3
Ergonomic Considerations .............................. 2–4
Summary ........................................ 2–4
Positioning System Components ...................... 2–4
Moving the System Unit ............................ 2–5
Positioning Illustration ............................. 2–5
Turning the System On or Off . . . ........................ 2–6
Summary ........................................ 2–6
Turning On the System ............................. 2–6
Turning Off the System ............................. 2–6
On/Off Switch Positions Illustration . . . ................ 2–7
OpenVMS and OSF/1 Console Power-Up Test Displays . ....... 2–8
Summary ........................................ 2–8
Power-Up Test Display Differences .................... 2–8
If the System Passes ............................... 2–8
If the System Fails. ................................ 2–8
Power-Up Test That Passes . . ........................ 2–9
Power-Up Test That Fails . . . ........................ 2–9
vi

Windows NT Firmware Power-Up Test Displays . . . .......... 2–10
Summary ........................................ 2–10
Power-Up Test Display Differences . ................... 2–10
If the System Passes ............................... 2–10
If the System Fails................................. 2–10
Power-Up Test That Passes .......................... 2–11
Power-Up Test That Fails ........................... 2–11
Booting Windows NT .................................. 2–12
Summary ........................................ 2–12
Windows NT Factory Installed Software ................ 2–12
Booting Windows NT Automatically. ................... 2–12
Boot Selections . ................................... 2–12
Using the Boot Menu ............................... 2–12
Windows NT Boot Menu . ........................... 2–13
Windows NT Boot Selection Menu . . ................... 2–13
Booting OpenVMS . ................................... 2–14
Summary ........................................ 2–14
OpenVMS Factory Installed Software .................. 2–14
Booting OpenVMS Automatically . . . ................... 2–14
System Defaults ................................... 2–14
Booting OpenVMS ................................. 2–14
Booting OSF/1 ....................................... 2–15
Summary ........................................ 2–15
OSF/1 Factory Installed Software . . ................... 2–15
Booting OSF/1 Automatically ......................... 2–15
System Defaults ................................... 2–15
Booting OSF/1 . ................................... 2–15
3 Using CD-ROM and Diskette Drives
Introduction . . . ................................... 3–1
In This Chapter ................................... 3–1
RRD42 CD-ROM Drive Description ....................... 3–2
Summary ........................................ 3–2
Description ....................................... 3–2
Controls and LEDs................................. 3–2
If Errors Occur . ................................... 3–2
Controls and LEDs Illustration ....................... 3–3
Inserting a Compact Disc into a Caddy . ................... 3–4
Summary ........................................ 3–4
Insertion Procedure ................................ 3–4
Compact Disc and Caddy Illustration .................. 3–5
Inserting a Caddy into the RRD42 CD-ROM Drive . .......... 3–6
vii

Summary ........................................ 3–6
Caddy Insertion Procedure . . . ........................ 3–6
Caddy Insertion Illustration . ........................ 3–7
Removing a Caddy from the RRD42 CD-ROM Drive . . . ....... 3–8
Summary ........................................ 3–8
Caddy Removal Procedure . . . ........................ 3–8
Caddy Removal Illustration . . ........................ 3–9
RX26 Diskette Drive Description . ........................ 3–10
Summary ........................................ 3–10
Description ....................................... 3–10
Controls and LEDs. ................................ 3–10
If Errors Occur .................................... 3–10
Controls and LEDs Illustration ....................... 3–11
Using the RX26 Diskette Drive . . ........................ 3–12
Summary ........................................ 3–12
Important Information .............................. 3–12
Insertion Procedure ................................ 3–12
Removal Procedure ................................ 3–12
Insertion and Removal Illustration .................... 3–13
Cleaning the RX26 Diskette Drive Heads . . ................ 3–14
Summary ........................................ 3–14
Cleaning Procedure ................................ 3–14
When to Clean the Heads . . . ........................ 3–14
4 Using Tape Drives
Introduction ...................................... 4–1
In This Chapter . . . ................................ 4–1
TLZ06 Tape Drive Description . . . ........................ 4–2
Summary ........................................ 4–2
Description ....................................... 4–2
Controls and LEDs. ................................ 4–2
If Errors Occur .................................... 4–2
Controls and LEDs Illustration ....................... 4–3
Using the TLZ06 Tape Drive ............................ 4–4
Summary ........................................ 4–4
Insertion Procedure ................................ 4–4
Removal Procedure ................................ 4–4
Installation and Removal Illustration . . ................ 4–5
TZK10 Tape Drive Description . . . ........................ 4–6
Summary ........................................ 4–6
Description ....................................... 4–6
Controls and LEDs. ................................ 4–6
viii

If Errors Occur . ................................... 4–6
Controls and LEDs Illustration ....................... 4–7
Inserting a QIC Tape into a TZK10 Tape Drive .............. 4–8
Summary ........................................ 4–8
Insertion Procedure ................................ 4–8
Insertion Illustration ............................... 4–9
Removing a QIC Tape from a TZK10 Tape Drive . . . .......... 4–10
Summary ........................................ 4–10
Removal Procedure ................................ 4–10
Removal Illustration ............................... 4–11
Cleaning the Tape Drive Heads .......................... 4–12
Summary ........................................ 4–12
Cleaning Procedure ................................ 4–12
When to Clean the Heads ........................... 4–12
5 Removable Storage Media
Introduction . . . ................................... 5–1
In This Chapter ................................... 5–1
Quarter-Inch Cartridge (QIC) Tapes . . . ................... 5–2
Summary ........................................ 5–2
QIC Tape Compatibility . . ........................... 5–2
Handling and Storing QIC Tapes . . . ................... 5–3
Write-Protecting QIC Tapes . . ........................... 5–4
Summary ........................................ 5–4
Write-Protect Switch Positions ........................ 5–4
Write-Protect Switch Illustration . . . ................... 5–5
Cassette Tapes ....................................... 5–6
Summary ........................................ 5–6
Cassette Tape Compatibility ......................... 5–6
Handling and Storing Cassette Tapes .................. 5–7
Write-Protecting Cassette Tapes ......................... 5–8
Summary ........................................ 5–8
Important Information . . . ........................... 5–8
Write-Protect Switch Positions ........................ 5–8
Write-Protect Switch Illustration . . . ................... 5–9
Diskettes ........................................... 5–10
Summary ........................................ 5–10
Diskette Compatibility . . . ........................... 5–10
Handling and Storing Diskettes ....................... 5–10
Write-Protect Switch Positions ........................ 5–10
Write-Protect Switch Illustration . . . ................... 5–11
Compact Discs ....................................... 5–12
ix

Summary ........................................ 5–12
Handling and Storing Compact Discs. . . ................ 5–12
Compact Disc and Caddy Illustration . . ................ 5–13
6 Connecting to External Ports
Introduction ...................................... 6–1
In This Chapter . . . ................................ 6–1
Before You Begin ..................................... 6–2
Summary ........................................ 6–2
Parallel and Serial Ports ............................ 6–2
Terminal Settings. . ................................ 6–2
External SCSI and Network Connections ............... 6–2
Other External Connections . . ........................ 6–2
Serial Port Terminal Settings............................ 6–3
Summary ........................................ 6–3
Terminal Settings. . ................................ 6–3
Connecting a Peripheral to a Serial Port . . . ................ 6–4
Summary ........................................ 6–4
Connection Procedure .............................. 6–4
Connection Illustration ............................. 6–5
Connecting a Peripheral to the Parallel Port ................ 6–6
Summary ........................................ 6–6
Connection Procedure .............................. 6–6
Connection Illustration ............................. 6–7
Connecting External SCSI Devices ....................... 6–8
Summary ........................................ 6–8
Deciding on External SCSI Devices .................... 6–8
External SCSI Drive Support . ........................ 6–8
Ordering SCSI Devices, Options, and Accessories . . ....... 6–8
Important Information .............................. 6–8
Specifying SCSI Cables ............................. 6–9
Connecting External SCSI Devices .................... 6–9
Connecting the System to a Network ...................... 6–10
Summary ........................................ 6–10
Network Option Board Support ....................... 6–10
Ordering Network Option Boards ..................... 6–10
Network Connection................................ 6–10
x

A Associated and Related Documents
Associated Documents . . . ........................... A–1
Factory Installed Software (FIS) Documentation .......... A–1
Related Documents ................................ A–2
Glossary
Index
Examples
2–1 OpenVMS and OSF/1 Console Power-Up Test That
Passes .......................................... 2–9
2–2 OpenVMS and OSF/1 Console Power-Up Test That Fails . . . 2–9
2–3 Windows NT Firmware Power-Up Test That Passes ....... 2–11
2–4 Windows NT Firmware Power-Up Test That Fails ......... 2–11
2–5 Windows NT Boot Menu . ........................... 2–13
2–6 Windows NT Boot Selection Menu . . ................... 2–13
Figures
1–1 Front Panel Controls and Indicators ................... 1–7
1–2 Back Panel Ports and Connectors . . ................... 1–9
1–3 Back Panel Controls and Indicators . ................... 1–11
1–4 Supported Internal Storage Options ................... 1–13
1–5 Sample EISA Option ............................... 1–15
1–6 Sample Memory Option . . ........................... 1–16
1–7 Key Number and Letter Location. . . ................... 1–17
2–1 Positioning the System Components ................... 2–5
2–2 On/Off Switch Positions . . ........................... 2–7
3–1 RRD42 Controls and LEDs .......................... 3–3
3–2 Inserting a Compact Disc into a Caddy ................. 3–5
3–3 Inserting a Caddy into the RRD42 CD-ROM Drive ........ 3–7
3–4 Removing a Caddy from the RRD42 CD-ROM Drive ....... 3–9
3–5 RX26 Controls and LEDs . ........................... 3–11
3–6 Inserting and Removing a Diskette . ................... 3–13
4–1 TLZ06 Tape Drive Controls and LEDs .................. 4–3
xi

4–2 Inserting and Removing a Cassette Tape ................ 4–5
4–3 TZK10 Eject Button and LED ........................ 4–7
4–4 Inserting a QIC Tape ............................... 4–9
4–5 Removing a QIC Tape .............................. 4–11
5–1 QIC Tape Write-Protect Switch Positions ................ 5–5
5–2 Cassette Tape Write-Protect Switch Positions ............ 5–9
5–3 3.5-Inch Diskette Write-Protect Switch Positions . . . ....... 5–11
5–4 Compact Disc, Caddy, and Shutter ..................... 5–13
6–1 Connecting a Peripheral to a Serial Port ................ 6–5
6–2 Connecting a Peripheral to the Parallel Port ............. 6–7
Tables
1–1 Operating System Support . . . ........................ 1–2
1–2 System Features . . ................................ 1–4
1–3 Front Panel Controls and Indicators . . . ................ 1–6
1–4 Back Panel Ports and Connectors ..................... 1–8
1–5 Back Panel Controls and Indicators .................... 1–10
1–6 Supported Internal Storage Options . . . ................ 1–12
2–1 Environmental Conditions . . . ........................ 2–2
2–2 Unsuitable Locations ............................... 2–3
2–3 Positioning the System Components . . . ................ 2–4
2–4 Turning On the System ............................. 2–6
2–5 Turning Off the System ............................ 2–6
2–6 Power-Up Test Failure Procedure ..................... 2–8
2–7 Power-Up Test Failure Procedure ..................... 2–10
2–8 Booting the Windows NT Operating System ............. 2–13
3–1 RRD42 CD-ROM Drive Controls and LEDs .............. 3–2
3–2 Inserting a Compact Disc into a Caddy . ................ 3–4
3–3 Inserting a Caddy into the RRD42 CD-ROM Drive . ....... 3–6
3–4 Removing a Caddy from the RRD42 CD-ROM Drive ....... 3–8
3–5 RX26 Diskette Drive Controls and LEDs ................ 3–10
4–1 TLZ06 Tape Drive Controls and LEDs . . ................ 4–2
4–2 Removing a Cassette Tape from the TLZ06 Tape Drive ..... 4–4
4–3 TZK10 Tape Drive Controls and LEDs. . ................ 4–6
4–4 Inserting a QIC Tape into a TZK10 Tape Drive ........... 4–8
4–5 Removing a QIC Tape from a TZK10 Tape Drive . . . ....... 4–10
xii

5–1 QIC Tape Compatibility . . ........................... 5–2
5–2 QIC Tape Write-Protect Switch Positions ................ 5–4
5–3 Cassette Tape Compatibility ......................... 5–6
5–4 Cassette Tape Write-Protect Switch Positions . . .......... 5–8
5–5 Diskette Compatibility . . . ........................... 5–10
5–6 3.5-Inch Diskette Write-Protect Switch Positions .......... 5–10
6–1 Terminal Settings.................................. 6–3
6–2 Connecting a Peripheral to a Serial Port ................ 6–4
6–3 Connecting a Peripheral to the Parallel Port . . . .......... 6–6
xiii

Preface
Purpose of This
Manual This manual describes how to operate the DECpc™ AXP™ 150
and the DEC™ 2000 Model 3000 AXP systems. It contains
information on software storage devices, connecting the system
toanetwork, and connecting hardware options to the system.
Audience This manual is intended for anyone using the systems. It is
written for both experienced and inexperienced users.
Structure of
This Manual This manual is divided into six chapters, an appendix, a glossary,
and an index:
• Chapter 1 describes the system unit and its internal options.
• Chapter 2 describes how to turn the system on or off and
how to boot the operating system.
• Chapter 3 describes how to use compact disc read-only
memory (CD-ROM) and diskette drive software storage
devices.
• Chapter 4 describes how to use tape drive software storage
devices.
• Chapter 5 describes how to care for the media associated
with the removable media devices.
• Chapter 6 describes how to connect external peripherals or
SCSI devices to the system. It also describes how to connect
the system to a network.
• Appendix A gives the list of associated and related
documents.
xv

• The glossary defines some of the technical terms used in this
manual.
Additional
Information See Appendix A for the list of associated and related documents.
Conventions The following conventions are used in this manual:
Convention Description
monospace Text displayed on the screen is shown in
monospace type.
boldface type Boldface type in examples indicates user input.
Boldface type in text indicates the first instance
of terms defined either in the text, in the
glossary, or both.
italic type Italic type emphasizes important information,
indicates variables, and indicates complete
titles of manuals.
nn nnn.nnn nn A space character separates digits in numerals
with 5 or more digits. For example, 10 000
equals ten thousand.
n.nn A period in numerals signals the decimal point
indicator. For example, 1.75 equals one and
three-fourths.
UPPERCASE Words in uppercase indicate a command.
nA lowercase italic nindicates the generic use
of a number. For example, 19nn indicates a
4-digit number in which the last 2 digits are
unknown.
xA lowercase italic xindicates the generic use
of a letter. For example, xxx indicates any
combination of three alphabetic characters.
Note A note contains information of special
importance to the reader.
Caution A caution contains information to prevent
damage to the equipment.
xvi

1
System Description
Introduction The DECpc AXP 150 and DEC 2000 Model 300 AXP systems
are high-performance systems with an architecture designed to
run a variety of operating systems. This chapter describes these
systems.
Note
The DECpc AXP 150 and DEC 2000 Model 300 AXP
systems use the same enclosure and basic system
components. They are differentiated by the operating
system and additional hardware options that they
support.
In This Chapter This chapter contains the following sections:
• Operating System Support
• Client/Server Use
• System Features
• Front Panel Controls and Indicators
• Back Panel Ports and Connectors
• Back Panel Controls and Indicators
• Internal Options
• System Unit Key Information
System Description 1–1

Operating System Support
Operating System Support
Summary This section describes how the DECpc AXP 150 and DEC 2000
Model 300 AXP systems can support different operating systems.
System
Architecture The systems use the Digital Equipment Corporation
DECchip 21064™ reduced instruction set computer (RISC)
microprocessor. Based on the Digital™ Alpha AXP™
architecture, it provides all the power of a 64-bit computing
environment. The Alpha AXP architecture privileged
architecture library code (PALcode) provides the ability to
use different operating systems, acting either as a client or a
server.
Supported
Operating
Systems
Table 1–1 lists the operating systems supported by the systems.
It also indicates whether you can operate the system as a client
or a server with each operating system.
Table 1–1 Operating System Support
System Name Operating System Client Support Server Support
DECpc AXP 150 Microsoft® Windows NT™ for AXP
Systems (Windows NT) Yes Yes
DEC 2000
Model 300 AXP System OpenVMS™ AXP Operating System (OpenVMS) No Yes
DEC OSF/1® AXP Operating System
(OSF/1) No Yes
Visual Display
Unit The DECpc AXP 150 and DEC 2000 Model 300 AXP systems use
different visual display units, as follows:
• The DECpc AXP 150 uses a PC-standard monitor.
• The DEC 2000 Model 300 AXP system uses a VT-series
terminal or equivalent. See Chapter 6 for information on
connecting terminals to the system.
1–2 System Description

Client/Server Use
Client/Server Use
Summary This section describes the different uses to which you can put
these systems, depending on whether it is a client system or a
server system.
Client Systems Client systems use the Windows NT operating system. You can
use a client system for the following tasks:
• To run PC applications locally, especially high-end
applications
• To display the output of applications that you run remotely
on a server, or to run the client portion of client/server
applications
Server Systems Server systems can use any of the supported operating systems.
You can use a server system for the following tasks:
• As a file server, providing disk storage to PCs and other
systems in a local area network (LAN)
• As a print server, providing common printing resources to
PCs and other systems in a LAN
• As a compute server, providing processing power for
client/server applications on one of the supported operating
systems
System Description 1–3

System Features
System Features
Summary This section describes the features provided by the system.
System
Features Table 1–2 lists the features of the system.
Table 1–2 System Features
Feature Description
64-bit Alpha AXP
RISC architecture The 64-bit architecture provides significant performance advantages over 32-bit
architectures, especially in the areas of
memory and cache bandwidth.
Flexible memory
architecture You can upgrade the system memory from 16 megabytes (M bytes) to 128M bytes
using memory options (see the section
entitled Internal Options ).
Six EISA
expansion slots The extended industry standard architecture (EISA) slots allow you
to include up to six industry standard
architecture (ISA) or EISA option boards.
Standard option boards included with the
system provide the following features:
• Super video graphics array (SVGA)
video adapter
•ThinWire™ and 10BASE-T Ethernet
connection capabilities
• Small computer system interface
(SCSI) storage device connection
capabilities
Other option boards provide different
capabilities (see the section entitled
Internal Options ).
(continued on next page)
1–4 System Description
